Plantronics Discovery 975 Manual de usuario

Plantronics Discovery®975

User Guide

Welcome

Thank you for purchasing the Plantronics Discovery®975 earpiece.

This guide contains instructions for setting up and using your new

earpiece.

Before using this product, please refer to the For Your Safety

guide for important product safety and charging information.

Getting Assistance

The Plantronics Technical Assistance Center is ready to assist

you. You can ﬁnd answers to frequently asked questions, ask a

question using e-mail, receive service over the Internet, or speak

directly with a representative. Visit www.plantronics.com/support

or call 1-866-363-BLUE (2583).

NOTE If you are considering returning this earpiece, please contact

the Technical Assistance Center ﬁrst.

Registering Your Product

Visit www.plantronics.com/productregistration to register your

product online so we can provide you with the best service and

technical support.

NOTE For pairing your Earpiece, your PIN code, or “Passkey,” is

0000.

iii

Contents

Package Contents, Features and Accessories ........................... iv

Charging Your Earpiece................................................................1

Using the AC or USB charger.............................................1

Using the Charging Case ...................................................2

Checking the Battery Level ................................................3

Automatric Battery Status Alerts........................................4

Recharging the Charging Case ....................................................5

Pairing Your Earpiece ...................................................................6

Plantronics QuickPair™ Technology ..................................6

How to Pair Your Phone With Your Earpiece

for the First Time ................................................................7

Adjusting the Fit ...........................................................................8

How to Install a Different Gel Eartip ...................................8

Earpiece Controls.........................................................................9

Hands-Free Features..................................................................10

Range .........................................................................................11

Indicator Lights and Tones .........................................................11

Troubleshooting..........................................................................13

Using More Than One Bluetooth Phone ....................................15

How to Turn the Multipoint Feature On and Off ...............15

How to Initiate a Call ........................................................15

How to Answer a Call While Talking on the Other Phone 15

Product Speciﬁcations ...............................................................16

Limited Warranty ........................................................................17

Package Contents and Features

Product Name & Number Accessories*

Vehicle Power Charger

#xxxxx-xx

Clothing Clip

#xxxxx-xx

Earpiece

Charging Case

* Not included. To order, please contact your Plantronics supplier

or go to www.plantronics.com

AC Charger

100 – 240V

USB Charging Cable

Volume Control

Button

Charging Jack

Eartip

Stabilizing Eartips

(small, medium, and large)

Call Control

Button

USB Lanyard

#74948-01

Option A: Using the AC Charger

1 Plug the AC charger into a power

outlet.

2 Connect the AC charger to the

charging jack on the earpiece.

Charging Your Earpiece

Your new earpiece performs best when fully charged. While your

earpiece is charging, the indicator light slowly ﬂashes red. When your

earpiece is fully charged, the indicator light turns off. This applies to

all charging options.

Never charge the battery where the temperature may fall below 0°C

(32°F) or rise above 40°C (104°F) – for example, in an unattended

motor vehicle. Do not use your earpiece while it is

connected to the charger. 1

Option B: Using the USB Charger

1 Connect USB charger to the USB

port on a computer or laptop.

2 Connect the USB charger to the

charging jack on the earpiece.

3 Turn the computer or laptop on.

CHARGING TIME

1.5 hours .....Full charge using

AC or USB

30 minutes...Minimum charge

before ﬁrst use

Option C: Using the Charging Case

Open the cover of the case. Align the charging jack on the

earpiece with the micro USB connection in the case. Gently push

the earpiece onto the micro USB connection until you feel it click

into place.

IMPORTANT Incorrect removal of the earpiece from the case will

damage the micro USB port in the case. Gently press the ejection

button with your thumb to release the earpiece.

Charging Your Earpiece

EjectInsert

Checking the Battery Level of Your Earpiece

Option A: With the earpiece on, simultaneously press and hold the

call control button and the volume button for about 2 seconds. The

indicator light flashes red to show the charge level.

Option B: The LCD display on the charging case will indicate battery

level of the earpiece when earpiece is inserted into case. The battery

icon (above the earpiece) flashes to indicate battery level.

Charging Your Earpiece

Volume Button

Call Control Button

CHARGE INDICATOR LIGHTS

Red Flashes Battery Level

SMore than 2/3 full

S S 1/3 to 2/3 full

S S S Less than 1/3 full

BATTERY LEVEL ICON

Bars Battery Level

3 Full battery

2 1/3 to 2/3 full

1 Less than 1/3 full

Charging Your Earpiece

LOW BATTERY WARNINGS

Battery Level Tone Voice Prompt

30 minutes of

talk time remaining

(this alert only

occurs during

an active call)

Double high

tone every

15 minutes

“Battery Low”

repeats every

30 minutes

10 minutes

of talk time

remaining

Triple high

tone every

30 seconds

“Recharge

Battery” repeats

every 3 minutes

Automatic Battery Status Alerts

When the battery charge is very low, a tone and voice prompt in English

will automatically occur.

Recharging the Battery Inside the Case

The charging case provides two full charges to your earpiece before

the battery within the case requires charging.

1 To check the battery status of the charging case, refer to

the LCD display on the case.

The battery status may change if you insert the earpiece because

the battery will transfer power to the earpiece.

2 Plug either the AC charger or the USB charger to power

source before connecting to the charging jack on the side

of the case.

While the case is charging, the LCD battery icon (above the case

image) ﬂashes to indicate charge level.

NOTE If you disconnect the power source from the case after 10

minutes of charging you must then wait at least 60 minutes before

reconnecting a power source to resume the charging cycle.

Recharging Your Charging Case

CHARGING TIME

3.5 hours. Full charge

using USB

1.5 hours. Full charge

using AC

Pairing Your Earpiece

Before using your earpiece for the ﬁrst time, you must pair it with

your Bluetooth®wireless technology enabled phone.

Your new earpiece includes Plantronics QuickPair™technology to

simplify the Bluetooth setup process. The ﬁrst time you turn your

earpiece on, your earpiece automatically enters pairing mode for 10

minutes. Once paired successfully, your earpiece stays on for instant

use.

If not successfully paired after 10 minutes, your earpiece automatically

powers off. When you turn the earpiece on again, it automatically

goes into pairing mode until successfully paired with a Bluetooth

phone.

NOTE This earpiece is equipped with Secure Simple Pairing (SSP).

If your phone supports SSP, you will not need to enter a PIN code or

Passkey.
