PSC QS200 Manual del propietario

QS200

Programming Manual

v 2.1

Handheld Scanner

PSC Inc

959 Terry Street

Eugene, Oregon 97402

Telephone: (541) 683-5700

Fax: (541) 345-7140

produced or transmitted in any form or by any means without prior written permission of PSC Inc. Owners of

PSC Inc.'s products are hereby granted non-exclusive, revocable license to reproduce and transmit this docu

mentation for the purchaser's own internal business purposes.Purchasershall notremove oralter any propri

etary notices, including copyright notices, contained on this documentation and shallensure that all notices

appear on any reproductions of the documentation.

Should future revisions of this manual be published, you can acquire printed versions by contacting PSC Cu

tomerAdministration.Electronicversions willeitherbedownloadablefromthePSCwebsite(www.pscnet.co

or provided on appropriate media. If youvisit our web site andwould like to make comments or suggestions

about this or other PSC publications, please let us know viathe “Contact PSC” page.

Disclaimer

Reasonable measures have been taken to ensure that the information included in this

manual is complete and accurate. However, PSC reserves the right to change any

specification at any time without prior notice.

PSC and the PSC logo are registered trademarks of PSC Inc. All other trademarks and trade names referred

herein are property of their respective owners.

This manual is copyrighted by Adascan and reprinted with permission by PSC, Inc.

TABLE OF CONTENTS

Introduction

FlowChart 1

Interfaces 2

On/OffSymbologies 3

Code 39 7

Codabar/NW7 8

Interleaved 2/5 9

Standard 2/5 11

Matrix2/5 12

EAN-13/EAN-8 13

UPC-A/UPC-E 14

CHINESE POSTAL 2/5 15

Reading Modes 16

General Parameters 17

Keyboard Parameters 20

Terminal Type 21

Function Key Setting 23

Function Key Table 24

Function Key Labels 25

Languages 27



RS232 Parameters 28

CCD Wand Emulation 31

OCIA Types 32

Magnetic Setting 33

Code Mark 34

Truncate Digits 36

ASCII Table 38

Hexadecimal Labels 39

Pinout Assignments 40

Notes:

1. Options marked by { } are

only available for some models.

2. Factory default values are

indicated by



3. All references to numbers in this

menu are in Decimal, but you

MUST input it as Hexadecimal.



INTRODUCTION

Bar Code devices provide an

accurate, easy, and fast

method of data entry and data

storage for computerized

information systems.

The products we are offering

now can be integrated into any

host computer system by the

following ways:

Keyboard emulation

Wand emulation

RS-232C serial asynchronous

Dual RS-232C

RS-422

RS-485

Parallel

OCIA

OTHERS

All the operating parameters

are programmed by bar code

programming menu and stored

in non-volatile RAM which

can retain the settings

after power is turned off.

For the functions which are

not listed in this menu,

please consult your supplier

for more details.

those to reprint this manual.



-1- FLOWCHART

START OF CONFIGURATION

ABORT CONFIGURATION *

SELECT INTERFACES

SELECT SYMBOLOGIES

OPERATION PARAMETERS



END OF CONFIGURATION **

SET FACTORY DEFAULTS **







SHOW VERSION



* Reject new settings & end.

** Accept new settings & end.



INTERFACES - 2 -



KEYBOARD



RS232C



CCD WAND EMULATION



{OCIA}



RESERVED 1



RESERVED 2

To choose an Interface,

e.g. KEYBOARD:

1. Scan START OF CONFIGURATION

2. Scan KEYBOARD

3. Scan END OF CONFIGURATION



- 3 - SYMBOLOGIES

CODE 39



OFF 





INTERLEAVED 2 OF 5





OFF





STANDARD 2 OF 5





OFF





MATRIX 2 OF 5





OFF





CODABAR



OFF 







SYMBOLOGIES - 4 -

EAN-8



OFF 





EAN-13/UPC-A



OFF 





UPC-E



OFF 





ISBN/ISSN





OFF





EAN/UPC ADDON 2/5





OFF







- 5 - SYMBOLOGIES

CODE 128



OFF 





CODE 93





OFF





CHINESE 2 OF 5





OFF





{MSI/PLESSEY}





OFF





{CODE 11}





OFF




