ProLights StudioCob PFC2 Manual de usuario
USER MANUAL
English version
StudioCob PFC2
150W IP65 rated full colour COB LED Par
REV.01-09/21
Thank you for choosing PROLIGHTS
Please note that every PROLIGHTS product has been designed in Italy to meet quality and performance requirements
for professionals and designed and manufactured for the use and application as shown in this document.
Any other use, if not expressly indicated, could compromise the good condition/operation of the product and/or be
a source of danger.
This product is meant for professional use. Therefore, commercial use of this equipment is subject to the respectively
applicable national accident prevention rules and regulations.
Features, specications and appearance are subject to change without notice. Music & Lights S.r.l. and all afliated
companies disclaim liability for any injury, damage, direct or indirect loss, consequential or economic loss or any other
loss occasioned by the use of, inability to use or reliance on the information contained in this document.
Product user manual can be downloaded from the website www.prolights.it , or can be inquired to the ofcial
PROLIGHTS distributors of your territory (https://www.prolights.it/sales_network.html).
Scanning the below QR Code, you will access the download area of the product page, where you can nd a broad
set of always updated technical documentation: specications, user manual, technical drawings, photometrics,
personalities, xture rmware updates.
The PROLIGHTS Logo, PROLIGHTS names and all other trademark in this document pertaining to PROLIGHTS servicesor
PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its afliates, and subsidiaries.
PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc -
04026 - Minturno (LT) ITALY.
Visit the download area
of the product page
PROLIGHTS - StudioCob PFC2 01
INDEX
SAFETY INFORMATION 02
1 - PACKAGING 05
PACKAGE CONTENT..................................................................................................... 05
OPTIONAL ACCESSORIES............................................................................................. 05
2 - TECHNICAL DRAWING 05
3 - INSTALLATION 06
MOUNTING.................................................................................................................... 06
4 - CONNECTION TO THE MAINS SUPPLY 07
5 - START UP 07
CONNECT AND DISCONNECT POWER FROM THE PRODUCT.................................. 07
6 - PRODUCT OVERVIEW 08
7 - DMX CONNECTION 09
CONNECTION OF THE CONTROL SIGNAL: DMX LINE .............................................. 09
INSTRUCTIONS FOR A RELIABLE DMX CONNECTION ............................................... 09
CONNECTION DAISY CHAIN........................................................................................ 09
CONNECTION OF THE DMX LINE................................................................................ 09
CONSTRUCTION OF THE DMX TERMINATION ........................................................... 10
DMX ADDRESSING ........................................................................................................ 10
8 - CONTROL PANEL 11
DISPLAY AND BUTTONS LAYOUT................................................................................. 11
9 - MENU STRUCTURE 12
10 - RDM FUNCTIONS 14
11 - DMX CHARTS 15
12 - ACCESSORIES INSTALLATION 17
FILTER FRAME (CODE STUDIOCOBTPG - OPTIONAL)................................................. 17
BARN DOOR (CODE STUDIOCOBBD - OPTIONAL)..................................................... 18
OPTIC (CODE STUDIOCOBPLUSL18/30/60 - OPTIONAL)............................................ 19
13 - MAINTENANCE 20
MAINTENANCE AND CLEANING THE PRODUCT........................................................ 20
VISUAL CHECK OF PRODUCT HOUSING ..................................................................... 20
TROUBLESHOOTING..................................................................................................... 21
PROLIGHTS - StudioCob PFC2
02
SAFETY INFORMATION
WARNING!
• Please read carefully the instruction reported in this section before installing, power-
ing, operating or servicing the product and observe the indications also for its future
handling.
This unit is not for household use, only professional applications.
Connection to mains supply
• The Connection to the mains supply must be carried out by a qualied electrical installer.
• Use only AC supplies 100-240V 50-60 Hz, the xture must be electrically connected
to ground (earth).
• Select the cable cross section in according with the maximum current draw of the
product and the possible number of products connected at the same power line.
• The AC mains power distribution circuit must be equipped with magnetic+residual
current circuit breaker protection.
• Do not connect it to a dimmer system; doing so may damage the product.
Protection and Warning against electrical shock
• Do not remove any cover from the product, always disconnect the product from AC
power before servicing.
• Ensure that the xture is electrically connected to ground (earth). And use only a
source of AC power that complies with local building and electrical codes and has
both overload and ground-fault (earth-fault) protection.
• Before using the xture, check that all power distribution equipment and cables are
in perfect condition and rated for the current requirements of all connected devices.
• Isolate the xture from power immediately if the power plug or any seal, cover, cable, or
other components are damaged, defective, deformed or showing signs of overheating.
• Do not reapply power until repairs have been completed.
• Refer any service operation not described in this manual to PROLIGHTS Service team
or an authorized PROLIGHTS service center.
Installation
• Make sure that all visible parts of the product are in good visible condition before its
use or installation.
• Make sure the point of anchorage is stable before positioning the projector.
• When suspending the xture above ground level, secure it against failure of primary
attachments by attaching a safety cable that is approved as a safety attachment for
the weight of the xture to the attachment point on the main frame of the product. ln
case the safety cable, enter in action, it needs to be replaced with a new one.
• Install the product only in well ventilated places.
• For non temporary installations, ensure that the xture is securely fastened to a load-
bearing surface with suitable corrosionresistant hardware.
• For a temporary installation with clamps, ensure that the quarter-turn fastener and/or
screws are turned fully, and secured with a suitable safety cable.
0,5 m Minimum distance of illuminated objects
• The projector needs to be positioned so that the objects hit by the beam of light are
at least 0.5 meters (1.64 ft) from the lens of the projector.
T
45°
C
a
Max operating ambient temperature (Ta)
• Do not operate the xture if the ambient temperature (Ta) exceeds 45 °C (113 °F).
PROLIGHTS - StudioCob PFC2 03
T
-20°
C
aMinimum operating ambient temperature (Ta)
• Do not operate the xture if the ambient temperature (Ta) is below -20 °C (-4 °F).
Protection from burns and re
• The exterior of the xture becomes hot during use. Avoid contact by persons and materials.
• Ensure that there is free and unobstructed airow around the xture.
• Keep ammable materials well away from the xture.
• Do not expose the front glass to sunlight or any other strong light source from any an-
gle. Lenses can focus the sun’s rays inside the xture, creating a potential re hazard.
• Do not attempt to bypass thermostatic switches or fuses.
IP65
Outdoor (temporary) use
• This product is rated with an IP (Ingress protection) for temporary outdoor use when
used and serviced according to the instruction contained in this document.
• Never use the xture in places subject to vibrations or bumps.
• Make certain that no inammable liquids, water or metal objects enter the xture.
• Excessive dust, smoke uid, and particle build up degrades performance, causes
overheating and will damage the xture.
• Damages caused by inadequate cleaning or maintenance are not covered by the
product warranty.
T
60°
C
c
Temperature of the external surface
• The surface of the xture can reach up to 60 °C (140 °F) during operation. Avoid
contact with people and materials.
Maintenance
• Warning! Disconnect the xture from AC mains power and allow to cool for at least
10 minutes before handling.
• Only technicians who are authorized by PROLIGHTS or Authorised service partners
are permitted to open the xture.
• Users may carry out external cleaning, following the warnings and instructions pro-
vided, but any service operation not described in this manual must be referred to a
qualied service technician.
• Important! Excessive dust, smoke uid, and particle build up degrades performance,
causes overheating and will damage the xture. Damages caused by inadequate
cleaning or maintenance is not covered by the product warranty.
Photobiological safety
• This device emits potentially dangerous optical radiation and is identied in the cat-
egory of Risk Group 1 according to EN 62471.
Do not stare at the operating light source
• Do not look directly at the LED source during operation. It can be harmful to the eyes
and skin.
• During Installation, operation and maintenance, be prepared for the xture to light
and move suddenly when connected to power.
Disposal
• This product is supplied in compliance with European Directive 2012/19/EU – Waste
Electrical and Electronic Equipment (WEEE). To preserve the environment please dis-
pose/ recycle this product at the end of its life according to the local regulation.
PROLIGHTS - StudioCob PFC2
04
The products to which this manual refers comply with:
• 2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD).
• 2014/30/EU - Electromagnetic Compatibility (EMC).
• 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS).
Other approvals
• The product meets the safety requirements of the certification procedures of the
market in which it is placed and sold.
PROLIGHTS - StudioCob PFC2 05
1 - PACKAGING
PACKAGE CONTENT
• STUDIOCOBPFC2;
• 1x 1,5 meters power cable (SCHUKO plug - SEETRONIC IP65 power connector);
• User manual.
OPTIONAL ACCESSORIES
• INF53415L03: dmx cable HC5340. SETMC5MXXB XLR 5p->SETMC5FXXB XLR (f) 5p;
• 938225L03: 3x2.5mm TH07 Cable, 16A SETSAC3MX, 16A SETSAC3FX, L. 3m;
• 9313FXWL03: ass. 3x2.5mm TH07 cable, 16A 3p 230V CEE plug, SETSAC3FX socket, L.3 m;
• 9333FXWL03: ass. 3x2.5mm TH07 cable, SHUKO plug, SETSAC3FX socket, L.3m;
• C6002: slim aluminium clamp, 200 kg loading, 48-51 mm tubes, M10 bolt;
• RSR0630A/B: steel security cable for hanging bodies, inox steel shackle, L=60 cm, silver/black;
• STUDIOCOBPLUSL18: optics for STUDIOCOBPLUS projectors series, 18°;
• STUDIOCOBPLUSL38: optics for STUDIOCOBLUS projectors series, 38°;
• STUDIOCOBPLUSL60: optics for STUDIOCOBLUS projectors series, 60°;
• STUDIOCOBTPG: lter frame for STUDIOCOB projectors;
• STUDIOCOBBD: barn door 4 directional aps to adjust the light beam, f. frame included;
• FCLCOBPLUS: ight case for 8 STUDIOCOBPLUS;
• UPBOX1U: rmware uploader kit, USB IN, 3p XLR DMX OUT.
2 - TECHNICAL DRAWING
Fig. 01Weight: 5.6 kg - 12.34 lbs
PROLIGHTS - StudioCob PFC2
06
Fig. 02
3 - INSTALLATION
MOUNTING
Check that the supporting structure can safely bear the weight of all installed xtures, clamps, cables,
auxiliary equipment, etc. and complies with locally applicable regulations.
When suspending the xture above ground level, secure it against failure of primary attachments by
attaching a safety wire that is approved as a safety attachment for the weight of the xture to an anchor
point on the product main frame.
Do not use removable parts or weak anchors for secondary attachment.
Warning! When clamping the xture to a truss or other structure at any angle, use clamps of half-cou-
pler type. Do not use any type of clamp that does not completely encircle the structure when fastened.
215 mm
8.5 in
Ø13 mm
Ø0.5 in
45 mm
1.8 in
RSR0630A/B
steel security cable
C6002
clamp
PROLIGHTS - StudioCob PFC2 07
5 - START UP
CONNECT AND DISCONNECT POWER FROM THE PRODUCT
To apply and disconnect power to the product:
• Check that the product is installed and secured as indicated in the Safety Informations, and that
personal safety will not be put at risk when the xture lights up.
• Connect the power connector into the Mains input socket (100-240 VAC-50/60 Hz).
• The product is then ready for its operations and can be controlled through the available input sig-
nals on board.
• To disconnect power from the product, disconnect the Mains from the socket.
4 - CONNECTION TO THE MAINS SUPPLY
WARNING: For protection from electric shock, the xture must be earthed!
The product is equipped with auto-switching power supply that automatically adjusts to any 50-60Hz
AC power source from 100-240 Volts.
If you need to install a power plug on the power cable to allow connection to power outlets, install a
grounding-type (earthed) plug, following the plug manufacturer’s instructions. If you have any doubts
about proper installation, consult a qualied electrician.
The max power consumption is 140W.
Core (EU) Core (US) Connection Plug terminal marking
Brown Black Live L
Blue White Neutral N
Yellow+green Green Earth
PROLIGHTS - StudioCob PFC2
08
36 5 489
1
2
7
6 - PRODUCT OVERVIEW
1. BRACKET;
2. SAFETY EYE to attach safety cable;
3. KNOB for bracket;
4. DMX IN (5-p XLR): 1 = GND, 2 = sign-, 3 = sign+, 4 N/C, 5 N/C;
5. POWER IN: for connection to the Mains 100-240V~/50-60Hz;
6. USER INTERFACE with display and buttons for access to the control panel functions.
7. DMX OUT (5-p XLR): 1 = GND, 2 = sign-, 3 = sign+, 4 N/C, 5 N/C;
8. POWER OUT: power output for connection of multiple units in series;
9. GORE VALVE.
Fig. 03
Tabla de contenidos
Otros manuales de Equipo de iluminación de ProLights
ProLights
ProLights LUMA 1500SH Manual de usuario
ProLights
ProLights Jet PAR7ZIP Manual de usuario
ProLights
ProLights 201119080 Manual de usuario
ProLights
ProLights Reflex Manual de usuario
ProLights
ProLights Halurock Manual de usuario
ProLights
ProLights Eclipse FC Manual de usuario
ProLights
ProLights STARDRAPE W Manual de usuario
ProLights
ProLights EXPLO3000D Manual de usuario
ProLights
ProLights EclFresnel 2KTW Manual de usuario
ProLights
ProLights FLATPAR6H SUPERSLIM LEDPAR Manual de usuario
ProLights
ProLights DIGIDRIVERIP Manual de usuario
ProLights
ProLights ECL Series Manual de usuario
ProLights
ProLights Diamond142L Manual de usuario
ProLights
ProLights ARCLED5118RGB Manual de usuario
ProLights
ProLights ELFIN FC Manual de usuario
ProLights
ProLights PANORAMA IP AIRBEAM Manual de usuario
ProLights
ProLights LUMIPAR18QTOUR Manual de usuario
ProLights
ProLights ARCLED3144RGBWA Manual de usuario
ProLights
ProLights PIXIE BEAM Manual de usuario
ProLights
ProLights MULTIFLOWER 102 Manual de usuario
Manuales populares de Equipo de iluminación de otras marcas
Qazqa
Qazqa Suplux SL 3 Black 103062 Manual de usuario
Commercial Electric
Commercial Electric 54568141 Manual de usuario
CREE LIGHTING
CREE LIGHTING 304 Series Manual de usuario
Goobay
Goobay 49867 Manual de usuario
ECOMAN ITALIA
ECOMAN ITALIA LED T8 Manual de usuario
Alkalite
Alkalite Krypton KT-81 Manual de usuario
