PROAIM Fly 22 Manual de usuario
1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Fly 22’ Crane with LW-100 Stand (P-FLY-22-S)
Assembly Manua l
LW-100 Jib Stand Spreader
2X Red Cables
2X Blue Cables
Weight Rod
Secon 1A
Secon 2B
Secon 3C
Secon 4D
Secon 5E
2
Weight Closer Weight Safety Ends Connecvity Plate
Cable Guide Support Rods
Packing
Safety Hints
ATTENTION: PLEASE READ THIS BEFORE USING TO PREVENT DAMAGE TO EQUIPMENT
& OPERATOR!
The crane may not be assembled or operated under the inuence of alcohol, drugs or any other intoxi-
cang substances. Lack of aenon while connecng the components can cause substanal damage
to equipment/operator.
The crane may only be operated on levelled horizontal posion. Make sure that the surface is stable.
To prevent any harm or injury, properly join all secons of the crane. It is suggested to use the support
stand while telescoping the complete length.
Do not exceed the maximum payload capacity of the Tripod. Do not adjust the tripod leg locks or move
the Tripod or remove the ground spreader while the crane is aached to the Tripod.
Always connect the steel cables properly to provide stability to the system. They should not negavely
impact the movements of the crane in any way.
Aer setup of the crane, the pan-lt head / gimbal head shall be posioned under the central pivot
secon. In the assembled state, when the pan-lt head / gimbal head is higher than the central pivot
secon, there should be someone to look aer the crane system.
The complete panning & liing range around it must be kept free. Avoid anybody standing under the
crane. No loose objects may be stored or placed on it. Be very careful while using it indoors.
Never operate the crane near high-voltage power cables. It holds danger to life.
Parcular care is required when operang the crane in unfavourable weather condions. The crane
must be shut down in sucient me. When it is used on a rainy day, the pan-lt head / gimbal head
and controlling bar shall be protected against rain.
When you want to transport the crane, lock the Pan & Tilt Axis for safety. Make sure that the
components do not rub together and cause any material wear.
3
Take out the Spreader from Accessory Bag.
Spread the spreader on oor and open the
legs of spreader with help of provided knob.
Jib Stand Setup
Open the legs of 100mm jib stand then aach
it to spreader, lock it in place with the rubber
grips.
Now mount central fork onto tripod , then
aach boom clamp to secure it well.
Jib Secons Setup
Slide the (1A Secon) into central fork
(secon 2B) and ghten with help of knob. Slide
Before the counterweights are removed, ensure the remote head is resng on the support stand.
Then gradually remove the counterweights before the remote head, camera or other parts.
In the interest of safe crane operaon, avoid abruptly swivelling or stopping the crane; otherwise, it
may cause severe damage to equipment.
FOLLOWING THESE GUIDELINES WILL PROVIDE BETTER SHOTS AND TROUBLE-FREE OPERATION.
SHOULD YOU NEED ADDITIONAL INFORMATION, TECHNICAL ASSISTANCE IS AVAILABLE ‘ONLINE’ BY
CONTACTING THE SALES REPRESENTATIVE.
4
Insert connecng bars (secon 1A) aached
it with both the ends (weight bar & secon
2B) the both ends using the provided knob.
Using the same approach insert 3rd, 4th and
remaining secons to joints and secure via
knobs as shown.
Aach short cable guide rod on 3rd secon
properly. Insert knob onto the cable guide
rod and ghten the knob properly.
Cable Guide & Support Rod Setup
Loosen the bolts on cable guide rod in order
to aach cable guide support rod to it.
Reghten the bolt.
Using the same steps to and aach long
cable guide rod on 2nd secon as shown.
Insert weight rod on (1 secon) and ghten
the bolt with help of allen key as shown in
the picture.
Connecon Bar
Knob
5
Then insert safety ends at both sides onto
the weight rod.
Cable Code (Red)
Stability Cables Setup
Aach (Red) cable to (2B secon) & (secon
3C) & align it properly with help of cable
guide clamp and aached with (5E secon).
Aach cables and insert the hook onto the
weight rod.
Align it to the cable guide side rod and aach
it to the end (secon 5th).
NOTE: You can adjust the cable with help of
wire tensioner.
Now aach both red cable hook onto the
provided bolts properly as shown.
Cable Code (Blue)
NOTE: Both the red cables are following same steps.
6
Aach your head plate properly and ghten
the knob.
Loosen the knob and adjust the height and
then reghten the knob.
Now slide in weight to it as per your
requirement and screw in weight closer
properly. (Counter weight not included)
YOUR PROAIM FLY 22’ CAMERA CRANE PRODUCTION PACKAGE
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
7
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
