Quinny 1474 Manual de usuario
Spanish Guide Included
Guía en español incluida
01474
User Guide
Guía del Usuario
Contents
TM T
i
Warnings 1
Parts List 2
Assembly 3-4
To Use 5-8
Care and Maintenance 9
Replaceable Parts 9
Warranty 9
Warnings
TM
T
FOR THE SAFETY OF YOUR CHILD, PLEASE READ THE FOLLOWING WARNINGS AND ASSEMBLY
INSTRUCTIONS AND KEEP FOR FUTURE REFERENCE.
•
Adult assembly required. CAUTION: Keep small parts away from children during assembly.
•NEVER LEAVE CHILD UNATTENDED. ALWAYS keep child in view when in stroller.
•AVOID SERIOUS INJURY from falling or sliding out. ALWAYS use seat belt. Check frequently to make sure
it is secure.
•ALWAYS keep fingers away from moving parts, when folding, unfolding or adjusting stroller to prevent
finger entrapment.
•ALWAYS make sure stroller is FULLY OPEN AND LOCKED before using.
•ALWAYS use the brakes when stroller is stopped.
•ALWAYS remove protective material and poly bags and dispose before assembly.
•NEVER use stroller on stairs or escalators.
•NEVER allow children to play with or hang onto the stroller.
•NEVER allow children to climb into the stroller unassisted. Stroller may tip over and injure child.
•NEVER place or hang parcels, bags or accessories on the handle or canopy. The stroller may tip over or the
canopy may collapse.
•This product will become unstable if a parcel bag or rack is used when there is no provision for one.
•This product may become unstable if a parcel bag, other than the one recommended by the manufacturer is
used.
•This product will become unstable if the manufacturer’s recommended load is exceeded.
•DO NOT carry additional children, goods or accessories in or on this product except as recommended in
the manufacturer’sinstructions.
•NEVER place more than 5-LBS. (2.27-kg) in the storage basket. If weight is exceeded, hazardous unstable
conditions may exist.
•STROLLER is only for use with children up to 40-LBS. (18.2-kg), and WHEN SEATED,the midpoint of the
child’s head is at or below the top of the stroller seat.
•ONLY use this stroller with ONE child at a time.
•STROLLER is for use with children who can sit up unassisted, and is NOT recommended for newborns.
WARNING
1
Parts List W
TM TM
T
2
Rear wheels (2)
Front wheels (2)
Canopy
Car seat adapters (2)
Shopping basket
Rain cover
Storage bag
Hinge covers (2)
Hinge points
A
B
C
E
F
G
AB
D
E
D
F
H
I
C
G
•Mico
TM
car seat sold separately.
•Lay out and identify all parts.
•Do not return this product to the
place of purchase. If any parts are
missing, call Consumer Relations at
(800) 951-4113. Or visit our website
at www.quinny.com.
•Include the model number and
manufacturedate(found on the back
of the stroller) and a brief description
of the part.
•Keep these instructions for future use.
I
H
Assembly
TM T
NOTE: If wheels begin to
squeak, spray lubricant to the
axles.
1Install Rear Wheels
Insert the rear wheel axle
into the frame until you
hear a “click” (Figure 1).
Repeat for other rear
wheel. Pull to confirm it is
assembled securely.
3
3Unfold Stroller
Gently lift the stroller by
the hinge points. The
frame will start to
unfold itself (Figure 3).
2Install Front Wheels
Position front wheel with
logo facing outward.
Insert front wheel into the
tube of the frame until you
hear “click” (Figure 2).
Repeat for other front
wheel. Pull to confirm it is
assembled securely.
1
2
3
Pull the coupling (labeled
3) outward until you hear
a“click” (Figure 3a).3a
3c
3b
3d
Press release button 1
(Figure 3b).The button
will stay pressed by itself.
Press release button 2,
while at the same time
raising the upper section
of the stroller (Figure 3c).
Release button 2 and lift
up further until you hear a
“click.”
Extend the handle crossbar
into the horizontal position
until you hear a “click”
(Figure 3d).
Assembly T
TM T
4
4Parking Brake
Always use the parking
brake, even when standing
still for only a few
moments! Push down on
the red pedal (P) behind
the rear wheel to set the
parking brake (Figure 4).
Push the opposite pedal to
release the parking brake.
5Attach Shopping
Basket
Locate two loops in the
area under the footrest.
Put strap end through
loop and secure snap
(Figure 5a).
Locate one ring above
each rear wheel. Put
strap end through each
ring and securesnap
(Figure 5b).
6Canopy
Slide offthe hinge covers
from the hinge points
and store them for future
use (Figure 6).
Slide both ends of the
canopy into the hinge
points until they are
securely in place
(Figure 6a).
4
6
6a
6b
6c
Fasten the canopy to the
top of the stroller using the
snaps and adhesive patches
(Figure 6b).Check to make
surethe canopy is fastened
securely.
The canopy can be adjusted
to two different positions:
folded out or folded back
(Figure 6c).
To remove the canopy:
Unfasten the snaps and
adhesive patches and pull
the canopy out of the hinge
points. Slide the hinge
covers onto the hinge
points (Figure 6d).
6d
CAUTION
When removing canopy,
always slide hinge
covers back on the
hinge points.
5
5a 5b
To Use
C
TM
T
5
7Swivel Wheel
TIP: Lock the swivel
wheel when using the
stroller in a straight
direction for a long
period.
To lock, push the
swivel wheel lock
downward and turn the
front wheel into the
backward position until
you hear a “click”
(Figure 7).
Tounlock, push the
swivel wheel lock
upward.
7
9Rain Cover
Place the rain cover over the canopy and secure
adhesive straps around the handles. Hook it under the
footrest (Figure 9).
WARNING –
SUFFOCATION HAZARD
•Be sure rain shield doesn’t cover the child’s face.
9
8Removing Seat
It is necessary to remove
the seat from the frame
when preparing to use
the car seat adapters.
Unzip seat zipper at the
back of the seat
(Figure 8).
8
To Use
TM
T
6
To avoid serious injury:
•Use ONLY MicoTM infant car seat (not included)
with this stroller (model 01474).
•Please refer to the manufacturer’s instructions
for the use of your infant car seat.
•ALWAYS install car seat facing to the rear of
the stroller.
•ALWAYS use the restraint system in the car
seat.
WARNING
10Install Infant Car Seat
Remove the seat. Push the parking brake pedal down.
Insert left and right car seat adapters into hinge points
until you hear a “click” (Figure 10).
Car seat must be in rear-facing position.
Lower car seat into car seat adapters until both sides
“click” (Figure 10a).
To remove car seat, press both buttons on car seat
(Figure 10b).Lift car seat up.
To remove car seat adapters, press gray button and
slide adapter off hinge points (Figure 10c).
10
10a
10c
10b
To Use
C
TM
T
7
11 To Use Restraint
System
Place your child in
the stroller, with the crotch
strap between the child’s
legs. Fit clips together. Slide
clips into buckle until you hear
a“click” (Figure 11).
Tighten straps snugly around
your child (Figure 11a).
Totighten strap, slide
buckles down (Figure 11b).
To loosen strap, slide
buckles up (Figure 11b).
WARNING
•NEVER LEAVE CHILD UNATTENDED.
•AVOID SERIOUS INJURY from falling or sliding out. Always use seat belt. Check frequently to make sure it is
secure. Belts must be threaded exactly as shown.
•Failure to follow these instructions could result in the serious injury or death of your child.
11 11a 11b
12Adjust Restraint Height
The shoulder straps have two height positions for your growing child. Push
each anchor through the seat back and into the desired slot (Figure 12).Be
sure the anchor lays flat against the seat back. Anchors
WARNING
•For proper installation of the restraint system,
make sureboth anchors lay flat against the
back board.
•NEVER use stroller without BOTH restraint and
crotch straps.
12
To Use
TM
T
8
13Fold Stroller
NOTE: It is not
necessary to remove
canopy before folding.
Close canopy (Figure
13).
Stand behind the
stroller and push release
button 1 (Figure 13a).
The button will stay
pressed by itself.
13
13a
13b
13c
13d
14
13e
14a
14Removing the
Wheels
Press the release button
and pull the rear wheel
out of the frame
(Figure 14).
Press the release button
on the bottom of each
front wheel and pull
wheel offof the frame
(Figure 14a).
Hold onto the stroller by
the hinge points and
push release pedal
down, and push
coupling (labeled 3)
forward (Figure 13d).
If necessary, push down
further on the frame
with your hands to make
it more compact. Place it
inside transport bag
(Figure 13e).
NOTE: To make the
stroller more compact,
you may remove the
wheels.
Ensure that the handle
crossbar is folded inward
(Figure 13c).
Push release button 2
while at the same time
pushing the upper frame
forward (Figure 13b).
