Pulsar Krypton 2 XQ35 Manual de usuario

Manual Krypton 2 XQ/XG

Specifications

You can learn more about the main parameters here.

Model

XQ35

XG50

SKU

77374

77376

Microbolometer

Type

Uncooled

Resolution, Pixels

384x288

640x480

Pixel Pitch, µm

NETD, mK

< 25

< 40

Frame Rate, Hz

Optical

Characteristics

Monocular

magnification, x

Recommended

Daylight Optics

Magnification, x

2-6

Lens

F35/1.0

F50/1.0

Field-of-view

(Horizontal), deg/m

per 100 m

10.7/18.7

8.8/15.4

Detection Range

(animal height 1.7 m),

m/y

1300/1422

2300/2515

Minimum Focusing

Distance, m/y

5/5.5

Display

Type

AMOLED

Resolution, Pixels

1920x1080

Operational

Characteristics

Power Supply, V

3-4.2

Battery type/ Capacity/

Rated Output Voltage

Li-Ion Battery Pack IPS 7 / 6400 mAh / DC 3.7 V

External Power Supply

5 V (USB Type-C)

Max. Battery Pack Life

(at t = 22 °C), Hour*

Degree of protection

IP code (IEC60529)

IPX7

Compatible Pulsar

adapters

PSP-42, PSP-50, PSP-56, PSP-30B, PSP-42B,

PSP-50B, PSP-56B

Operating

temperature, °C / °F

-25 –+50 / -13 –+122

Overall Dimensions,

mm/inch

201x73x83 /

7.9x2.9x3.3

217x78x84 /

8.5x3.1x3.3

Weight (with Battery),

kg/oz

0.54 / 19

0.58 / 20.5

Video Recorder

Photo/Video

Resolution, Pixels

1244x934

Video/Photo Format

.mp4/.jpg

Built-in Memory

eMMC 16 GB

Wi-Fi Channel**

Frequency

2.4/5 GHz

Standard

IEEE 802.11 b/g/n/ac (WPA)

* Actual operating time will depend to what extent the Wi-Fi and built-in video

recorder is used.

** The reception range may vary depending on various factors: obstacles,

other Wi-Fi networks.

About the device

Description

The Krypton 2 thermal imager is designed for a variety of applications,

including hunting surveillance, security activities, day and night photo and

video shooting.

The Krypton 2 thermal imaging module can be mounted (using the correct

Ring Adapter) on to the objective lens housing of various daylight optical

devices, converting them into a highly-sensitive thermal imaging device.

To get started, see the sections:

Battery Charging

Battery Installation

Installing the Monocular on to the Thermal Imaging Module

Mounting the Adapter on the Device

Mounting the Thermal Imaging Module on the Adapter

Powering on and Image Setting

Stream Vision 2

Package Contents

•Thermal Imager

•Pulsar 3x20 B Monocular

•Single-point neck strap

•Carrying Case

•Wireless Remote Control

•IPS7 Battery Pack

•Battery Pack Charger

•Power Adapter

•USB Type-C cable with USB Type-A adapter

•USB Type-C to MicroUSB Type-B adapter

•Quick Start Guide

•Lens-Cleaning Cloth

•Warranty Card

•Allen Key S3

Components and Controls

1. Lens cover

2. Eyepiece cover

3. Battery locking lever

4. Battery pack

5. UP/REC button

6. MENU button

7. DOWN/MODE button

8. ON/OFF/Calibration button

9. Lens focus knob

10.USB Type-C port

11.Objective lens end of daylight optical device*

12.Insert**

13.Adapter**

14.Screw**

15.Tightening screw**

16.Screw**

17.Adapter lever**

18.Mount**

*Not included in the package contents

**Items of PSP B Ring Adapter (available separately)

Features

•Easily converts daylight optical devices into thermal imaging devices

•Preserves the benefits of daylight optics in night-time conditions

•Three calibration modes (manual, semi-automatic and automatic)

•3 levels of sensitivity enhancement: Normal, High, Ultra

•Compatible with a wide range of daylight optical magnifications

•Wireless remote control

•Instant start

•Display off function

•Built-in video recording

•Remote Firmware update

•Fully watertight (IPX7 protection class)

•Wide operating temperature range (-25 °С –+50°С)

Video/audio recording

•Built-in video recorder

•Integration with iOS and Android devices

•Wi-Fi Smartphone remote control and surveillance

•Storing photos and videos in Cloud when using the Stream Vision 2 App

Battery Pack

•Quick-change IPS7 Li-ion battery pack

•Charging via USB Type-C port

Power supply

Precautions

•Always use the IPS charger supplied with the device (or purchased

separately) to charge IPS batteries. Using an unsuitable charger can cause

irreparable damage to the battery and fire.

•Do not charge the battery immediately after bringing it from cold to warm. Wait

at least 30 minutes for the battery to warm up.

•Do not leave the battery unattended while charging.

•Do not use the charger if it has been modified or damaged.

•Do not leave the battery in a charger connected to the network after charging

is complete.

•Do not expose the battery to high temperatures and naked flame.

•Do not use the battery as a power source for devices that do not support IPS7

batteries.

•Do not disassemble or deform the battery.

•Do not drop or strike the battery.

•Do not submerge the battery.

•Keep the battery out of the reach of children.

Attention! Please do not use the IPS 14 Battery Pack with the Krypton 2

FXQ35/FXG50 due to the battery´s heavy weight.

Recommendations for Battery Use

•The battery should be partially charged for long-term storage –50 to 80 %.

•The battery should be charged at an ambient temperature of 0 °C…+35 °C

(+32 °F…+95° F). Otherwise, lifespan of the battery will decrease significantly.

•When using the battery at sub-zero temperatures, the battery capacity

decreases, this is normal and not a defect.

•Do not use the battery at temperatures outside the range of -25 °С...+50 °С (-

13 °F…+122 °F) – this may reduce battery’s life.

•The battery has a short-circuit protection. However, any situation that may

cause short-circuiting should be avoided.

Battery Charging

The device is supplied with a rechargeable IPS7 Lithium-ion Battery Pack

which allows the device to be used for up to 11 hours. Charge the battery

before first use.

The icon in the status bar will flash when the battery is low. The battery

needs to be charged.

Option 1

1. Install the IPS7 battery (4) in the battery compartment of the device.

2. Connect the USB Type-C cable (20) to the USB Type-C connector (10) of the

device.

3. Connect the other end of the USB cable (20) to the Power Adapter (21) by

removing the USB Type-A adapter.

4. Plug the Power Adapter (21) into a 100-240 V socket.

5. Wait until the battery is fully charged (indication in the status bar: ).

If the device is off, the LED indicator will display the battery charge

status:

LED indication

Battery status

Battery is charging

Battery is charged

Defective battery. Do not use the

battery!

The device is switched on

Option 2

Charging

Step 1. Install the battery into the charger

1. Move the lever (3) to the open position .

2. Install the Battery Pack (4) into the charger.

3. Lock the battery (4) by moving the lever to the closed position .

Step 2. Сheck the current battery level
