Rollei COMPACTLINE 50 - Manual de usuario

EN-1

GETTING TO KNOW YOUR CAMERA

Front View

1. Shutter button

2. Power button

3. Flash

4. Focus switch

[ ]Normal mode

[ ]Macro mode

5. Lens

6. Beeper

7. USB connector

8. Self-timer LED

EN-2

Rear View

1. LCD monitor

2. Status LED

3. OK OK button

Digtal Zoom button

4. Strap holder

5. 4-way control button

Up button

MENU Menu button

Right button

Flash button

Down button

MODE

Mode button

Left button

Self-timer button

6. Playback button

7. Battery cover

8. SD/SDHC memory card slot

9. Tripod socket

123

EN-3

GETTING STARTED

Preparation

1. Attach the camera strap.

2. Open the battery cover.

3. Load the batteries with correct orientation as shown.

4. Close the battery cover and make sure it is locked

securely.

5. Insert an SD/SDHC memory card (Optional).

The camera has 16MB internal memory (13.5MB

available for image storage), but you can load an

SD/SDHC memory card (SDHC memory card up

to 4GB) to expand the camera’s memory

capacity.

Be sure to format the memory card with this

camera before its initial usage.

EN-4

Turning the Power On/Off

Load the battery and insert an SD/SDHC memory card before starting.

Press the POWER button until the digital still camera

turns on.

To turn the power off, press the POWER button

again.

Capturing Images

Your camera is equipped with a 2.48" full color LTPS-TFT LCD monitor to help you compose

images, playback recorded images/video clips or adjust menu settings.

1. Press the Power button to turn the power on.

2. Compose the image on the monitor screen so that the main subject is within the focus

frame.

3. Press the shutter button to capture the image.

Setting the Scene Mode

You can select the scene mode according to the shooting scene. There are 6 available

modes in this scene mode.

[ ] Auto: Select this mode to adjust point-and-shoot action.

[ ] Sport: Select this mode when you want to photograph fast-moving

subjects.

[ ] Night: Select this mode when you want to capture dark scenes such as

night views.

[ ] Portrait: Select this mode when you want to capture an image that makes

the person stand out against a defocused (blurred) background.

[ ] Landscape: Select this mode to capture an image with infinity focus, hard

sharpness and high saturation.

[ ] Backlight: Select this mode when you want to capture images as the

light comes from behind the object.

1. Press the MENU button.

The [Capture] menu is displayed.

2. Select [Scene Mode] with the c/ dbuttons, then press the OK button.

3. Select the desired scene mode with the c/ dbuttons, then press the OK button.

4. To exit from the menu, press the ebutton.

EN-5

Recording Video Clips

This mode allows you to record video clips at a resolution of VGA (640 x 480) / QVGA (320

x 240) pixels.

1. Press the MODE button to set the camera mode

to [ ].

2. Compose the image.

3. Press the shutter button.

The recording of the video clip will start.



Pressing the shutter button one more time will

end the recording of the video clip.

The recording time depends on the storage

size and the subject of the image to be

recorded.

Playing Back Video Clips

You can play back recorded video clips on the camera.

1. Press the [ ] button.

The last image appears on the screen.

2. Select the desired video clip with the e/ fbuttons.

3. Press the OK button.

A press of the f/ ebuttons during playback

allows fast forward play / fast reverse play.

To stop video playback, press the dbutton.

This stops playback and returns to the

start of the video clip.

To pause video playback, press the OK button.

This pauses video playback.

To cancel pause, press the OK button again.

VGA

+1/3

59:59

00:11

100-0001

00:11

100-0001

VGA

EN-6

Playing Back Still Images

You can play back the still images on the LCD monitor.

1. Press the [ ] button.

The last image appears on the screen.

2. The images can be displayed in reverse or forward

sequence with the e/ fbuttons.

To view the previous image, press the ebutton.

To view the next image, press the fbutton.

3. Press the OK / button to adjust the zoom ratio. The

magnification factor is displayed on the LCD monitor.

4. To view different portion of the images,press the c/ d

/ e/ fbutton to adjust the display area.

100-0004

2.0X

100-0004

EN-7

Erasing Images

Erasing single image / Erasing all images

1. Press the [ ] button.

The last image will be displayed on the screen.

2. Select the image you want to erase with the e/ f

buttons.

3. Press the MENU button.

4. Select [Delete] with the c/ dbuttons and press the

OK button.

5. Select [Single], [All], or [Select] with the c/ d

buttons, and press the OK button.

[Single]: Erases the selected image or the last

image.

[All]: Erases all of the images except for the

protected images.

[Select]: Select the image you want to erase in

thumbnail mode.

6. Select [Execute] with the c/ dbuttons, and press

the OK button.

To not erase, select [Cancel], and press the OK

button.

Delete Next Menu

Copy to Card

Slide Show

DPOF

Protect

Thumbnail

Next Menu

3 sec.

Next Menu

Play

Delete

Single

All

Select

Delete

Cancel

Execute

Delete This File?

EN-8

TRANSFERRING FILES TO YOUR

COMPUTER

System Requirement

Downloading Your Files

1. Connect one end of the USB cable to an available

USB port on your computer.

2. Connect the other end of the USB cable to the USB

terminal on the camera.

3. Select [PC] using the

buttons, and press the

button.

4. From the Windows desktop, double click on “My

Computer”.

5. Look for a new “removable disk” icon.

This “removable disk” is actually the memory (or memory card) in your camera.

Typically, the camera will be assigned drive letter “e” or higher.

6. Double click on the removable disk and locate the DCIM folder.

7. Double click on the DCIM folder to open it to find more folders.

Your recorded images and video clips will be inside these folders.

8. Copy & Paste or Drag-N-Drop image and video files to a folder on your computer.

Mac users: Double-click the “untitled” or “unlabeled” disk drive icon on your desktop. iPhoto

may automatically launch.

Windows Macintosh

Pentium 166 MHz or higher

Windows 2000/XP/Vista

128MB RAM

128MB hard disk space

CD-ROM drive

Available USB port

PowerPC G3/G4/G5

OS 9.0 or later

128MB RAM

128MB hard disk space

CD-ROM drive

Available USB port
