Communication Interface Module

Cat. No. 1784-KT2/B

Installation Data

The 1784-KT2/B Communication Interface Module allows an IBM PS/2

compatible MicroChannel computer to communicate directly with

Allen-Bradley PLC-2 or PLC-3 family programmable controllers. The

1784-KT2/B also allows an IBM PS/2 compatible MicroChannel computer

to communicate over the Allen-Bradley Data Highway Plus network to all

Data Highway Plus family programmable controllers.

WARNING: The following provides information for

Allen-Bradley Industrial Computer and Communication Group

(ICCG) products that have been verified to meet the

Electromagnetic Interference (EMI) requirements of the Federal

Communication Commission (FCC) and the Canadian

Department of Communications for use in a commercial

environment:

This device complies with Part 15 of the FCC rules. Operation

is subject to the following two conditions: (1) this device may

not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause

undesired operation.

WARNING: This digital apparatus does not exceed the Class A

limits for radio noise emissions from digital apparatus set out in

the Radio Interference Regulations of the Canadian Department

of Communications.

Le présent appareil numérique n’émet pas de bruits

radioélectriques dépassant les limites applicables aux appareils

numériques de la class A prescrites dans le Règlement sur le

brouillage radioélectrique édicté par le ministère des

Communications du Canada.

Introducing the 1784KT2/B

Communication Interface

Module

Installation Data

Communication Interface Module

Cat. No. 1784-KT2/B

We will refer to the 1784–KT2/B Communication Interface Module as

simply the 1784–KT2 throughout this document.

This document contains information on the following topics:

Introducing the 1784–KT2/B Communication Interface Module

Important User Information

Features of the 1784-KT2

How the 1784–KT2 Operates

Preparing the IBM PS/2 Reference Diskette for the 1784–KT2

Configuration

Installing the 1784–KT2

Configuring the 1784–KT2

Connecting the 1784–KT2

The 1784–KT2 Diagnostic Program

Diagnostic Program Files

Installing the Diagnostic Program onto a Hard Disk

Starting Up the Diagnostic Program

Running the Diagnostic Program

Diagnostic Program Error Messages

The Diagnostic Program Output File

Building Loopback Connectors

Ordering Information

Specifications

Because of the variety of uses for products described in this publication,

those responsible for the application and use of this control equipment

must satisfy themselves that all necessary steps have been taken to assure

that each application and use meets all performance and safety

requirements, including any applicable laws, regulations, codes and

standards.

The illustrations, charts, sample programs and layout examples shown in

this guide are intended solely for purposes of example. Since there are

many variables and requirements associated with any particular

installation, Allen–Bradley does not assume responsibility or liability (to

include intellectual property liability) for actual use based upon the

examples shown in this publication.

What this Document Contains

Important User Information

Installation Data

Communication Interface Module

Cat. No. 1784-KT2/B

Allen–Bradley publication SGI–1.1, “Safety Guidelines for the

Application, Installation and Maintenance of Solid State Control”

(available from your local Allen–Bradley office) describes some important

differences between solid–state equipment and electromechanical devices

which should be taken into consideration when applying products such as

those described in this publication.

Reproduction of the contents of this copyrighted publication, in whole or

in part, without written permission of Allen–Bradley Company, Inc. is

prohibited.

WARNING: With any complex communication system you

need to identify potential application–related communication

problems and make provisions in the system design to prevent

hazardous or undesired consequences if a problem occurs.

These problems include, but are not necessarily limited to, the

possibility of:

unexpected loss of communication

erroneous or incomplete data being supplied to the network

and passed on to your application

The 1784-KT2 Communication Interface Module is an IBM PS/2

MicroChannel card that you can insert into any 8- or 16-bit IBM PS/2

expansion slot. The 1784-KT2 provides the following features:

makes your PS/2 computer an active node on Data Highway Plus

provides single cable connection to a PLC-2, PLC- 3, or PLC-5 family

programmable controller

operates with 6200 programming software

is address selectable; you can use with other option boards installed in

your PS/2 computer

when combined with Allen-Bradley 6001-F1E2 software, allows you to

create your own custom interface to Data Highway Plus

The 1784-KT2 has been verified for operation with the following

computers:

Allen-Bradley 6123, 6124

IBM PS/2 7541, 7561, 8550, 8555, 8560, 8570, 8580

Features of the 1784KT2

Compatibility

Installation Data

Communication Interface Module

Cat. No. 1784-KT2/B

The 1784-KT2 allows you to communicate with PLC-2s, PLC-3s, and Data

Highway Plus nodes. The 1784-KT2 conducts the data communication,

management, and local Data Highway Plus diagnostics. The interface to

the personal computer is through board-resident shared memory that passes

preformatted Data Highway Plus packets. Upon powering up the computer

and downloading module code, diagnostics are run automatically to verify

the 1784-KT2’s operation. Allen-Bradley’s 6001-F1E2 software manages

the transmission and reception of data through board-resident shared

memory.

To prepare the IBM PS/2 Reference diskette for 1784-KT2 configuration

capability, you must:

create a backup copy of the IBM PS/2 Reference diskette and the

1784-KT2 Options and Diagnostics diskette

copy the 1784-KT2 Adapter Description file to the backup copy of the

IBM PS/2 Reference diskette

create a backup copy of your PS/2 computer’s current configuration

The following sections provide information on the above procedures.

Creating Backup Diskettes

Before installing or configuring your 1784-KT2, make a backup of the

1784-KT2 Options and Diagnostics diskette that was shipped with your

1784-KT2. Follow IBM instructions for completing this process.

Also make a backup of your most recent version of the IBM PS/2

Reference diskette. In this document, we refer to this backup copy as the

“current” IBM PS/2 Reference diskette. Follow IBM instructions for

completing this process.

After you have created the above backup copies, store the original

diskettes.

Copying the 1784-KT2 Adapter Description File

This section provides information on how to copy the 1784-KT2 Adapter

Description file (60C6.ADF) from the backup 1784-KT2 Options and

Diagnostics diskette to the current IBM PS/2 Reference diskette. You

cannot configure the 1784-KT2 until the Adapter Description file is added

to the current IBM PS/2 Reference diskette.

To copy the Adapter Description file, follow the steps below:

1. Insert the current IBM PS/2 Reference diskette into drive A of your

computer.

How the 1784KT2 Operates

Preparing the IBM PS/2

Reference Diskette for 1784KT2

Configuration

Installation Data

Communication Interface Module

Cat. No. 1784-KT2/B

2. Turn on the power switch. The following message appears:

Press [ENTER] to continue.

Press [ENTER].

3. The main menu appears:

MAIN MENU

1. Learn about the computer

2. Backup the Reference Diskette

3. Set configuration

4. Set features

5. Copy an option diskette

6. Move the computer

7. Test the computer

Use or to select. Press Enter.

Escape=Quit F1=Help

Move the cursor down to the Copy an Option Diskette option and

press [ENTER].

4. The following message appears:

Remove your backup copy of the Reference

diskette and insert the options diskette into drive

Insert the 1784-KT2 Options and Diagnostics diskette into drive A and

press [ENTER]. Follow the instructions on your screen.

The above process copies only the 1784-KT2 Adapter Description

file to the current IBM PS/2 Reference diskette. When this copy

procedure is complete, store both diskettes.

Creating a Backup of the PS/2 Computer's Current Configuration

Important: We assume you have prepared your current IBM PS/2

Reference diskette for 1784-KT2 configuration capability. If you have not

yet done so, turn to the section earlier in this document.

To create a backup of the PS/2 computer’s current configuration, follow

the steps below:

1. Insert the current IBM PS/2 Reference diskette into drive A.

Installation Data

Communication Interface Module

Cat. No. 1784-KT2/B

2. Turn on the power switch. The following message appears:

Press [ENTER] to continue.

Press [ENTER].

3. The main menu appears:

MAIN MENU

1. Learn about the computer

2. Backup the Reference Diskette

3. Set configuration

4. Set features

5. Copy an option diskette

6. Move the computer

7. Test the computer

Use or to select. Press Enter.

Escape=Quit F1=Help

Move the cursor down to the Set Configuration option and press

[ENTER].

4. The Set Configuration menu appears:

Set Configuration

1. View configuration

2. Change configuration

3. Backup configuration

4. Restore configuration

5. Run automatic configuration

Press a number to select

Esc=Quit F1=Help

Move the cursor down to the Backup Configuration option and

press [ENTER]. This creates a backup of your PS/2 computer’s

current configuration.

5. When the procedure is complete, press [ENTER] to return to the Set

Configuration menu.

Installation Data

Communication Interface Module

Cat. No. 1784-KT2/B

6. Press [ESC] to quit.

7. Remove the current IBM PS/2 Reference diskette from drive A and

re-start the PS/2 computer.

This section provides information on installing the 1784-KT2 into an

Allen-Bradley 6123, an Allen-Bradley 6124, or an IBM PS/2 computer.

When installing the 1784-KT2 into a 6123 or 6124, refer to the 6123/6124

User’s Manual (publication 6123-2.1).

Important: Read the IBM PS/2 Model Quick Reference guide before you

install the 1784-KT2. Pay close attention to the section entitled “Installing

Options.”

CAUTION: The 1784-KT2 utilizes CMOS Technology

, which is

highly sensitive to electrostatic dischar

ge (ESD). ESD may be present

whenever you are handling the 1784-KT2. Handling the 1784-KT2

without any ESD protection can cause internal circuit damage that may

not be apparent during installation or initial use. A grounding wrist

strap has been shipped with the 1784-KT2 to be worn during the

installation procedure. Instructions for use of the strap are found on the

back of its package.

The following is a list of precautions to guard against ESD damage:

Before handling the module, be sure to wear the provided static strap

and touch a grounded object to discharge any built-up static charge.

Avoid touching the backplane connector or interface connector pins

located on the 1784-KT2.

If the module is not in use, store the 1784-KT2 in the static bag that the

module was shipped in.

To install the 1784-KT2, follow the steps below:

1. Disconnect the ac power to the computer.

2. Remove the computer’s system-unit cover (according to the

manufacturer’s instructions).

3. Select a vacant 8- or 16-bit expansion slot.

Important: The 1784-KT2 will function in an 8- or a 16-bit

expansion slot only.

4. Remove the rear bracket-slot’s expansion cover by loosening the

screw on the back of the computer.

Installing the 1784KT2

Installation Data

Communication Interface Module

Cat. No. 1784-KT2/B

5. Insert the 1784-KT2 into the edge connector and tighten the

expansion slot screw.

6. Replace the system-unit cover.

7. Connect the ac power to the computer.

You are now ready to configure your 1784-KT2.

Important: We assume you have already made a backup of your IBM

PS/2 Reference diskette and prepared it for 1784-KT2 configuration

capability. If you have not yet done so, refer to the section earlier in this

document.

In the following, [ENTER] indicates when you must press the enter key.

To configure the 1784-KT2, follow the steps below:

1. Insert the current IBM PS/2 Reference diskette into drive A.

2. Turn on the computer.

3. During the boot process, the computer beeps twice and error code 165

appears on the screen. This indicates an adapter configuration

change. The following message appears:

Press Enter to continue

Press [ENTER].

4. You are asked the following:

Automatically configure the system? (Y/N)

Type:

n [ENTER].

5. When the main menu appears, move the cursor down to the Set

Configuration option and press [ENTER].

6. When the Set Configuration menu appears, move the cursor down to

the Change Configuration option and press [ENTER]. A

configuration table with the following type of information appears

(variation is probable):

Configuring the 1784KT2

Installation Data

Communication Interface Module

Cat. No. 1784-KT2/B

Total

System Memory

Installed Memory

..............2048KB (2.0MB)

Useable Memory

..............2048KB (2.0MB)

BuiltIn Features

Installed Memory

..............2048KB (2.0MB)

Diskette Drive A T

ype......1.44MB [3.5"]

Diskette Drive B T

ype.......[Not Installed]

Math Coprocessor

.............[Not Installed]

Serial Port..........................[Serial_1]

Parallel Port.......................[Parallel_1]

Slot 1AllenBradley Company 1784KT2

Memory Address...............[0C0000h0C3FFFh]

Interrupt Level....................[IRQ9]

Auxiliary Communication

Port.........................[PLC2/3 Direct Connect]

Esc=Quit F5=Previous F10=Save Home Page up

F1=Help F6=Next End Page Down

Change Configuration

7. Select a memory address by moving the cursor down to the

1784-KT2 Memory Address option. The 1784-KT2 supports the

following memory addresses (in hexadecimal):

0C0000 - 0C3FFF

0C4000 - 0C7FFF

0C8000 - 0CBFFF

0CC000 - 0CFFFF

0D0000 - 0D3FFF

0D4000 - 0D7FFF

0D8000 - 0DBFFF

0DC000 - 0DFFFF

Use [F5] and [F6] to scroll back and forth through the addresses.

Display your selection on the screen. Make sure you select an

address that is not being used by another adapter card in your PS/2

computer. If you select an address currently in use, an asterisk will

appear next it.

Installation Data

Communication Interface Module

Cat. No. 1784-KT2/B

CAUTION: Configuring two adapter cards at the same address

may damage your cards and your PS/2 computer.

8. Set the interrupt level by moving the cursor down to the Interrupt

Level option. The 1784-KT2 supports the following interrupts:

- IRQ9

- IRQ10

- IRQ11

- IRQ12

Use [F5] and [F6] to scroll back and forth through the interrupts.

Display your selection on the screen. Make sure you select an

interrupt that is not being used by another adapter card in your PS/2

computer.

9. Set the auxiliary communication port by moving the cursor down to

the Auxiliary Communication Port option. This port, one of the

two communication ports available through a single 1784-KT2

connector, is used for communication with a PLC-2 or PLC-3

connected to the 1784-KT2.

The other communication port, the main port, is used for Data

Highway Plus communication when the 1784-KT2 is connected to

the Data Highway Plus network. You do not need to configure the

main port.

The 1784-KT2 supports the following auxiliary port options:

PLC-2/3 Direct Connect Reserved (for future 1784-KT2 auxiliary

port usage)

Use [F5] and [F6] to display “PLC-2/-3 Direct Connect” on your

screen.

10. Press [F10] to save the memory, interrupt, and auxiliary

communication port options.

11. You are asked if you want to continue. Press [ENTER].

12. Press [ESC] to return to the Set Configuration menu.

13. Press [ESC] again. A message indicating a configuration change has

been made appears on your screen. Remove the current IBM PS/2

Reference diskette.

14. Press [ENTER] to restart the computer.

Otros manuales de Unidad de control de Rockwell Automation

Rockwell Automation

Rockwell Automation Allen-Bradley EtherNet/IP Manual de usuario

Rockwell Automation

Rockwell Automation Allen-Bradley 800G-XLS Z-EX Series Manual de usuario

Rockwell Automation

Rockwell Automation Allen-Bradley Guard I/O DeviceNet 1732DS-IB8 Manual de usuario

Rockwell Automation

Rockwell Automation Allen-Bradley 1770-KFC15 Manual de usuario

Rockwell Automation

Rockwell Automation Allen-Bradley Kinetix 5700 Series Manual de usuario

Rockwell Automation

Rockwell Automation ControlLogix 1756-M02AE Manual de instrucciones

Rockwell Automation

Rockwell Automation Allen-Bradley SynchLink 1756-SYNCH Manual de usuario

Rockwell Automation

Rockwell Automation ControlLogix 1756-EN2TR Manual de usuario

Rockwell Automation

Rockwell Automation Reliance Electric LiquiFlo 41L4060 Manual de usuario

Rockwell Automation

Rockwell Automation ControlLogix 1756 Series Manual de usuario

Rockwell Automation

Rockwell Automation Allen-Bradley 1746-HSCE Manual de usuario

Rockwell Automation

Rockwell Automation DeviceNet ArmorBlock A Series Manual de usuario

Rockwell Automation

Rockwell Automation Allen-Bradley PowerFlex 20-750-PNET Manual de usuario

Rockwell Automation

Rockwell Automation MAO04NND Manual de usuario

Rockwell Automation

Rockwell Automation Allen-Bradley 1756-ENBT Manual de usuario

Rockwell Automation

Rockwell Automation Bulletin 193 E1 PLUS Guía del usuario

Rockwell Automation

Rockwell Automation Allen-Bradley 1606-XLSBUFFER24 Manual de usuario

Rockwell Automation

Rockwell Automation Allen-Bradley 1769-SM2 Manual de usuario

Rockwell Automation

Rockwell Automation Allen-Bradley 1794-IV16 Manual de usuario

Rockwell Automation

Rockwell Automation Allen-Bradley 1794-IRT8 Manual de usuario

Rockwell Automation

Rockwell Automation Allen-Bradley FLEX 5000 Series Manual de usuario

Rockwell Automation

Rockwell Automation Allen-Bradley PowerFlex 750 Series Manual de usuario

Rockwell Automation

Rockwell Automation Reliance electric GV3000/SE Manual de usuario

Rockwell Automation

Rockwell Automation CENTERLINE 2100 LVMCC Manual de operación y mantenimiento

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
