USER’S

MANUAL

ForP5/6x86

EmbeddedBoard

With VGA/SOUND/LAN

ProX-1580

ProX-1580 P5/6x86 Embedded Board

With VGA / SOUND / LAN

OPERATION MANUAL

This operation manual is meant to assist both Embedded Computer manu-

facturers and end-users in installing and setting up the system. The infor-

mation contained in this document is subject to change without any prior

notice.

This manual is copyrighted June 2001. You may not reproduce or transmit in

any form or by any means, electronic, or mechanical, including photo-

copying and recording.

ACKNOWLEDGEMENTS

All trademarks and registered trademarks mentioned herein are the property

of their respective owners.

Contents

TABLE OF CONTENTS

CHAPTER 1 INTRODUCTION

1-1 About This Manual ....................................................... 1-2

1-2 System Specifications ................................................... 1-3

1-3 Safety Precautions ......................................................... 1-7

CHAPTER 2 HARDWARE CONFIGURATION

2-1 Jumper & Connector Quick Reference Table ............... 2-2

2-2 Component Locations ........................…....................... 2-3

2-3 How to Set the Jumpers ...........................................… 2-4

2-4 CPU type & Clock Selection ........................................ 2-6

2-4-1 Intel® 150/166 CPU type & Clock jumper settings .………… 2-6

2-4-2 Intel® 200/MMX-166 CPU type & Clock jumper settings ……. 2-7

2-4-3 Intel® MMX-200/233 CPU type & Clock jumper settings ….. 2-8

2-4-4 Intel® Tillamook 166/266 CPU type & Clock jumper settings .. 2-9

2-4-5 Cyrix 6x86 MX-233/266 CPU type & Clock jumper settings …. 2-10

2-4-6 Cyrix 6x86 MX-300/M2-300 CPU type & Clock jumper setting 2-11

2-4-7 AMD K6-200/233 CPU type & Clock jumper settings ………... 2-12

2-4-8 AMD K6-2-266/300 CPU type & Clock jumper settings ….... 2-13

2-4-9 AMD K6-2-333/350 CPU type & Clock jumper settings …… 2-14

2-4-10

AMD K6-2-366/380 CPU type & Clock jumper settings …… 2-15

2-4-11

AMD K6-2-400/450 CPU type & Clock jumper settings …… 2-16

2-4-12

AMD K6-2-450/500 CPU type & Clock jumper settings …… 2-17

2-4-13

AMD K6-2-500/550 CPU type & Clock jumper settings …… 2-18

2-4-14

AMD K6-3-400 CPU type & Clock jumper settings ………… 2-19

2-4-15

AMD K6-3-450 CPU type & Clock jumper settings ………… 2-20

2-4-16

AMD K6-3-500 CPU type & Clock jumper settings ………… 2-21

2-5 COM Port Connector .................................................... 2-22

2-6 RS232/422/485 (COM4) Selection ............................... 2-24

2-7 Keyboard Connector ………………............................. 2-25

2-8 PS/2 Mouse Connector ..........................……………… 2-25

2-9 Reset Connector ............................................................ 2-26

2-10 External Speaker Connector ………………………….. 2-26

2-11 Turbo LED …………………………………………… 2-26

2-12 CPUFAN Power Connector ………………………….. 2-27

2-13 SYSFAN Power Connector …………………………... 2-27

2-14 Hard Disk Drive LED Connector .................................. 2-27

2-15 Power Led & Keylock Connector ................................. 2-28

Contents

2-16 VGA CRT Connector ………………………………… 2-28

2-17 USB Connector …………………………………….. 2-29

2-18 Panel Power Connector ………………………………. 2-29

2-19 LCD VDD Selection …………………………………. 2-30

2-20 ATX Power Button …………………………………… 2-30

2-21 ATX Power Connector ……………………………….. 2-31

2-22 LAN Connector ………………………………………. 2-31

2-23 LAN Led Indicator ........................................................ 2-32

2-24 IrDA Connector …………………………………….... 2-32

2-25 LCD Panel Connector ………………………………… 2-33

2-26 Solid-State Disk Socket ………………………………. 2-34

2-27 SSD Memory Mapping Selection …………………….. 2-35

2-28 Floppy Disk Drive Connector ....................................... 2-36

2-29 Hard Disk Drive Connector .......................................... 2-37

2-30 Printer Connector .......................................................... 2-39

2-31 PCI or Riser Card Selection ………………………….. 2-41

2-32 Mono Connector ……………………………………… 2-41

2-33 CD Audio-in Connector ……………………………… 2-42

2-34 Sound Connector ………………….………………… 2-42

2-35 Reset/NMI/Clear Watchdog Selection ……………….. 2-43

2-36 Memory Installation ...................................................... 2-43

2-37 COM Port RI & Voltage Selection ..………………… 2-44

2-38 AT or ATX Power Selection …………………………. 2-45

CHAPTER 3 SOFTWARE UTILITIES

3-1 Introduction ................................................................... 3-2

3-2 VGA Driver Utility ....................................................... 3-2

3-3 Flash BIOS Update ....................................................... 3-5

3-4 LAN Driver Utility …................................................... 3-7

3-5 Sound Driver Utility ………………………………….. 3-9

3-6 Watchdog Timer Configuration .................................... 3-11

CHAPTER 4 GREEN PC FUNCTION

4-1 Power Saving Block Diagram ....................................... 4-2

4-2 CPU Doze Mode ........................................................... 4-2

4-3 System Standby Mode .................................................. 4-2

Contents

4-4 System Suspend Mode .................................................. 4-3

CHAPTER 5 AWARD BIOS SETUP

5-1 Introduction ................................................................... 5-2

5-2 Entering Setup ............................................................... 5-3

5-3 The Standard CMOS Setup Menu ................................ 5-4

5-4 The BIOS Features Setup Menu ................................... 5-9

5-5 Chipset Features Setup .................................................. 5-13

5-6 Power Management Setup ............................................ 5-17

5-7 PNP/PCI Configuration ................................................ 5-20

5-8 Load BIOS Defaults ...................................................... 5-22

5-9 Load Setup Defaults ...................................................... 5-22

5-10 Integrated Peripherals ................................................... 5-23

5-11 Password Setting ........................................................... 5-25

5-12 IDE HDD Auto Detection ............................................. 5-27

5-13 Save & Exit Setup ......................................................... 5-28

5-14 Exit Without Saving ...................................................... 5-29

APPENDIX A ADAPTER CARD

W-581-Sound Adapter Card ..................................................... A-2

APPENDIX B EXPANSION BUS

PC104 Connector Pin Assignment ........................................... B-2

PCI Bus Pin Assignment …..………………………………... B-3

APPENDIX C TECHNICAL SUMMARY

Block Diagram ......................................................................... C-2

Interrupt Map ............................................................................ C-3

RTC & CMOS RAM Map ....................................................... C-4

Timer & DMA Channels Map .................................................. C-5

I/O & Memory Map ................................................................. C-6

APPENDIX D TROUBLE SHOOTING

Trouble Shooting for Error Messages ...................................... D-2

Trouble Shooting for POST Codes .......................................... D-6

Page:1-1

INTRODUCTION

This chapter gives you the information for Prox-1580. It also

outlines the System specifications.

Section includes:

zAbout This Manual

zSystem Specifications

zSafety precautions

Experienced users can skip to chapter 2 on page 2-1

for a Quick Start.

CHAPTER

Chapter 1 Introduction

Page: 1-2 Prox-1580 USER

′

S MANUAL

1-1. ABOUT THIS MANUAL

Thank you for purchasing our Prox-1580 P5/6x86 Embedded Board with

VGA/Sound/LAN, which is fully PC / AT compatible. The Prox-1580

provides faster processing speed, greater expandability and can handle

more tasks than before. This manual is designed to assist you how to

install and set up the system. It contains five chapters. The user can apply

this manual for configuration according to the following chapters :

Chapter 1 Introduction

This chapter introduces you to the background of this manual, and the

specifications for this system. The final page of this chapter will indicate

how to avoid damaging this Embedded Board.

Chapter 2 Hardware Configuration

This chapter outlines the component locations and their functions. In the

end of this chapter, you will learn how to set jumper and how to configure

this card to meet your own needs.

Chapter 3 Software Utilities

This chapter contains helpful information for proper installations of the

VGA Utility, LAN Utility, Sound Utility, and Flash BIOS Update. It also

describes the Watchdog-timer configuration.

Chapter 4 Green PC Function

This chapter explains the Green PC functions concisely.

Chapter 5 Award BIOS Setup

This chapter indicates you how to set up the BIOS configurations.

Appendix A Adapter Card

This Appendix introduces you the sound adapter card.

Appendix B Expansion Bus

This Appendix introduces you the expansion bus for PCI and PC104

expansion bus.

Appendix C Technical Summary

This section gives you the information about the Technical maps.

Chapter 1 Introduction

Prox-1580 USER

′

S MANUAL Page: 1-3

Appendix D Trouble Shooting

This section outlines the error messages and offers you the methods to

solve the problems.

1-2. SYSTEM SPECIFICATIONS

zCPU :

Intel®, AMD, Cyrix processors.

54C/55C/MMX, K5/K6/K6-2/K6-3, M1/M2

320/321 pin PGA socket.

1.8/1.9/2.0/2.1/2.2/2.3/2.4/2.5/2.8/2.9/3.0/3.1/3.2/3.3/3.4/3.5V regulator.

zMEMORY :

Up to 256MB SDRAM

One 168pin DIMM socket on board.

zCACHE :

L1 Cache: Capacity depended on CPU type

L2 Cache: Onboard 512KB

zREAL-TIME CLOCK / CALENDAR :

CMOS data back up from BIOS set or BIOS default.

Dallas DS 12887 Real Time Clock.

zBIOS :

Award Flash BIOS for plug & play function.

Easy update 256KB flash EEPROM.

Support Green Function.

Support S/IO Setup.

zKEYBOARD CONNECTOR :

5-pin PC/At keyboard connector with mini DIN cable.

zMOUSE CONNECTOR :

PS/2 mouse connector with min DIN cable.

Chapter 1 Introduction

Page: 1-4 Prox-1580 USER

′

S MANUAL

zBUS SUPPORT :

Internal PCI Bus for VGA, LAN, Sound, & IDE.

One PCI Bus and PC104 Bus.

zDISPLAY :

Onboard C&T 69000 chipset, support SVGA for CRT & Panel.

Support 32bits PCI Local Bus.

VGA BIOS combines in 256KB flash ROM together with system BIOS.

Integrates 2 Mbytes of SDRAM for the graphics / video frame buffer.

Support 15-pin connector 1280 x 1024 (256 color) resolution on SVGA

Monitor.

Support 51-pin connector 640 x 480, 800 x 600, 1024 x 768 resolutions on

LCD Panel.

Panel Display support STN and TFT modes.

Support simultaneous display of CRT & LCD flat Panel.

zWATCHDOG :

I / O port 0443H to Enable watchdog.

I / O port 0441H to Disable watchdog.

Support Reset or NMI watchdog with jumper selection.

Time-out timing select 0 / 8 / 16 / 24 / 32 / 40 / 48 / 56 / 64 / 72 / 80 / 88 /

96 / 104 / 112 / 120 sec +/- 25%.

zIDE INTERFACE :

Two IDE ports, support Ultra DMA-33.

Two channel, support up to four devices.

zFLOPPY DISK DRIVER INTERFACE :

Support up to two Floppy Disk Drives, 3.5" and 5.25" (360K / 720K /

1.2M / 1.44M / 2.88M / LS-120).

zDISK-ON-CHIPS SOCKET :

A 32-pin SSD socket on board, supports up to 144MB Disk-on-chips.

zUSB CONNECTOR :

Universal Serial Bus Connector, supports up to two USB ports.

Chapter 1 Introduction

Prox-1580 USER

′

S MANUAL Page: 1-5

zLAN ADAPTER :

Realtek RTL8139 PCI Fast Ethernet

10/100 Base-T PCI-BUS

zINFRARED FUNCTION :

One Infrared port.

Support IrDA v.1.0 SIR protocol.

zSERIAL PORT :

Four high speed 16550 Compatible UARTs with Send / Receive 16 Byte

FIFOs; COM1/3/4 for RS-232; COM2 for RS-232/422/485.

MIDI Compatible.

Programmable Baud Rate Generator.

zPARALLEL PORT :

SPP, ECP, EPP Function.

Bi-directional parallel port.

zSOUND FUNCTION :

Enhance ESS 1938S (Solo-1, Single Chip PCI audio)

BUS: 32 bit PCI BUS

Stereo full duplex for playback and recording.

Software compatible: Windows 95/98, Windows NT 4.0

Sampling rate: Support from 4kHz up to 48kHz.

Power Management: ACPI 1.0 compliant

3D sound: Integrated Spatializer 3D sound software wavetable, general

MIDI and MPU-401 support.

Interface: MIC, SPK, Line-In, Gameport, CD Audio-in, and Mono.

zGREEN FUNCTION :

Software supported by BIOS setup.

Hardware supported by switch control.

zHARDWARE MONITORING FUNCTION :

Monitor CPU Voltage, CPU temperature, and Cooling Fan.

Tabla de contenidos

Otros manuales de Hardware de computadora de protech

protech

protech ProX-1680 Manual de usuario

protech

protech prox BE-U236 Manual de usuario

protech

protech PC-550 Manual de usuario

protech

protech EB-471 Manual de usuario

protech

protech PC-560-G5 Manual de usuario

protech

protech PC-420 Manual de usuario

protech

protech PCI-531LF Manual de usuario

protech

protech BM-0972 Manual de usuario

protech

protech Celeron EB-471LF M1 Manual de usuario

protech

protech Prox-1260 M4 Manual de usuario

protech

protech ProX-1215 Manual de usuario

protech

protech ST-1942 Manual de usuario

protech

protech BM-0982 Manual de usuario

protech

protech ProX-1695 Manual de usuario

protech

protech ProX-1690 Manual de usuario

protech

protech Prox SE-8124 Manual de usuario

protech

protech SA-5082 Manual de usuario

protech

protech BE-0961 Manual de usuario

protech

protech ProX-1520 M1 Manual de usuario

protech

protech ProX-1230 Manual de usuario

protech

protech ProX-1630 Manual de usuario

protech

protech BE-0996 Manual de usuario

protech

protech SE-8300 Manual de usuario

protech

protech prox BC-K201 Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario

protech ProX-1580 Manual de usuario

Manuales populares de Hardware de computadora de otras marcas
