ROSE DISPLAYS ANOSKYBOX-TOP LOADING 4 WAY Manual de usuario

The AnoSkybox™ is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products.

Part #03INAnoSkyboxTopLoad4Way

Incept-2.07.03

Top Load 4-Way Instruction Sheet

Page 1 of 2

Note:

We recommended that two people

assemble this AnoSkybox.

Step 1a

Slide spine into vertical rail.

Step 1b

Slide another vertical rail onto the

other edge of spine. Repeat for all

vertical rails and spines.

Step 2

Carefully insert corner brackets into

ends of bottom rails, using thumb as

shown in illustration. Two brackets

per end of each rail. Bracket can

bend if forced.

Detail- It is important that the corner

bracket tension tab faces toward

outside of frame. (2b)

Step 3

Lay out the bottom rails on the floor as

they will be configured.

AnoSkybox™

Instructions for Assembly

Corner brackets

Parts

Single rails Split rails

(Continued on other side)

2a 2b

1a 1b

35 Congress Street, Salem, MA 01970

Tel# 1- 800 631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

4-Way

Spines with

pre-drilled holes

The AnoSkybox™ is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products.

Part #03INAnoSkyboxTopLoad4Way

Incept-2.07.03

Instructions for Assembly continued

Step 4

Assemble the vertical rail assemblies

onto the upward facing corner brackets

already inserted into the bottom rails.

All four brackets should go into the

vertical rails at one time.

Note: The last vertical rail will be

tensioned. This is normal.

Note: Insert end of spine without the

predrilled holes. Holes should

remain at the top of the AnoSkybox

for hanging.

Step 5

Insert corner brackets into ends

of split rails, 1 per end. Use thumb

as shown in illustration.

Step 6

Assemble split rails onto top ends

of vertical rails, one inside and one

outside of each side of the AnoSkybox.

Step 7

Insert and change signs through top

of each side.

Step 8

Assemble hanging hardware by

inserting hooks through holes on the

spines.

Step 9

Hang the completed assembly.

Note: Steps 7-9 illustrate a 3-Way

AnoSkybox. Assembly is the same for

a 4-Way

AnoSkybox™

4 5

35 Congress Street, Salem, MA 01970

Tel# 1- 800 631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Top Load 3-Way Instruction Sheet

Page 2 of 2

The AnoSkybox™ is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products.

Part #03INAnoSkyboxTopLoad4Way

Incept-2.07.03

Note:

We recommended that two people

assemble this AnoSkybox.

Step 1a

Slide spine into vertical rail.

Step 1b

Slide another vertical rail onto the

other edge of spine. Repeat for all

vertical rails and spines.

Step 2

Carefully insert corner brackets into

ends of bottom rails, using thumb as

shown in illustration. Two brackets

per end of each rail. Bracket can

bend if forced.

Detail- It is important that the corner

bracket tension tab faces toward

outside of frame. (2b)

Step 3

Lay out the bottom rails on the floor as

they will be configured.

AnoSkybox™

Instructions for Assembly

Corner brackets

Parts

Single rails Split rails

(Continued on other side)

2a 2b

1a 1b

Spines with

pre-drilled holes

4-Way

Top Load 4-Way Instruction Sheet

Page 1 of 2

The AnoSkybox™ is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products.

Part #03INAnoSkyboxTopLoad4Way

Incept-2.07.03

Instructions for Assembly continued

Step 4

Assemble the vertical rail assemblies

onto the upward facing corner brackets

already inserted into the bottom rails.

All four brackets should go into the

vertical rails at one time.

Note: The last vertical rail will be

tensioned. This is normal.

Note: Insert end of spine without the

predrilled holes. Holes should

remain at the top of the AnoSkybox

for hanging.

Step 5

Insert corner brackets into ends

of split rails, 1 per end. Use thumb

as shown in illustration.

Step 6

Assemble split rails onto top ends

of vertical rails, one inside and one

outside of each side of the AnoSkybox.

Step 7

Insert and change signs through top

of each side.

Step 8

Assemble hanging hardware by

inserting hooks through holes on the

spines.

Step 9

Hang the completed assembly.

Note: Steps 7-9 illustrate a 3-Way

AnoSkybox. Assembly is the same for

a 4-Way

AnoSkybox™

4 5

Top Load 3-Way Instruction Sheet

Page 2 of 2
