Precision Digital Corporation NOVA PD570 Series Manual de usuario

LIMIT CONTROLLER

NOVA PD570 Series

Instruction Manual

PD570 & PD578

PRECISION DIGITAL CORPORATION

GGGGGGGGGGGGGGGGGGGGG

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Disclaimer

The information contained in this document is subject to change without notice.

Precision Digital Corporation makes no representations or warranties with

respect to the contents hereof, and specifically disclaims any implied warranties

of merchantability or fitness for a particular purpose.

Registered Trademarks

MODBUS®is a registered trademark of Schneider Automation Inc. All other

trademarks mentioned in this document are the property of their respective

owners.

Nova PD570 Series Model Number Guide

Options

10 = 1 alarm relay

14 = 1 alarm relay & RS-485

Main Control Output

A = 1 latching relay & 1 analog

output

0-6RA-10PD57

Limit Controller

Size - DIN Cutout

0 = 1/16 DIN

8 = 1/4 DIN

Power

6 = 100-240 VAC

Display

R = Red LED

GGGGGGGGGGGGGGGGGGGGwk\^WGzGuGwGG{GsGj pGtGGGGGGGGGGGGG

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

1. Safety Guide and Specifications 5

2. Front Panel Buttons and LED Indicators 11

5. Controller Parameter Setup

5.1 Input Group (G.IN) 14

5.2 Control Group (G.CTL) 18

5.5 Communication Group (G.COM) 27

3. Parameter Map

6. Error Display and Correction 29

7. Installation 30

7.1 Dimensions and Panel Cutouts

7.2 Panel Mounting 32

7.3 Power Cable Specification 33

7.4 Terminal Specification 33

7.5 Terminal Assignment, Connections, and Ratings 34

4. Operation Flow Chart 13

5.3 Alarm Group (G.ALM) 23

5.4 Retransmission Group (G.RET) 26

Table of Contents

1.1 Specifications 7

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

7.7 Signal Input Connection

7.8 Retransmission Output Connection (RET) 37

7.9 Relay Output Connection (RELAY) 37

7.10 Use of an External Relay 38

7.11 Communication Wiring (RS485) 39

7.6 Grounding and Power Cable Connection 36

Table 1: Universal Input Selection 14

Table 2: Alarm Selection 24

Fig 2: Bias Formula Calculation 16

Fig 3: Operation of Limit Functions with O.ACT set to REV 19

Fig 4: Operation of Limit Functions with O.ACT set to FWD 19

Fig 5: Example of Limit Control Relay Operation and Reset Function 20

Fig 6: Alarm Operation 24

Fig 1: Temperature Bias 16

Table of D-Registers 40

Appendix

Tables and Figures

[

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

1. Safety Guide and Specifications

Precautions Regarding This Instruction Manual

(1)This manual must be kept in the possession of theend userand in a suitable place for the operator to

study and to check the functions of the product.

(2)The installer and operator should carefully study and understand how to operate this product before use.

(3)This manual describes the functions of the product. Precision Digital Corporation does not guarantee

that the functions will suit a particular purpose.

(4)The contents of this manual have been reviewed for accuracyand correctness. However,should any

errors or omissions come to the attention of the user, contact technical support as listed on the backof this

manual

CAUTION

Safety Procedures and Unauthorized Modification Warning

(1)In order to protect this product and the system controlled by it against damage and ensure itssafe use,

make certain that all of the safety instructions and precautions in this manual arestrictly adhered to.

(2)Precision Digital Corporation does not guarantee safety if the products are not handled in accordance

with this instruction manual.

(3) If separate protection or safety circuits are to be installed in the system which is controlledbythis product,

ensure that such circuits are installed external to this product.

(4)Do not make modifications or additions internallyto the product. It may cause personal injury to the user or

damage to the product.

(5)Contact technical support as listed on the back of the manual for warranty and repairissues.

(6)Exposure to excessive moisture, electrical overloads, or mechanical vibration may damage the product.

CAUTION

Limited Liability

Precision Digital Corporation assumes no liability to any party for any loss or damage, direct or indirect,

caused by the use of or any unpredictable defect of the product.

CAUTION

The following safety symbols are used in this manual

(1) This symbol notifies the user of specific information relating to the safe operation of the controller.

Information noted with this symbol must be observed to protect the user from injuryand to prevent damage

to the product.

(A) For User: Be aware of this markinginthe manual and refer to the explanation in the manual to

prevent injury and damage.

(2) For Installer: Study the warnings marked to prevent injury and damage.

(2) Functional earth terminal: This symbol indicates that the terminal must be connected to ground.

(3) This symbol indicates additional information on the features of the product.

(4) This symbol directs the reader to further information on the current topic.

NOTE

CAUTION

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

CAUTION

Controller Mounting Precautions

Keep the input circuit wiring as far as possible away from power and ground circuits.

Keep the units in 10 to 50ºC (50 to 110ºF) with 20% to 90% relative humidity (RH).

The controller may need a warm up period to return to operating temperature ranges when below 10ºC.

To prevent electric shock, be sure to turn off the power source and circuit breaker before wiring.

The power requirements are 100 to 240 VAC, 50/60 Hz, 10 VA max. Do not switch power

supplies without first disconnecting the power supply.

Follow the operating procedures and precautions in the manual to avoid fire, shock, damage to the unit,

or injury. Follow the operations and mounting directions indicated in this manual.

Always create a ground connection where indicated, however do not ground to gas pipes,

water pipes, lightening rods, or other potentially hazardous metal objects.

Do not apply power to the unit until all connections have been made.

Do not cover the venting holes in the rear of the unit.

CAUTION

Operational Environment Precautions

(1)Only operate the controller when it is properly installed.

(2)When installing the controller, select a location where:

Rear terminals are protected from accidental contact.

Mechanical vibrations are minimal.

No corrosive gas is present.

Temperature fluctuation is minimal.

Temperature can be maintained between 10 and 50 ºC (50 and 110ºF) with 20 to 90% RH.

No direct heat radiation is present.

High levels of electromagnetic interference are not present

The unit is not exposed to water.

No flammable materials are present.

Dust particles are not present in the air.

Exposure to ultraviolet rays is minimal.

Openings on the rear of the controller are not blocked.

(3)This unit is suitable for installation in an enviornment classified as Pollution Degree 2.

(4)This unit is designated as Installation CategoryII.

(5)If the equipment is used in a manner not specified by the manufacturer, the protection provided by

the equipment maybe impaired.

(6)A switch or circuit-breaker acting as the disconnect device shall be included in the application or the

installation.

]

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

1.1 SPECIFICATIONS

General

DISPLAY Dual 4 digits, red LED, -1999 to 9999

DIN Sizes PV Display SP Display Weight

mm (inch) mm (inch) g (oz)

1/16 11.3 (0.45) 9.5 (0.37) 198 (7.0)

1/4 20.5 (0.81) 11.0 (0.43) 389 (13.7)

FRONT PANEL 1/16 DIN: IP65; 1/4 DIN: IP55

SAMPLINGTIME 250 ms

OVERRANGE Over range PV reads ovR, under range PV reads -ovR

PROGRAMMING Four front panel buttons and Modbus

METHODS

NOISEFILTER Programmable from 1 to 120

CALIBRATION All ranges are calibrated at the factory

MAX/MIN Max/min readings reached by the process are stored until

DISPLAY limit reset or until power to the controller is turned off.

OVERLIMIT Time since the last PV over limit occurnace is stored until the

TIMER system is reset by the user or until power to the controller is

turned off.

PASSWORD Programmable password restricts modification of

programmed settings

POWER 100-240 VAC, 50/60 HZ, 10 Watts

FUSE Required fuse: UL Recognized, 1 A, 250 V, slow blow

ISOLATION 2300 V input-to-output-to-power line;

4 kV relay output-to-input/output/power line

ENVIRONMENTAL Operating temperature range: 10ºC to 50ºC (50ºF to 110ºF)

Relative humidity: 20 to 90% non-condensing

MOUNTING 1/16 or 1/4 DIN size cutout required

Two panel mounting bracket assemblies provided for PD578

One one-piece bracket provided for the PD570

WARRANTY Three years parts and labor

Except where noted all specifications apply to operation at 23ºC.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

K1 -200 to 1370 -300 to 2500

K2 -199.9 to 999.9 0 to 2300 > 0°C : ±0.1% FS ±1 digit

J -199.9 to 999.9 -300 to 2300 < 0°C : ±0.2% FS ±1 digit

T -199.9 to 400.0 -300 to 750

B 0 to 1800 32 to 3300 > 400°C : ±0.15% FS ±1 digit

< 400°C : ±5% FS ±1 digit

R 0 to 1700 32 to 3100 ±0.15% FS ±1 digit

Thermocouple S 0 to1700 32 to 3100

E -199.9 to 999.9 -300 to 1800 > 0°C : ±0.1% FS ±1 digit

L -199.9 to 900.0 -300 to 1600 < 0°C : ±0.2% FS ±1 digit

U -199.9 to 400.0 -300 to 750

N -200 to 1300 -300 to 2400 > 0°C : ±0.1% FS ±1 digit

< 0°C : ±0.25% FS ±1 digit

W 0 to 2300 32 to 4200 ±0.2% FS ±1 digit

Platinel II 0 to 1390 32 to 2500 ±0.1% FS ±1 digit

PtA -199.9 to 850.0 -300 to 1560 ±0.1% FS ±1 digit**

PtB -199.9 to 500.0 -199.9 to 999.9

RTD PtC -19.99 to 99.99 -4.0 to 212.0 ±0.2% FS ±1 digit

JPtA -199.9 to 500.0 -199.9 to 999.9 ±0.1% FS ±1 digit**

JPtB -150.0 to 150.0 -199.9 to 300.0

0.4 to 2.0 V ±0.1% FS ±1 digit

1 to 5 V

Process 0to 10V

-10 to 20 mV

0 to 100 mV

0.400 to 2.000

1.000 to 5.000

0.00 to 10.00

-10.00 to 20.00

0.0 to 100.0

Temp Temp

Range (ºC) Range (ºF) Accuracy*

Input Type

UNIVERSAL INPUT TYPE AND ACCURACY

*Performance within recommended operating conditions (10 to 50°C, 20 to 90% RH)

**For a range scale of 0 to 100°C: +0.3°C +1 digit, and for a range scale of -100 to 100°C: +0.5°C +1 digit

Process and Temperature Inputs

TEMPERATUREDRIFT Refer to accuracy specifications below

DECIMALPOINT Up to three decimal places for process inputs:

9.999, 99.99, 999.9, or 9999

REAR JUNCTION Automatic or off settings for temperature inputs. No user

COMPENSATION calibration required.

OFFSETADJUSTMENT Four programmable input bias zones

SENSORBREAK Open sensor indicated by PV display flashing S.OPN.

DETECTION Up or down scale, user selectable; relays will follow the up

or down scale selection.

TRANSMITTER 14 to 18 VDC @ 20 mA; available at terminals OUT2 or

SUPPLY OUT3, instead of a retransmitting analog output

Display range can be scaled between -1999 and 9999.

4 to 20 mA Input

To accept a 4 to 20 mA signal, select 0.4 to 2.0 VDC input

and connect a 100 Ωresistor across the input terminals.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Relay Outputs

RATINGS Out1: 250 VAC @ 3 A or 30 VDC @ 3 A (resistive load)

Alarm: 250 VAC @ 1 A or 30 VDC @ 1 A (resistive load)

ELECTRICALNOISE A suppressor (snubber) should be connected to each

SUPPRESSION relay contact switching inductive loads, to prevent

disruption to the microprocessor's operation.

Recommended suppressor value: 0.1 μF/470 Ω,

250 VAC (PDX6901)

DEADBAND For alarm operations, 0-100% of full scale, user selectable

HIGH ORLOW User may program the alarm relay for high or low trip point

ALARM

DEVIATION ALARM User may program the alarm relay for a high, low, or range

set point deivation alarm.

RELAYOPERATION Out 1, the Limit Control Relay, will activate when the PV

exceeds the limit set point. It will remain in this state until the

PV no longer exceeds the limit set point and the relay is reset

by the user. The alarm relay may be set to any alarm type.

TIME DELAY 0 to 99 minutes 59 seconds alarm trip delay for each alarm.

FAIL-SAFE Programmable

OPERATION Independent for each alarm relay

AUTO INITIALIZATION When power is applied to the controller, alarm relays will

reflect the state of the input to the controller except standby

alarms.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Retransmitting Output

OUTPUTRANGE Retransmitting: 4 to 20 mA (600 Ω maximum)

SCALINGRANGE Any display range (see range for the input selected)

ACCURACY +0.1% of full scale

Serial Communications

PROTOCOLS Modbus (ASCII, RTU), PC software,

UNITADDRESS 1 to 99 (Max 31 units connected)

BAUD RATE 600, 1200, 2400, 4800, 9600, 19200 bps, user selectable

RESPONSETIME 0 to 100 ms delay response time

10 ms increments user selectable

DATA 7 or 8 bit user selectable

PARITY None, even, or odd

Approvals

ULRECOGNIZED USA and Canada

Process Control Equipment

UL FILE NUMBER E244207

CE COMPLIANT

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Controladores de Precision Digital Corporation

Precision Digital Corporation

Precision Digital Corporation PRO VU Series Manual de usuario

Precision Digital Corporation

Precision Digital Corporation ProtEX-MAX PD8-6310-6H2-WM Manual de usuario

Precision Digital Corporation

Precision Digital Corporation PROVU PD6310 Manual de usuario

Precision Digital Corporation

Precision Digital Corporation Helios PD2-6310-7H7 Manual de usuario

Precision Digital Corporation

Precision Digital Corporation ProtEX-MAX PD8-6310 Manual de usuario

Precision Digital Corporation

Precision Digital Corporation ProVu PD6210 Manual de usuario

Precision Digital Corporation

Precision Digital Corporation SuperNova PD500 Manual de usuario

Precision Digital Corporation

Precision Digital Corporation ProtEX-MAX PD8-6210 Manual de usuario

Precision Digital Corporation

Precision Digital Corporation ProtEX-MAX PD8-6210 Manual de usuario

Precision Digital Corporation

Precision Digital Corporation PD9000 ConsoliDator+ Manual de usuario

Precision Digital Corporation

Precision Digital Corporation ProVu PD6310-WM Manual de usuario

Precision Digital Corporation

Precision Digital Corporation SuperNova PD500 Manual de usuario

Precision Digital Corporation

Precision Digital Corporation ConsoliDator PD980-8K9-15 Manual de usuario

Precision Digital Corporation

Precision Digital Corporation CondoliDator 8 Manual de usuario

Precision Digital Corporation

Precision Digital Corporation ProtEX-MAX PD8-6310-WM Manual de usuario

Precision Digital Corporation

Precision Digital Corporation ProtEX-MAX PD8-6210 Manual de usuario

Precision Digital Corporation

Precision Digital Corporation ConsoliDator Plus PD9000 Manual de usuario

Precision Digital Corporation

Precision Digital Corporation PD9000 ConsoliDator+ Manual de usuario

Precision Digital Corporation

Precision Digital Corporation ConsoliDator+ Manual de usuario

Precision Digital Corporation

Precision Digital Corporation Helios PD2-6210 Manual de usuario

Precision Digital Corporation

Precision Digital Corporation ConsoliDator+ Manual de usuario

Precision Digital Corporation

Precision Digital Corporation Helios PD2-6310 Manual de usuario

Precision Digital Corporation

Precision Digital Corporation PD9000 ConsoliDator+ Manual de usuario

Precision Digital Corporation

Precision Digital Corporation NOVA PD540 Series Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
