Planet BM-2101 Manual de usuario

Bandwidth Management Gateway

BM-2101

User’s Manual

The products and programs described in this User’s Manual are licensed products of PLANET

Technology, This User’s Manual contains proprietary information protected by copyright, and this User’s

Manual and all accompanying hardware, software, and documentation are copyrighted.

No part of this User’s Manual may be copied, photocopied, reproduced, translated, or reduced to any

electronic medium or machine-readable form by any means by electronic or mechanical. Including

photocopying, recording, or information storage and retrieval systems, for any purpose other than the

purchaser's personal use, and without the prior express written permission of PLANET Technology.

Disclaimer

PLANET Technology does not warrant that the hardware will work properly in all environments and

applications, and makes no warranty and representation, either implied or expressed, with respect to the

quality, performance, merchantability, or fitness for a particular purpose.

PLANET has made every effort to ensure that this User’s Manual is accurate; PLANET disclaims liability

for any inaccuracies or omissions that may have occurred.

Information in this User’s Manual is subject to change without notice and does not represent a

commitment on the part of PLANET. PLANET assumes no responsibility for any inaccuracies that may

be contained in this User’s Manual. PLANET makes no commitment to update or keep current the

information in this User’s Manual, and reserves the right to make improvements to this User’s Manual

and/or to the products described in this User’s Manual, at any time without notice.

If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate

your comments and suggestions.

CE mark Warning

This is a class A device, in a domestic environment, this product may cause radio interference, in which

case the user may be required to take adequate measures.

Trademarks

The PLANET logo is a trademark of PLANET Technology.

This documentation may refer to numerous hardware and software products by their trade names. In most,

if not all cases, these designations are claimed as trademarks or registered trademarks by their respective

companies.

To avoid the potential effects on the environment and human health as a result of the presence

of hazardous substances in electrical and electronic equipment, end users of electrical and

electronic equipment should understand the meaning of the crossed-out wheeled bin symbol.

Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE

separately.

１

２

Customer Service

For information on customer service and support for the Internet Monitor, please refer to the following

Website URL:

http://www.planet.com.tw

Before contacting customer service, please take a moment to gather the following information:

♦Internet Monitor serial number and MAC address

♦Any error messages that displayed when the problem occurred

♦Any software running when the problem occurred

♦Steps you took to resolve the problem on your own

Revision

User’s Manual for PLANET Bandwidth Management Gateway

Model: BM-2101

Rev: 1.0 (March, 2007)

PartNo.EM-BM2101v1

３

Table of Contents

Chapter 1 Introduction ....................................................................................... 6

1.1 Package Contents............................................................................... 6

1.2 Front View ........................................................................................ 6

1.3 Specification ..................................................................................... 7

System

Chapter 2

Administration…………………......................................................

2.1

Admin…………………………………………….............................

2.2

Permitted IPs……………………... …………………………...........

2.3

System Log Out…………..................................................................

2.4

Software Update…………………......................................................

Chapter 3

Configure……………………………………...................................

3.1

Setting …………………………………………………...................

3.2

Date/Time …………………………………………………............

3.3

Multiple Subnet ………………………………...…………..............

3.4

Route Table ……………………………………………….............

3.5

DHCP ………………………………………………………………

3.6

DDNS ……………………………………………...……………….

3.7

Host Table ………………………………………………...............

3.8

SNMP ……………………………………………..………..............

3.9

Language ……………………………………………..…………….

Interface

Chapter 4

Interface …………………………………………………...............

4.1

LAN……………………………........................................................

4.2

WAN…………………………...........................................................

4.3

DMZ………………………...............................................................

Policy Object

Chapter 5

Address………………………………….…………………………. 60

5.1

Example………………….….. …………………………………….. 63

４

Chapter 6

Service……………………………….……………………………...

6.1

Custom……………………... ………………………………………

6.2

Group………………………... ……………………………………..

Chapter 7

Schedule………………………………….…………………………

Chapter 8

QoS…………………………………………….……………………

8.1

Example………………….………………………………………….

Chapter 9

Authentication………………….…………………………………..

9.1

User / User Group…………………………………………………...

9.2

RADIUS …………………………………... ……………………...

9.3

POP3 …………………………………............................................. 119

9.4

LDAP …………………………………............................................ 122

Chapter 10

Content Blocking..............................................................................

147

10.1

URL …………………………...........................................................

150

10.2

Script ……………………………….……………………………….

153

10.3

Download……...................................................................................

155

10.4

Upload……………….........................................................................

157

Chapter 11

IM / P2P Blocking…………………………………………………. 159

11.1

Example…………………………………………………………….. 162

Chapter 12

Virtual Server…………....................................................................

167

12.2

Example …….....................................................................................

171

Policy

Chapter 13

Policy……………………………………... ………………………..

185

13.1

Example……………………..............................................................

191

Anomaly Flow IP

Chapter 14

Anomaly Flow IP……………………………………………..........

212

14.1

Example…………………..................................................................

217

Monitor

Chapter 15

Monitor………………………………..............................................

224

15.1

Traffic……….………………………………………………………

226

15.2

Event…………….…………………………………………………..

231

15.3

Connection.………………………………………………………….

232

５

15.4

Backup………….………….. ………………………………………

235

Chapter 16

Accounting Report…........................................................................

237

16.1

Outbound…….……………………………………………………...

241

16.2

Inbound………….………………………………………………….

247

Chapter 17

Statistics……………………….........................................................

253

17.1

WAN……………….……………………………………………….

255

17.2

Policy……….……………………………………………………….

257

Chapter 18

Diagnostic……………………………………………............. ……

259

18.1

Ping ……………………….……………………………………….

260

18.2

Traceroute ……………………….…………………………. ……..

263

Chapter 19

Wake On Lan………………………………………... ……………

265

19.1

Example…………………….……………………………………….

266

Chapter 20

Status…………………………………..............................................

267

20.1

Interface….………………………………………………………….

270

20.1

System Info………………………………………………………….

272

20.3

Authentication……………………………………………………….

274

20.4

ARP Table………….…………………………….............................

275

20.5

Sessions Info…………………………………………………….......

276

20.6

DHCP Client……….…………………….………………………….

277

６

Chapter 1

Introduction

The BM-2101 is specifically designed for SMB networks. It has built-in four

10/100Mbps Ethernet ports include two WAN and one LAN and DMZ ports. No

broadband router is required for users with only one public IP address. It also supports

virtual server, Multi-DMZ, and dynamic DNS functions that are very useful for our

customers to share local resources with Internet users.

For bandwidth management, packets can be classified based on IP address, IP subnet,

and TCP/UDP port number. The device has more than 40 of the most common

protocols such as H.323, Oracle, HTTP, FTP, and so on for easy definition. The

administrator can then define policies to ensure committed and maximum bandwidth

levels for inbound and outbound traffic in each class. The administrator can also define

three priority levels for each policy to ensure high priority packets receive the maximum

available bandwidth. In addition, each policy can have a schedule defined for when the

policy is activated or inactivated in increments of 30 minutes.

Both the NAT and DMZ mode are supported, and therefore can maintain the existing

network infrastructure without reconfiguring. The BM-2101 provides policy-based

firewall protection and several hacker protections to prevent hackers’ attack. Besides,

the comprehensive alarm and log function allow the network manager to easily enhance

the security of local network.

1.1 Package Contents

BM-2101 x 1

Power Cord x 1

Quick Installation Guide x 1

User’s Manual CD x 1

Console cable x 1

Cat5 cross cable x 1

Cat5 cable x 1

Rack-mount ear x 2

Mat x 4

1.2 Front View

LED definition

LED Description

PWR Power is supplied to this device.

Green Steady on indicates the port is

connected to other network device.

Blink to indicates there is traffic on

the port

WAN1,

WAN2,

LAN,

DMZ Orange Steady on indicates the port is

connected at 100Mbps speed

1.3 SPECIFICATION

Product Bandwidth Management Gateway

Model BM-2101

Hardware WAN 2 x 10/100Base-TXConnections LAN

DMZ 1 x 10/100Base-TX, Auto-MDI/MDI-X

1 x 10/100Base-TX, Auto-MDI/MDI-X

Console 1 x RS-232 (DB-9)

H/W Watch-Dog Auto reboot when detecting system fail

Software

Maximum Controlled

Bandwidth 100Mbps

Maximum Controlled

concurrent session 241,000

Management Web (English, Traditional Chinese, Simplified

Chinese)

Operation Mode DMZ_NAT, DMZ_Transparent, NAT

WAN connection type in

NAT mode PPPoE, DHCP, and Fixed IP

Traffic Classification IP, IP subnet, and TCP/UDP port

Bandwidth Allocation Policy rules with Inbound/Outbound traffic

management

Guaranteed and maximum bandwidth

Scheduled in unit of 30 minutes

７

８

3 Priorities

Quota per Session and Quota per Day

Log Traffic Log, Event Log, Connection Log, Log backup

by mail or syslog server

Statistics WAN port statistics and policy statistics with graph

display

Firewall Security Policy-based access control

Stateful Packet Inspection (SPI)

Scheduled in unit of 30 minutes

Hacker Alert and

Anomaly Flow Detection Detect SYN Attack, Detect ICMP Flood, Detect UDP

Flood, Detect Ping of Death Attack, Detect Tear Drop

Attack, Detect IP Spoofing Attack, Filter IP Route

Option, Detect Port Scan Attack, Detect Land Attack,

Virus-Infected Blocking, E-Mail Alert Notification,

NetBIOS Notification

Alarm Event alarm for hacker attack

The alarm message can sent to administrator by e-mail

Other Functions Firmware Upgradeable through Web

NTP support

Configuration Backup and Restore through Web

Dynamic DNS support

Multiple NAT and multiple DMZ (mapped IP) support

Multiple server load balancing

９

Chapter 2

Generally speaking, the system administration refers to the privileges of log in/out,

monitor and control the BM-2101 appliance with some relevant settings. In this Chapter,

the system administration will be defined as the management of the MIS engineer ,

Permitted IPs , System Log-Out, and Software Update.

Chief administrator configures and manages the BM-2101 appliance. The

administrator can add, delete or modify system settings and monitor system status while

sub-administrator (title named by first MIS engineer) is read-only.

Otros manuales para BM-2101

Tabla de contenidos

Otros manuales de Puerta de Planet

Planet

Planet ICG-2510W-LTE Series Manual de usuario

Planet

Planet UMG-2000 Manual de usuario

Planet

Planet MH-2001 Manual de usuario

Planet

Planet WPG-200N Manual de usuario

Planet

Planet WPG-120 Manual de usuario

Planet

Planet IMG-2100T Manual de usuario

Planet

Planet VIP 24 Series Manual de usuario

Planet

Planet VCG-1500WG-LTE Manual de usuario

Planet

Planet VIP-110 Manual de usuario

Planet

Planet CS-2001 Manual de usuario

Planet

Planet Network Device MAP-2105 Manual de usuario

Planet

Planet MH-2300 Manual de usuario

Planet

Planet WPG-130N Manual de usuario

Planet

Planet MH-5000 Manual de usuario

Planet

Planet VIP-110 Manual de instalación

Planet

Planet VIP-281 Series Manual de usuario

Planet

Planet VGW-804 Manual de usuario

Planet

Planet VIP-281 SW Manual de usuario

Planet

Planet MH-2001 Manual de usuario

Planet

Planet IMG-110T Manual de usuario

Planet

Planet UMG-1000 Manual de usuario

Planet

Planet VGW 10 Series Manual de usuario

Planet

Planet IG-100 Manual de usuario

Planet

Planet LCG-300 Series Manual de usuario

Manuales populares de Puerta de otras marcas

LST

LST M500RFE-AS Manual de usuario

Kinnex

Kinnex Media Gateway Manual de usuario

2N Telekomunikace

2N Telekomunikace 2N StarGate Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manual de usuario

Telsey

Telsey CPVA 500 - SIP Manual de usuario

RTA

RTA 460A-NNA4 Hoja de especificaciones

Shaw

Shaw Gateway HDPVR Manual de usuario

ABB

ABB VSN900 Guía de inicio rápido

Commander

Commander Pulse Manual de usuario

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manual de usuario

NETGEAR

NETGEAR C6300BD Manual de usuario

Amit

Amit CDW531AM Manual de usuario

HMS

HMS Netbiter EasyConnect EC150 Manual de usuario

Huawei

Huawei EchoLife HG620 Manual de usuario

AT&T

AT&T U-verse 3801 Manual de uso y cuidado

Logic IO

Logic IO RTCU MX2 turbo Manual de usuario

Suttle

Suttle MediaMAX MXM-521 Manual de usuario
