PureLink DCE II Manual de usuario

DCE II Owner’s Manual

DVI over CATx Extension Module

PureLinkTM

535 East Crescent Ave

Ramsey, NJ 07446

Tel: 201.488.3232

Fax: 201.621.6118

Website : www.purelinkav.com

E-mail : info@purelinkav.com

For Technical Support, contact us at

: support@purelinkav.com

PureLink by Dtrovision

Package Contents

Please make sure all of the following items are included in the package:

1 x DCE II Transmitter Module

1 x DCE II Receiver Module

1 x User Manual

Description

The PureLink DCE II is a transmitter and receiver set for long distance extension of DVI

video signal over single CAT 5/6/7- type cable. It is designed on PureLink’s proprietary

CATx extension technology which allows signal extension up to 165 ft (50m) at 1920 x

1200 @60Hz or 1080p. A compact and low profile enclosure makes the DCE II ideal for

extending DVI video to limited space environment such as behind a flat-panel display.

Features

Zero loss & Zero noise delivery of digital high definition video and audio signal

using UTP connection, DCE II delivers HD signals over CAT5/6/7-type cables

without loss or digital interference maintaining the clarity and colors. Noise

cancellation and error correction logic enhances DVI video signal over long

distance.

Compact and Robust enclosure design allows for discreet installation behind a

flat-panel display.

Uncompressed high definition video up 1920 x 1200@60Hz and 1080p@60Hz.

Video Bandwidth –1.65 Gbps.

No external power required. –If transmitter receives 5V from the source device,

you do not need external power.

Built-in micro USB port on the transmitter for external power just in case DVI

source does not provide enough power. (PSU is not included)

LED signal indicator

1920 x 1200@60Hz & 1080p EDID pre-built in to the transmitter

DCE II does not support HDCP

PureLink by Dtrovision

Product application note

Figure 1 –Schematic Connection Diagram of DCE II Tx/Rx

Product Specification

Transmitter

Model

DCE II Tx

Input type

DVI-D, 1 port

Micro USB, 1 port

Output type

CATx, 1 port

Supporting Display

Resolutions

VGA ~ WUXGA (up to 1920 x 1200 @ 60Hz),

480i ~ 1080p@60Hz

Max. Distance

1920x1200 @ 60Hz or 1080p@60Hz: 165ft (50m)

Conformations

DVI version 1.0

Power Rating

DC 5V , 1A

Power Consumption

320mA

Dimension (WxDxH)

1.6’’ x 2.2’’ x 0.9’’ (40.2 x 55.5 x 22.5 mm)

Weight

0.08 lbs (35 g)

Factory default EDID table

1024 x 768 @ 60Hz

1280 x 720 @ 60Hz

1280 x 800 @ 60Hz

1280 x 960 @ 60Hz

1280 x 1024 @ 60Hz

1440 x 900 @ 60Hz

PureLink by Dtrovision

1600 x 900 @ 60Hz

1600 x 1200 @ 60Hz

1680 x 1050 @ 60Hz

1920 x 1080 @ 60Hz

1920 x 1200 @ 60Hz

Receiver

Model

DCE II Rx

Input type

CATx, 1 port

Output type

DVI-D, 1 port

Micro USB, 1 port

Supporting Display

Resolutions

VGA ~ WUXGA (up to 1920 x 1200 @ 60Hz),

480i ~ 1080p@60Hz

Max. Distance

1920x1200 @ 60Hz or 1080p@60Hz: 165ft (50m)

Conformations

DVI version 1.0

Power Rating

DC 5V , 1A

Power Consumption

320mA

Dimension (WxDxH)

1.6’’ x 2.2’’ x 0.9’’ (40.2 x 55.5 x 22.5 mm)

Weight

0.08 lbs (35 g)

PureLink by Dtrovision

Operation and Reliability Specification

1. Operating Environment

Temperature : 32F ~ 131F (0℃~ 55℃)

Humidity : 10% ~ 80%

Altitude : 3,000m Max.

2. Transit Environment

Temperature : -13F ~ 140F (-25℃~ 60℃)

Humidity : 5% ~ 95%

Altitude : 15,000m Max.

3. Storage Environment

Temperature : -4F ~ 185F (-20℃~ 85℃)

Humidity : 5% ~ 95%

Altitude : 3,000m Max.

4. Reliability

MTBF: 90% at over 50,000 hours aging test

In compliance with LCD Monitor reliability test standard

PureLink by Dtrovision

Installation and Connection Instructions

1. Turn off both the video source and the display before connecting any cables.

2. Connect CATx cable between the DCE II transmitter and the DCE II receiver.

3. Connect DVI cable between the source and the DCE II transmitter and the DCE II

receiver and the display.

4. Connect the power supply unit to DCE II transmitter (only if video source does

not output enough power to the transmitter).

5. Turn on Display.

6. Turn on Video Source.

How to terminate CATx cable

DCE II was designed to conform to TIA/EIA-568-B standard. Please ensure that each PIN

layout of DCE II transmitter and DCE II receiver are corresponding with the picture

below before connecting the cable. Please note that CAT5e or above level cable enables

to deliver better video quality and longer distance.

CATx cable

Link cable recommend use high quality CAT5e, CAT6, CAT6a, CAT7 UTP / STP or FTP

cable.

Wire color

Digital RGB

Orange/ White

TMDS DATA2 +

Orange

TMDS DATA2 -

Green/ White

TMDS CLOCK +

Blue

TMDS DATA1 +

Blue/ White

TMDS DATA1 -

Green

TMDS CLOCK -

Brown/ White

TMDS DATA0 +

Brown

TMDS DATA0 -

PureLink by Dtrovision

Transmission Distance

The maximum transmission distance up to 165ft (50 meters) at 1920x1200@60Hz or

1080p@60Hz.

If connection through the wall socket, the cable length must less 5 meters between DVI

extender and wall jack, as below drawing:

PureLink by Dtrovision

Chapter 3. Additional Information

3.1 Manufacturer’s Warranty (3-Years)

PureLink warrants this DCEII Tx/Rx extender to be free from defects in workmanship

and materials, under normal use and service, for a period of three (3) years from the

date of purchase from PureLink or its authorized resellers.

If the product does not operate as warranted during the applicable warranty period,

PureLink shall, at its option and expense, execute one of the following as necessary:

1. Repair the defective product or part

2. Deliver to customer and equivalent product or part to replace the defective

item

3. Refund to customer the purchase price paid for the defective product

All products that are replaced become the property of PureLink. Replacement

products may be new or reconditioned. Repaired or replacement products or parts

come with a 90-day warranty or the remainder of the warranty period. PureLink

shall not be responsible for any software, firmware, information, or memory data

loss of contained in, stored on, or integrated with any products returned to PureLink

for repair under warranty.

3.2 Customer Service

Any customer service inquiries can be submitted electronically through the Q&A

form on our website ( www.purelinkav.com ).

For immediate assistance please contact us at (201) 488-3232 to reach our customer

care or tech support team.

PureLink by Dtrovision

FCC/CE Statement

This device complies with part 15 of FCC Rules and EN 55022/55024/61000-3 for CE

certification. Operation is subject to the following two conditions: (1) this device may

not cause harmful interference, and (2) this device must not accept any interference

received, including interference that may cause undesired operation. This equipment

has been tested and found to comply with the limits for a Class A digital device,

pursuant to part 15 and 2 of FCC Rules and EN 55022/55024/61000-3 for CE

certification. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy and. if not installed

and used in accordance with the instruction guide, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur

in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

Re-orient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult a service representative for help.

Properly shielded and grounded cables and connectors must be used in order to comply

with FCC/CE emission limits. Changes or modifications not expressly approved by the

party responsible for compliance could void the user s authority to operate the

equipment.
