ProSoft Technology ProLinx ASCII Nota de publicación

ASCII

ProLinx Standalone

Generic ASCII Serial Communication Module

Driver Manual

July 07, 2008

Please Read This Notice

Successful application of this module requires a reasonable working knowledge of the ProLinx Module, its

connected devices, and the application in which the combination is to be used. For this reason, it is

important that those responsible for implementation satisfy themselves that the combination will meet the

needs of the application without exposing personnel or equipment to unsafe or inappropriate working

conditions.

This manual is provided to assist the user. Every attempt has been made to assure that the information

provided is accurate and a true reflection of the product's installation requirements. In order to assure a

complete understanding of the operation of the product, the user should read all applicable documentation

on the operation of the connected devices.

Under no conditions will ProSoft Technology be responsible or liable for indirect or consequential damages

resulting from the use or application of the product.

Reproduction of the contents of this manual, in whole or in part, without written permission from ProSoft

Technology is prohibited.

Information in this manual is subject to change without notice and does not represent a commitment on the

part of ProSoft Technology Improvements and/or changes in this manual or the product may be made at any

time. These changes will be made periodically to correct technical inaccuracies or typographical errors.

Important Installation Instructions

Power, input and output wiring must be in accordance with Class I, Division 2 wiring

methods - Article 501-4 (b) of the National Electrical Code, NFPA 70 and in accordance

with the authority having jurisdiction. The following warnings must be heeded:

A WARNING - EXPLOSION HAZARD - SUBSTITUTION OF COMPONENTS MAY

IMPAIR SUITABILITY FOR CLASS I, DIV. 2;

B WARNING - EXPLOSION HAZARD - WHEN IN HAZARDOUS LOCATIONS, TURN

OFF POWER BEFORE REPLACING OR WIRING MODULES, and

C WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT EQUIPMENT

UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE

NONHAZARDOUS.

D "THIS DEVICE SHALL BE POWERED BY CLASS 2 OUTPUTS ONLY."

All ProLinx® Products

Power, input and output wiring must be in accordance with Class I, Division 2 wiring

methods - Article 501-4 (b) of the National Electrical Code, NFPA 70 and in accordance

with the authority having jurisdiction. The following warnings must be heeded:

A WARNING - EXPLOSION HAZARD - SUBSTITUTION OF COMPONENTS MAY

IMPAIR SUITABILITY FOR CLASS I, DIV. 2;

B WARNING - EXPLOSION HAZARD - WHEN IN HAZARDOUS LOCATIONS, TURN

OFF POWER BEFORE REPLACING OR WIRING MODULES, and

C WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT EQUIPMENT

UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE

NONHAZARDOUS.

D "THIS DEVICE SHALL BE POWERED BY CLASS 2 OUTPUTS ONLY."

ProLinx Modules with Ethernet Ports

Series C ProLinx™ modules with Ethernet ports do NOT include the HTML Web Server.

The HTML Web Server must be ordered as an option. This option requires a factory-

installed hardware addition. The HTML Web Server now supports:

8 MB file storage for HTML files and associated graphics files (previously limited to

384K)

32K maximum HTML page size (previously limited to 16K)

To upgrade a previously purchased Series C model:

Contact your ProSoft Technology distributor to order the upgrade and obtain a Returned

Merchandise Authorization (RMA) to return the unit to ProSoft Technology.

To Order a Series C mode with the -WEB option:

Add -WEB to the standard ProLinx part number. For example, 5201-MNET-MCM-WEB.

ProLinx Plus with Radio

The following Information and warnings pertaining to the radio must be heeded:

A "THIS DEVICE CONTAINS A TRASMITTER MODULE, FCC ID: SDZ-WA-1.

PLEASE SEE FCC ID LABEL ON BACK OF DEVICE."

B "THIS DEVICE USES AND INTERNAL COMPACT FLASH RADIO MODULE AS

THE PRIMARY RADIO COMPONENT. THE COMPACT FLASH RADIO MODULE

DOES NOT HAVE AN FXX ID LABE. THE COMPACT FLASH RADIO MODULE

HAS NO USER SERVICABLE PARTS."

C "THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT

VAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY

INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE

UNDESIRED OPERATION.

D THIS DEVICE AND ANY RADIO ACCESSORY SOLD BY PROSOFT MUST BE

INSTALLED BY AN AUTHORIZED PROFESSIONAL INDUSTRIAL RADIO SYSTEM

INTEGRATOR. FURTHER, ONLY RADIO ACCESSORIES SOLD BY PROSOFT

AND SPECIFICALLY TESTED FOR USE WITH THIS DEVICE MAY BE USED

WITH THIS DEVICE.

E THE USER OF THIS EQUIPMENT CANNOT BE WITHIN 20 cm. FROM THE

RADIATING ELEMENT DEVICE.

F CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY

RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER'S AUTHORITY TO

OPERATE THE EQUIPMENT.

Industry Canada Requirements:

A "THIS DEVICE HAS BEEN DESIGNED TO OPERATE WITH AN ANTENNA

HAVING A MAXIMUM GAIN OF 24 dB. AN ANTENNA HAVING A HIGHER GAIN IS

STRICTLY PROHIBITED PER REGULATIONS OF INDUSTRY CANADA. THE

REQUIRED ANTENNA IMPEDANCE IS 50 OHMS."

ProLinx Series C (4000); ProLinx Plus (5000); ProLinx Plus with Radio

(6000)

Product Installation Warning

Power, Input and Output (I/O) wiring must be in accordance with Class 1, Division 2

wiring methods, Article 501-4 (b) of the National Electrical Code, NFPA 70 for installation

in the U.S., or as specified in Section 18-1J2 of the Canadian Electrical Code for

installations in Canada, and in accordance with the authority having jurisdiction.

A Warning - Explosion Hazard - Substitution of components may impair suitability for

Class 1, Division 2.

B Warning - Explosion Hazard - When in Hazardous locations, turn off power before

replacing or wiring modules.

C Warning - Explosion Hazard - Do not disconnect equipment unless power has been

switched off or the area is known to be non-hazardous.

Your Feedback Please

We always want you to feel that you made the right decision to use our products. If you have suggestions,

comments, compliments or complaints about the product, documentation or support, please write or call us.

ProSoft Technology

1675 Chester Avenue, Fourth Floor

Bakersfield, CA 93301

+1 (661) 716-5100

+1 (661) 716-5101 (Fax)

http://www.prosoft-technology.com

ASCII Driver Manual

July 07, 2008

PSFT.ASCII.ProLinx.UM.08.07.07

ProSoft Technology ®, ProLinx ®, inRAx ®, ProTalk® and RadioLinx ® are Registered Trademarks of

ProSoft Technology, Inc.

Contents ASCII ♦ProLinx Standalone

Generic ASCII Serial Communication Module

ProSoft Technology, Inc. Page 5 of 40

July 7, 2008

Contents

PLEASE READ THIS NOTICE................................................................................................................2

Important Installation Instructions......................................................................................................2

Your Feedback Please ......................................................................................................................4

1INTRODUCTION...............................................................................................................................7

1.1 General Specifications..........................................................................................................7

1.2 Resources.............................................................................................................................7

2FUNCTIONALITY..............................................................................................................................9

2.1 Data Flow..............................................................................................................................9

3MODES OF OPERATION...............................................................................................................13

3.1 Data Flow............................................................................................................................13

3.2 Termination of Received Data............................................................................................15

4ASCII PROTOCOL CONFIGURATION..........................................................................................19

4.1 [ASCII Port 0]......................................................................................................................19

5DRIVER STATUS DATA.................................................................................................................25

6LED INDICATORS..........................................................................................................................29

6.1 Base Module LEDs.............................................................................................................29

6.2 LEDs for Port 0 Serial Port .................................................................................................30

6.3 4101 Series LEDs...............................................................................................................30

7SUPPORT, SERVICE & WARRANTY............................................................................................31

7.1 Return Material Authorization (RMA) Policies and Conditions...........................................31

7.2 LIMITED WARRANTY........................................................................................................33

7.3 How to Contact Us: Technical Support ..............................................................................37

INDEX ....................................................................................................................................................39

Contents ASCII ♦ProLinx Standalone

Generic ASCII Serial Communication Module

Page 6 of 40 ProSoft Technology, Inc.

July 7, 2008

Introduction ASCII ♦ProLinx Standalone

Generic ASCII Serial Communication Module

ProSoft Technology, Inc. Page 7 of 40

July 7, 2008

1 Introduction

In This Chapter

General Specifications ............................................................................7

Resources ...............................................................................................7

The ASCII driver permits the ProLinx module to interface any ASCII device to the

many protocols and networks available. ASCII devices include barcode

scanners, weigh scales, many field instruments, printers, and terminals. The

driver supports one to four ports that provide accessibility from one to four

independent serial networks.

1.1 General Specifications

Ports: One to four ports to receive and/or transmit data

Receive buffer size: 255 bytes

Receive termination: Stream mode, termination character(s), message

timeout, inter-character delay, or packet size length

Receive database location: -1=disable receiver, 0 to 3896

Transmit buffer size: 255 bytes

Transmit characters with pacing: 0 to 65535 millisecond delay between

each transmitted character

Transmit database location: -1=disable transmitter, 0 to 3896

Communication Configuration

oBaud Rate: 110 to 115,200

oParity: None, Odd, Even

oData Bits: 5 to 8

oStop Bits: 1 or 2

oRTS On and Off Timing: 0 to 65535 milliseconds

oMinimum Response Delay: 0 to 65535 milliseconds

oHardware or Software Handshaking: RTS/CTS, DTR/DSR, or

XON/XOFF

1.2 Resources

The ProLinx Reference Guide provides general information on all ProLinx

modules including installation, editing configuration files, cabling and jumper

configurations, troubleshooting, and a wide range of useful information. You

should have this manual available when installing and configuring ProLinx

modules.

ASCII ♦ProLinx Standalone Introduction

Generic ASCII Serial Communication Module

Page 8 of 40 ProSoft Technology, Inc.

July 7, 2008

Functionality ASCII ♦ProLinx Standalone

Generic ASCII Serial Communication Module

ProSoft Technology, Inc. Page 9 of 40

July 7, 2008

2 Functionality

In This Chapter

Data Flow ................................................................................................9

This section describes the functionality of the ASCII driver.

2.1 Data Flow

The following illustration shows receive and transmit dataflow of the ASCII driver.

Data received from the ASCII device is accepted by the receive driver and placed

in the receive database location configured by the user. The receive driver waits

until the user-configured termination condition is recognized while receiving the

data before placing the new data into the database.

For example, if the carriage-return character (ASCII 13) is used as the

termination condition for a received message, this signals the end of the

message. When the receive driver observes this character in the input stream, it

takes all received characters and places them in the internal database.

In both receive and transmit operations, a signal is required to determine when

new data is received or must be transmitted. The first word in the two data area

is used for this purpose. When the value of the first word changes, new data is

available. Lets look at a receive example. The sequence number in the receive

data block has a value of 0 as set when the module initializes. The ASCII device

sends a new data packet and the termination condition is present. The receive

driver copies the data into the internal data area, sets the message length in the

data area, and finally, sets the new sequence number. Receive and transmit data

block structure is discussed in the following topics.

ASCII ♦ProLinx Standalone Functionality

Generic ASCII Serial Communication Module

Page 10 of 40 ProSoft Technology, Inc.

July 7, 2008

2.1.1 Receive Data

Data received by the receive driver is placed in the module's internal database in

a fixed format at the location selected by the user. The receiver driver is disabled

if the database start location is set to a value of -1. The following table shows the

structure of the received data.

Word Offset Description

0 Receive sequence number. This register is incremented by the Module's Receive

Driver for each new packet received.

1 Number of characters transmitted (0 to 255) from last transmit request.

2 Number of characters (0 to 256) in receive block (3 to 130).

3 to 130 Received data on port.

The first word of the data block is used to signal when new receive data is

available. Word 1 of the block contains the number of bytes in the last message

transmitted on the port. Word 2 contains the number of bytes in the received

message data area. Words 3 to 130 contain the data received. If the module is

configured to swap the data bytes received, the receive driver will swap the bytes

in each word received before placing the data into the data block. Because the

data received may contain an odd number of bytes, the length of the message

received will be incremented by 1 when an odd number of bytes are received and

the swap option is utilized. This is to avoid losing the last byte of data in the

message.

2.1.2 Transmit Data

Data to transmit by the transmit driver is placed in the module's internal database

in a fixed format at the location selected by the user. The transmit driver is

disabled if the database start location is set to a value of -1. The following table

shows the structure of transmit data.

Word Offset Description

0 Transmit sequence number. This number is incremented by the user's application

for each new packet to transmit.

1 Number of characters received (0 to 256) from last receive request.

2 Inter-character delay for this message (milliseconds between characters)

3 Number of characters to transmit on Port (0 to 255)

4 to 131 Data to transmit on port

The first word of the data block is used to signal when new transmit data is

available. Word 1 of the block may optionally contain the number of characters

processed in the last receive message. Word 2 of the message is used to pace

the characters during the transmission process. This may be required when

interfacing with slow ASCII devices (that is, modems in command mode).

Tabla de contenidos

Otros manuales de Unidad de control de ProSoft Technology

ProSoft Technology

ProSoft Technology inRAx MVI56-CAS Manual de usuario

ProSoft Technology

ProSoft Technology MVI69E-GSC Manual de usuario

ProSoft Technology

ProSoft Technology MVI69E-LDM-MQTT Manual de usuario

ProSoft Technology

ProSoft Technology ILX800-SMSG Manual de usuario

ProSoft Technology

ProSoft Technology inRax MVI71-BDW Manual de usuario

ProSoft Technology

ProSoft Technology MVI69L-MBTCP Manual de usuario

ProSoft Technology

ProSoft Technology inRax MVI56-DNPSNET Manual de usuario

ProSoft Technology

ProSoft Technology ProTalk PTQ-104C Manual de usuario

ProSoft Technology

ProSoft Technology ControlLogix inRAx MVI56E-MNETR Manual de usuario

ProSoft Technology

ProSoft Technology MVI56E-LDM-MQTT Manual de usuario

ProSoft Technology

ProSoft Technology MVI69-GSC CompactLogix Manual de usuario

ProSoft Technology

ProSoft Technology inRax MVI56-DH485R Manual de usuario

ProSoft Technology

ProSoft Technology ILX34-MBS485 Manual de usuario

ProSoft Technology

ProSoft Technology MVI56E-SIE Manual de usuario

ProSoft Technology

ProSoft Technology PS69-DPM Manual de usuario

ProSoft Technology

ProSoft Technology MVI69E-MBTCP Manual de usuario

ProSoft Technology

ProSoft Technology inRAX MVI69-S3964R Manual de usuario

ProSoft Technology

ProSoft Technology MVI56E-LDM Manual de usuario

ProSoft Technology

ProSoft Technology MVI56-PNPM Manual de usuario

ProSoft Technology

ProSoft Technology MVI69-DFCM Manual de usuario

ProSoft Technology

ProSoft Technology MVI71-GEC Manual de usuario

ProSoft Technology

ProSoft Technology ILX69-PBM Manual de usuario

ProSoft Technology

ProSoft Technology inRax MVI69-101M Manual de usuario

ProSoft Technology

ProSoft Technology inRAx MVI56-HART Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
