RGBlink VENUS X3 Manual de usuario
X3
User Manual
Article No: RGB-RD-UM- X3 E007
Revision No: V1.7
X3 User Manual
1
CONTENTS
Declarations
................................................................................................................................................................ 3
FCC/Warranty..................................................................................................................................................... 3
Operators Safety Summary ............................................................................................................................ 4
Installation Safety Summary .......................................................................................................................... 6
Chapter 1 Your Product
........................................................................................................................................... 7
1.1 In the Box ...................................................................................................................................................... 7
1.2 Product Overview ....................................................................................................................................... 8
1.2.1 Front Panel........................................................................................................................................ 9
1.2.2 Rear Panel........................................................................................................................................10
1.2.3 Dimension ....................................................................................................................................... 11
Chapter 2 Installing Your Product
...................................................................................................................... 12
2.1 Plugging in Signals .................................................................................................................................. 12
2.2 Plugging in Main Power ......................................................................................................................... 12
2.3 Turning on Your Product ....................................................................................................................... 12
2.4 Connect X3 and Computer .................................................................................................................... 13
Chapter 3 Using Your Product
............................................................................................................................. 14
3.1 XPOSE 2.0 Installation............................................................................................................................. 14
3.2 XPOSE 2.0 Operation ...............................................................................................................................17
3.2.1 Login in XPOSE.............................................................................................................................. 17
3.2.2 System Setting ............................................................................................................................... 18
3.2.3 Output | Input | Overview ...........................................................................................................22
X3 User Manual
2
3.2.4 Display Management ...................................................................................................................31
3.2.5 Layer Management.......................................................................................................................33
3.2.6 Preset Management..................................................................................................................... 37
Chapter 4 Ordering Codes
....................................................................................................................................40
4.1 Product Code .............................................................................................................................................40
4.2 Module Code ............................................................................................................................................. 40
4.2.1 Input Modules ................................................................................................................................40
4.2.2 Output Modules ............................................................................................................................ 40
4.2.3 Others ............................................................................................................................................... 40
Chapter 5 Support
...................................................................................................................................................41
5.1 Contact Us .................................................................................................................................................. 41
Chapter 6 Appendix
................................................................................................................................................42
6.1 Specification ...............................................................................................................................................42
6.2 Installing Options ..................................................................................................................................... 48
6.3 Terms & Definitions ................................................................................................................................. 53
6.4 Revision History ........................................................................................................................................ 59
X3 User Manual
3
Thank you for choosing our product!
This User Manual is designed to show you how to use this video processor quickly and make use
of all the features. Please read all directions and instructions carefully before using this product.
Declarations
FCC/Warranty
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a class A digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area may cause harmful
interference, in which case the user will be responsible for correcting any interference.
Guarantee and Compensation
RGBlink provides a guarantee relating to perfect manufacturing as part of the legally
stipulated terms of guarantee. On receipt, the purchaser must immediately inspect all
delivered goods for damage incurred during transport, as well as for material and
manufacturing faults. RGBlink must be informed immediately in writing of any complains.
The period of guarantee begins on the date of transfer of risks, in the case of special systems and
software on the date of commissioning, at latest 30 days after the transfer of risks. In the event of
justified notice of compliant, RGBlink can repair the fault or provide a replacement at its own
X3 User Manual
4
discretion within an appropriate period. If this measure proves to be impossible or unsuccessful,
the purchaser can demand a reduction in the purchase price or cancellation of the contract. All
other claims, in particular those relating to compensation for direct or indirect damage, and also
damage attributed to the operation of software as well as to other service provided by RGBlink,
being a component of the system or independent service, will be deemed invalid provided the
damage is not proven to be attributed to the absence of properties guaranteed in writing or due
to the intent or gross negligence or part of RGBlink.
If the purchaser or a third party carries out modifications or repairs on goods delivered by RGBlink,
or if the goods are handled incorrectly, in particular if the systems are commissioned operated
incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in
the contract, all guarantee claims of the purchaser will be rendered invalid. Not included in the
guarantee coverage are system failures which are attributed to programs or special electronic
circuitry provided by the purchaser, e.g. interfaces. Normal wear as well as normal maintenance
are not subject to the guarantee provided by RGBlink either.
The environmental conditions as well as the servicing and maintenance regulations specified in
this manual must be complied with by the customer.
Operators Safety Summary
The general safety information in this summary is for operating personnel.
Do Not Remove Covers or Panels
There are no user-serviceable parts within the unit. Removal of the top cover will expose
dangerous voltages. To avoid personal injury, do not remove the top cover. Do not operate the
X3 User Manual
5
unit without the cover installed.
Power Source
This product is intended to operate from a power source that will not apply more than 230 volts
rms between the supply conductors or between both supply conductor and ground. A protective
ground connection by way of grounding conductor in the power cord is essential for safe
operation.
Grounding the Product
This product is grounded through the grounding conductor of the power cord. To avoid electrical
shock, plug the power cord into a properly wired receptacle before connecting to the product
input or output terminals. A protective-ground connection by way of the grounding conductor in
the power cord is essential for safe operation.
Use the Proper Power Cord
Use only the power cord and connector specified for your product. Use only a power cord that is
in good condition. Refer cord and connector changes to qualified service personnel.
Use the Proper Fuse
To avoid fire hazard, use only the fuse having identical type, voltage rating, and current rating
characteristics. Refer fuse replacement to qualified service personnel.
Do Not Operate in Explosive Atmospheres
To avoid explosion, do not operate this product in an explosive atmosphere.
X3 User Manual
6
Installation Safety Summary
Safety Precautions
For all product installation procedures, please observe the following important safety and
handling rules to avoid damage to yourself and the equipment.
To protect users from electric shock, ensure that the chassis connects to earth via the ground wire
provided in the AC power Cord.
The AC Socket-outlet should be installed near the equipment and be easily accessible.
Unpacking and Inspection
Before opening product shipping box, inspect it for damage. If you find any damage, notify the
shipping carrier immediately for all claims adjustments. As you open the box, compare its
contents against the packing slip. If you find any shortages, contact your sales representative.
Once you have removed all the components from their packaging and checked that all the listed
components are present, visually inspect the system to ensure there was no damage during
shipping. If there is damage, notify the shipping carrier immediately for all claims adjustments.
Site Preparation
The environment in which you install your product should be clean, properly lit, free from static,
and have adequate power, ventilation, and space for all components.
X3 User Manual
7
1 x AC Power
Cord
Chapter 1 Your Product
1.1 In the Box
1 x Network Cable
1 x HDMI to DVI
Cable
1 x DB9 to RJ11
Cable
1 x Anti-static Bag
1 x SDI Cable
1 x USB Cable
1 x DVI Cable
Note: AC Power Cable supplied as standard according to destination market.
X3 User Manual
8
1.2 Product Overview
X3 is an HDCP-compliant, scalable, expandable videowall processor configurable to support a
variety of input, output and windowing capabilities. It features high performance video scaling
capable of producing very high quality images.
X3 offers six card cages that support various combinations of input and output cards for DVI, VGA,
HDMI, CVBS, SDI and USB (for media files play) or video sources. Hundreds of additional video or
graphic sources can be input to the X3 using the RGBlink AVDXP Matrix and Router. Multiple X3
can be cascaded to create very large display arrays. A dedicated, high-speed video/graphic bus
maintains real-time performance even under heavy loading of inputs.
Compared with other videowall processors, X3 extends two main important performance for
presentation application. One is seamless switching between the inputs, the other comes with
local control panel option. These advantages make the X3 ideal for all types for all types of
surveillance, presentation, and visualization applications, whether traffic, security, military, or
process control.
X3 User Manual
9
1.2.1 Front Panel
1
OLED Panel
Show the input shot and output slot information, device status, COM.
Version, IP address and serial address.
2
POWER
Power button, long push the button, the device can be boot up. Under
normal running state, push the button once, the info shown on OLED can
be refreshed once ; long push the button, the OLED will pop up a confirm
box, release the power button, push the power again before the confirm
box disappears, and the power can be turned off.
