Rexing V1 Max Manual de usuario
V1 Max
Quick Start Guide
FR
IT
DE
SP
V1 Max クイックスタートガイド
Guide de démarrage rapide de la V1 Max
Guida di avvio rapido V1 Max
Guía de inicio rápido V1 Max
V1 Max Schnellstartanleitung
JP
2
Table of Contents
English
Overview
What’s in the Box
Camera Overview
Installation
Basic Operation
日本語
概説
本製品の同梱物
カメラの概説
画面のアイコン
基本操作
Français
Aperçu
Que contient la Boîte
Aperçu de la Caméra
Installation
Opération de Base
Italiano
Descrizione
Nella Confezione
Descrizione Telecamera
Installazione
Funzionamento Base
page
4
5
6
8
12
18
19
20
22
27
32
33
34
36
41
46
47
48
50
55
3
Español
Visión General
Qué hay en la Caja
Resumen de la Cámara
Instalación
Operación Básica
Deutsch
Übersicht
Verpackungsinhalt
Kamera übersicht
Installation
Grundbedienungen
60
61
62
64
69
74
75
76
78
83
page
4
1. Overview
Thank you for choosing REXING! We hope you love your new
product as much as we do.
If you need assistance, or have any suggestions to improve it,
please contact us. You can reach us via [email protected] or
call us at (203) 800-4466. Our support team will respond you as
soon as possible.
Always a surprise in Rexing. Check us out here.
https://www.facebook.com/rexingusa/
https://www.instagram.com/rexingdashcam/
https://www.rexingusa.com/support/registration/
Facebook Instagram Site Product Support
5
1. Overview
1. Rexing V1 Max Dashboard
Camera
2. Car Power Connector
(12ft)
3. 3M Adhesive Mount
4. USB Cable
5. User Manual
6. Safety Guide
7. Cable Management Tool
2. What’s in the box
3.
2.
4.
5.6.
7.
1.
V1 Max
Quick Start Guide
FR Guide de démarrage rapide de la V1 Max
IT Guida di avvio rapido V1 Max
DE V1 Max Schnellstartanleitung
SP Guía de inicio rápido V1 Max
JP V1 Max クイックスタートガイド
6
3. Camera Overview
1. OK (Confirm) Button / Emergency Lock Button
2. Up Navigation Button / Record Button*
3. Power Button / Screen Toggle Button
4. Down Navigation Button / Mic Button**
5. Menu Button / Mode Button
6. Micro SD Card Slot
7. Reset Button
8. USB Charging Port
9. Rear Camera Port (Not Support )
10. GPS Logger Port (Built-in GPS Logger)
*The camera is recording when the LED is flashing red.
**The device is charging or powered on when the LED is solid white.
2. 4. 5.
3.
1.
9.
10.
6.
8.
7.
7
Screen Icons
Recording (ON) GPS Signal
(Connected)
Wi-Fi
(ON)
MIC(ON)
Current Date
(MM/DD/YYYY)
Time(24h)
Emergency
Lock
GPS Signal
(Not Connect)
Wi-Fi (Not Connect)
MIC (OFF)
8
4. Installation
Step 1: Install the Dash Cam
Place the 3M tape on the Mount and properly orient the
Mount square to the roof and hood line of the vehicle.
Important! Ensure the T-interlock on the Mount is oriented in
the correct direction.
Firmly press the Mount onto the windshield. Wait at least 20
minutes before mounting the camera.
On the illustration Orient the mount as shown.
Orient the
mount as shown
Press the Power
button to turn the
the power off
9
Step 3: Power the Camera and Format the
Memory Card
Power the camera by connecting the charger to
the car cigarette lighter and camera. To ensure the V1
Max records to your memory card properly and
without error. Before you start using a new memory
card, you must format the card within the camera
using the format function. Always backup important
data stored on the memory card before formatting.
To format the memory card, make sure you have
inserted your memory card, then turn on the device by
connecting to a power source. Press REC to stop
recording. Then press the MENU button twice to enter
the System Setup Menu. Use the REC and MIC
buttons and go to the Format setting. Press the OK
button to confirm the selection.
Step 2: Insert the Memory Card
The Rexing V1 Max accepts [Class 10/UHS-1 or
higher] Micro SD memory cards up to 256GB. You will
need to insert a memory card before you can begin
recording. Before inserting or removing a memory
card, first ensure you’ve powered down the
device. Gently push the memory card in until you
hear a click, and allow the spring release to push the card
out.
10
You may now disconnect from power. The camera will shut
down after 3 seconds. The camera should begin recording
automatically the next time it is powered on.
Press the Menu button
twice
Press the Confirm
button to confirm
formatting the card
