Operator Manual

SR85/CF85 COVER FEEDER

October 2001

x04034

Operator Manual SR85/CF85 COVER FEEDER

Operator Manual SR85/CF85 COVER FEEDER i

Table of contents

1. Introduction page

1.1 Operational safety 1-1

2. Getting to know the Cover Feeder

2.1 Main components 2-1

2.2 The control panel 2-3

3. Operating modes

3.1 The Online/Offline mode 3-1

3.2 The Operating modes 3-1

3.3 Indications 3-2

4. Operator instructions

4.1 Load paper 4-1

4.2 Loading paper during run 4-1

4.3 Set the first job 4-2

5. Maintenance

5.1 Cleaning of Feed roller and Separator pad 5-1

6. Clearing Jams

6.1 Clearing jams in vertical transport area 6-1

7. Problem solving

7.1 Problem solving 7-1

8. Specifications

8.1 Specifications 8-1

Operator Manual SR85/CF85 COVER FEEDER 1-1

Always connect the equipment to a properly

grounded power source receptacle. In doubt,

have the receptacle checked by a qualified

electrician.

WARNING: Improper connection of the equip-

ment grounding conductor can result in electri-

cal shock.

Always follow all warnings marked on, or

supplied with, the equipment.

Always locate the equipment on a solid sup-

port surface with adequate strength for the

weight of the machine.

Always exercise care in moving or relocating

the equipment.

Always keep magnets and all devices with

strong magnetic field away from the machine.

Never use a ground adapter plug to connect

the equipment to a power source receptacle

that lacks a ground connection terminal.

Never attempt any maintenance function that

is not specifically described in this documenta-

tion.

Never remove the covers or guards that are

fastened with screws.

Never install the unit near a radiator or any

other heat source.

Never override or “cheat” electrical or me-

chanical interlock devices.

Never operate the equipment if you notice

unusual noises or odours. Disconnect the

power cord from the power source receptacle

and call your customer service engineer to

correct the problem.

Attention to the following notes ensures the continued safe operation of your equipment.

1. Introduction

1.1 Operational safety

Operator Manual SR85/CF85 COVER FEEDER 2-1

2. Getting to know the Cover Feeder

2.1 Main components

1. Rear side guide

2. Paper separator pad

3. Bin extension plate

4. Air nozzle

5. Paper orientation label

6. Length adjustment handle

7. Feed roller assembly

8. Control panel

9. Loading capacity mark

10. Front side guide and

Loading handle

11. Copier finisher connector

12. Booklet maker connector

13. Power Supply connector

14. Bin extension plate connector

Operator Manual SR85/CF85 COVER FEEDER 2-2

2.1 Main components, continues

1. Upper paper path

2. Jam clearance baffle

Operator Manual SR85/CF85 COVER FEEDER

2.2 The control panel

2-3

12 34

7658910

1. Flashing light, Bin low detection

2. Constant light, Empty Paper Bin detection

3. Constant light, Double feed detection or Paper jam indication

4. Flashing light, Missfeed detection

5. Offline

6. Online

7. Online/Offline button

8. Single sheet mode

9. Copier cover mode

10. Operating select button

Operator Manual SR85/CF85 COVER FEEDER 3-1

3. Operating modes

The Cover Feeder can be operated in two modes. It is

possible to select two Operating modes. In this section

we will explain the modes and how they are selected.

3.1 The Online/Offline mode

The two modes are:

1. Online mode

The Online mode is selected on a unit, that is to operate

together with a copier as an on-line system.

The Online mode is set by pressing the Online/Offline button

on the Control panel, and is shown by the Online indicator-

LED.

2. Offline mode

The Offline mode is selected to run booklets without covers.

The Offline mode is set by pressing the Online/Offline button

on the Control panel, and is shown by the Offline indicator-

LED.

3.2 The Operating modes

The two Operating modes are:

1. Single sheet mode

When selecting this mode by pressing the Operating select

button. It is possible to run the Cover Feeder and the Booklet

maker without the copier. The Cover Feeder will automatically

feed one sheet at a time to the Booklet maker.

2. Copier cover mode

When selecting this mode by pressing the Operating select

button. It is possible to run the Cover Feeder together with the

Booklet maker and the copier as an on-line system. The

Cover Feeder will automatically feed one cover at a time

together with the set from the copier to the Booklet maker.

Operator Manual SR85/CF85 COVER FEEDER

3.3 Indications

LED-

INDICATION

PROBLEM

DESCRIPTION

INDICATED BY

LEDs

NOTES

Flashing light Misfeed detection

Constant light Double sheet detected

Can be caused by:

Double sheets

Reduced paper feed

capability

Flashing light Bin low detection

Constant light Empty bin detection

Constant light Jam detected Paper jam

3-2

Operator Manual SR85/CF85 COVER FEEDER 4-1

4. Operator instructions

4.1 Load paper

4.2 Loading paper during run.

1 Make sure that the sheets are well fanned to avoid

missfeeds or double-feeds.

2 Align the sheets well to achieve a reliable collating

operation and good finishing result.

3 Make sure that the ink has dried out well, to avoid

smearing.

4 Load the covers into the paper bin.

5 Move the adjustable side guide up against the sheets

until there is no clearance.

6 Move the adjustable Air nozzle, so that the green stripe

on the Air nozzle bracket is level with the paper stack.

1 When the Bin low detection LED is flashing, it is

possible to load paper while the machine is running.

Wait until the Cover Feeder has fed a cover. Press the

green label on the front side guide. Slide the new

covers in place under the existing covers in the paper

Bin.
