POSIFLEX RT-2015E Manual de usuario

Package Contents

RT-2015E 15” fanless touch terminal or

RT-2016E 15.6” fanless touch terminal…..x1

Power adapter……………………………..x1

Power cord………………………………...x1

User manual……………………………….x1

Screw for back cover……………………...x1

Views of RT-2015E/2016E

Front View

15” RT-2015E

15.6” RT-2016E

Rear View

RT-2015E/2016E

Fanless Touch POS Terminal

User Manual

P-Cap Touch Panel

LED indicator

Camera (Optional)

System Back Cover

Attachment Bay

Wall- Mount

Screw Hole

16950902010 Ver. A0

http://www.posiflex.com

Bottom View

Right-Side View

Left-Side View

Release Lever for System Back Cover

Brightness Adjustment Button ＋

Power Button

Brightness Adjustment Button －

Rubber Shield for USB2.0 Port

Screw Hole

View of I/O Interface of RT-2015E/2016E

Bottom Side

Left Side

Connecting Power Adapter and Cables

The following provides instructions required to connect your cables.

1. To remove the back cover, hold down the

release levers at the bottom of the system

back cover and then pulling the cover

outwards.

2. Connect the connector of the power adapter to

the DC-IN power jack. If necessary, properly

insert other cables into the correct ports.

24V PoweredUSB Port

DB9 COM Port

CR Port

LAN Port

DC IN Power Connector

Mini DisplayPort

RJ50 COM Ports

USB 2.0 Ports

USB 2.0 Port

USB 3.0 Port

3. Neatly arrange the cables along the cable slots.

4. Place back the sytem back cover. Make sure it

is well locked into place with a click sound.

5. Make sure the cable could be pulled out of the cable exit from the bottom

of the base.

6. Locate the dedicated back cover screw from the

packing box. Then, please insert the screwinto

the screw hole indicated in the figure, and secure

it.

Installing Optional Upgrade Kits and Peripherals

RT-2015E/2016E is an expandable model which allows you to upgrade its own

capacity by additionally installing multiple peripheral devices, such as

magnetic stripe reader (MSR), fingerprint or iButton sensors, and 2nd POS

monitor, according to your preference. The following will give you brief

instructions on how to expand on your current POS system with these optional

upgrade kits. Before proceeding with the installation of peripherals, please

make sure the POS system is completely shut down to prevent damage.

Status LED Indicator

LED status indicator, which is located at the bottom edge of the LCD panel, is

mainly responsible for notifying users of the current system status by emitting

various LED signals. In the chart provided below, it describes all the possible

LED status as a quick reference.

15” RT-2015E

LED Status

Description

Off

System power OFF

Green

System standby

Blue

System power ON

15.6” RT-2016E

LED Status

Description

Off

System power OFF

Orange

System standby

Blue

System power ON

Powering ON/OFF RT-2015E/2016E

Power ON RT-2015E/2016E

Press down the power button to power on the POS.

Power OFF RT-2015E/2016E

In most cases, press the power button of the POS to power

the system off. If the terminal fails to turn off the machine

for unknown reasons, please be advised to hold the power

button more than 10 seconds to force a shutdown of the

system.

Installing an Operating System

You are highly advised not to install an operating system on

RT-2015E/2016E without professional instructions. Improper installation

could lead to system malfunction or failure. Please contact with your dealers

about the issues of operating system installation.

Power

Button

Performing System Recovery

For RT-2015E/2016E model with preloaded operating systems, Recovery

DVD which includes useful utilities will be provided in the package to assist

you in efficiently restoring or repairing your damaged system. However, you

are not encouraged to recover your system without the help of system

integrators. Please be advised to contact your service center for further

assistance with system recovery.

Operation Environment

To prevent RT-2015E/2016E from overheating, it is suggested to position your

terminal in a well-ventilated working environment. In doing so, please be

advised to keep the POS terminal at least 25mm away from other devices to

ensure the machine is properly cooled down and functioning normally.

Specifications

RT-2015E

RT-2016E

CPU

Intel Bay Trail-D

Intel Celeron - J1900 (2.0 GHz, QC, 10W TDP)

System Memory

1 x DDR3L SO-DIMM

Storage Port

2 x S-ATA port

Power Source

12V/60W external power adapter (can be upgraded

to 150W while adopting poweredUSB module)

LCD Panel

15" with LED

backlight

15.6" LCD with LED

backlight

LCD Resolution

1024 x 768

1920 x 1080 FHD

Touch Sensor

P-CAP touch

Serial Port

3 ports, 1 x DB9 + 2 x RJ-50 (on I/O plate)

USB Port

(External Port)

1.) 3, 1 x USB 3.0 (on I/O plate) + 2 x USB2.0 (1

on I/O plate + 1 on side edge)

2.) 1 x 24V PoweredUSB port

PoweredUSB

Port

1 x 24V PoweredUSB port

LAN Port

1 x 10/100/1000 Mb (on I/O plate)

Display Port

1.) eDP connector (internal header, support 15.6"

LCD)

2.) 1 x Mini DP port (on I/O plate)

CR Port

1 port, controlling 2 CR (on I/O plate)

Audio Port

1 x internal 2W speaker

Expansion Slot

1 x M.2 slot

Dimension

(W x V x D in mm)

368 x 292 x 46.6

402 x 251 x 41.2

Weight

5.9 kg

5.0 kg

Environmental

Requirements

Operating：

0°C 〜40°C, 20%RH - 90%RH (with HDD)

0°C 〜50°C, 20%RH - 90%RH (with SSD)

Storage：

-20°C 〜70°C, 10%RH - 90%RH

Regulation Rules

FCC/CE

Attachment

RA-101

Slim MSR attachment for RT series

RA-103

iButton (or RFID) with one USB port attachment

for RT series

RA-104

2D scanner attachment for RT series

RA-301

3-in-1 MSR + Fingerprint Sensor + 2D scanner

attachment for RT series

LM/TM-4010DP

9.7" 2nd display for RT series terminal

LM/TM-4011DP

10.1" 2nd display for RT series terminal

LM/TM-4015DP

15" 2nd display for RT series terminal

※

The product information and specifications are subject to change without

prior notice. To get the detailed information on the RT-2015E/2016E,

please check this model from Posiflex Global Website.

This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions manual, may cause

interference to radio communications. It has been tested and found to comply

with limits for a Class A digital device pursuant to subpart J of Part 15 of FCC

Rules, which are designed to provide reasonable protection against

interference when operated in a commercial environment. Operation of this

equipment in a residential area is likely to cause interference in which case the

user at his own expense will be required to take whatever measures to correct

the interference.

This is a class A product. In a domestic environment this

product may cause radio interference in which case the user

may be required to take adequate measures.

CAUTION

RISK OF EXPLOSION IF BATTERY IS REPLACED

BY AN INCORRECT TYPE

DISPOSE OF USED BATTERIES ACCORDING

TO THE INSTRUCTIONS

警告

本電池如果更換不正確會有爆炸的危險

請依製造商說明書處理用過之電池

警告使用者

這是甲類的資訊產品，在居住的

環境中使用時，可能會造成射頻

干擾，在這種情況下，使用者會

被要求採取某些適當的對策。
