Pulsar Axion 2 LRF Manual de usuario
Axion 2 LRF
Manual
Content
Specifications
About the device
Description
Package Contents
Features
Components and Controls
Power supply
Precautions
Recommendations for Battery Use
Battery Charging
Battery Installation
External Power Supply
Getting Started
Powering on and Image Settings
Button Operation
Interface
Status Bar
Quick Menu
Main Menu
Enter the Main Menu
Colour Modes
Smoothing Filter
User Mode
Icon Brightness
PiP Mode
Wi-Fi Activation
Wi-Fi Settings
Microphone
Rangefinder
Calibration Mode
General Settings
Defective Pixel Repair
Defective Pixel Repair
Restore Default Pixel Map
Device Information
Functions
Amplification Level
Video Recording and Photography
Laser Rangefinder
Discrete Digital Zoom
PiP Function
Display-Off Function
Wi-Fi Function
Installing the Device on a Tripod
USB Connection
Software
Stream Vision 2
Firmware Update
Maintenance
Technical Inspection
Technical Maintenance and Storage
Troubleshooting
Legal Compliances and Disclaimers
Specifications
XQ35
Model XQ35
SKU 77479
Microbolometer
Type uncooled
Resolution, Pixels 384x288
Pixel Pitch, µm 17
Frame Rate, Hz 50
Optical Characteristics
Optical Magnification, x 2
Smooth Digital Zoom 2-8
Digital Zoom, x x1, x2, x4
Lens Focus, mm 35
Relative Aperture, D/f' 1.0
Minimum Focus Distance, m/y 5 / 5.47
Eye Relief Diameter, mm/inch 4 / 0.16
Angular Field of View
(Horizontal x Vertical), degree 10.7х8
Linear Field of View, m at 100
m18.2
Eyepiece Focus Range, Dioptre +4 / -5
Detection Distance for Deer-
Sized Objects, m/y 1300 / 1422
Display
Type AMOLED
Resolution, Pixels 640x400
Operational Characteristics
Power Supply, V 3 - 4.2
Battery Type/Capacity/Nominal
Output Voltage APS 5 Li-ion Battery Pack /
4900 mAh / DC 3.7 V
External Power Supply 5 V, 9 V (USB Type-C)
Battery Run Time at t=22°C,
hours* 11
Degree of Protection, IP Code
(IEC60529) IPX7
Operating Temperature Range,
°C / °F -25 … +40 / -13 – +104
Dimensions, mm/inch 152x74x75 / 5.98x2.91x2.95
Weight (without battery), kg/oz 0.35 / 12.34
Video Recorder
Photo/Video Resolution, Pixels 528x400
Video/Photo Format .mp4 / .jpg
Built-in Memory 16 GB
Wi-Fi Channel**
Frequency 2.4/5 GHz
Standard IEEE 802.11 b/g/n/ac
Characteristics of the
Rangefinder
Wavelength, nm 905
Measurement Range, m/y*** 1000/1094
Measurement Accuracy, m 1
* Actual battery life may vary depending on the use of Wi-Fi and the built-in
video recorder.
** Reception range may vary depending on various factors: obstacles, other
Wi-Fi networks.
*** Depends on the characteristics of the object under observation and
environmental conditions.
XG35
Model XG35
SKU 77477
Microbolometer
Type uncooled
Resolution, Pixels 640x480
Pixel Pitch, µm 12
Frame Rate, Hz 50
Optical Characteristics
Optical Magnification, x 2.5
Smooth Digital Zoom 2.5-20
Digital Zoom, x x1, x2, x4, x8
Lens Focus, mm 35
Relative Aperture, D/f' 1.0
Minimum Focus Distance, m/y 5 / 5.5
Eye Relief Diameter, mm/inch 4 / 0.16
Angular Field of View
(Horizontal x Vertical), degree 12.5х9.4
Linear Field of View, m at 100
m21.9
Eyepiece Focus Range, Dioptre +4 / -5
Detection Distance for Deer-
Sized Objects, m/y 1750 / 1914
Display
Type AMOLED
Resolution, Pixels 1024x768
Operational Characteristics
Power Supply, V 3 - 4.2
Battery Type/Capacity/Nominal
Output Voltage APS 5 Li-ion Battery Pack /
4900 mAh / DC 3.7 V
External Power Supply 5 V, 9 V (USB Type-C)
Battery Run Time at t=22°C,
hours* 7
Degree of Protection, IP Code
(IEC60529) IPX7
Operating Temperature Range,
°C / °F -25 … +40 / -13 – +104
Dimensions, mm/inch 152x74x75 / 5.98x2.91x2.95
Weight (without battery), kg/oz 0.35 / 12.34
Video Recorder
Photo/Video Resolution, Pixels 1024x768
Video/Photo Format .mp4 / .jpg
Built-in Memory 16 GB
Wi-Fi Channel**
Frequency 2.4/5 GHz
Standard IEEE 802.11 b/g/n/ac
Characteristics of the
Rangefinder
Wavelength, nm 905
Measurement Range, m/y*** 1000/1094
Measurement Accuracy, m 1
* Actual battery life may vary depending on the use of Wi-Fi and the built-in
video recorder.
** Reception range may vary depending on various factors: obstacles, other
Wi-Fi networks.
*** Depends on the characteristics of the object under observation and
environmental conditions.
