Provision ISR I2-320A-28 Manual de usuario

1080P Pro HD Analog Series

USER MANUAL

1080P Pro HD Analog Series

Contents

1) Cautions:

2 ) Product Introduction

2.1 Camera Introduction

2.2 Product Features

Menu Setup

4) Product Installation

Technical Specification

4.1 General Notes

4.2 Installation Tools and Information

4.3 Installation Method

4.4 Setting the video output type

4.5

4.7

Setting the Camera

OSD Control

4.6Connection

2 3

1 Cautions:

1. To reduce the risk of electric shock, do not open the

camera or perform internal maintainance by yourself.

Please consult a professional service person if needed.

2. To prevent fire or electrical shock hazard, make sure

that the input voltage, current, polarity and operating

temperature meet the requirements of the camera.

3. Please note the operating temperature and environ-

mental limits of the camera. Do not install in higher/low-

er temperatures than -20°C~+50°C (-4°F~122°F).

These cameras are not waterproof! Minimize dust and

moisture erosion, otherwise camera would be damaged.

4. Avoid directing the camera to sunlight while powered

on, otherwise the sensor will be damaged.

5. Do not touch the sensor surface. If any foreign objects

exists use a cotton swab or lens paper to clean. if it is

difficult to remove, use a neutral detergent diluted with

water.

6. In order to ensure smooth and satisfactory image,

the power and video cables shouldn’t be too long.

Please follow general AHD/Analog sepcifications for

cables types and lenghts.

7. In order to prevent the camera from falling, please

install the camera on a stable surface.

8. The camera should not be placed near a radiator or

heating resistor.

4 5

2 Product Introduction

2.1 Camera Introduction

PROVISION-ISR’s new series of cameras have

adopted a high performance CMOS image sensor

which provides HD resolution and supports high

resolution video output. The cameras support video

transmission distance of around 400M base on Rg59

standard coaxial cable. This series can support AHD/

TVI/CVI/CVBS 960H analog output.

2.2 Product Features

● Coaxial Cable with BNC Connector

● DIP Switch

● Auto Day/Night (ICR)

● BLC / HLC

● 2D/3D NR

● AHD/TVI/CVI/CVBS Signal Selectable (by jumper)

3 Menu Setup

AHD/TVI: Click on “Iris+” button from the DVR’s PTZ

interface to call the OSD Menu. Use the PTZ interface to

scroll through the menu and “Iris+” to confirm.

CVI: Click “

►” button from the DVR’s PTZ interface, then

click “ ” and press “Enter” to call the OSD Menu.

4 Product Installation

4.1 General Notes

1. Make sure the unit is powered off before installation.

2. Check that power supply voltage complies with the

camera requirement to prevent damage to the camera.

3. The installation and maintenance of this product

should be done by a professional. Please do not remove

or modify the camera in any way.

6 7

4.2 Installation Tools and Information:

Prepare the required tools and instructions. Before

installation please prepare the following tools:

A straight or a Phillips-head screwdriver, multi-meter,

cutter, needle nose pliers, measuring tape, pencil.

4.3 Installation Method:

1. Check the camera for any external damage.

2. Mount the bracket or base:

① For cement wall, install the expansion screws, and

then mount the bracket/base.

② For wooden wall use self-tapping screws to mount.

4.4 Setting the video output type:

The camera supports AHD/TVI/CVI/CBVS video output,

And PAL/NTSC system is switable by setting a DIP

switch on the cable as illustrated:

The Default Setting is PAL + AHD

4.5. Setting the camera:

a. Dome Camera

Adjust the lens position so it aims at the main monitoring

point and gives a clear picture.

b. Bullet Camera

Adjust the body so that the lens aims at the main

monitoring point and gives a clear picture. Tighten the

screws to ensure that it does not move.

Note:

The wall needs to bear at least 3

times the weight of the camera.

8 9

4.6 Connection

Connection as shown in the figure below:

4.7 OSD Control

The OSD control is available by CoC (Control over

Coax). If your AHD/TVI/CVI DVR supports this

function*, use the DVR’s PTZ interface to press on

“Iris+” or “

” to open the OSD menu.

Navigate through the OSD menu using the PTZ

direction arrows.

* Notice: CoC function works no more than 200M by Rg59 coaxial cable

* All of Provision-ISR’s DVRs support CoC Starting from version 3.4.4

4.8 OSD Menu Scheme:

Main Menu Second Menu Third Menu

Brightness 0~100

Global / Center / BLC / FLC

ATW

Red Gain

Blue Gain

0~100

EXT

Color

B&W

Contrast

Sharpness

Manual

Auto

AWB Manuel

Grey Mode

Day / Night

Image Enhance

Manual

Auto

Saturate

Manual

Auto

3DNR

Manual

Auto

2DNR

Manual

10 11

5 Specifications:

2MP Pro HD Analog Series

Model

Image Sensor

Image Format

Effective Pixels

Scanning System

Resolution

FPS

Min. Illumination

D&N

IR LED

OSD Menu

CoC Support

Day & Night Mode

Backlight Compensation

S/N Ratio

White Balance

Noise Reduction

Video Output

Privacy Mask

D-Effect

WDR

Lens (Field Of View)

Power

Operation Temperature

Protection Rate

Dimensions

Net Weight

1/2.9" 2MP Sensor

16:9

1936x1096

Progressive

2MP: 1920x1080 AHD/TVI/CVI

1MP: 1280x720 AHD/TVI/CVI

CVBS: 700TVL

25/30FPS

Color: 0.005lux @F1.2, AGC ON B/W: 0lux with IR

True Day&Night-ICR

Available via CoC Only

Yes

Ext/Auto/Day/Night

≥52dB (AGC OFF)

Auto / Manual

3D-DNR

2MP / 1MP (Selected by OSD Menu)

AHD/TVI/CVI/CVBS + PAL/NTSC (Selected by DIP Switch)"

-30°C ~ 50°C, 10% ~ 90% humidity

IP67

I2-320A-28

1LED Array (20m)

2.8mm Fixed (88°)

DC12V/320mA

172.2*73.4*74.5mm

475g

I4-320A-VF

3LED Array (40m)

2.8-12mm VF (88°-33°)

DC12V/560mA

220.8*79.4*81.2mm

700g

Main Menu Second Menu Third Menu

HD AHD / CVI / TVI / CVBS

1080P@25 / 1080P@30

720P@25 / 720P@30

PAL/NTSC (For CVBS)

English

Video Settings

Language

Chinese

Reset

Standard

I4-320A-28

2LED Array (40m)

2.8mm Fixed (88°)

DC12V/470mA

220.8*79.4*81.2mm

645g

12 13

Model

Image Sensor

Image Format

Effective Pixels

Scanning System

Resolution

FPS

Min. Illumination

D&N

IR LED

OSD Menu

CoC Support

Day & Night Mode

Backlight Compensation

S/N Ratio

White Balance

Noise Reduction

Video Output

Privacy Mask

D-Effect

WDR

Lens (Field Of View)

Power

Operation Temperature

Protection Rate

Dimensions

Net Weight

1/2.9" 2MP Sensor

16:9

1936x1096

Progressive

2MP: 1920x1080 AHD/TVI/CVI

1MP: 1280x720 AHD/TVI/CVI

CVBS: 700TVL

25/30FPS

Color: 0.005lux @F1.2, AGC ON B/W: 0lux with IR

True Day&Night-ICR

Available via CoC Only

Yes

Ext/Auto/Day/Night

≥52dB (AGC OFF)

Auto / Manual

3D-DNR

2MP / 1MP (Selected by OSD Menu)

AHD/TVI/CVI/CVBS + PAL/NTSC (Selected by DIP Switch)"

-30°C ~ 50°C, 10% ~ 90% humidity

IP67

DI-320A-28

1LED Array (20m)

2.8mm Fixed (88°)

DC12V/270mA

Φ97*82.6mm

485g

DI-320A-VF

3LED Array (40m)

2.8-12mm VF (84°-32°)

DC12V/660mA

Φ113*99.6mm

695g
