Premier Mounts BW-BASE Manual de usuario

Page 1

TL-BASE

PSD-HDCA

PSD-DPB

TS-BASE

DUAL POLE CARTS AND STANDS

POLE LENGTH OPTIONS

EB-BASE CS-BASE

BW-BASE

Nesting cart Lightweight stand

Floor stand

EB-BASE-C

Elliptical cart

Elliptical stand Floor stand (back to back)

Back to back adapter

includes with CS-BASE

Dual pole adapter

includes with all base

(except CS-BASE)

Poles are available in single or pair, black or chrome, full length or cut-in-half length [actual cut lengths]*.

Poles and splice collar (PSD-EXT), Sold separately.

40”

60” - [33/27]*

72” - [36/36]*

84” - [42/42]*

9500434 v1.0

publ. 07/22/20

PSD-EXT*

Installation Guide

DUAL POLE CARTS AND STANDS

Page 2

Type A Type B

INSTALLING THE PSD-HDCA

BW and EB bases TL, TS, CS bases

Tighten to engage the jaw.

Insert poles and align openings to

the set screws. Insert poles and align the openings.

Plastic

collar

Opening

FRONT

(4) M8 x 10

Set screws

Refer to PSD-HDCA installation manual for detail.

Installation Guide

DUAL POLE CARTS AND STANDS

Page 3

INSTALLING THE PSD-DPB

OPTIONAL

ACCESSORIES

CTM Series RTM Series UFA/USA Series Shelf Option

w/ additional

casters

Bolted

Ø 3/8” thru hole at four locations.

3/8”-16 x 1” long threaded stem.

Commercially available hardware

shown for reference.

Contact a sales representative for compatible mounting and bundling options.

Part Number Wheel Size Description

CAST-BW 3” dia. Set of 4, Black, 2 non-locking and

2 locking casters.

CAST 4” dia.

(4) M8 x 10

set screws

(8) M8 x 25

hex screws

w/ washers

Compatible

mounts and

accessories

Installation Guide

DUAL POLE CARTS AND STANDS
