Plantronics DISCOVERY 925 Manual de usuario

Plantronics Discovery®925

User Guide

iii

Welcome

Thank you for purchasing the Plantronics Discovery®925 earpiece.

This guide contains instructions for setting up and using

your new earpiece.

Please refer to the Safety Information in this booklet for important

product safety information prior to use of the product.

Getting Assistance

The Plantronics Technical Assistance Center is ready to assist you.

You can ﬁnd answers to frequently asked questions, ask a question

using e-mail, receive service over the Internet, or speak directly

with a representative. Visit www.plantronics.com/support or call

1-866-363-BLUE (2583).

NOTE If you are considering returning this earpiece, please contact

the Technical Assistance Center ﬁrst.

Registering Your Product

Visit www.plantronics.com/productregistration to register your product

online so we can provide you with the best service and technical support.

NOTE For pairing your Earpiece, your PIN code, or “Passkey,” is 0000.

Contents

Package Contents, Features and Accessories......................................iv

Charging Your Earpiece ........................................................................ 1

Using the AC or USB charger...................................................... 1

Using the Charging Case............................................................. 2

Checking the Battery Level.......................................................... 2

Recharging the Charging Case....................................................3

Pairing Your Earpiece............................................................................ 4

Plantronics QuickPair™ Technology ............................................ 4

How to Pair Your Phone With Your Earpiece for the First Time.....5

Adjusting the Fit....................................................................................6

How to Install a Different Gel Eartip.............................................. 6

Earpiece Controls ................................................................................. 7

Hands-Free Features ............................................................................ 8

Range .................................................................................................. 9

Indicator Lights and Tones.................................................................... 9

Troubleshooting.................................................................................. 11

Using More Than One Bluetooth Phone.............................................. 13

How to Turn the Multipoint Feature On and Off.......................... 13

How to Initiate a Call..................................................................13

How to Answer a Call While Talking on the Other Phone ........... 13

Product Speciﬁcations........................................................................ 14

Limited Warranty................................................................................. 15

Important Safety and Operational Information..................................... 16

Regulatory Notices ............................................................................. 19

Package Contents and Features

Product Name & Number Accessories*

Vehicle Power Charger

#78583-01

Earpiece

Charging Case

* Not included. To order, please contact your Plantronics supplier or go

to www.plantronics.com

AC Charger

100–240V

USB Charging Cable

Volume Control Button

Charging Jack

Eartip

Stabilizing Eartips

(small, medium, and large)

Call Control Button

USB Lanyard

#79393-01

Option A: Using the AC Charger

1 Plug the AC charger into a power outlet.

2 Connect the AC charger to the charging jack on the earpiece.

Charging Your Earpiece

Your new earpiece performs best when fully charged. While your

earpiece is charging, the indicator light slowly ﬂashes red. When your

earpiece is fully charged, the indicator light turns off. This applies to

all charging options.

Option B: Using the USB Charger

1 Connect USB charger to the USB

port on a computer or laptop.

2 Connect the USB charger to the

charging jack on the earpiece.

3 Turn the computer or laptop on.

WARNING Do not use your earpiece while it is

connected to the charger.

CHARGING TIME

3 hours .....Full charge using

AC or USB

1 hour .......Minimum charge

before ﬁrst use

Option C: Using the Charging Case

Open the cover of the case. Align the charging jack on the earpiece with

the micro USB connection in the case. Gently push the earpiece onto

the micro USB connection until you feel it click into place.

IMPORTANT Incorrect removal of the earpiece from the case will

damage the micro USB port in the case. To properly remove the

earpiece, use your thumb to gently push the earpiece in a diagonal,

not vertical, direction away from the micro USB connector.

Checking the Battery Level of Your Earpiece

With the earpiece on, simultaneously press and hold the call control

button and the volume button for about 2 seconds. The indicator light

flashes red to show the charge level.

Charging Your Earpiece

CHARGE INDICATOR LIGHTS

Red Flashes Battery Level

1 Full battery

2 1/3 to 2/3 full

3 Less than 1/3 full

Volume Button

Call Control Button

The charging case provides one full charge to your earpiece before the

battery within the case requires charging. While the case is charging,

the indicator light on the bottom of the case ﬂashes red. When fully

charged, the indicator turns off.

Recharging the Charging Case

1 To check the battery status of the charging case, you must

connect the earpiece to the case.

If the earpiece does not begin charging mode (indicator light slowly

ﬂashes red) then both the earpiece and case need recharging.

2 Plug either the AC charger or the USB charger to power

source before connecting to the charging jack on the bottom

of the case.

If you disconnect the power source from the case after 10 minutes of

charging you must then wait at least 60 minutes before reconnecting

a power source to resume the charging cycle.

NOTE If recharging with the AC charger, the charging case will feel

warm to the touch during the charging cycle. Once fully charged, the

case will cool down. See “Safety Information” on page 16 for more

information.

Charging Your Earpiece

Indicator Light

Charging Jack

CHARGING TIME

3 hours .....Full charge using

charging case

1 hour .......Minimum charge

before ﬁrst use

CHARGING TIME

9 hours....Full charge

using USB

3 hours....Full charge

using AC

Pairing Your Earpiece

Pairing is the process of introducing your earpiece to your phone.

Before using your earpiece for the ﬁrst time, you must pair it with

your Bluetooth®wireless technology enabled phone. Normally you

need to pair your earpiece with your phone only once.

To see a demo of the pairing process, visit www.plantronics.com/

EasyToPair.

Plantronics QuickPair™Technology

Your new earpiece includes Plantronics QuickPair technology to simplify

the Bluetooth setup process. The ﬁrst time you turn your earpiece on,

your earpiece automatically enters pairing mode for 10 minutes. Once

paired successfully, your earpiece stays on for instant use.

If not successfully paired after 10 minutes, your earpiece automatically

powers off. When you turn the earpiece on again, it automatically goes

into pairing mode until successfully paired with a Bluetooth phone.

How to Pair Your Phone with Your Earpiece for the First Time

1 Turn on the Bluetooth feature on your phone.

For most phones, select Settings/Tools > Connections >

Bluetooth > On. See your phone’s user guide for more information.

2 Turn the earpiece on.

Press and hold the call control button until the indicator ﬂashes

red/blue. The earpiece is now in pairing mode.

If you don’t see the red/blue ﬂash, press and hold the call control

button to turn your earpiece off, and then press and hold the call

control button again until you see the red/blue ﬂash.

3 Use the commands on your phone to locate your earpiece.

For most phones, select Settings/Tools > Connections > Bluetooth

> Search > 9XXPlantronics. See your phone’s user guide for more

information.

4 When prompted for the PIN code or Passkey, enter 0000.

Pairing is successful when the indicator on your earpiece ﬂashes

blue. Your earpiece is now connected and ready to use.

Pairing Your Earpiece

SETTINGS

Time and Date

Phone Settings

Bluetooth

Sound Settings

Network Services

Security

Reset Settings

SETTINGS

Time and Date

Phone Settings

Bluetooth

Sound Settings

Network Services

Security

Reset Settings

BLUE TOOTH

9XXPlantronics

PAS SKE Y

0000

BLUETOOTH

9XXPlantronics

PAS SKEY

0000

How to Install a Different Gel Eartip

If the earpiece does not feel stable, the eartip needs adjusting or it may

be the wrong size for your ear. The earpiece comes with the medium

eartip installed, but you can replace it with the optional small or large

eartip provided.

Adjusting the Fit

For optimal voice clarity,

point the boom towards

the corner of your mouth.

Correct Fit Incorrect Fit

2 3

1 Remove the earpiece from your ear.

Rotate the eartip on the earpiece to position the stabilizer to rest

comfortably in your ear. If the earpiece still feels unstable, then remove

the ear-piece from your ear and change the eartip to a different size.

2 To remove the eartip, gently pull the stabilizer loop of eartip

off of the speaker housing.

3 To ﬁt a new eartip, position the eartip over the speaker

housing with the stabilizer pointed away from the microphone

boom and gently press the eartip onto speaker housing.

Eartip

Speaker housing

Earpiece Controls

Turn on the earpiece Press and hold the call control button for 2

seconds until the indicator glows blue. If earpiece

ﬂashes red 3 times when you turn on the earpiece

then the battery is very low and should be

recharged.

NOTE When your earpiece is in standby mode, the indicator

is off. To conﬁrm that your earpiece is on, press any button.

You should see a blue light ﬂash.

Turn off the earpiece Press and hold the call control button for 4

seconds until the indicator glows red. When

power is off, indicator stays off.

NOTE If you’re wearing the earpiece, you hear ascending

tones when the power turns on and descending tones when

the power turns off.

Answer or reject

a call

When your earpiece rings, tap the power button

once; you should hear 1 low tone.

To reject a call and send the caller to voice mail,

press the call control button for 2 seconds.

NOTE Your phone may ring before your earpiece rings.

Wait until you hear the ring in your earpiece to press the call

control button and answer the call.

End a call During active call, tap the call control button.

Make a call When the earpiece is paired to your phone and in

range, enter phone number on your phone and

press send. The call automatically transfers to

your earpiece.

Transfer a call

between earpiece

and phone

During an active call, press and hold the call

control button for 2 seconds. You will hear a

single low tone followed by a double low tone.

Range

To maintain a connection, keep your earpiece within 33 feet (10 meters)

of the Bluetooth phone. If there are obstacles between your earpiece and

the phone you may experience interference. For optimal performance,

place your earpiece and phone on the same side of your body.

Audio quality degrades as you move out of range. When you are

far enough away to lose the connection, you hear a high tone in the

earpiece.

The earpiece attempts to reconnect for 60 seconds. If you move back in

range, you can manually reconnect by pressing the call control button.

NOTE Audio quality is also dependent upon the device with which the

Earpiece is paired.

Earpiece Controls

Turning the

multipoint feature on

To prolong battery life, the multipoint feature

is turned off by default. To turn on feature, see

“Turning the Multipoint Feature On and Off” on

page 13.

Turn off the online

indicator

Press and hold the volume button for 4 seconds

while the earpiece is on. Blue light will dim over

2 seconds. Repeat action to activate online

indicators. Blue light will brighten over 2 seconds.

You will hear a single low tone, silence, and then

a double low tone.

Adjust the volume During an active call, tap the volume button.

There are 3 volume settings. Each tap will

increase the volume until maximum is reached

and you hear two low tones. Tapping again will

drop volume to minimum setting and subsequent

taps will increase volume until maximum is again

reached.

Hands-Free Features

If your phone and your wireless service provider both support hands-free

operation, you can use the following features:

Redial the last number

you called

Tap the call control button twice. You will

hear two low tones.

Voice activated dialing When the earpiece is on, press and hold

the call control button for 2 seconds until

you hear 1 low tone.

WARNING Do not use headphones/Earpieces at high volumes for an extended

period of time. Doing so can cause hearing loss. Always listen at moderate levels. See

www.plantronics.com/healthandsafety for more information on Earpieces and hearing.

Indicator Lights and Tones

Light Tone

Status check 1 blue ﬂash 1 tone

Charging 1 red ﬂash every 10 seconds None

Fully charged None None

Low battery 2 red ﬂashes for 2/3 full battery None

Very low battery 3 red ﬂashes every 10 seconds 3 high tones every

10 seconds

Pairing Red and blue ﬂashes 1 low tone

Paired Blue ﬂashes 1 low tone

Turning on Solid blue for 2 seconds Ascending tones

Turning off Solid red for 4 seconds Descending tones

Indicator Lights and Tones

Light Tone

Incoming call 3 blue ﬂashes every 2 seconds 3 rapid low tones

every 2 seconds

Answer call 1 blue ﬂash 1 low tone

Call in progress 1 blue ﬂash every 2 seconds None

Volume up or

down

1 blue ﬂash for each volume

adjustment

1 tone with volume

corresponding to

volume level

2 low tones to

indicate maximum

volume level

reached

End call 1 blue ﬂash 1 low tone

Missed call 3 purple ﬂashes every 10

seconds for 5 minutes

None

Out of range None 1 high tone

Back in range Flashes to match current

earpiece state

1 low tone

Turning on

multipoint

2 blue ﬂashes None

Turning off

multipoint

1 blue ﬂash None

NOTE By default, the online indicator is turned on. To turn off the online

indicator, see “Earpiece Controls” on page 8.

Troubleshooting

My earpiece

does not work

with my phone.

Make sure the earpiece is fully charged.

Make sure earpiece is paired with the Bluetooth

phone you are trying to use.

See “Pairing Your Earpiece” on page 4.

My phone did not

locate the earpiece.

Turn both your phone and earpiece off and on,

and then repeat the pairing process on page 4.

I could not enter

my PIN code.

Turn both your phone and earpiece off and on,

and then repeat the pairing process on page 4.

Your PIN code, or Passkey, is 0000.

I cannot hear

caller/dial tone.

The earpiece is not turned on. Press the call

control button for approximately 2 seconds until

you hear a tone or see the indicator glow blue.

Your earpiece is out of range. Move the earpiece

closer to the Bluetooth phone.

Your earpiece battery is drained. Charge your

battery. See “Charging Your Earpiece” on page 1.

The listening volume is too low. Incremental

tapping of the volume button will adjust volume.

See instructions for adjusting the volume in

“Earpiece Controls” on page 8.

Make sure that the eartip ﬁts properly. See

“Adjusting the Fit” on page 6.

Using More Than One Bluetooth Phone

Plantronics Discovery 925 supports multipoint technology, which allows

you to use one earpiece with two different Bluetooth mobile phones.

How to Turn the Multipoint Feature On and Off

To use more than one phone, you must turn the multipoint feature on.

When this feature is off, your earpiece can connect to only one Bluetooth

phone.

1 With your earpiece turned off, press and hold the volume and

call control buttons simultaneously until earpiece turns on and

indicator ﬂashes blue 2 times.

2 To pair earpiece to a second phone, see “Pairing Your

Earpiece” on page 5.

NOTE To turn the multipoint feature off, repeat step 1. The indicator

ﬂashes blue 1 time to indicate multipoint is off.

How to Initiate a Call

The earpiece initiates a call on the phone you most recently used. To

use the second phone, initiate the call using the controls on the second

phone. The second phone forms an active link with the earpiece.

How to Answer a Call While Talking on the Other Phone

To answer the second call, the ﬁrst call must be terminated. There is no

function for placing one call on hold while answering another call from the

earpiece.

1 Press the call control button once to hang up the existing call.

2 Press the call control button again to answer the new call from

the other phone.

NOTE If you choose not to answer the second call, and you have voice

mail on the second phone, the call will go to voice mail.

Troubleshooting

Audio quality

is poor.

Make sure that earpiece is sitting correctly in ear

with boom pointing towards corner of mouth.

See “Adjusting the Fit” on page 6.

Callers cannot

hear me.

Your earpiece is out of range. Move the earpiece

closer to the Bluetooth phone. See “Range” on

page 9.

The eartips do not

ﬁt my ear.

Try a different size eartip. See “Adjusting the Fit”

on page 6.

My earpiece falls

out of my ear.

Make sure that Earpiece is sitting correctly in ear

with boom pointing towards corner of mouth.

See “Adjusting the Fit” on page 6.

My eartip needs to

be cleaned.

Remove the eartip from the earpiece and wash it

in warm soapy water and dry thoroughly. When

the eartip is completely dry, put it back on your

earpiece.

Limited Warranty

This warranty covers defects in materials and workmanship of products manufactured,

sold or certiﬁed by Plantronics which were purchased and used in the United States

and Canada.

The warranty lasts for one year from the date of purchase of the products.

This warranty extends to you only if you are the end user with the original

purchase receipt.

We will, at our option, repair or replace the products that do not conform to the

warranty. We may use functionally equivalent reconditioned/refurbished/remanufactured/

pre-owned or new products or parts.

To obtain service in the U.S., contact Plantronics at 1-866-363-BLUE (2583). To obtain

service in Canada call (800) 540-8363.

THIS IS PLANTRONICS’ COMPLETE WARRANTY FOR THE PRODUCTS.

This warranty gives you speciﬁc legal rights, and you may also have other rights that

vary from state to state. Please contact your dealer or our service center for the full

details of our limited warranty, including items not covered by this limited warranty.

Product Speciﬁcations

Talk Time* Battery enables up to 5 hours

Standby Time* Battery enables up to 175 hours with

multipoint feature OFF

Battery enables up to 100 hours with

multipoint feature ON

Charge Time Charging headset using AC = 3 hours

Charging headset using USB = 3 hours

Charging headset using the case = 3 hours

Charging the case using AC = 3 hours

Charging the case using USB = 9 hours

Range Up to 33 feet (10 meters)

Earpiece Weight 8 grams

Battery Type Headset: Lithium ion polymer

Charging Case: Nickel-metal hydride

Storage/Usage

Temperature

50F–104F (10C – 40C)

Version Bluetooth 2.0 + EDR (Enhanced Data Rate)

Bluetooth Proﬁles Headset Proﬁle (HSP) for talking on the phone

Hands-free Proﬁle (HFP) for talking on the

phone and operating the phone

* Performance may vary by device.

Otros manuales para DISCOVERY 925

Tabla de contenidos

Otros manuales de Auriculares de Plantronics

Plantronics

Plantronics Tristar Manual de usuario

Plantronics

Plantronics RIG 700 Series Manual de usuario

Plantronics

Plantronics SupraPlus CS351N Manual de usuario

Plantronics

Plantronics Discovery 650 Manual de usuario

Plantronics

Plantronics Blacktop 500 Manual de usuario

Plantronics

Plantronics Practica T50 Manual de usuario

Plantronics

Plantronics Stereo SupraPlus USB Manual de usuario

Plantronics

Plantronics CS510-XD Manual de usuario

Plantronics

Plantronics Voyager 3200 Series Manual de usuario

Plantronics

Plantronics EXPLORER 300 Manual de usuario

Plantronics

Plantronics BackBeat 216 Dimensiones

Plantronics

Plantronics M90 Series Manual de usuario

Plantronics

Plantronics Voyager Edge UC Series Manual de usuario

Plantronics

Plantronics GameCom 307 Manual de usuario

Plantronics

Plantronics Marque M155 Manual de usuario

Plantronics

Plantronics SAVI GO WG200/B Guía de referencia

Plantronics

Plantronics Voyager Edge Series Manual de usuario

Plantronics

Plantronics Savi 410 Manual de usuario

Plantronics

Plantronics CS50 Guía de configuración

Plantronics

Plantronics Stereo SupraPlus USB Manual de instrucciones

Plantronics

Plantronics Poly Voyager 4300 UC Series Manual de usuario

Plantronics

Plantronics SHR2083-01 Dimensiones

Plantronics

Plantronics Savi Office WO200 Manual de usuario

Plantronics

Plantronics CT10 Manual de usuario

Manuales populares de Auriculares de otras marcas

Sena

Sena SMH10 Manual de usuario

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manual de usuario

Sennheiser

Sennheiser EPOS ADAPT 230 Manual de usuario

Doro

Doro Flexus HS2005 Manual de usuario

GE 98971 Manual de usuario

Hama

Hama 00184070 Manual de usuario

Blue Tiger

Blue Tiger Advantage PLUS Manual de usuario

Jawbone

Jawbone Icon Manual de usuario

Jabra

Jabra FR 20 Manual de usuario

Roxcore

Roxcore Flow A+ Manual de usuario

Turtle Beach

Turtle Beach XP 510 Manual de usuario

Philips

Philips SHB6101 Manual de usuario

Jabra

Jabra PRO 9460 Duo Manual de usuario

HyperX

HyperX HyperX Cloud Flight Manual de usuario

Bose

Bose MIE2 Mobile Manual de usuario

Jabra

Jabra Steel Manual de usuario

HyperX

HyperX cloud ii Manual de usuario

Southwing

Southwing SA505 Manual de usuario
