Planet WPG-120 Manual de usuario

WPG-120 User Manual

Wireless Presentation Gateway

WPG-120

User’s Manual

WPG-120 User Manual

be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or

computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,

manual or otherwise, without the prior written permission of PLANET.

PLANET makes no representations or warranties, either expressed or implied, with respect to the

contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular

purpose. Any software described in this manual is sold or licensed "as is". Should the programs prove

defective following their purchase, the buyer (and not PLANET, its distributor, or its dealer) assumes

the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting

from any defect in the software. Further, PLANET reserves the right to revise this publication and to

make changes from time to time in the contents hereof without obligation to notify any person of such

revision or changes.

All brand and product names mentioned in this manual are trademarks

and/or registered trademarks of their respective holders.

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur in

a particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

4. Consult the dealer or an experienced radio technician for help.

WPG-120 User Manual

FCC Caution

To assure continued compliance. (example-use only shielded interface cables when connecting to

computer or peripheral devices). Any changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the Following two

conditions: ( 1 ) This device may not cause harmful interference, and ( 2 ) this Device must accept any

interference received, including interference that may cause undesired operation.

Federal Communication Commission (FCC) Radiation Exposure

Statement

This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In

order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human

proximity to the antenna shall not be less than 20 cm (8 inches) during normal operation.

R&TTE Compliance Statement

This equipment complies with all the requirements of DIRECTIVE 1999/5/CE OF THE EUROPEAN

PARLIAMENT AND THE COUNCIL OF 9 March 1999 on radio equipment and telecommunication

terminal Equipment and the mutual recognition of their conformity (R&TTE)

The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal

Equipment and Satellite Earth Station Equipment) As of April 8, 2000.

Safety

This equipment is designed with the utmost care for the safety of those who install and use it.

However, special attention must be paid to the dangers of electric shock and static electricity when

working with electrical equipment. All guidelines of this and of the computer manufacture must

therefore be allowed at all times to ensure the safe use of the equipment.

WEEE regulation

To avoid the potential effects on the environment and human health as a result of the

presence of hazardous substances in electrical and electronic equipment, end users of

electrical and electronic equipment should understand the meaning of the crossed-out

wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to

collect such WEEE separately.

Revision

User’s Manual for PLANET Wireless Presentation Gateway

Model: WPG-120

Rev: 1.0 (October. 2009)

Part No. EM-WPG120

WPG-120 User Manual

Table of Contents

Overview

.....................................................................................................5

Quick Start

.................................................................................................6

Windows Client Utility

...........................................................................9

3.1

Starting Program

.................................................................................9

3.2

......................................................................................................10

3.3

Main User Interface

..........................................................................10

3.4

Screen Projection

..............................................................................10

3.5

Menu Description

.............................................................................. 11

3.5.1

Show Login Code

........................................................................... 11

3.5.2

Open Admin Web Page

................................................................12

3.5.3

Searching Server

...........................................................................13

3.5.4

Projection Quality

.........................................................................13

3.5.5

Projection Source

..........................................................................14

3.5.6

Connection Profile

.........................................................................15

3.5.7

Auto WiFi Connect

........................................................................16

3.5.8

Auto Power Manager

...................................................................16

3.5.9

Hide UI

..............................................................................................17

3.5.10

Advanced Screen Capture

......................................................17

3.5.11

Make PnS Token

........................................................................18

3.5.12

Copy Application to desktop

.................................................19

3.5.13

About

..............................................................................................20

3.5.14

Exit

..................................................................................................20

Web Management

.................................................................................21

4.1

Home Page

...........................................................................................21

4.2

Download Software

..........................................................................22

4.3

..............................................................................23

4.3.1

System Status

.................................................................................23

4.3.2

Network Setup

...............................................................................24

4.3.3

Projection Setup

............................................................................25

4.3.4

Change Passwords

........................................................................25

4.3.5

Reset to Default

.............................................................................26

4.3.6

Firmware Upgrade

........................................................................27

4.3.7

Reboot System

...............................................................................28

4.3.8

Logout

................................................................................................29

- 4 -

WPG-120 User Manual

1.Overview

PLANET WPG-120 is a portable wireless presentation gateway based on 802.11g technology.

The size is only 8*3.5*2 cm and the weight is 53g. You cloud take WPG-120 to anywhere you

want present at anytime. It cloud provide four wireless users to easily display their

presentations without swapping cables at the same time.

The output resolution of WPG-120 supports up to 1024x768 with 16-bit color, which gives the

high quality displaying in both presentation. To ensure the session security, every user is

required to key in a valid password prior than using WPG-120. Also, the built-in wireless AP

supports 64/128-bit WEP and WPA-PSK/WPA2-PSK encryption to secure its communication.

The WPG-120 is compatible with VGA-equipped devices; you can connect this gadget to any

projector, LCD TV or large screen display. The embedded windows-based utility enables

connected users directly download the utility from the WPG-120 web screen, CD or USB

adapter, that offers the most convenient way for the new user access to presentation in

seconds.

Plug & Show

With Plug & Show USB Token, wireless presentation becomes easy! Just link your

PC/Laptop to WPG-120, plug the token into a USB port, and in seconds, your screen will be

wirelessly projected to the connected projector!

High performance screen projection

WPG-120 provides the latest generation screen projection technology.

The smoothest screen works by the projection wirelessly, no matter what screen shows on

your PC.

4-to-1 Split Screen Projection

With this 4-to-1 split screen feature, up to four PC screens can be projected to one projector at

the same time. Thus you can easily do side-by-side comparison from four PC / PDAs to

increase meeting productivity!

¾Features

■Web-based GUI for and Control Panel for easily configuration

■Projection Quality Option

■Support Windows Vista, XP, 2000.

■Auto Power Manager

■Hide Utility Panel

■Supports 64/128-bit WEP, WPA –TKIP(PSK), WPA2-AES(PSK),

contents and keep good security to office networks.

■Supports Win-XP Virtual Desktop

WPG-120 User Manual

2.Quick Start

1) Plug the WPG-120 into the projector VGA input or connect a VGA cable to

the WPG-120 VGA connector and turn on projector power.

2) Turn on WPG-120.

♦When projector shows the default menu on the screen as below, it

indicates the WPG-120 is ready.

3) Make sure your PC WLAN is enabled then connect to your PC with the

WPG-120 User Manual

WPG-120.

4) Open your browser and it will redirect to the WPG-120 main page

automatically, or you can enter the IP address to access the WPG-120 web

home page.

♦The default IP address of WPG-120 is 192.168.1.1 or refers to the IP

address shown on the bottom left corner of projector screen.

5) Download the client software, select “ Windows Vista / XP / 2000” and

execute the installation program.

♦After installing the program, you will see the WPG-120 shortcut on the PC

screen.

WPG-120 User Manual

6) Make sure your personal firewall allows WPG-120 software to pass through.

7) Enter the LOGIN CODE and

♦You can see the login code is the top left of the projector screen.

8) Click the “Play” button to start projection!

WPG-120 User Manual

3.Windows Client Utility

3.1 Starting Program

After you download the WPG-120 windows program via web page successfully

follow the steps below to start.

1) Click WPG-120 icon to execute the program.

2) Program will start to search for WPG-120 automatically,

3) If WPG-120 is found the “Login Code” dialog box will pop up on the PC

screen.

Searching for WPG-120.

When WPG-120 is found, enter login code to start.

WPG-120 User Manual

3.2 Login

1) After “Login Code” dialog box shown, enter login code to start presentation.

2) You can see the login code shown in the top left of the projector screen.

3.3 Main User Interface

Menu Area

3.4 Screen Projection

Status Indicator

Control Area for Screen

Projection Feature

Click the “Play” button for full or split screen, you can project the main screen

on to the display immediately, click the “Pause” button, to freeze the image,

and click the “Stop” button to end the presentation.

Otros manuales para WPG-120

Tabla de contenidos

Otros manuales de Puerta de Planet

Planet

Planet MH-2300 Manual de usuario

Planet

Planet SKD-200 Manual de usuario

Planet

Planet UMG-2000 Manual de usuario

Planet

Planet ICG-2510W-LTE Series Manual de usuario

Planet

Planet VIP-281 Series Manual de usuario

Planet

Planet WPG-210N Manual de usuario

Planet

Planet VIP-160 Manual de usuario

Planet

Planet VIP-410 Manual de usuario

Planet

Planet ISG-101 Manual de usuario

Planet

Planet WIPG-300H Manual de usuario

Planet

Planet WIPG-300H Manual de usuario

Planet

Planet BM-2101 Manual de usuario

Planet

Planet IG-100 Manual de usuario

Planet

Planet IMG-110T Manual de usuario

Planet

Planet WPG-100 Manual de usuario

Planet

Planet MH-5000 Manual de usuario

Planet

Planet WSG-500 Manual de usuario

Planet

Planet VIP-450 Manual de usuario

Planet

Planet VGW 10 Series Manual de usuario

Planet

Planet VIP-1680 Series Manual de usuario

Planet

Planet LCG-300 Series Manual de usuario

Planet

Planet WPG-120 Manual de usuario

Planet

Planet VGW-402 Manual de usuario

Planet

Planet WPG-200N Manual de usuario

Manuales populares de Puerta de otras marcas

LST

LST M500RFE-AS Manual de usuario

Kinnex

Kinnex Media Gateway Manual de usuario

2N Telekomunikace

2N Telekomunikace 2N StarGate Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manual de usuario

Telsey

Telsey CPVA 500 - SIP Manual de usuario

RTA

RTA 460A-NNA4 Hoja de especificaciones

Shaw

Shaw Gateway HDPVR Manual de usuario

ABB

ABB VSN900 Guía de inicio rápido

Commander

Commander Pulse Manual de usuario

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manual de usuario

NETGEAR

NETGEAR C6300BD Manual de usuario

Amit

Amit CDW531AM Manual de usuario

HMS

HMS Netbiter EasyConnect EC150 Manual de usuario

Huawei

Huawei EchoLife HG620 Manual de usuario

AT&T

AT&T U-verse 3801 Manual de uso y cuidado

Logic IO

Logic IO RTCU MX2 turbo Manual de usuario

Suttle

Suttle MediaMAX MXM-521 Manual de usuario
