Quick Reference Guide

DM100i / DM200L Digital Mailing Systems

DM100i / DM200L

1 Elmcroft Road

Stamford, Connecticut 06926-0700

www.pitneybowes.com

Customer Support: 1.800.522.0020

DM100i / DM200L

Funds

Menu Options

Print Menu

The Print Menu key provides quick access to what will, or will not, be printed on your mail.

Selecting the Print Menu key provides

these additional printing options.

Seal Only allows you to use your system moistener and

transport mechanism to wet and seal envelopes. In this mode

nothing will be printed on the envelope as it moves through the

system.

Date & Time Only allows you to print a “received” stamp, usually

placed on incoming mail. Nothing except this stamp is printed in this

mode.

Ad Only allows you to print only the currently selected ad slogan on

the envelope. This can be most useful if you have a personalized

ad slogan that you want to print in the area the meter stamp usually

appears.

Selecting Omit day/date/other allows you to print a normal meter

stamp without the day...or without the date altogether.

Free Auto Repair Estimates

Jake’s Garage

99 Main Street

Somecity, US 12345

VOID VOID

Date omitted

Day omitted

Seal Only

Date & Time Only

Ad Only

PRINT MENU

Omit day/date/other

PRINT MENU

Page

Down

Normal

Preset Home

Yes/Enter

Custom

Preset

Page

Down

Print Menu

Reports

Add

Postage

PQRS

Weigh/Rate

Options

®®

Funds

ABC DEF

GHI

Clear Space Shift

JKL MNO

TUV WXYZ

"TF

Getting to know the DM100i / DM200L

These cards provide quick step-by-

step instructions to perform basic

operations with your DM Series meter.

For more detailed information

refer to the Operator Guide that is

included on the CD, or visit

www.pitneyworks.com/DM100 or

www.pitneyworks.com/DM200

for the most current version.

Selection Keys are active when

display arrow ( ) is present.

Home Screen

When 3 bars are visible the

system is ready to print postage.

When scroll keys are lit,

more information is available

by pressing keys.

Power and Lock

Return to the

Home Screen

at any time from

any place.

Return to your most

frequently used setting.

Determine instantly how much

postage you have used, and

how much is left.

Add postage to your

system with as few as 2

button presses.

Changing Ink Cartridge

Print Menu

Overview

Key in Postage / Meter Stamp

CLICK

Changing the Ink Cartridge

Remove the scale by placing your hands in

the left and right scoops and lifting straight

up. (DM200L only. The scale does not

have to be removed for DM100i.)

Open the top cover. The Top Cover Open

message will appear on the display.

Select Replace Ink Tank to continue.

Flip open the ink cartridge cover.

Lift and remove the old ink cartridge.

Close the cover. The system will auto-

matically recognize the new cartridge,

perform a brief maintenance operation,

and return you to the home screen.

Replace the scale. (DM200L only)

Lower the new ink cartridge into position.

The printing on the top of the cartridge

should face the front of your system.

Return the guard to the closed position

and click to secure.

1 2 3

4 5 6

a b c d

Changing Ink Cartridge

Print Menu

CLASS: None

SCALE: 0lb 0.0 oz

Aug 24 08

Key in Postage

If you know the value of the postage you want to print... simply key it in!

Select Enter.

Your system is ready to print

postage.

Select 2.

PQRS

ABC DEF

GHI

Clear Space Shift

JKL MNO

TUV WXYZ

CLASS: None

SCALE: 0lb 0.0 oz

Aug 24 08 42

PQRS

ABC DEF

GHI

Clear Space Shift

JKL MNO

TUV WXYZ

For example: At the home screen

Select 4.

CLASS: None

SCALE: 0lb 0.0 oz

Aug 24 08 4

Yes/Enter

Registration wall

Tape sheet

Place the long edge of the envelope ush against the registration wall. Slide the mail into the

meter. The system will detect the envelope and automatically guide it through the printing

mechanism.

If you’re mailing a package, or your letter is too thick to pass through the meter, you may print a

postage tape. Tape sheets may be fed and printed the same as envelopes.

Print a Meter Stamp

Overview

Key in Postage / Meter Stamp

0.42

Using the Moistener

You may moisten, seal, and print postage in one smooth operation.

Install moistener as shown. Fill reservoir with E-Z Seal™

Sealing Solution.

Guide envelope ap around gray edge

of moistener deck as shown.

1 2 3

Clear a Jam

Turn the jam clearance lever to the

right (clockwise).

To clear a jam, do the following:

Remove the mail piece.

Rotate lever back to its home

position.

Set up a preset.

Press the Custom Presets key.

Select Dene Normal Preset.

Select YES: store preset.

CLASS 1st ClLtr

SCALE 0lb 0.0 oz

Aug 24 08 0.42

Custom

Preset

Normal

Preset Home

Return to the Home Screen by

selecting Home or Clear.

From this point on whenever you

select the Normal Preset key the values

you just chose will be set on your meter.

If these values are acceptable, select

YES: store preset.

YES: store preset

NO:review values

Are all the curernt

values correct?

Select Class.

Set up a class of mail (for example, select 1st Class followed

by Letter, followed by Done).

Conrm that the screen now shows the correct class (in this

example, it should read “Class: 1st ClLtr” and “0.42”).

If you dene a preset based on a Postal Class (e.g. First Class Letter) instead of only a value (e.g. $0.42) your preset will update automati-

cally whenever the postal rates change. This is highly recommended.

Setting the Normal Preset to a Class

Complete the process.

When the system returns to the “Custom Presets” screen,

press the Home key.

Clear Jam / Moistener

Rate Preview

Normal Preset - Value

Normal Preset - Class

PQRS

ABC DEF

GHI

Clear Space Shift

JKL MNO

TUV WXYZ

Rate Preview

Make sure the Class is set to “None”. You can set the

Class to “None” by keying in 0 on the keypad, and pressing

the Yes/Enter button.

Put the mail piece on the scale. The weight of the mail

piece will appear in the upper right of the display, and pos-

sible classes and rates for this weight will be displayed on

the screen. If there is no value next to a class name your

system needs more information to calculate an accurate

rate.

Selecting a key with no associated rate will either prompt

you for the additional information needed or present

alternative rates. For example, selecting 1st Class on the

screen above would present a screen such as:

(Don’t forget the lighted scroll keys to view additional

classes and rates.)

If you are unsure if a particular class is valid for your mail

piece, visit www.`usps.com

CLASS: None

SCALE: 0lb 0.0 oz

Aug 24 08 0.00

0lb 10 oz

1st Class

Priority

Pkg. Service

3Page

Page

Down

Lighted scroll keys

Custom

Preset

Normal

Preset

DEF

Setting a Normal Preset

The normal preset is a shortcut; a single button selection to call up your most frequently used settings. Many customers choose to set the

Normal preset to the cost of a 1 oz First Class letter, since that is the most frequently used setting. Whenever your meter is powered on, or

wakes from the sleep mode, it will display the Normal preset values.

Key in the value you wish to

make the Normal Preset.

Select Custom Preset key.

Setting the Normal Preset to a Value

Select Dene Normal Preset. You can view all the values

associated with this Normal Preset by selecting NO: review

values. This will show you which ads and inscriptions, if any,

are associated with your Normal Preset.

CUSTOM PRESETS

Select Preset

Define New Preset

Define Normal Preset

YES: store preset

NO:review values

Are all the current

values correct?

If your meter recognizes the value you keyed in as a common-

ly used value (such as the cost of a 1 oz First Class letter),

you will be prompted to include a class in your Normal Preset.

It is recommended

a class be included

in this preset

Continue

Select Continue.

Include a Class?

Yes

Tell me why

Follow the screen prompts to

either include the class, or not.

Note: It is strongly recommended that you INCLUDE the class in

your preset. See additional information in the section, “Setting

the Normal Preset to a Class.”

Normal Preset - Value

Normal Preset - Class

Clear Jam / Moistener

Rate Preview

0lb 10 oz

Flat $2.36

Parcel $2.70

Enter Weight

Adding Postage

Enter Weight

Adding Postage

Reports Weigh/Rate

PQRS

ABC DEF

GHI

Clear Space Shift

JKL MNO

TUV WXYZ

PQRS

ABC DEF

GHI

Clear Space Shift

JKL MNO

TUV WXYZ

Enter a Known Weight

If you have not purchased the optional

scale, or you know the weight of your

mail piece, or if your package is too

heavy for the scale...

Select Weight/Rate key.

Select Enter Manual

Weight.

Key in pounds. Select Set pounds.Key in ounces. Select Set oz. and Continue.

You will see the screen as shown on the Rate Preview card.

In this example, all of the classes

available for a 5lb, 2 oz. package will

require additional information, such

as Destination ZIP Code.

Set pounds

Clear pounds

Enter weight

5 lb oz

5lb 2 oz

Aug 24 08

Priority

Pkg. Service

Express

Set oz and Continue

Clear ounces

Enter weight

5 lb 2 oz

0lb 0 oz

Enter Manual Weight

Rate mail on scale

$X.XX

Aug 24 08

ACCT: Xyz

CLASS: Pkg

MAN WT 5lb 2.0 oz

After you have completed the

rating process, including any fee

services desired (e.g. insurance)

you return to the Home screen

by selecting Done.

The bottom line on the home

screen will remind you that a

manually entered weight was

used ot compute the postal rate.

Diff.weighing

ADD POSTAGE TO METER

Add $ 50.00

Add another amount

Check PBP balance

Continue

Enter amount of

postage to add.

$100.00

Adding Postage

It is very simple and convenient to add postage to your system.

Press the Add Postage key.

You can pick the default amount

shown, key in a different amount to

add, or call the Data Center to check

your balance.

Suppose you wish to add $100.00,

select Add another amount.

Key in the amount of postage you wish

to add. You can only enter whole dollar

amounts. Select

Continue.

You will be asked to conrm the

amount requested.

1 2 3

Refill

Receipt

Refill: AUG 2 4 08 11:3 8 A Ac c oun t N o: 12 0 000

Refill Amount: $1 00.0 0 Me t er N o .: 111114 6

Funds Avai la bl e in M et er : $ 115. 0 0 AU G 24 08

Prepaid: $ 9 35. 0 00 11: 3 8 A

Additional Funds Available: 000000000000

Add

Postage Reports

* PBP is Postage by Phone

Postage Added

Amt Added $100.00

Available $115.00

Receipt (Yes or No)

Yes/Enter

Please insert

envelope or tape

sheet to print

receipt.

The system contacts the Postage

By Phone™ Data Center automati-

cally. The funds transfer should take

less than 60 seconds.

To print your receipt select Yes.

CONFIRM ADD POSTAGE

Adding $100.00

(Yes or No)?

Yes/Enter

Otros manuales para DM100i Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de correo digital de Pitney Bowes

Pitney Bowes

Pitney Bowes E500 Manual de usuario

Pitney Bowes

Pitney Bowes DM800 Series Manual

Pitney Bowes

Pitney Bowes DM300c series Manual

Pitney Bowes

Pitney Bowes DM100i Series Manual

Pitney Bowes

Pitney Bowes DM100i Series Manual de usuario

Pitney Bowes

Pitney Bowes DM50 Series Manual

Pitney Bowes

Pitney Bowes DM300c series Manual de usuario

Pitney Bowes

Pitney Bowes SendPro 300 Manual

Pitney Bowes

Pitney Bowes dm300m series Manual de usuario

Pitney Bowes

Pitney Bowes DM100i Series Manual de usuario

Pitney Bowes

Pitney Bowes DM50 Series Guía

Pitney Bowes

Pitney Bowes DM50 Series Manual de usuario

Pitney Bowes

Pitney Bowes MAILSTATION 2 Manual

Pitney Bowes

Pitney Bowes dm60 series Manual de usuario

Pitney Bowes

Pitney Bowes MAILSTATION 2 Manual de usuario

Pitney Bowes

Pitney Bowes SendPro Mailstation Manual de usuario

Pitney Bowes

Pitney Bowes DM100i Series Manual de usuario

Pitney Bowes

Pitney Bowes SV62214 Manual

Pitney Bowes

Pitney Bowes DM300c series Manual de usuario

Pitney Bowes

Pitney Bowes DM300c series Manual

Pitney Bowes

Pitney Bowes DM100i Series Manual de usuario

Pitney Bowes

Pitney Bowes DM Series Especificaciones

Pitney Bowes

Pitney Bowes SendPro 300 Manual de usuario

Pitney Bowes

Pitney Bowes DM220i Series Manual

Manuales populares de Sistema de correo digital de otras marcas

Neopost

Neopost IJ 80 Manual de usuario

Costway

Costway NP10936CP Manual de usuario

Neopost

Neopost IS-430 Manual de usuario

Salsbury Industries

Salsbury Industries 4855E Manual de usuario

quadient

quadient iX-3 Series Manual de usuario

quadient

quadient IS-350 Manual de usuario

Martin Yale

Martin Yale 2051 SmartFold Manual

quadient

quadient iA Series Manual de usuario

quadient

quadient IN-360 Series Manual de usuario

Neopost

Neopost IS-350 Manual de usuario

Vade Retro

Vade Retro mailcube Manual de uso y cuidado

Hasler

Hasler WJ185 Manual de usuario

quadient

quadient IN-600 Manual de usuario

FP PostBase Vision Guía del usuario

Neopost

Neopost IJ 110 Manual de usuario

quadient

quadient IS-280 Manual de usuario

FP Post Base Vision Manual del operador

Neopost

Neopost HD-CXENVL-FDR V2 Instrucciones de instalación
