Plantronics GAMECOM X95 - QUICK START GUIDES Manual de usuario

Pair/Connect

button

LED

Power

button

CONNECT

GameCom®X95™:

1. Place batteries in headset.

2. Connect the wireless adapter to the Xbox.

3. Press the Power button for 2 seconds to turn the

headset on. The headset and the adapter should

connect immediately (see LED status on reverse).

If you cannot hear anything through your headset,

try adjusting the volume up or restarting the

game or application.

If headset is still not paired

(see LED status on reverse)

you can manually pair your

headset and adapter.

From powered off state,

press the Power button

for 6 seconds until LED

begins to ﬂash rapidly.

Release the button; headset

is now in pairing mode.

On wireless adapter: press the Pair/Connect button

on the wireless adapter for 6 seconds until the LED

ﬂashes rapidly. Release button; headset and adapter

should now be paired.

TROUBLESHOOT

HEADSET

STATUS/CONDITION LED STATUS OR ACTION

Paired/connected LED solid blue ﬂash

Pairing LED rapid blue ﬂash

Not connected LED slow blue ﬂash

Pairing fails If pairing mode times out, LED

changes from rapid ﬂash to

headset power off

Power off 2 second button press,

LED gets bright then turns off

Power on Press the Power button for

2 seconds, LED comes on to

appropriate status

Low battery LED triple blue ﬂashes

Auto shut down Headset shuts down after

deﬁned period of time with no

signal from wireless adapter

WIRELESS ADAPTER

Paired LED solid blue ﬂash

Pairing LED rapid blue ﬂash

LED slow blue ﬂash

Pairing fails If pairing mode times out,

LED goes into “not connected”

state

Patents US D589492; Brazil DI68056010; China ZL200830349586.8;

EM 001053631-0001; Taiwan D132123; and Patent Pending

84246-01 (09.10) Rev B AM 84247-01

STATUS/CONDITION LED STATUS OR ACTION

Not connected

Pair/Connect

button

LED

Power

button

CONNECT

GameCom®X95™:

1. Place batteries in headset.

2. Connect the wireless adapter to the Xbox.

3. Press the Power button for 2 seconds to turn the

headset on. The headset and the adapter should

connect immediately (see LED status on reverse).

If you cannot hear anything through your headset,

try adjusting the volume up or restarting the

game or application.

If headset is still not paired

(see LED status on reverse)

you can manually pair your

headset and adapter.

From powered off state,

press the Power button

for 6 seconds until LED

begins to ﬂash rapidly.

Release the button; headset

is now in pairing mode.

On wireless adapter: press the Pair/Connect button

on the wireless adapter for 6 seconds until the LED

ﬂashes rapidly. Release button; headset and adapter

should now be paired.

TROUBLESHOOT

HEADSET

STATUS/CONDITION LED STATUS OR ACTION

Paired/connected LED solid blue ﬂash

Pairing LED rapid blue ﬂash

Not connected LED slow blue ﬂash

Pairing fails If pairing mode times out, LED

changes from rapid ﬂash to

headset power off

Power off 2 second button press,

LED gets bright then turns off

Power on Press the Power button for

2 seconds, LED comes on to

appropriate status

Low battery LED triple blue ﬂashes

Auto shut down Headset shuts down after

deﬁned period of time with no

signal from wireless adapter

WIRELESS ADAPTER

Paired LED solid blue ﬂash

Pairing LED rapid blue ﬂash

LED slow blue ﬂash

Pairing fails If pairing mode times out,

LED goes into “not connected”

state

Patents US D589492; Brazil DI68056010; China ZL200830349586.8;

EM 001053631-0001; Taiwan D132123; and Patent Pending

84246-01 (09.10) Rev B AM 84247-01

STATUS/CONDITION LED STATUS OR ACTION

Not connected
