ROSE DISPLAYS GOTCHA WITH LOOP TO LOOP Manual de usuario

The Gotcha®is a registered trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products. Part #00INSGO

Parts

35 Congress Street, Salem MA 01970

Tel# 1-800-631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Instructions For Hanging

Instruction Sheet

Step 1

Place poster on a flat surface. Snap the Gotcha

Holder open and insert poster (top and bottom).

To close, snap the Gotcha Holder shut. Fig. 1

Note: It is easier to open and close the Gotcha

Holder by starting at one end and working your

way down the holder.

Step 2

Thread loop through V-clip. Fig. 2

Step 3

Thread the other loop through the One Up

Gotcha Clip. Insert the One Up Gotcha Clip

into the backside of the Gotcha. You should hear

a “SNAP” when the clips are inserted properly.

If you are hanging a one-up application you will

use only one clip. Fig. 3

Step 4

Squeeze the V-clip onto the ceiling grid

to suspend poster.

Important note:

Please save and reuse the Gotcha Holder, V Clip,

Loop to Loop Cable and the OneUp Gotcha

Clips for future projects.

OneUp Gotcha Clip

1UP-5066 Loop to Loop

Cables V Clip

25-0394

Gotcha

®

Gotcha

12G100

Incept-7.16.01

Figure 1

Figure 2

Figure 3

Este manual sirve para los siguientes modelos
