PLACING AND ANSWERING AUDIO CALLS

VVX 301, 401, 501 and 601 can manage a maximum of 24 active, incoming, and held audio calls at

a time. However, you can have only one active call in progress with numerous other incoming calls

or calls on hold on all phones. Additionally, your system administrator can set up your phone to

have up to six lines with unique extension numbers, or the same extension number as other lines

on your network.

PLACING AUDIO CALLS

You can place audio calls on your phone, and you have the option to use the handset, the

speakerphone, or a headset.

To place a call from the Dialer

1. Do one of the following:

a. Start typing a phone number.

b. Press a line key, OR

c. Pick up the handset, or press the Speakerphone key or Headset key.

2. Enter a number or select a recent contact. On VVX 501 and 601 phones, tap the onscreen

keyboard icon pad to enter numbers.

3. On VVX 301 and 401 phones, select Dial. On VVX 501 and 601 phones, tap the Dial icon.

REDIALING A NUMBER

Your phone automatically keeps a record of all the calls placed on your phone. You can recall the last

contact you call using the Redial icon or soft key.

To redial a number:

1. Do one of the following:

a. Select the Redial icon on the Home screen.

b. Press the Redial soft key.

SWITCH AMONG THE HANDSET, HEADSET, AND SPEAKERPHONE

To switch among methods:

During a call, pick up the handset, press the Headset key or press the Speakerphone key.

For example, if you’re using the handset, press the Headset key to switch to the headset,

or press the Speakerphone key to switch to the speakerphone.

POLYCOM®

Phone User Guide

For more information, visit epb.com/customer-support/business-support

or call 423-648-1500, option 2

When using the speakerphone, the Speakerphone key glows green. When using the headset, the

Headset key glows green if an analog headset is connected or blue if a USB headset is connected.

HOLDING AND RESUMING CALLS

When you are in a call, you can place a call on hold and resume the call.

To hold a call:

During an active call, select Hold. If you’re in the Calls screen, highlight the call rst.

A hold icon is displayed on the line of the held call, and a red LED light ashes on the line key for

all phones.

To resume a held call:

1. Do one of the following:

a. Select Resume.

b. From the Calls screen, select the call to highlight it, and select Resume.

TRANSFERING A CALL

You can transfer a call to another contact and choose the transfer type you want to use for the call.

To transfer a call:

1. During a call, do one of the following:

a. Press Transfer to use the default transfer type.

b. Press and hold Transfer and select a transfer type - either Blind or Consulative.

2. Dial a number or choose a contact from the call list or directory. If the transfer type is set to

Blind, the call is transferred immediately.

3. If the transfer type is set to Consultative, press Transfer after speaking with your contact.

MANAGING CALLS

You can see the number of calls for each line from the Lines screen, as shown next. On all VVX

phones, a green light on the line key indicates a line with an active call, and a red light indicates

a line with one or more held calls.

To manage a call from the Calls screen:

1. Select a call. The call is highlighted.

2. Do one of the following:

a. Select Hold to place an active call on hold.

b. Select Resume to make a held call active.

For more information, visit epb.com/customer-support/business-support

or call 423-648-1500, option 2

c. Select End Call to end a call with a contact. You can end active calls only, so resume the held

call rst before ending it.

d. Select Transfer to send the call to another contact.

e. Select Conference to initiate a conference call.

IGNORE OR SILENCE INCOMING CALLS

You can ignore or silence a call to stop your phone from ringing. Even if you ignore the call and

silence the ringer, an incoming call notication continues to display on your phone.

To ignore or silence a call:

From the Incoming Call screen, select Ignore for private lines, or Silence for shared lines.

The Incoming Call screen disappears, your phone stops ringing, and either the Home or Calls

screen is displayed.

Reject Incoming Calls

You can reject a call and send the call directly to voicemail. Rejected calls display in the Missed Calls

list in your Recent Calls list. Rejecting calls is not available for shared lines.

To reject an incoming call:

From the Incoming Call screen, select Reject. The call goes directly to voicemail.

INITIATING CONFERENCE CALLS

You can initiate an audio conference call with two contacts and hold, resume, or split a conference

call on your VVX phone. VVX phones can manage a maximum of 12 active or held conference calls

at a time. However, you can have only one active conference call in progress with numerous other

conference calls on hold.

Initiate Conference Calls

You can initiate a conference by calling two people and selecting the Conference soft key or hard key.

To initiate a conference call:

1. Call a contact.

2. After the contact answers, select the Conference soft key. The call is held.

3. Enter another contact’s number or select a contact from the directory or the call lists.

4. When the contact answers, select the Conference soft key. All call participants are added to a

conference call.

WORKING WITH SHARED LINES

All VVX phones support multiple and shared lines. Your administrator can customize your phone so

that you have multiple shared lines enabled.

For more information, visit epb.com/customer-support/business-support

or call 423-648-1500, option 2

The following features are not available or have limitations on phones with shared lines:

• Forwarding an incoming call is not available.

• Enabling Do Not Disturb on shared lines disables ringing only, and a visual notication of the call

is displayed with the option to answer the call.

MANAGE CALL LISTS AND DIRECTORIES

VIEW RECENT CALLS

All VVX phones maintain a Recent Calls list that includes missed, received, and placed calls.

Each list holds up to 100 entries.

You can perform the following tasks from the Recent Calls list:

• Remove calls from the list.

• Select a call record to view call details.

• Select a call record to automatically call a contact.

To view your Recent Calls list:

Navigate to Directories > Recent Calls.

VIEW CALL DETAILS

In the Recent Calls list, you can view call details, edit call details before calling a contact,

save a contact to your directory, and delete call entries.

To view call details:

Select Info or tap the Info icon next to a call record.

SAVE A RECENT CONTACT

From the Call Details screen, you can save a contact to the Contact Directory.

To save a contact to your Contact Directory:

From the Call Details screen, select Save. If the person is already in your Contact Directory,

but is not a favorite, Add to Favorites is displayed.

DELETE A CONTACT

You can delete contacts from the Recent Calls list.

For more information, visit epb.com/customer-support/business-support

or call 423-648-1500, option 2

To delete a contact from the Recent Calls list:

Select Delete or tap the Delete icon.

EDIT RECENT CONTACT ENTRIES

You can edit a contact’s phone number stored in your Recent Calls list before returning the contact’s call.

To edit a recent contact’s number before calling the contact:

1. Select Edit or tap the Edit Number icon.

2. Edit the number, and select Dial or tap the dial icon.

COMMPORTAL WEB INTERFACE

This helpful tool enables you to manage your phone and settings through an easy-to-use

Web based portal.

LOGGING IN

1. Go to https://phone.epbFi.com

2. Enter your phone number.

3. Enter your password (same as your voicemail PIN).

DASHBOARD PAGE

This displays new voice messages, recent received and missed calls, contacts and settings you have

applied to your phone.

MESSAGES & CALLS

• The Messages tab displays new and saved voice messages. Play, delete or mark as

heard/unheard.

• Missed Calls, Dialed Calls and Received Calls show you all your recent call activity.

CALL MANAGER

• The Summary tab of Call Manager provides a description of what will happen to your incoming calls.

• The other tabs enable you to change the settings of your call coverage, including Call

Forwarding, Do Not Disturb and Find Me/Follow Me.

CHANGE PASSWORD

1. Go to Settings page.

2. Click Change Password next to Account Password.

3. Enter your new password in the Conﬁrm Password box.

For more information, visit epb.com/customer-support/business-support

or call 423-648-1500, option 2

4. Re-enter your new password.

5. Click Change Password.

CONFIGURE PHONE KEYS

1. Select the Settings page.

2. Click on the Set Keys link.

SET THE TIME AND DATE DISPLAY

To update the time and date display:

1. Navigate to Settings > Basic > Preferences > Time & Date.

2. From the Time & Date screen, do one of the following:

a. Select Clock Date to change the date format.

b. Select Clock Time to change the time format.

VOICEMAIL-TO-EMAIL

1. Log into CommPortal.

2. Click the Settings tab.

3. Click Messages tab under settings.

4. Check the Forward Messages as Emails check box.

5. Click on the text Add an Email Address.

6. Enter your email address. If you want to leave the message in the inbox, check the Leave

Original in Inbox check box. (This will NOT clear when you check your email messages,

you will have to go and delete them thru the phone or CommPortal).

7. Click Apply for your changes to work.

DELETE MESSAGES FROM IN BOX

1. Login to CommPortal.

2. Click the Messages & Calls tab. Here you can listen, delete or forward messages to another

voicemail box or an email. You can even reply if you have microphone set up on your computer.

3. To delete, click the X to the right of each message you want to delete. That message will be sent

to the Deleted tab, where it will stay for a specied amount of time.

4. To permanently delete messages, go to the Deleted tab and click the Xto the right of message.

5. Under both the Messages & Deleted tabs you have the option to delete all at one time. Click

the Delete All tab at bottom left of each screen.

For more information, see the Help Section under the gear icon in the upper right hand corner of the

CommPortal screen.

CUSTOMIZE YOUR PHONE

For more information, visit epb.com/customer-support/business-support

or call 423-648-1500, option 2

CUSTOMIZE YOUR PHONE

SET THE LANGUAGE Your phone supports several languages that you can choose to display.

Check with your system administrator to nd out which languages are supported on your phone.

To change the language:

1. Navigate to Settings > Basic > Preferences > Language.

2. From the Language screen, select a language. The language on your phone updates

automatically.

SET THE TIME AND DATE DISPLAY

To update the time and date display:

1. Navigate to Settings > Basic > Preferences > Time & Date.

2. From the Time & Date screen, do one of the following:

a. Select Clock Date to change the date format.

b. Select Clock Time to change the time format.

c. Select Clock Order to change the order of the time and date display.

3. From the Clock Date, Clock Time, or Clock Order screen, select the format you want.

SELECT A BACKGROUND PICTURE

To change the background picture:

1. Navigate to Settings > Basic > Preferences > Background. The Background screen is

displayed. Depending how your system is set up, you might have to navigate to Settings >

Basic > Preferences > Background > Select Background. The Select Background

screen is displayed instead.

2. Select a background image, if available.

Adding Personal Photos as Your Background

You can upload a personal photo to use as your background using the Web Conguration Utility

or using a USB ash drive on VVX 501 and 601 phones. When you set one of your pictures as the

background picture, the picture is displayed as Local File in the Backgrounds list.

ENABLE TRANSPARENT LINE KEYS

By default, your phone displays line keys with a blue background. If you have a background picture

set on your VVX phone, the background is partially or fully covered depending on the amount of

line keys you have. On VVX 501 and 601 phones, you can change line keys to have a transparent

background that enables you to fully see the background you set for your phone.

For more information, visit epb.com/customer-support/business-support

or call 423-648-1500, option 2

To enable transparent line keys:

1. Navigate to Settings > Basic > Preferences > Idle Screen Settings.

2. On the Idle Screen Settings screen, select Transparent Lines, and select Enabled. The

line keys are displayed without a background, as shown next.

ENABLE SCREEN SAVERS

The screen saver automatically starts each time your phone is idle for a certain amount of time.

When you enable the screen saver, you can choose to have your phone either display default photos

stored on the phone, or the idle browser.

To enable a screen saver:

1. Navigate to Settings > Basic > Preferences > Screen Saver.

2. From the Screen Saver screen, select Screen Saver and select Enabled.

3. Select Wait Time and enter the number of minutes the phone can wait after no activity before

displaying the screen saver. You can enter any time between one and 9999 minutes.

The default time is 15 minutes.

4. Select Type and select either Default or Idle Browser.

5. Press Save.

You can stop the screen saver at any time by Pressing any key or touching the screen. When your

phone is idle again for a specied period of time, the screen saver starts again.

Use Personal Photos as Screen Savers

On VVX 501 and 601 phones you can enable your phone to display your personal photos as a screen

saver. To set up a screen saver of your pictures, you need to set up certain screen saver settings,

place your pictures on a USB ash drive, and attach the USB ash drive to the phone.

CHANGING AUDIO SETTINGS

Change Incoming Call Notiﬁcations

You can choose whether you hear sound eects—all phone sounds except call audio—from

the handset, headset, speaker, or the active audio device you set. For example, you can congure

your phone to ring on your headset instead of the speaker. By default, you hear all sound eects

from the speaker.

To change your incoming call notiﬁcations:

1. Navigate to Settings > Basic > Preferences > Audible Ringer.

2. From the Audible Ringer screen, select a location to hear sound eects.

For more information, visit epb.com/customer-support/business-support

or call 423-648-1500, option 2

SET A RINGTONE FOR INCOMING CALLS

A simple way to personalize your phone is to change your phone’s ringtone. You can pick unique

ringtones for the dierent lines on your phone. The default ringtone is Low Trill.

To select an incoming call ringtone for your phone or a line:

1. Navigate to Settings > Basic > Ring Type.

2. When there are multiple lines on your phone, select a line.

3. From the Ring Type screen, select a ringtone.

4. Select Play or tap the Play icon to hear the ringtone.

SET A RINGTONE FOR INDIVIDUAL CONTACTS

You can select unique ringtones for various contacts in your directory. This helps you quickly identify

callers as your phone rings.

To select a ringtone for a contact:

1. From your Contact Directory, select a contact.

2. From the Contact Information screen, select Edit or tap the Edit icon.

3. From the Edit Contact screen, select Ring Type and select a ringtone.

4. Select Play or tap the Play icon to hear the ringtone.

5. From the Edit Contact screen, select Save.

CHANGE THE VOLUME

You can increase the volume of your ringtone and the audio during a call.

To change the volume of the ringtone or audio during calls:

Press one of the Volume keys to increase or decrease the audio.

For more information, visit epb.com/customer-support/business-support

or call 423-648-1500, option 2

Otros manuales para VVX 601

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Teléfono IP de Polycom

Polycom

Polycom SoundPoint IP 550 Manual de usuario

Polycom

Polycom VVX 400 Manual de usuario

Polycom

Polycom SoundPoint IP 335 Manual de instrucciones

Polycom

Polycom VVX 250 Manual de usuario

Polycom

Polycom CX300 Manual de usuario

Polycom

Polycom VVX 600 series Manual de usuario

Polycom

Polycom SoundPoint IP 550 Manual de usuario

Polycom

Polycom SoundPoint 600 SIP Manual de usuario

Polycom

Polycom SoundPoint IP 450 Manual de usuario

Polycom

Polycom SoundPoint IP 331 Manual de usuario

Polycom

Polycom SoundPoint IP 500 Manual de usuario

Polycom

Polycom SoundPoint IP 550 Manual de usuario

Polycom

Polycom VVX 4 Series Manual de usuario

Polycom

Polycom SoundStation IP 5000 Manual de usuario

Polycom

Polycom SoundPoint IP 321 Manual de usuario

Polycom

Polycom VVX 201 Manual de usuario

Polycom

Polycom SoundPoint IP 320 Manual de servicio

Polycom

Polycom SoundPoint IP 560 Manual de usuario

Polycom

Polycom VVX 600 series Manual de instrucciones

Polycom

Polycom VVX-250 Series Manual de instrucciones

Polycom

Polycom VVX 400 Manual de usuario

Polycom

Polycom SoundPoint Manual de instalación y operación

Polycom

Polycom SoundPoint IP 321 Guía de instalación

Polycom

Polycom SoundPoint IP 300 Manual de instrucciones

Manuales populares de Teléfono IP de otras marcas

Alcatel

Alcatel 4028 Manual de usuario

Cisco

Cisco SPA-500 Series Manual de usuario

Proximus

Proximus Maestro 3016 IP Manual de usuario

Fanvil

Fanvil X4 Manual de usuario

Cisco

Cisco 7962 Manual de usuario

Snom

Snom 320 Manual de usuario

Yealink

Yealink Yealink SIP-T46G Manual de usuario

Avaya

Avaya 4625SW Manual de usuario

Yealink

Yealink SIP-T52S Manual de usuario

Nortel

Nortel 1140E Manual de usuario

Nexotek

Nexotek NT-P500 Manual de usuario

Avaya

Avaya Integral 5 R3.0 Manual de usuario

GE 28320EE2 - Dect 6.0 InfoLink 2 Manual de usuario

Avaya

Avaya 4600 Series Manual de servicio

Mitel

Mitel MIVOICE OFFICE 400 6940 SIP Manual de usuario

Nortel

Nortel i2050 Manual de usuario

Fiberme

Fiberme FAP260 Series Manual de usuario

Meridian

Meridian M5009 Manual de usuario
