Pulsar 7T92 Manual de usuario
CAL. 7T92 & YM92
CHRONOGRAPH
ENGLISH
TIME/CALENDAR
●Hour, minute and small second hands
●Date displayed in numerals
STOPWATCH
●Measures up to 12 hours in 1/20 second increments.
●Split time measurement
English
2
6
DISPLAY AND CROWN/BUTTONS
c: Second clickb: First click
a: Normal position
Hour hand
A
B
Date
CROWN
a b c
Small second
hand
STOPWATCH hour hand
Minute hand
STOPWATCH minute hand
STOPWATCH
1/20-second hand
STOPWATCH
second hand
English
3
SCREW DOWN CROWN
[for models with screw down crown]
Locking the crown
1Turn Crown counterclockwise until you no
longer feel the threads turning.
2Crown can be pulled out.
1Push Crown back in to normal position.
2TurnCrownclockwisewhilepressingitlightly
until tight.
Unlocking the crown
English
4
SETTING THE TIME AND
ADJUSTING THE STOPWATCH HAND POSITION
●This watch is so designed that:
1) time setting and
2) stopwatch hand position adjustment
are both made with the crown at the second click position. Once the crown is
pulled out to the second click, be sure to make the above adjustments at the same
time.
Pull out to second click when the second hand is at the 12
o’clock position.
CROWN
English
5
6
1) TIME SETTING
Hour hand Minute hand
Small second hand
2) STOPWATCH HAND POSITION ADJUSTMENT
●If the STOPWATCH hands are not in the “0” position, follow the procedure below
to set them to the “0” position.
* It is recommended that the hands be set to the time a few minutes ahead of the
current time, taking into consideration the time required to adjust the STOPWATCH
hand position if necessary.
Turn to set the hour
and minute hands.
CROWN
English
6
6
A
●Selection of the hand(s) to be adjusted can be made in the
following order by pressing button A for 2 seconds.
STOPWATCH
1/20-second hand
STOPWATCH
second hand
▲
▲
▲
STOPWATCH
hour and minute
hands
* The selected hand(s) turn(s) a full circle.
▲
STOPWATCH
minute hand
Press for 2 seconds to select the STOPWATCH hand(s) to be
adjusted.
▲
A
B
STOPWATCH
hour hand
STOPWATCH
second hand
STOPWATCH
1/20-second hand
English
7
BPress repeatedly to set the selected STOPWATCH hand(s) to the
“0” position.
▲
* The hand(s) move(s) quickly if button B is kept pressed.
* After all the adjustments are completed, check that the hour and minute
hands for time display indicate the current time.
▲
▲
Push back in to normal position in accordance with a time
signal.
CROWN
English
8
6
1Pull out to first click.
2Turn clockwise until the desired
date appears.
3Push back in to normal position.
CROWN
SETTING THE DATE
●Before setting the date, be sure to set the time.
Date
➠
➠
English
9
STOPWATCH
●The stopwatch can measure up to 12 hours in 1/20-second increments.
●When the measurement reaches 12 hours, the stopwatch automatically stops
counting.
Ex.: 2 hours, 30 minutes and 10.85 seconds
AStart / Stop / Restart
BReset /
Split /Split release
STOPWATCH hour hand
STOPWATCH minute hand
STOPWATCH
1/20-second hand
STOPWATCH
second hand
English
10
Movement of the STOPWATCH 1/20-second hand
●After the stopwatch is started, the STOPWATCH 1/20-second hand moves for
about 10 minutes and automatically stops at the “0” position.
●When the measurement is stopped or split time is measured, it moves to
indicate the elapsed 1/20 seconds.
●After the stopwatch is restarted or split time is released, the STOPWATCH 1/
20-second hand moves for about 10 minutes and stops automatically.
●In the same manner, if the stopwatch is stopped and restarted repeatedly or
split time is measured and released repeatedly, the STOPWATCH 1/20-
second hand moves for about 10 minutes and stops automatically.
●Before using the stopwatch, be sure to check that the crown is set at the normal
position and that the STOPWATCH hands are reset to the “0” position.
* If the STOPWATCH hands do not return to the “0” position when the stopwatch
is reset to “0”, follow the procedure in “SETTING THE TIME AND ADJUSTING
THE STOPWATCH HAND POSITION”.
