INSTALLATION INSTRUCTIONS

PP-FCTA-QL

Ceiling Adapter

NORTH AMERICA

3130 East Miraloma Avenue

Anaheim, CA 92806 USA

USA and Canada –

Phone: 800-368-9700

Fax: 800-832-4888

EUROPE

Swallow House,

Shilton Industrial Estate,

Shilton, Coventry, England CV79JY

Phone: +44 (0) 2476 614700

Fax: +44 (0) 2476 614710

Other Locations – Phone: (001)-714-632-7100; Fax: (001)-714-632-1044

©Premier Mounts 2008

9533-030-001-01

Page 2 Installation Instructions

PP-FCTA-QL

Table of Contents

Warning Statements

Warning Statements 2

Parts List 3

Installation Tools 3

Plate Assembly 4

Securing the Plate 5

Electrical Box Installation 5

Ceiling Anchoring 7

Cable Lock Operation 8

Securing Pipe to PP-FCTA-QL 10

Technical Speciﬁcations 10

Warranty 11

Contact Premier Mounts with any questions

(800) 368-9700

[email protected]

Do not install near sources of high heat. Do not install on a structure that is prone to vibration, movement or chance of impact

This product is intended for indoor use only. Use of this product outdoors could lead to product failure and personal injury.

Be aware of the mounting environment. If drilling and/or cutting into the mounting surface, always make sure that there are no electrical wires in the surface

or utility pipe. Cutting/drilling into an electrical line may cause serious injury or property damage.

If mounting to studs, make sure that the mounting screws are anchored into the center of the studs. Use of an edge-to-edge stud finder is recommended.

At least two qualified people should perform the assembly procedure. Injury and/or damage can result from dropping or mishandling the product.

SAFETY MEASURES MUST BE PRACTICED AT ALL TIMES DURING THE ASSEMBLY OF THIS PRODUCT. USE PROPER SAFETY GEAR AND

TOOLS FOR THE ASSEMBLY PROCEDURE TO PREVENT PERSONAL INJURY.

THE SURFACE MUST BE CAPABLE OF SUPPORTING 250LBS. IF NOT, THE SURFACE STRUCTURE MUST BE REINFORCED. DO NOT

HAND OR ATTACH MORE THAN 50LBS. TO THIS PRODUCT. PROPER INSTALLATION PROCEDURE BY A QUALIFIED SERVICE

TECHNICIAN, AS OUTLINED IN THE INSTALLATION INSTRUCTIONS, MUST BE ADHERED TO. FAILURE TO DO SO COULD RESULT IN

SERIOUS PERSONAL INJURY, OR EVEN DEATH.

PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS PRODUCT FOR PURPOSES

OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY UNAUTHORIZED ATTACHMENTS OR MODIFICATIONS,

AND IS NOT RESPONSIBLE FOR ANY DAMAGES, CLAIMS, DEMANDS, SUITS, ACTIONS OR CAUSES OF ACTION OF WHATEVER KIND RE-

SULTING FROM, ARISING OUT OF OR IN ANY MANNER RELATING TO ANY SUCH USE, ATTACHMENTS OR MODIFICATIONS.

PRIOR TO THE INSTALLATION OF THIS PRODUCT, THE INSTALLATION INSTRUCTIONS SHOULD BE READ AND COMPLETELY

UNDERSTOOD. THE INSTALLATION INSTRUCTIONS MUST BE READ TO PREVENT PERSONAL INJURY AND PROPERTY DAMAGE. KEEP

THESE INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE LOCATION FOR FUTURE REFERENCE.

Installation Instructions Page 3

Parts List

This ceiling adapter comes packaged with installation hardware and components. Make sure that none of these parts

are missing and/or damaged before beginning installation. If there are parts missing and/or damaged, please stop the

installation and contact Premier Mounts (800-368-9700).

Ceiling Adapter

(Qty 1)

M5 x 16 Phillips Head

Screws (Qty 5)

1/4-20 Wing Nuts

(Qty 4)

Installation Tools

Phillips Head Screwdriver Cable Cutters Ladder

¼” x 3” Eye Lag Screws

(Qty 4)

1/16” Braided Cable

(Qty 4 Strands)

Quick Locks

(Qty 4)

PP-FCTA-QL

¼” x 3” Concrete Anchors

(Qty 4)

Page 4 Installation Instructions

Plate Assembly

Step 1. Assemble the plate.

Step 2. Place the lower adapter plate with the threaded

studs on it up through mounting plate.

Step 3. The threaded studs will align with the

adjustable slide on the mount.

Step 4. Once the two pieces are together, align the

mounting holes on the upper adapter plate with

the threaded shafts of the lower adapter plate.

Step 5. Place the three units together and loosely attach

four (4) 1/4-20 wing nuts onto the threaded

shafts.

Read all cautions and warnings before continuing.

PP-FCTA-QL

1/4-20 Wing Nuts

Upper Adapter

Plate

Lower Adapter

Plate

Wing Nut Threaded

Studs

Adjustable Slide

Step 6. Pre-set the M5 x 16 Phillips screws (two on

each outer ends) of the plate and one (1) on the

1½” NPT coupler.

Step 7. Observe the room and the ceiling; find the most

appropriate location for the projector placement

and lightly mark the bottom of the tile.

Step 8. Remove any of the 24” x 24” or 24” x 48” tiles

that are surrounding the marked tile.

Step 9. Measure 3” from the edge of the t-bar to the

inside of the tile (do this for all four edges of the

ceiling tile).

Step 10. The mounting hole should be located in the

center-most location of the ceiling tile.

Step 11. Once the mounting hole has been cut, place the

ceiling plate assembly on the t-bar rails.

Mount

M5 x 16mm

Screws

Slider Plate

Ceiling Plate

Assembly

Mounting Hole

T-Bar Frame

Ceiling Tile

Installation Instructions Page 5

PP-FCTA-QL

Securing the Plate

Adjust and Tighten

Wing Nut

M5 x 16mm Set

Screw

Tiles

T-Bar Frame Rails

Step 1. Position and slide the adapter plate to the hole and secure the ceiling plate to the rails by tightening the four (4) M5 x 16mm

Phillips head screws.

Step 2. Center the stud plate to the hole and secure the plate by tightening the four wing nuts..

Electrical installation should be done in accordance to local codes and regulations.

Step 1. Cut the tile where the electrical base box is going to be secured.

Step 2. Using (commercially available) hardware depending on electrical installation environment, install the electrical box and secure

it to the plate.

Step 3. Make all electrical connections at this time.

Electrical Box Installation

Electrical Box

Cut-out

CUT

Page 6 Installation Instructions

The electrical cut-outs allow for both single and square electrical box installations.

PP-FCTA-QL

Electrical Box

Installation Instructions Page 7

PP-FCTA-QL

Ceiling Anchoring

Truss Concrete Wood

Truss ceiling

Step 1. Loop the braided cable

around the truss.

Step 2. Run the open end through

the loop.

Step 3. Pull the open end down until

the braided cable tightens

around the truss.

Wood joist

Step 1. Secure the four (4) ¼” eye

lag screws to the wood joist

in the ceiling.

Step 2. Make sure eye lag screws

are properly secured to the

joistbeforesecuringthecable

to the cable locks on the

plate.

Step 3. Run the open end through

the hole in the eye lag

screw.

Step 4. Run the open end through

the loop.

Step 5. Pull the open end down until

the braided cable tightens

around the eye lag screw.

Concrete

Step 1. Determine the mounting

location.

Step 2. Use a 1/4” masonry drill bit

to pre-drill the mounting

holes.

Step 3. Place the concrete anchor

into the pre-drilled hole and

gently tap into place using a

rubber mallet or hammer.

Truss

Loop

Braided Cable

Loop

Eye Lag Hole

Concrete

Wood Joist

THE PP-FCTA-QL MUST SECURED USING THE SUPPLIED QUICK LOCKS AND

BRAIDED CABLES.

Braided Cable

Page 8 Installation Instructions

PP-FCTA-QL

Release Pin Release Pin

Release Pin

6” Excess

Braided

Cable Braided

Cable

Mounting Hole Mounting Hole Mounting Hole

Directional Input

Arrows

Directional Input

Arrows

Directional Input

Arrows

Cable Output

Cable Input

Directional Input Arrows

Release Pin

Directional Input Arrows

Feed braided cable into the Quick Lock (see

directional input arrows). To release the braided cable,

slide the release pin to disengage.

Quick Lock Operation

Installation Instructions Page 9

Braided

Cable

T-Bar

Frame

Ceiling

Tile

Quick

Lock

PP-FCTA-QL

Step 1. Thread each braided cable through the Quick Lock, the mounting hole in the corner of ceiling mount, and then completely

through the opposite side of the Quick Lock to secure.

Step 2. Adjust the braided cable tension. but do not overtighten.

Step 3. When adjusting the tension of the weight-bearing side of the Quick Lock, the cable must be pulled through the Quick Lock until

the desired tension is attained. Once attained, pull the braided cable through the other side of the Quick Lock.

Step 4. Once the tension has been adjusted, be sure that there is at least 6” of excess braided cable on the non-weight bearing side of the

Quick Lock.

Step 5. Use cable cutters to remove any remaining braided cable (optional).

To relieve tension on the braided cable, slide the release pin on the Quick Lock.

6” Excess-

Braided

Cable

Page 10 Installation Instructions

PP-FCTA-QL

Technical Speciﬁcations

All measurements are in inches [mm].

Securing Pipe to the PP-FCTA-QL

Step 1. Secure the 1½” (NPT) pipe to the ceiling plate and tighten by using one (1) M5 x 16 Phillips head screw (supplied)

to the plate.

1-1/2” Pipe

M5 x 16mm Set

Screw

1-1/2” Pipe

Ceiling Plate

Assembly

Tiles

T-Bar Frame Rails

The M5 x 16 Phillip head screw must be used to stabilize the 1½” (NPT) pipe.
