Rockwell Automation 1336 PLUS Manual de usuario

Instructions

This publication will guide you through installation (or replacement)

of the 1336 PLUS Language Module.

1. Check the version of ﬁrmware presently installed in the drive.

If the current version is 1.04 or greater, proceed to step 2.

If you have version 1.03, parameters 111-127 and 180 must be

checked. The value of each parameter must be greater than zero

and less than 212. If any value is outside of this range, reprogram

using the Program mode before proceeding to step 2.

Important:

Ifparameters127and/or180aresetto“0”(zero),these

must be reprogrammed to “1.”

If the above is not performed, an "EE Init Read" fault (F53) will

be issued when the drive is powered up with the new Language

Module.

2. Remove and lock-out all incoming power to the drive. Remove

the drive cover.

!ATTENTION: This drive contains ESD (Electrostatic

Discharge) sensitive parts and assemblies. Static control

precautions are required when installing, testing, servicing

or repairing this assembly. Component damage may result

if ESD control procedures are not followed. If you are not

familiar with static control procedures, reference A-B

publication 8000-4.5.2, “Guarding Against Electrostatic

Damage” or any other applicable ESD protection

handbook.

!ATTENTION: To avoid a shock hazard, assure that all

powertothedrivehasbeenremovedbeforeproceedingwith

thefollowingprocedure.Inaddition,verifythattheDCbus

hasdischargedbymeasuringacrossthe“+DC”and“–DC”

terminals of TB1 with a voltmeter. The voltage should be

0.0V DC.

1336 PLUS Language Module

Installation/Replacement

21336 PLUS Language Module Installation/Replacement

3. Using the ﬁgure above, locate the Language

Module for your drive and note orientation.

On 0.37-3.7 kW (0.5 - 5 HP) drives, the HIM

and cradle must be removed before

proceeding.

A. To remove the HIM, slide it down and

out of its cradle.

B. Remove the cradle by taking the 4 corner

screws out. Position the cradle and

attached cable out of the way.

0.37-3.7 kW (0.5-5 HP) Only

LANGUAGE MODULE

ALLEN-BRADLEY

LANGUAGE MODULE

ALLEN-BRADLEY

Frames A1 - A4 Frames B - G

JOG

ESC SEL

JOG

ESC SEL

JOG

ESC SEL

LANGUAGE MODULE

ALLEN-BRADLEY

1336 PLUS Language Module Installation/Replacement 3

4. Remove the module by squeezing the sides-

in, and pulling outward. Discard module.

5. Position the new Language Module on the

Main Control Board, using the silk screen

outline on the board as a guide.

6. Carefully align the module connector with

the Main Control Board connector. Firmly

press the module onto the Main Control

Board until fully seated. The module will

“snap” (lock) in place.

7. Replace HIM and cradle (if removed).

Replace drive cover and restore power to the

drive. An

F53, F54

F66

fault will occur.

Reset parameters to the factory default values

– then, clear the fault by pressing the Stop

key or cycling power. The drive may now be

programmed as required.

Important:

Each module contains English

and an alternate language. The

factory default setting for the

[Language] parameter is

“English.” To program and

operate the drive in the alternate

language, the [Language]

parameter must be programmed

to the alternate language.

LANGUAGE MODULE

ALLEN-BRADLEY

LANGUAGE MODULE

ALLEN-BRADLEY

LANGUAGE MODULE

ALLEN-BRADLEY

JOG

ESC SEL

Publication 1336 PLUS-5.5 – May, 1996 P/N74001-007-01(C)
