Reolink RLC-830A Manual de usuario

Jan 2023

QSG1_A_EN

Quick Start Guide

@ReolinkTech https://reolink.com

58.03.001.0312

Apply to:RLC-830A

English English1 2

What's in the Box 2

Camera Introduction 3

Connection Diagram 5

Set UP the Camera 6

Mount the Camera 7

Troubleshooting 10

Specication 11

NoticationofCompliance 12

What's in the Box

Contents

Quick Start Guide

Camera Waterproof Lid

Pack of Screws

Mounting Hole

Template

Ethernet Cable

Surveillance Sign

English English3 4

VGAHDMIUSB

AUDIO

OUT

DC 48V

2 4 6 8

1 3 5 7

OFF

LAN

eSATA

Lens

Spotlight

Daylight Sensor

lnfrared Light

Built-in Mic

Mount

Speaker

Waterproof Lid

Network Cable

Power Port (Optional)

SD Card Slot

Reset Button

*Pressforabout10secondstorestorethe

devicetofactorysettings.

Camera Introduction

English English5 6

Connection Diagram

VGAHDMIUSB

AUDIO

OUT

DC 48V

2 4 6 8

1 3 5 7

OFF

LAN

eSATA

Beforeusingthecamera,pleaseconnectyourcameraasinstructed

belowtonishinitialsetup.

1.ConnectthecameratoaReolinkNVR(notincluded)withanEthernet

cable.

2.ConnecttheNVRtoyourrouter,andthenpowerontheNVR.

PoEIPCamera

ReolinkNVR Router

Power Adapter

EthernetCable

NOTE:Thecamerashouldbepoweredwitha12VDCadapteroraPoE

poweringdevicesuchasPoEinjector,PoEswitchorReolinkNVR(notin-

cludedinthepackage).

*YoumayalsoconnectthecameratoaPoEswitchorPoEinjector.

Set UP the Camera

• On Smartphone

• On PC

Scan to download

theReolinkApp.

DownloadpathoftheReolinkClient:Gotohttps://reolink.com>Support

>App&Client.

DownloadandlaunchtheReolinkApporClientsoftware,andfollowthe

onscreeninstructionstonishinitialsetup.

NOTE:

•IfyouareconnectingthePoEcameratoaReolinkPoENVR,pleaseset

upthecameraviatheNVRinterface.

English English7 8

Mount the Camera

•Donotfacethecameratowardsanylightsources.

•Donotpointthecameratowardsaglasswindow.Otherwise,itmay

resultinpoorimagequalitybecauseofthewindowglarecausedby

infraredLEDs,ambientlightsorstatuslights.

• Do not place the camera in a shaded area and point it towards a

well-litarea.Otherwise,itmayresultinpoorimagequality.Toensure

bestimagequality,thelightingconditionforboththecameraandthe

captureobjectshouldbethesame.

•Makesurethepowerportsarenotdirectlyexposedtowateror

moistureandnotblockedbydirtorotherelements.

•Thewaterproofcameracanworkproperlyunderconditionslikerain

andsnow.However,itdoesn’tmeanthecameracanworkunderwater.

• Do not install the camera at places where rain and snow can hit the lens

directly.

Installation Tips

Mount the camera to the wall

1.Drillholesinaccordancewiththemountingholetemplate.

2.Installthemountbasewithscrewsincludedinthepackage.

3.Toadjustthecameradirection,youmaycontrolthecameratopan

andtiltviaReolinkApporClient.

VGAHDMIUSB

AUDIO

OUT

DC 48V

2 4 6 8

1 3 5 7

OFF

LAN

eSATA

NOTE:Usethedrywallanchorsincludedinthepackageifneeded.

English English9 10

VGAHDMIUSB

AUDIO

OUT

DC 48V

2 4 6 8

1 3 5 7

OFF

LAN

eSATA

Mount the Camera to Ceiling

1.Drillholesinaccordancewith

themountingholetemplate.

2.Installthemountbasewith

screwsincludedinthepackage.

3.Toadjustthecameradirection,

youmaycontrolthecamerato

panandtiltviaReolinkAppor

Client.

NOTE:Usethedrywallanchors

includedinthepackageif

needed.

Troubleshooting

•Makesureyourcameraispoweredonproperly.ThePoEcamerashould

bepoweredbyaPoEswitch/injector,aReolinkNVRora12Vpower

adapter.

•IfthecameraisconnectedtoaPoEdeviceaslistedabove,connectitto

anotherPoEportandcheckagain.

•TryagainwithanotherEthernetcable.

Ifyourcameraisnotpoweringon,pleasetrythefollowingsolutions:

Camera is not powering on

Ifthepicturefromthecameraisnotclear,pleasetrythefollowing

solutions:

•Checkthecameralensfordirt,dustorspiderwebs.Pleasecleanwitha

soft,cleancloth.

•Pointthecameratoawell-litarea.Thelightingconditionwillaectthe

picturequalityalot.

•Upgradethermwareofyourcameratothelatestversion.

•Restorethecameratofactorysettingsandcheckitagain.

Picture is not clear

English English11 12

Dimension:248x110x147mm

Weight:1.21KG

OperatingTemperature:-10°C~+55°C(14°F~131°F)

OperatingHumidity:10%~90%

Formorespecications,visithttps://reolink.com/.

Specication

InfraredNightVision:15Meters

Day/NightMode:Autoswitchover

Hardware Features

General

Notication of Compliance

FCC Compliance Statement

ThisdevicecomplieswithPart15oftheFCCRules.Operationissubject

tothefollowingtwoconditions:(1)thisdevicemaynotcauseharmful

interference,and(2)thisdevicemustacceptanyinterferencereceived,

includinginterferencethatmaycauseundesiredoperation.

NOTE: Thisequipmenthasbeentestedandfoundtocomplywiththe

limitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules.

These limits are designed to provide reasonable protection against

harmfulinterferenceinaresidentialinstallation.Thisequipment

generatesusesandcanradiateradiofrequencyenergyand,ifnot

installedandusedinaccordancewiththeinstructions,maycause

harmfulinterferencetoradiocommunications.However,thereisno

guaranteethatinterferencewillnotoccurinaparticularinstallation.If

thisequipmentdoescauseharmfulinterferencetoradioortelevision

reception,whichcanbedeterminedbyturningtheequipmentoandon,

theuserisencouragedtotrytocorrecttheinterferencebyoneormore

ofthefollowingmeasures:

•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connecttheequipmentintoanoutletonacircuitdierentfromthatto

whichthereceiverisconnected.

English English13 14

Reolinkdeclaresthatthisdeviceisincompliancewiththeessentialre-

quirementsandotherrelevantprovisionsofEMCDirective2014/30/EU

andLVD2014/35/EU.

Simplied EU Declaration of Conformity

ThisClassBdigitalapparatuscomplieswithCanadianICES-003.

CetappareilnumériquedelaclasseBestconformeàlanormeNMB-003

duCanada.

ISED Compliance Statements

Thisproductcomeswitha2-yearlimitedwarrantythatisvalidonlyif

purchasedfromReolinkOcialStoreoraReolinkauthorizedreseller.

Learnmore:https://reolink.com/warranty-and-return/.

Limited Warranty

NOTE: Wehopethatyouenjoythenewpurchase.Butifyouarenot

satisedwiththeproductandplantoreturn,westronglysuggestthat

youresetthecameratofactorydefaultsettingsbeforereturning.

UseoftheproductissubjecttoyouragreementtotheTermsofService

andPrivacyPolicyatreolink.com.Keepoutofreachofchildren.

Terms and Privacy

Thismarkingindicatesthatthisproductshouldnotbedisposedwith

otherhouseholdwastes.throughouttheEU.Topreventpossibleharmto

theenvironmentorhumanhealthfromuncontrolledwastedisposal,

recycleitresponsiblytopromotethesustainablereuseofmaterial

resources.Toreturnyouruseddevice,pleaseusethereturnand

collectionsystemsorcontacttheretailerwheretheproductwas

purchased.Theycantakethisproductforenvironmentallysaferecycling.

Correct Disposal of This Product

•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Caution:Changesormodicationsnotexpresslyapprovedbytheparty

responsibleforcompliancecouldvoidtheuser’sauthoritytooperatethe

equipment.

ReolinkdeclaresthatthisproductisincompliancewithElectromagnetic

CompatibilityRegulations2016andElectricalEquipmentSafety

Regulations2016.

UKCA Declaration of Conformity

English English15 16

ByusingtheProductSoftwarethatisembeddedontheReolinkproduct,

youagreetothetermsofthisEndUserLicenseAgreement(“EULA”)

betweenyouandReolink.Learnmore:https://reolink.com/eula/.

End User License Agreement

Ifyouneedanytechnicalhelp,pleasevisitourocialsupportsiteand

contactoursupportteambeforereturningtheproducts,

https://support.reolink.com.

Technical Support
