Roland Texart XT-640 Manual de usuario
TERMS OF USE
Users of this Product Guide shall be deemed to agree with the following Terms of Use.
1. USERS
This Product Guide is only for authorized persons with user ID and password issued by Roland
DG Corporation.
2. PURPOSE
Authorized persons can use this Product Guide only for the purposes of selling and providing
the customers with maintenance services of XT-640.
3. REUSE
Authorized persons shall not disclose, transfer, rent or distribute this Product Guide to, or allow
this Product Guide to be used in any manner by, any third party other than authorized persons.
4. REPRODUCTION
Authorized persons shall not copy, change or alter this Product Guide without permission of
Roland DG Corporation.
5. EFFECT OF VIOLATION
Regardless of circumstances, we will vigorously respond to any violation hereof, through legal
action.
Copyright © 2015 ROLAND DG CORPORATION
Product Guide
Confidential
1/47
XT-640
Version 1.1 March 29, 2016
2/47
Version Date Description of Changes
1.0 December 14, 2015
First Edition
1.1 March 29, 2016
P
. 11: Correction of erroneous description
Incorrect: refer to the setup guide and the service note.
Correct: refer to Chapter 5 of the service note.
P
. 21:Added 1 pass print mode
Contents
1. Product Information
2. Printing Theory
3. Ink
4. Ink Line
5. Take-up Unit
6. Media Heating System
7. Cleaning Function
8. Special Pump Operation
9. Interface
10.Other Features
11. Software
12. Installation
13. Transport
14. Consumables
3/47
1. Product Information
4/47
XT-640 is dye-sublimation printer developed based EJ-640
Series name:
64 inch, print only
Dual gold print heads in staggered arrangement
Ink: Texart INK
Ink configuration:
4 colors CMYK×2
8 colors CMYKLcLmOrVi
Electrical driven auto-choke system
(Each of 8 valves closes individually)
Roland ink switching system (4 colors only)
1 liter ink system (BIF-1)
Feed adjuster optimized for roll media
Take-up unit: TUC-3/TU3-64 (Optional)
RIP software: ErgoSoft Roland Edition
Item Specification EJ-640 XT-640
Heating System
Built-In Heater pre, print, dryer
only dryer
Feed Adjuster
Front Side -
Rear Side
Ink Supply
Roland Ink System
1L Ink System BIF-2 BIF-1
Ink Type EJ ink Texart Ink
RIP
Bundled RIP Software RVW Dual ErgoSoft
Colors
Number of Colors 4 / 7 4 / 8
1. Product Information
5/47
Difference from EJ-640
Packing
1. Product Information
Media width 259 to 1625mm
Maximum printing width 1615mm
Media weight 40kg
Exterior dimensions
(with stand)
2835[W] x 830[D] x 1650[H]mm
Weight: 214Kg
Power requirements AC100 to 120V ±10%,5.5A, 50/60Hz
AC220 to 240V ±10%,2.8A, 50/60Hz
Power consumption During operation: approx. 750W,
Sleep mode: approx.70W
Environment Power on: Temperature: 18 to 25°C, humidity: 35 to 65% RH (noncondensing)
Power off: Temperature: 15 to 30°C, humidity: 20 to 80% RH (noncondensing)
2900mm
836mm
1026mm
Specification
800mm
410mm
380mm
Machine 1 liter ink system（BIF-1）
*Packed in a separate box
6/47
1. Product Information
Stand with improved
stiffness
Large-sized acrylic cover
Dual print heads
in staggered arrangement
BIF-1
1 liter ink system
Rear feed adjuster
Adjuster
Caster with improved
durability
Front feed adjuster
Dryer
7/47
Product Overview
4C
Subtank cartridge
Cartridge IC
Empty detector
Subtank slot
1000ml
Ink pouch
Ink pouch holder
8C Damper
Valve
1. Product Information
8/47
BIF-1
Original 1L Ink System
Designed to prevent ink from being exposed to the air,
which ensures stable printing
Enables continuous printing for hours
Roland Ink Switching System (4 colors only)
Easy to install and remove an ink pouch
The installation of BIF-1 should be performed by service
engineers.
1. Product Information
Subtank cartridge
Cartridge IC
Empty detector
Subtank slot
1000ml
Ink pouch
Ink pouch holder
Damper
1000ml
Ink pouch
* The ink remaining amount in the ink pouch cannot be checked neither with RIP software nor in the Main Menu on the Operation Panel.
In other words, there is no “INK REMAINING” menu in the Menu List.
* The sensor detects empty only when the ink in the sub tank runs out.
1. When an ink pouch is installed,
approx.100cc of ink moves to the
sub tank.
2. Then ink will be supplied only from
the ink pouch.
Valve
3. When the ink pouch is removed,
the valve closes, and the sub tank
becomes active.
Ink pouch holder Ink pouch holder
Subtank slot Subtank slot
Subtank cartridge Subtank cartridge
Empty detector
Empty detector Cartridge IC
Cartridge IC
Damper
Damper
9/47
BIF-1 - Ink Flow
