Upgrading Host Interface Cards

StorNext QD7000

Firmware 8.30.xx.xx

6-68564-01 Rev A

ii Upgrading Host Interface Cards

Upgrading Host Interface Cards, 6-68564-01 Rev A, April 2017 Product of USA.

Quantum Corporation provides this publication “as is” without warranty of any kind, either express or implied, including but not

limited to the implied warranties of merchantability or fitness for a particular purpose. Quantum Corporation may revise this

publication from time to time without notice.

Your right to copy this manual is limited by copyright law. Making copies or adaptations without prior written authorization of

Quantum Corporation is prohibited by law and constitutes a punishable violation of the law.

TRADEMARK STATEMENT

Artico, Be Certain (and the Q brackets design), DLT, DXi, DXi Accent, DXi V1000, DXi V2000, DXi V4000, DXiV-Series, FlexTier,

Lattus, the Q logo, the Q Quantum logo, Q-Cloud, Quantum (and the Q brackets design), the Quantum logo, Quantum Be Certain

(and the Q brackets design), Quantum Vision, Scalar, StorageCare, StorNext, SuperLoader, Symform, the Symform logo (and

design), vmPRO, and Xcellis are either registered trademarks or trademarks of Quantum Corporation and its affiliates in the United

States and/or other countries. All other trademarks are the property of their respective owners. Products mentioned herein are for

identification purposes only and may be registered trademarks or trademarks of their respective companies. All other brand names

or trademarks are the property of their respective owners. Quantum specifications are subject to change.

Upgrading Host Interface Cards iii

Preface

Note: The 8.30.xx.xx firmware (Lehigh) is used in the QD7000 (E5600,

Titan RAID controller, only). Refer to the NetApp to Quantum

Naming Decoder section for additional information.

This section provides the following information:

•Audience

•Prerequisites

•NetApp to Quantum Naming Decoder

•Product Safety Statements

•Contacts

•Comments

•Quantum Global Services

Audience This manual is intended for storage customers and technicians.

Preface

iv Upgrading Host Interface Cards

Prerequisites Prerequisites for installing and using this product include knowledge of:

• Servers and computer networks

• Network administration

• Storage system installation and configuration

• Storage area network (SAN) management and direct attach storage

(DAS)

• Fibre Channel (FC) and Ethernet protocols

NetApp to Quantum

Naming Decoder

Use Table 1 to correlate the NetApp product nomenclature to the

equivalent Quantum-storage naming conventions.

Table 1 Product Nomenclature

E-Series NetApp

Product Quantum-Storage Description

Controller-Drive Tray Base System Quantum uses Base System when referring to a drive

tray with the RAID controllers.

Drive Tray Expansion Unit Quantum uses Expansion Unit when referring to a

drive tray with the environmental services modules

(ESMs).

E5600 (Code Name:

Titan)

RAID Controller Four 16Gb/s FC SFP+ host ports

E5500 (Code Name:

Soyuz)

RAID Controller Four 16Gb/s FC SFP+ host ports

E5400 (Code Name:

Pikes Peak)

RAID Controller Four 8Gb/s FC SFP+ host ports

DE6600 (Code Name:

Wembley)

4U 60-drive

enclosure

Sixty 3.5 inch disk drives

Preface

Upgrading Host Interface Cards v

E5560 or E5660

(DE6600 4U drive

enclosure with

E5500 or E5600 RAID

controllers)

Quantum StorNext

QD7000

E5460

(DE6600 4U drive

enclosure with

E5400 RAID

controllers)

Quantum StorNext

QD6000

E5424

(DE5600 24-drive 2U

drive enclosure

(Code Name:

Camden with E5400

RAID controllers)

Quantum StorNext

QS2400

E5412

(DE1600 12-drive 2U

drive enclosure

(Code Name: Ebbets

with E5400 RAID

controllers)

Quantum StorNext

QS1200

E-Series NetApp

Product Quantum-Storage Description

Preface

vi Upgrading Host Interface Cards

Product Safety

Statements

Quantum will not be held liable for damage arising from unauthorized

use of the product. The user assumes all risk in this aspect.

This unit is engineered and manufactured to meet all safety and

regulatory requirements. Be aware that improper use may result in

bodily injury, damage to the equipment, or interference with other

equipment.

WARNING: Before operating this product, read all instructions and

warnings in this document and in the system, safety, and

regulatory guide.

Preface

Upgrading Host Interface Cards vii

Contacts For information about contacting Quantum, including Quantum office

locations, go to:

http://www.quantum.com/aboutus/contactus/index.aspx

Comments To provide comments or feedback about this document, or about other

Quantum technical publications, send e-mail to:

[email protected]

Preface

viii Upgrading Host Interface Cards

Quantum Global

Services

Accelerate service issue resolution with these exclusive Quantum

StorageCare services:

•Service and Support Website - Register products, license software,

browse Quantum Learning courses, check backup software and

operating system support, and locate manuals, FAQs, firmware

downloads, product updates and more in one convenient location.

Benefit today at:

http://www.quantum.com/serviceandsupport/get-help/

index.aspx#contact-support

•eSupport - Submit online service requests, update contact

information, add attachments, and receive status updates via email.

Online Service accounts are free from Quantum. That account can

also be used to access Quantum’s Knowledge Base, a

comprehensive repository of product support information. Get

started at:

http://www.quantum.com/customercenter/

For further assistance, or if training is desired, contact the Quantum

Customer Support Center:

North America 1-800-284-5101 (toll free)

+1-720-249-5700

EMEA +800-7826-8888 (toll free)

+49-6131-324-185

APAC +800-7826-8887 (toll free)

+603-7953-3010

For worldwide support:

http://www.quantum.com/serviceandsupport/get-help/

index.aspx#contact-support

Replacing Controller Canisters in the E5660 Controller-Drive

Tray to Upgrade Host Interface Cards

To access this product, go to the NetApp® support site at mysupport.netapp.com.

Planning the Host Interface Card Upgrade

Use these procedures to upgrade the host interface in a controller-drive tray by replacing all of the controllers. For

duplex controller-drive trays, you replace both controllers. For simplex controller-drive trays, you replace the one

controller. In both cases, you must power off the controller-drive tray. As a result, you cannot access data on the

storage array until you successfully complete the replacement.

If your storage array participates in remote volume mirroring, only iSCSI or Fibre Channel connections are

supported between the primary site and the remote site. If your new HIC configuration does not include iSCSI or

Fibre Channel connections, remote volume mirroring will not be supported.

If you upgrade to 56 Gb/s InfiniBand, you must perform the steps from the InfiniBand Configuration and Provisioning

for Linux® Express Guide to configure your storage array to use the iSCSI Extensions for RDMA (iSER) protocol.

Make sure that you have access to that document before you start these procedures.

To complete this procedure, you will need antistatic protection and one or two new controller canisters. Depending

on your new host interface, you might need new host bus adapters (HBAs), host channel adapters (HCAs),

switches, cables, Small Form-factor Pluggable (SFP) transceivers, or quad SFP (QSFP) transceivers to re-cable

your host connections. Table 1 summarizes requirements for cabling and SFP transceivers.

Your new controller canisters are shipped without a battery installed. You will remove the battery from each of your

old controllers and then install those batteries in the new controllers.

ATTENTION Possible loss of data access – If any controller that you are replacing manages any secure volumes,

the new controller needs the correct security key to manage those volumes. After you replace the controller and

restore power to the controller-drive tray, you can use SANtricity Storage Manager to load the key from the file in

which it was saved. Be sure that such a file exists and that you know the pass phrase required to install the security

key before you replace the controller.

Cabling Considerations for the E5600 Controller-Drive Trays

Compare your current host cabling to the supported cabling for your new controllers to determine whether you can

reuse SFPs, QSFPs or cables from your old cabling configuration. The HBAs, HCAs, or Ethernet adapters, as well

as switches in the network fabric used to connect your hosts to your storage array must match the HICs in your

controller canisters.

2 - Replacing Controller Canisters in the E5660 Controller-Drive Tray to Update HICs

Table 1. Host Cabling Configurations

HIC Cable

Data Rate and

Protocol

Number of

Connectors

Connector Type Length

MiniSAS-HD passive copper 1-5m

MiniSAS-HD active copper 8-15m

MiniSAS-HD optical 5-100m

Fan-out cable type #2 passive copper 2m

12 Gb/s SAS 4

Fan-out cable type #3 passive copper 2m

QSFP+ passive copper 1-3m56 Gb/s InfiniBand 2

QSFP+ optical 5-100m

SFP+ OM2 SW optical 2,3,5,10,25m

SFP+ OM3 SW optical 50-150m

16 Gb/s Fibre Channel 4

SFP+ OS2 LW optical 50-300m

SFP+ OM2 optical 2,3,5,10,25m

SFP+ OM3 optical 50-150m

10 Gb/s iSCSI 4

Twin-Ax passive copper 2-7m

1 Gb/s iSCSI 4 RJ-45 passive copper 2-70m

Preparing to Replace the Controllers

1. Make sure that the existing storage array is updated to the latest released controller firmware.

2. If an FDE security key exists on the storage array, save the FDE security key to a location not on the storage

array.

3. Perform the following steps to record the serial number for your storage array:

a. In the EMW tree view, double-click your storage array.

The AMW opens

b. In the Summary tab of the AMW, click the View Storage Array Profile link.

c. Make a record of the value for Chassis Serial Number.

You need this serial number to perform the steps in Powering On the E5600 Storage Array.

4. Gather support data about your storage array by using one of these methods:

Use the storage management software to collect and save a support bundle of your storage array. From the

Array Management Window toolbar, select Monitor > Health > Collect Support Data Manually. Then

name and specify a location on your system where you want to store the support bundle.

Use the command line interface (CLI) to run the save storageArray supportData command to gather

comprehensive support data about the storage array. For more information about this command, refer to the

current version of the Command Line Interface and Script Commands Programming Guide.

NOTE Gathering support data can temporarily impact performance on your storage array.

5. Stop all I/O operations between the storage array and all connected hosts.
