LEARN

M100™Bluetooth®Headset

LEARN

Voyager™PRO+

Bluetooth®Headset

TAKE A GOOD LOOK

CALL BUTTON

• Takeacallorendit (1 tap)

• Redial(2 taps)

• Initiatephone’svoice-dialing

(2-second press until tone heard)

• Reconnectlostconnection (1 tap)

• Transferaudioto/fromheadset

(1-second press while on a call)

• DialPlantronicsVocalystTMvoice

andtextservice(3 taps) (Available

in U.S. only)

POWER BUTTON

• Onoroff(2-second press)

• Batterylevelvoicealerts(1 tap)

• Activatepairingafterinitialsetup

(press until LED ﬂashes red/blue)

MICRO USB CHARGING PORT

• WithACcharger:

90 minutes for full charge

• Fullychargebeforerstuse

• Bestperformancewhenfullycharged

VOLUME/MUTE BUTTONS

• Volume:up/down(tap + or – buttons per

level change)

• Muteduringacall:on/off(1-second press

of both + and – buttons)

• Musicoraudio:pause/play(1-second

press of both + and – buttons)

LED

• Charging(solid red)

• Batterystatus(1-6 hrs left = 1 red ﬂash,

low = 2 red ﬂashes, critically low = 3 red

ﬂashes)

• Missedcall(3 purple ﬂashes, repeats for

5 minutes or until canceled by tapping

Call button)

• Pairingmode(repeating blue/red ﬂashes)

• Multipoint (on = 2 blue ﬂashes, off =

1 blue ﬂash)

Besafe!Pleasereadthesafetyguidebefore

usingyournewheadset.

CONNECT TO YOUR PHONE

“Pairing” connects your

headset to your phone.

“Multipoint” lets you use

this headset with two phones.

Activate this feature before

pairing your second phone.

1. READY

Activate the Bluetooth feature on

your phone, then use the phone’s

settings to add/search/discover

new Bluetooth devices.

iPhone: Settings > General >

Bluetooth > On

(starts the search for devices)

BlackBerry®smartphone:

Settings/options >

Bluetooth: On >

Search for devices

VIDEO TUTORIAL IN USA:

www.plantronics.com/pairing

2. SET

FirstTime:

With headset turned off, activate

Bluetooth pairing mode by pressing

the Power button. The LED ﬂashes

red/blue to indicate pairing mode.

ActivateMultipoint:

While pressing the Call button, turn

on the headset and keep pressing

the Call button until LED ﬂashes

blue twice. (Repeat to deactivate.)

PairingSecondPhone/

ReconnectingOriginal:

Start in “OFF” mode. Press and

hold the Power button until the

LED ﬂashes red/blue.

3. CONNECT

Select “VoyagerPRO+” from the

list of Bluetooth devices shown

on your phone.

If phone asks for a passcode, enter

four zeros (0000). You may see

**** on screen.

Some phones also ask to conﬁrm

headset connection after pairing.

Headset LED will stop ﬂashing red/

blue once your phone and headset

are successfully paired/connected.

MIX AND MATCH FOR BEST FIT

The headset comes with the medium eartip installed, but

you can replace it with the optional small or large eartip

provided.

RemovingtheEartip:

1. Grip the eartip and gently push it into the speaker

housing then rotate it a quarter turn to the left to

unlock.

2. Pull the eartip away from the headset.

AttachingaNewEartip:

1. Align the tabs on the eartip with the slots on the

speaker housing.

2. Gently push the eartip into housing while turning

it a quarter turn to the right. The eartip will stop

rotating when it is locked.

You may want to add the foam eartip covers

for additional comfort.

SoftGelEartips

(S,M,L)andFoam

EartipCovers

TRY IT ON

For the best sound clarity and comfort, make sure

you have a secure ﬁt.

TheOver-and-InTechnique:

1. Guide the earloop behind your ear and position

the headset so that the speaker and eartip rest

comfortably in your ear.

2. Pivot the boom up or down to point the microphones

toward the corner of your mouth.

TheQuick-TurnAdjustment:

1. Pivot the boom into an upright position.

2. Rotate the boom and speaker to the other side

of the headset and lower it before ﬁtting the headset

on your other ear.

MORE ABOUT MULTIPOINT

Plantronics VoyagerPRO+ supports

multipoint technology, which allows

you to use one headset with two

different Bluetooth mobile phones.

To pair your headset to a second

phone, see “Connect to Your Phone”.

How to Initiate a Call

When multipoint is on, the headset

initiates or redials a call from the

phone that last made an outgoing

call.

To use the second paired phone

instead, make the call using the

controls on that phone. The second

phone activates its link with the

headset.

NOTE: The headset cannot place a

current call on hold while answering

a call from the second phone.

How to Answer a Call While Talking

on the Other Paired Phone

To answer a second call on the

other phone, the current call must

be terminated or transferred back

to the ﬁrst phone. To transfer the call,

see “Take a Good Look”.

If you choose not to answer, the

second call will go to voice mail.

Answeringanincomingcallfrom

thesecondphone,whilealreadyon

anothercall:

1. To answer the second call, end the

ﬁrst call by tapping the Call button.

2. Answer the second call by tapping

the Call button again.

TIP: To avoid issues with multipoint,

use the Call button on the headset

rather than your phone controls.

LISTEN TO THE VOICE

WHAT YOU’LL HEAR WHEN YOU’LL HEAR IT

PowerOn After pressing the Power button for 2 seconds

PowerOff After pressing the Power button for 2 seconds

TalkTime:(“6hrs”,“5hrs”,“4hrs”,

“3hrs”,“lessthan2hrs”)

After powering the headset “on”

BatteryLow When you have under 30 minutes left before the

battery must be recharged

RechargeHeadset When you have approximately 10 minutes left before

the battery must be recharged

Connected After turning the headset on or reconnecting a dropped

Bluetooth signal

Phone1Connected After powering the headset to “on” or reconnecting a

dropped Bluetooth connection

Phone2Connected After pairing a second phone using multipoint feature

Pairing While the headset and phone are trying to pair/connect

PairingSuccessful After the headset and phone are successfully paired/

connected

PairingIncomplete,RestartHeadset After the headset and phone tried to pair but failed

MuteOn After pressing the Volume + and - buttons simultane-

ously during a call

MuteOff When on mute, after pressing the Volume + and -

buttons simultaneously during a call

LostConnection When the phone loses the Bluetooth connection with

the headset

VolumeMaximum When the highest volume level is reach after tapping

Volume + button

VolumeMinimum When the lowest volume level is reached after tapping

Volume - button

This headset announces various

status alerts when you power

on/off, run low on talk time, or

lose/reconnect the Bluetooth

connection to your phone.

TIPS

Stream Music and More:

Once your phone is connected, music

or audio ﬁles like GPS directions or

podcasts can be streamed through

the headset.

The headset supports A2DP when

connected to a device capable of

streaming A2DP audio.

PAUSE/PLAY: You can pause and play

music and audio ﬁles using controls

on the headset if your device also

supports Bluetooth AVRCP. Simply

press both volume +/- buttons simul-

taneously until you hear a beep.

Use Multipoint One Call at a Time:

You cannot place a current call on

hold while answering a call from the

second phone.

Tap the Call button to end the ﬁrst

call and tap it again to take the

second call.

Check Headset Battery Level

on an iPhone:

The battery level of your headset is

shown on-screen beside the phone’s

battery level icon.

Check the Battery Level:

The battery alert announces remaining

talk time after calls end.

In addition, you can tap the Power

button to check battery level.

Know How to Reconnect:

Your headset tries to reconnect a lost

connection. If it can’t, then tap the Call

button once or manually reconnect via

the phone’s Bluetooth device menu.

Stay Near Your Phone:

Bluetooth has a working “range” of

up to 33 feet between the phone and

headset before audio degrades and

the connection is lost.

SPECIFICATIONS

TalkTime Up to 6 hours talk time

StandbyTime Up to 5 days standby

OperatingDistance(Range) Up to 33 foot range

HeadsetWeight 17 grams

ChargeConnector Micro USB cable with micro USB connection and

AC/DC 100–240V

BatteryType Rechargeable, non-replaceable Lithum-ion polymer

ChargeTime(Maximum) 1.5 hours

PowerRequirements 5V DC - 180mA

BluetoothVersion Version 2.1 + Enhanced Data Rate (EDR), eSCO data

packet transfer, Secure Simple Pairing (SSP) if supported

by phone

BluetoothProles Hands-free v1.5 (HFP), Headset v1.1 (HSP), Advanced

Audio Distribution (A2DP) and Audio/Video Remote

Control (AVRCP)

Operating,Storageand

ChargingTemperature

32°F - 104°F (0 - 40°C)

LEARN

M100™Bluetooth®Headset

NEED MORE HELP?

24-hour support in USA:

1-866-363-BLUE (2583)

1-year limited warranty details:

www.plantronics.com/warranty

Voyager Pro+ are trademarks or registered trademarks of Plantronics, Inc.

The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.

and any use of such marks by Plantronics, Inc. is under license. iPhone

is a trademark of Apple Inc. registered in the U.S. and other countries.

Blackberry is owned by Research In Motion Limited and is registered in

the United States and may be pending or registered in other countries.

Plantronics, Inc is not endorsed, sponsored, afﬁliated with or otherwise

authorized by Research In Motion Limited.

Patents US 5,210,791; D612,840; D612,834; D612,835; BR DI69022011;

China ZL200930191189.7; EM 001142582-001; IN 223437; Taiwan

D134706; Patents Pending. 84470-01

Z109

N10687

Otros manuales para 84100-01

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Auriculares de Plantronics

Plantronics

Plantronics SupraPlus H261 Manual de usuario

Plantronics

Plantronics Savi W430-M Manual de usuario

Plantronics

Plantronics EXPLORER 380 Manual de usuario

Plantronics

Plantronics CS510-XD Manual de usuario

Plantronics

Plantronics ML15 Manual de usuario

Plantronics

Plantronics Explorer 500 Series Manual de usuario

Plantronics

Plantronics MARQUE A170 Hoja de especificaciones

Plantronics

Plantronics SupraPlus CS361N Manual de usuario

Plantronics

Plantronics Voyager Legend UC B235-M Manual de usuario

Plantronics

Plantronics M70 Series Manual de usuario

Plantronics

Plantronics M205 Manual de usuario

Plantronics

Plantronics Blackwire C320 Manual de usuario

Plantronics

Plantronics Voyager Edge Series Manual de usuario

Plantronics

Plantronics Savi W740-M Manual de usuario

Plantronics

Plantronics C65 PROGRAMMER Manual de usuario

Plantronics

Plantronics BLACKWIRE C210 Manual de usuario

Plantronics

Plantronics Blackwire C710 Manual de usuario

Plantronics

Plantronics ENCOREPRO 710 DIGITAL Manual de usuario

Plantronics

Plantronics M140 - QUICK START GUIDES Manual de usuario

Plantronics

Plantronics Legend UC Manual de usuario

Plantronics

Plantronics CS70N Manual de uso y mantenimiento

Plantronics

Plantronics M220C Manual de usuario

Plantronics

Plantronics RIG 100HS Manual de usuario

Plantronics

Plantronics DuoPro H151N Guía de configuración

Manuales populares de Auriculares de otras marcas

Sena

Sena SMH10 Manual de usuario

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manual de usuario

Sennheiser

Sennheiser EPOS ADAPT 230 Manual de usuario

Doro

Doro Flexus HS2005 Manual de usuario

GE 98971 Manual de usuario

Hama

Hama 00184070 Manual de usuario

Blue Tiger

Blue Tiger Advantage PLUS Manual de usuario

Jawbone

Jawbone Icon Manual de usuario

Jabra

Jabra FR 20 Manual de usuario

Roxcore

Roxcore Flow A+ Manual de usuario

Turtle Beach

Turtle Beach XP 510 Manual de usuario

Philips

Philips SHB6101 Manual de usuario

Jabra

Jabra PRO 9460 Duo Manual de usuario

HyperX

HyperX HyperX Cloud Flight Manual de usuario

Bose

Bose MIE2 Mobile Manual de usuario

Jabra

Jabra Steel Manual de usuario

HyperX

HyperX cloud ii Manual de usuario

Southwing

Southwing SA505 Manual de usuario
