DTS50R/DRS50R

Stand Alone DVI CAT5 Extension System

DVI + Stereo Audio + RS-232 + IR over two CAT5

Owner’s Manual

Dtrovision LLC

9A Bergen Turnpike

Little Ferry, NJ 07643

USA

Tel: +1.201.488.3232

Fax: +1.201.621.6118

Email: support@dtrovision.com

www.dtrovision.com

For order support, please contact your local dealer.

For technical support, please contact us at supp[email protected]

DTS50R/DRS50R Package Contents

Please make sure all of the following items are included in the package;

1) DTS50R/DRS50R x1

2) DC 12V Power Supply Unit with a power cord x1

3) User Manual

DTS50R: DVI CAT5 Transmitter Module

DRS50R: DVI CAT5 Receiver Module

General Specification

• DTS50R/DRS50R is a DVI, stereo audio, RS-232, IR extension system over two CAT5 cables for

long distance up to 165ft.

• Compact & durable design and lower power consumption makes it an ideal solution for connection

for high definition video/audio signal of digital displays such as LCD/Plasma/LED displays and

projectors.

• DTS50R/DRS50R’s unique circuitry design for the best quality of HDTV and its CAT5 connection

enables to minimize electrical noise and EMI free that is ideal for long distance extension of high

definition DVI signal .

• DTS50R: Transmitter module

DRS50R: Receiver module

Model

DTS50R/DRS50R

Input Signal

DVI, 3.5mm Analog Audio, RS-232, IR

Output Signal

DVI, 3.5mm Analog Audio, RS-232, IR

Supporting Display

Resolutions

VGA ~WUXGA(up to 1920 x 1200 @ 60Hz) ,

480i ~ 1080p

Max. Distance

1920x1200 @ 60Hz or at 1080p: 50M(165ft)

1280x1024 @ 60Hz or at 1080i: 60M(200ft)

Connector Type

DC Power Jack

DVI 29 Pin Female

RJ45 * 2 EA

3.5mm Stereo Jack

IR: 4P Phoenix connector

RS-232C: 3P Phoenix connector

Conformations

DDWG DVI 1.0 with HDCP

Power Rating

DC +12V , 8W Max

Dimension

4.3x3.1x1.6(inches) 110x78x40(mm)

Weight

0.81 lbs (0.37Kg)

Operation and Reliability Specification

1. Operating Environment

Temperature: 50F ~ 104F (10℃~ 40℃)

Humidity: 10% ~ 80%

Altitude: 3,000m Max.

2. Transit Environment

Temperature: -13F ~ 140F (-25℃~ 60℃)

Humidity: 5% ~ 95%

Altitude: 15,000m Max.

3. Storage Environment

Temperature: -4F ~ -49F (-20℃~ 45℃)

Humidity: 5% ~ 95%

Altitude: 3,000m Max.

4. Reliability

MTBF: 90% at over 50,000 hours aging test

In compliance with LCD Monitor reliability test standard

Main Features

1. Zero loss & Zero noise delivery of digital high definition video and audio signal using CAT5

conversion technology, DTS50R/DRS50R delivers HD signals over Cat5 cables without

loss or digital interference maintaining the clarity and colors. Noise cancellation and error

correction logic enhances video and audio signals over long distance.

2. Built-in signal repeater to support longer distance between the source and the DTS50R &

DRS50R and the display. This Signal Repeater logic supports up to 50ft copper based

DVI/HDMI cables.

3. Compact and Robust Module Design.

4. Long distance (Up to 200ft at 1080i or lower signal) over cost effective RJ45 (CAT5/e/6)

cables.

5. Full EDID Management

1) Built-in EDID library

Choose one from 14 pre-saved most widely used EDID (Rotary switch)

2) EDID Emulation

Saving/Emulating display’s EDID in the DTS50R transmitter module enhances reliability

and compatibility with various displays.

6. HDCP (High-bandwidth Digital Content Protection) Support.

7. DDWG DVI 1.0

Installation and Connection Instructions

1. Turn off both the video source and the display before connecting any cables.

2. Connect DVI, 3.5mm stereo audio, RS-232 and IR cables between the source and DTS50R

AND between the DRS50R and the display.

3. Cable Connection:

CAT5 Cable: DTS50R/DRS50R was designed to conform to TIA/EIA-568-B Standard.

Please ensure that each PIN layout of DTS50R/DRS50R is corresponding with the picture

below before connecting the cable. Please note that CAT5e or above level cable enables to

deliver better video quality and longer distance.

1. AV PIN MAP 2. CONTROL PIN MAP

TIA/EIA-568B

Signal

Wire color

Digital RGB

Orange/ White

RS-232C_TXD

Orange

GND

Green/ White

RS-232C_RXD

Blue

IR Out

Blue/ White

GND

Green

GND

Brown/ White

IR In

Brown

GND

TIA/EIA-568B

Signal

Wire color

Digital RGB

Orange/ White

TMDS Data2+

Orange

TMDS Data2-

Green/ White

TMDS Data1+

Blue

TMDS Data0+

Blue/ White

TMDS Data0-

Green

TMDS Data1-

Brown/ White

TMDS Clock+

Brown

TMDS Clock-

4. Connect the power supply unit to both DTS50R AND the DRS50R units.

5. Turn on Display

6. Turn on Video Source

Cable Termination

IR cable

DTS50R/DRS50R supports both 5V and 12V and it can be selected by IR voltage

switch on the side of the unit. Please choose the voltage that IR cable requires.

(Factory default is 5V)

Please refer below for the IR cable termination;

RS-232 cable

Please refer below for the RS-232C cable termination;

DTS50R/DRS50R Specification

Dimensions: 4.3x3.1x1.6(inches) 110x78x40(mm)

DTS50R: Transmitter Module

DRS50R: Receiver Module

Front Panel:

PWR: Power LED indicator

ST: Status LED indicator

MODE: EDID library rotary switch

EDID S/W: EDID save button

Side Panel:

IR voltage: 5V / 12V select switch

Rear Panel:

DVI IN, OUT: DVI-D Input/output port

Audio IN, OUT: 3.5mm stereo Input/output port

CONTROL, AV: CAT5 connection ports

IR: IR signal Input/output port

RS232C: RS-232 signal Input/output port

DC 12V: Power input port

Operating Instruction

EDID library

: Use MODE rotary switch on the front panel of DTS50R to select EDID to use.

EDID library list;

0- External EDID

1-800x600 60Hz , 2-1024x768 60Hz , 3-1280x768 60Hz ,4-1280x1024 60Hz

5-1360x768 60Hz ,6-1366x768 60Hz , 7-1400x1050 60Hz , 8-1600x900 60Hz

9-1600x1200 60Hz , A-1680x1050 60Hz ,B-1920x1200 60Hz , C-HD1080i 60Hz

D-HD1080p (2CH) , E-HD1080p(Multi)

External EDID;

Connect display device to DTS50R’s DVI port and then press EDID S/W button.

It will copy and save display’s EDID information to DTS50R’s EEPRom.
