LightSYS2 Quick User Guide 1

LightSYS2 Quick User Guide

This quick user guide describes the main user operating actions of the LightSYS. To view

the full version of the user manual, please refer to our website www.riscogroup.com.

Registering with RISCO Cloud enables you to monitor and control your system.

1. Go to www.riscocloud.com and click Registe

2. Enter your first name and last name.

3. Enter your email address as Login Name (required for 1st time activation).

4. Define password (must be: a minimum of eight characters; contain at least one

capital letter and one lower case letter; contain at least one number; and contain at

least one special symbol) and confirm.

5. Enter in the 15 digits Panel ID as it appears: on the panel or supplied by the installer

(also available in the keypad menu as described below).

6. Complete registration form and click Register.

7. To complete registration open the email message received on the email account you

defined as Login Name.

1. . Go to www.riscocloud.com

2. . Enter User Name and Password (same as supplied during the registration process).

3. . Enter Passcode/PIN (LightSYS user code).

4. . Click Enter.

iRISCO – RISCO’s Smartphone Application

Homeowners can now enjoy the iRISCO Smartphone app for smart and easy control of

their LightSYS2 system from any location.

Download the iRISCO app from the Apple App store or Android Play Store (Search for

“iRISCO”).

Locating Panel ID in Keypad

1. From the main display press .

2. Enter master code (default code 1234) followed by .

3. Scroll to the option “View” and press .

4. Scroll to “Service Info” and press .

5. Scroll to “Panel ID” and press ; the15 digit panel ID displays.

2 LightSYS2 Quick User Guide

Interface:

Panda Keypad (RW432KPP)

Full Set Code >

Part Set Code >

System Unset and

Silence an Alarm Code>

Partition Full Set Code > >Partition No. >

Partition Part Set Code > >Partition No. >

Partition Unset Code> > Partition No. >

Duress Unset Duress Code >

Panic Alarm Pressing simultaneously for 2 seconds

Fire Alarm Pressing simultaneously for 2 seconds

Medical Alarm Pressing simultaneously for 2 seconds

Quick Zones Omit Code > [Zone No.]

Activate Output [Code] [Activities] [Output Control]

[Prgrm Output Num]

Define Follow-Me >[Code] [Follow Me] [Define]

View Fault [Code] [View] [Fault]

View Event Log [Code] [Event Log]

Keypad Chime On/Off [Code] [Activities] [Keypad sound]

[Chime]

Edit User Code [Code] [Codes/Tags] [Define]

LightSYS2 Quick User Guide 3

Elegant Keypad (RPKEL/RPKELP)

Full Set Code >

Part Set Code >

System Unset and

Silence an Alarm Code>

Partition Full Set Code > >Partition No. >

Partition Part Set Code > >Partition No. >

Partition Unset Code> > Partition No. >

Duress Unset Duress Code >

Panic Alarm

Pressing simultaneously for 2 seconds

Fire Alarm Pressing simultaneously for 2 seconds

Medical Alarm Pressing simultaneously for 2 seconds

4 LightSYS2 Quick User Guide

LCD Keypad (432KP)

Full Set Code >

Part Set Code >

System Unset and

Silence an Alarm Code>

Partition Full Set Code > >Partition No. >

Partition Part Set Code > >Partition No. >

Partition Unset Code> > Partition No. >

Duress Unset Duress Code >

Panic Alarm Pressing simultaneously for 2 seconds

Fire Alarm Pressing simultaneously for 2 seconds

Medical Alarm Pressing simultaneously for 2 seconds

Quick Zones Omit Code > [Zone No.]

Activate Output [Code] [Activities] [Prgrm Output Num]

Define Follow-Me >[Code] [Follow Me] [Define]

View Fault [Code] [View] [Fault]

View Event Log [Code] [Event Log]

Keypad Chime On/Off [Code] [Activities] [Keypad sound] [Chime]

Edit User Code [Code] [Codes/Tags] [Define]

Zone Testing (Walk Test

)

[Code] [Maintenance] [Walk Test]

LightSYS2 Quick User Guide 5

2-way Slim keypad

Operation Quick High-Security Mode1

Set – System > [Code] 2

Full Set – Partition

Select partition

[1/2/3/4] >

Select partition [1/2/3/4]

> > [Code] 2

Full

Unset > [Code] or Proximity tag (after waking)

Partial Set – System3> [Code]

Partial Set – Partition

Select partition Select partition

[1/2/3/4] > [1/2/3/4] > > [Code]

Partition Unset Select partition 1/2/3/4 and press followed by [Code]

Panic alarm Press + simultaneously for 2 seconds

Fire alarm Press + simultaneously for 2 seconds

Emergency/Med alarm Press + simultaneiously for 2 seconds

Status Request

Press for 2 seconds to view

LED display of system status (see

Indicators below)

Press for 2 seconds

followed by code2to

view LED display of

system status (see

Indicators below)

Output Control Press 1/2/3/4 for 2 seconds Press 1/2/3/4 for 2 seconds

followed by code2

Wake up keypad Press

6 LightSYS2 Quick User Guide

2-way Remote Control Keyfob

Operation Quick High Security Mode1

Full Set > [Code]

Partial Set* > [Code]

Full Unset > [Code]

System

Status for 2 seconds for 2 seconds >

Code

Output Control A/B/C for 2

seconds

for 2

seconds > [Code]

Panic Alarm simultaneously for 2 seconds

Clear Operation

Notes:

*For Part setting with no entry delay, press and hold for two seconds

1. Consult your engineer for the operations defined with a code.

2. The proximity tag can be used instead of code.

3. For Part Setting with no entry delay press for 2 seconds.

4. Light sensor is used to save battery by turning on/off the keypad backlight.

5. Needs to be defined by your engineer.

LightSYS2 Quick User Guide 7

Smartphone

Full Set – System

Full Set – Partition

Partial Set –

System

Partial Set –

Partition

System Unset

> [Code]

Partition Unset

Detector Omit

(On/Off toggle) > >

Web Application

SET/UNSET

Full Set All Partitions or PARTITION x> Full Set

Full Set –

Group

(if suppored)

[Group Letter] > Full Set

Or PARTITION x > [Group Letter]

Part Set All Partitions or PARTITION x> Partial Set

Unset All Partitions or PARTITION x> [Code] >

UNSET

8 LightSYS2 Quick User Guide

SETTINGS

System user and codes Edit, Delete and ADD NEW USERs

Web interface users and

codes Edit user fields and access credentials

Change Password Enter Old/New/Confirm > SET NEW PASSWORD

Quick Zone Omit Select ZONE xx > Omit > Update

Change Appearance Select ZONE xx > Omit > Update

Alerts/Add New

Contact

Enter Name, Email/Mobile phone #.

Select Alert Language, Partition association,

and toggle Set/Unset Email and SMS

Time Zone Select system TIME ZONE

HISTORY

Review activity log and export

AUTOMATION

Programmable Outputs Toggle ON/OFF > Update

Indicators:

LCD and Touchscreen Keypads

(Power):

On: Power OK, No faults

Off: No power

Rapid Flash: System fault

(Ready):

On: Ready to set

Off: Not ready to set

Slow Flash: Ready to set with

open Exit/Entry zone

(Set) / RED LED

On: System set

(Full or Part)

Off: System unset

Slow Flash: System

is in Exit Delay

Rapid Flash:

Alarm

(Tamper) :

On: Tamper alarm

Off: No tamper

alarm

( PartSet/Omit):

On: System part setting/omit

zones in the system

Off: No omitted zones

(Fire):

On: Fire alarm

Off: No fire alarm

Flash: Fire fault

(Proximity) [Touchscreen

only]

Flashing: Indicates keypad has

a proximity reader

LightSYS2 Quick User Guide 9

Panda Keypad Indicators

Fault

On: System Fault

Off: System operating

normally

Ready

On: Ready to set

Off: Not ready to set

Slow flash: System is

ready to be set while

exit/entry zone is open

Set

On: System is armed in Full Set

or Part Set mode

Off: System unset

Slow flash: System in Exit Delay

Rapid flash: Alarm

Partial (Stay) Set / Omit

On: System is Part Set mode

or Zone Omit mode

Off: No omitted zones

Tamper

On: Tamper alarm

Off: No tamper alarm

Cloud connectivity

On: System connected to cloud

Off: No cloud connection

configured Slow flash: Cloud

connectivity fault

2-way Slim Keypad

LED Indicator

Color State Status

Blue Blink During communication with the

panel

Red On

Slow flash

Rapid flash

System fully or partially set

During exit delay

During alarm

Green Blink Fault indication in the system while

the system is unset*

Green/Red Toggle Waiting for code to be entered

10 LightSYS2 Quick User Guide

2-way Keyfob

Operation (Send command)* (Receive Status)

Full Setting Green Red

Part Set Green Orange

Unset Green Green

Alarm Green Flash LED

* If the LED changes to orange, it indicates a low battery condition.

Edit User Code

1. From the main display press .

2. Enter master code (default code 1234) followed by .

3. Scroll to the option Codes/Tags > .

4. Scroll to Define and press .

5. Select a user and press .

6. Select Edit Code and press .

7. Enter the new code followed by .

8. To edit user label scroll to Edit Label and enter label.

9. Repeat the above steps for additional codes.

Assign Proximity Tag

1. Follow steps 1-5 of the Edit User Code above.

2. Select (Re)Write tag and press .

3. Within 10 seconds, approach the proximity tag to the keypad.

Setting and Changing System Time and Date

1. Press and enter grand master code followed by .

2. Using the arrow keys, scroll to the option Clock and press .

3. The display will show Time & Date. Press .

4. Enter the correct time in 24-hour format and date. For entering the date use the

keys to move the cursor and the / key to toggle among the

choices.

5. Press to save your settings.
