Ricoh 3800E Manual de funcionamiento

Printer Maintenance Kit Type 3800E

(Code: G767)

MAINTENANCE GUIDE

WARNING:

CAUTION:

ACheck the contents of the box for

the following items:

BBe sure to check the following

points:

• The power is turned off.

• The power cord is unplugged

from the wall outlet.

• The interface cable is un-

plugged from the printer.

CTurn off the power, and then un-

plug the power cable.

DSlowly open the front cover by

pulling down from the two areas

on the left and right.

Note

❒For machine models without

waste oil bottles, proceed to

step F.

•Do not incinerate spilled toner

or used toner. Toner dust is

flammable and might ignite

when exposed to an open

flame. Disposal should take

place at an authorized dealer

or an appropriate collection

site. If you dispose of the used

toner containers yourself, dis-

pose of them according to lo-

cal regulations.

•The inside of the machine be-

comes very hot. Do not touch the

parts with a label indicating a

"hot surface". Touching a "hot

surface" could result in a burn.

•Keep toner (used or unused) and

the toner cartridge out of reach

of children.

•Our products are engineered to

meet the highest standards of

quality and functionality. When

purchasing expendable sup-

plies, we recommend using only

those provided by an authorized

dealer.

Description Q'ty

Waste Toner Bottle 1

Maintenance Guide (This man-

ual)

ZDJH007J

G767-8517B

ECarefully pivot the waste oil bot-

tle outward, in the direction of the

arrow.

CAUTION:

FTake the new waste toner bottle

out of the bag.

GSlowly remove the used waste

toner bottle from inside the print-

er.

Important

❒Be sure to remove the waste

toner bottle horizontally.

HRemove the lid (A

A), and then put

it in the position shown in the il-

lustration (B

B).

IPut the used waste toner bottle

into the bag that contained the

new waste toner bottle, and then

seal the bag.

Important

❒Be sure to handle the bottle

carefully so waste toner does

not spill.

JInsert the new waste toner bottle

as shown.

•Keep the waste oil bottle away

from flames. There is a risk of

fire or burns.

ZHXH150J

ZDJH228J

ZHXH590J

ZDJH229J

ZHXH610J

KPush it in until it stops.

Important

❒Be sure to firmly insert the

waste toner bottle to avoid ton-

er leakage inside the printer.

Note

❒For machine models without

waste oil bottles, proceed to

step M.

LSlowly close the waste oil bottle

in the direction of the arrow.

MSlowly close the front cover by

pushing the two areas on the left

and right.

NPlug in the power cable, and then

turn on the power.

ZHXH600J

ZHXH160J

ZDJH041J
