SYSTEM OWNER’S MANUAL

PRO FLO WASTEWATERTREATMENT SYSTEMS

ForAll Models: 500, 600, 800, 1000 &1500

System

Owner’s

Manual

IMPORTANT! It is important that you read and understand your System Owner’s Manual. This

manual contains information you should know and procedures you should follow in order to help

ensure your new Pro Flo Aerobic System operates to its full potential. This manual also contains

safety precautions you should be aware of in order to help keep you,your family, and visitors safe.

SYSTEM OWNER’S MANUAL

FORALL MODELS

500, 600, 800, 1000 & 1500

System Owner’s Manual

Third Edition, Revised August. 2015

Pro Flo Aerobic Systems, LP

Street Address: Mailing Address:

20222 FM 362 P.O. Box 1425

Waller, Texas 77484 Waller, Texas 77484-1425

Telephone: 936-372-5222

Fax: 936-372-5235

www.profloaerobic.com

WE ARE COMMITTED TO QUALITYAND CUSTOMER SATISFACTION.

SYSTEM OWNER’S MANUAL

Table of Contents

INTRODUCTION .........................................................................................................ii

HOWYOUR NEWTREATMENT SYSTEM FUNCTIONS ................................................ 1

PRO FLOTREATMENT SYSTEM DIAGRAM .................................................................. 2

PRO FLO 500 SL2TREATMENT SYSTEM DIAGRAM...................................................... 3

PRO FLO 500 SLPT2TREATMENT SYSTEM DIAGRAM ................................................. 4

PRO FLO 500 SLPT5TREATMENT SYSTEM DIAGRAM ................................................. 5

PRO FLO 600 SLTREATMENT SYSTEM DIAGRAM ....................................................... 6

PRO FLO 600 SLPTTREATMENT SYSTEM DIAGRAM ................................................... 7

PRO FLO 800 SLTREATMENT SYSTEM DIAGRAM ....................................................... 8

PRO FLO 800 PTSLTREATMENT SYSTEM DIAGRAM ................................................... 9

PRO FLO 800 PTSL5 TREATMENT SYSTEM DIAGRAM ................................................ 10

PRO FLO 1000 S TREATMENT SYSTEM DIAGRAM ..................................................... 11

PRO FLO 1500 S TREATMENT SYSTEM DIAGRAM ..................................................... 12

TREATMENT SYSTEM STARTUP ................................................................................ 13

OWNER MAINTENANCE,CARE,AND OPERATION INSTRUCTIONS ......................... 13

ITEMS THAT ARE SAFETO USE INYOUR NEW SYSTEM ............................................ 15

ITEMS THAT ARE NOT SAFE TO USE IN YOUR NEW SYSTEM .................

THEAERATOR ........................................................................................................... 17

THE CONTROL PANEL .............................................................................................. 18

PERIODIC PUMPING AND CLEANING ...................................................................... 18

YOUR RESPONSIBILITIES .......................................................................................... 19

DETECTING MALFUNCTIONS OR PROBLEMS .......................................................... 20

INFREQUENT USE OFTHE PRO FLO ......................................................................... 20

WHAT TO DO FOR SERVICE ...................................................................................... 20

SERVICE CONTRACTSAND OBLIGATIONS ............................................................... 20

WARRANTIES ............................................................................................................ 21

SOURCES FOR OBTAINING REPLACEMENT PARTS OR COMPONENTS ................... 23

GENERAL INFORMATION ......................................................................................... 23

NOTES ....................................................................................................................... 24

SYSTEM OWNER’S MANUAL

Introduction

Thank you for purchasing the Pro FloWastewater Treatment System.

Your new Pro Flo system uses the very best technology the industry

has to offer for individual on-site wastewater treatment. The Pro Flo

system is a mechanical, aerobic, wastewater treatment system that

processes household sewage into a clear odorless liquid within a 24-

hour time frame.The Pro Flo Models 500, 600, 800, 1000, and 1500

were certified against the ANSI/NSF Standard No. 40, approved and

listed by NSF International,and meet and/or exceed the criteria for a

Class I system to treat both black and graywater.

Pro Flo Aerobic Systems, LP has over 30 years of experience in the

wastewater industry. Our company works hard to keep costs as low

as possible, yet we stay on the cutting edge of technology by

continuously updating and offering consumers the very best products.

We are committed to producing a superior quality product that will

give you years of outstanding performance, and we are committed to

customer service and satisfaction.

Please help us by sending in your warranty card located at the back

of this manual.

Once again,thank you for choosing the Pro Flo. And remember,

“Start with the Pro, and end with the BEST!”

SYSTEM OWNER’S MANUAL

How Your New Treatment System

Functions

The Pro Flo Wastewater Treatment System is similar to large

municipality sewage treatment plants. It uses an extended aeration

activated sludge process. This type of treatment depends primarily

on the use of air. When air is introduced to the wastewater,it promotes

the growth of aerobic bacteria and other microorganisms that break

down the organic material found in regular household sewage.

Raw unsettled waste/water from your home enters directly into the

pretreatment tank. Inside the pretreatment tank,the solids separate

from the liquid and the liquid flows into the aeration chamber. Inside

the aeration chamber,simple hydraulic displacement is accomplished

by the introduction of air. Air is introduced into the aeration chamber

by passing from the aerator motor through the air diffuser and into

the system. This air promotes the growth of aerobic organisms in

much larger amounts than would naturally occur. It is these aerobic

organisms (bacteria) that break down the organic material. As the

wastewater leaves the aeration chamber, it enters the “quiet zone”

better known as the clarifier. No mixing occurs inside the clarifier.

In the clarifier,any“leftover”solids separate from the liquid and settle

to the bottom of the clarifier. This solid material is called sludge.

Sludge contains dissolved oxygen and the sludge bacteria are activated

by oxygen.This activated sludge is returned to the aeration chamber

where it is mixed and digested again.The sludge then mixes with

incoming wastewater. This mixture of returned sludge, wastewater,

and dissolved oxygen is referred to as mixed liquor.The mixed liquor

flows back into the clarifier, the solids separate and return once again

to the aeration chamber. This never-ending cycle produces a clear,

odorless, high quality effluent that is ready to be released to the

environment.

(See the diagrams on the following pages illustrating basic system

design and flow path.)

SYSTEM OWNER’S MANUAL

Pro Flo Treatment System Diagram

Drawing Not to Scale All Gallonage Approximate

Configurations may vary.

Inspection Cap

Inlet

Pretreatment Access

Warning Light

Pretreatment

Chamber

4”

Pretreatment

Outlet Baffle

Aeration

Chamber Air Diffuser

45° Slope

4” Gap

Clarifier

Mute Switch

Pump Tank

Outlet

Pump Tank Riser

& Access

Clarifier Access

Aeration Access

Aerator Cover

Submersible Pump

Model of:

500 SLPT2

This Model has affixed

768 gallon pump tank

(optional)

(NOTE:SYSTEM TESTED DID NOT

HAVE AFFIXED PUMP TANK.)

500 SL

397 – Gallon Pretreatment Tank

620 – Gallon Aeration Chamber

219 – Gallon Clarifier Chamber

*Pump Tank Sold Separately

600 SL

447 – Gallon Pretreatment Tank

748 – Gallon Aeration Chamber

268 – Gallon Clarifier Chamber

*Pump Tank Sold Separately

800 SL

*Pretreatment Tank Sold Separately

(Pro Flo recommends the pretreatment

tank be no smaller than 550 gallons)

913 – Gallon Aeration Chamber

304 – Gallon Clarifier Chamber

*Pump Tank Sold Separately

1000 S

*Pretreatment Tank Sold Separately

(Pro Flo recommends the pretreatment

tank be no smaller than 800 gallons)

1109 – Gallon Aeration Chamber

371 – Gallon Clarifier Chamber

* PumpTank Sold Separately

500 SLPT

396 – Gallon Pretreatment Tank

620 – Gallon Aeration Chamber

224 – Gallon Clarifier Chamber

503 – Gallon Pump Tank

600 SLPT

447 – Gallon Pretreatment Tank

748 – Gallon Aeration Chamber

268 – Gallon Clarifier Chamber

796 – Gallon Pump Tank

800 PTSL

503 Gallon Pretreatment Tank affixed

911 – Gallon Aeration Chamber

317 – Gallon Clarifier Chamber

*Pump Tank Sold Separately

500 SLPT

397 – Gallon Pretreatment Tank

620 – Gallon Aeration Chamber

219 – Gallon Clarifier Chamber

768 – Gallon Pump Tank

600 SLPT

447 – Gallon Pretreatment Tank

748 – Gallon Aeration Chamber

268 – Gallon Clarifier Chamber

796 – Gallon Pump Tank

800 PTSL

768 Gallon Pretreatment Tank affixed

913 – Gallon Aeration Chamber

304 – Gallon Clarifier Chamber

*Pump Tank Sold Separately

1500 S

*Pretreatment Tank Sold Separately

(Pro Flo recommends the pretreatment

tank be no smaller than 1125 gallons)

1657 – Gallon Aeration Chamber

540 – Gallon Clarifier Chamber

* PumpTank Sold Separately

SYSTEM OWNER’S MANUAL

Inlet

Pretreatment

Access

Warning Light

397 Gal.

Pretreatment

4”

Pretreatment

Outlet Baffle

620 Gal.

Aeration Chamber

Air Diffuser

45°

Slope

219 Gal.

Clarifier

Mute Switch

Outlet

Clarifier Access

Aerator

Cover

Aerator

Outlet

Baffle

#/4” PVC

Pipe

Control

Panel

Pro Flo 500 SL2

SPECIFICATIONS

Pro Flo 500 SL2System Diagram

Overall Length ............ 101 #/4”(t) - 99!/4”(b)

Overall Width ...................... 68”(t) - 64”(b)

Height without Risers ......................... 71”

Exterior Wall Thickness ........................ 3”

Interior Wall Thickness ........... 2”(t) - 3”(b)

Top Thickness ...................................... 5”

Bottom Thickness ................................. 3”

Pretreatment Length .... 29 !/4”(t) - 26#/4”(b)

Aeration Length.................. 44”(t) - 43”(b)

Clarifier Length ............ 18!/2”(t) - 17!/2”(b)

Water Level ........................................ 55”

Air Diffuser ......................................... 27”

Bottom of Inlet to Bottom of Tank .... 60!/2”

Total Tank Weight (Empty) .... 12,040* lbs

(t) = Top Dimension - (b) = Bottom Dimension

*Actual Scaled Weight

Pump Tank Sold Separately (Not Shown)

Drawing Not to Scale All Gallonage Approximate

20” Pretreatment

Riser

16” Clarifier

Riser

Configurations may vary.

Pro Flo 500 SL

GPD Unit

NOTE: If the wall between the Clarifier and Aeration

Chamber is a drop-in wall, the thickness shall be 2!/2”

20” Aeration Riser

Solids

Deflector

SYSTEM OWNER’S MANUAL

Inlet

20”

Pretreatment

Riser

Warning Light

397 Gal.

Pretreatment

4”

Pretreatment

Outlet Baffle

620 Gal.

Aeration Chamber

Air Diffuser 45°

Slope

219 Gal.

Clarifier

Mute Switch

768 Gal.

Pump Tank

Clarifier Access

Aerator Cover

Aerator

Outlet

Baffle

#/4” PVC

Pipe

Control

Panel

Pro Flo 500 SLPT2

Pro Flo 500 SLPT2System Diagram

20” Pump Tank

Riser

SPECIFICATIONS

Overall Length ....................... 159”(t) - 155”(b)

Overall Width ............................ 68”(t) - 64”(b)

Height without Risers ............................... 71”

Exter ior Wall Thickness .............................. 3”

Interior Wall Thickness ................... 2”(t) - 3”(b)

TopThic kness ............................................ 5”

Bottom Thickness ...................................... 3”

Pretreatment Length ............ 29 !/4”(t) - 26#/4”(b)

Aeration Length ........................ 44”(t) - 43”(b)

Clarifier Length .................... 18!/2”(t) - 17!/2”(b)

Pump Tank .......................... 55!/4”(t) - 52#/4”(b)

Water Level ............................................. 55”

Air Diffuser ............................................... 27”

Bottom of Inlet to Bottom of Tank ............ 60!/2”

Total Tank Weight (Empty) ............ 17,710* lbs

(t) = Top Dimension - (b) = Bottom Dimension

*Actual Scaled Weight

Drawing Not to Scale

NOTE: Unit tested did not have affixed pump tank All Gallonage Approximate

Pump Tank Access

Configurations may vary.

Pro Flo 500 SLPT

GPD Unit

NOTE: If the wall between the Clarifier and Aeration

Chamber is a drop-in wall, the thickness shall be 2!/2”

20” Aeration Riser

Solids

Deflector

Pretreatment

Access

16” Clarifier

Riser

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Producto de plomería de ProFlo

ProFlo

ProFlo PFWSCM2M101 Manual de usuario

ProFlo

ProFlo PFX3045 Manual de usuario

ProFlo

ProFlo PFWSC1240A CP Manual de usuario

ProFlo

ProFlo PFWSCM1M103 Manual de usuario

ProFlo

ProFlo PFXC1717CP Manual de usuario

ProFlo

ProFlo PFWSCM2M316 Manual de usuario

ProFlo

ProFlo PF2830GCP Manual de usuario

ProFlo

ProFlo PFWSC4857CP Manual de usuario

ProFlo

ProFlo PFXC1080LSCP Manual de usuario

ProFlo

ProFlo PFWSC6840CP Manual de usuario

ProFlo

ProFlo PF1612PA Manual de usuario

ProFlo

ProFlo PF3870CP Manual de usuario

ProFlo

ProFlo PFWSCM1M1087 Manual de usuario

ProFlo

ProFlo PFWSCM2A100 Manual de usuario

ProFlo

ProFlo PFWSC6897CP Manual de usuario

ProFlo

ProFlo PFWSC4757CP Manual de usuario

ProFlo

ProFlo PFXC8012 CP Manual de usuario

ProFlo

ProFlo PFEM Series Manual de usuario

ProFlo

ProFlo PFXC5150CP Manual de usuario

ProFlo

ProFlo PFXC5017CP Manual de usuario

ProFlo

ProFlo PF3800CP Manual de usuario

ProFlo

ProFlo Kiger PFXC1711CP Manual de usuario

ProFlo

ProFlo PFWSC1850CP Manual de usuario

ProFlo

ProFlo PFWSCM1M1097 Manual de usuario

Manuales populares de Producto de plomería de otras marcas

Weka

Weka 506.2020.00E Instrucciones de funcionamiento

Kohler

Kohler K-6228 Instrucciones de montaje

UBERHAUS DESIGN

UBERHAUS DESIGN 75175017 Manual de usuario

American Standard

American Standard DetectLink 6072121 Manual de usuario

Uponor

Uponor Contec TS Manual de usuario

Pfister

Pfister Selia 49-SL Manual de usuario

Fortis

Fortis VITRINA 6068700 Manual de usuario

Fortis

Fortis MILANO 78211JS Manual de usuario

Kohler

Kohler K-12183 Instrucciones de montaje

Maxxus

Maxxus MX-M206-01 Manual de usuario

Moen

Moen 5922 Series Manual de usuario

Viega

Viega Prevista Pure 8512 Manual de usuario

Kohler

Kohler Centerset K-15240 Instrucciones de montaje

Viega

Viega Prevista Dry 8522.33 Manual de usuario

Sanela

Sanela Lema SLP 59RB Manual de usuario

Elkay

Elkay EDF15AC Manual de instalación

Hans Grohe

Hans Grohe AXOR Citterio E 36702000 Manual

baliv

baliv WT-140 Manual de usuario
