PSS u2 ES 4IOL
Operating Manual-1004880-EN-01
}Control system PSS u2
}Remote I/O system PSS u2
Preface
This document is the original document.
All rights to this documentation are reserved by Pilz GmbH & Co. KG. Copies may be made
for the user's internal purposes. Suggestions and comments for improving this documenta-
tion will be gratefully received.
Source code from third-party manufacturers or open source software has been used for
some components. The relevant licence information is available on the Internet on the Pilz
homepage.
Pilz®, PIT®, PMI®, PNOZ®, Primo®, PSEN®, PSS®, PVIS®, SafetyBUS p®,
SafetyEYE®, SafetyNET p®, the spirit of safety® are registered and protected trademarks
of Pilz GmbH & Co. KG in some countries.
SD means Secure Digital
Contents
Operating Manual PSS u2 ES 4IOL
1004880-EN-01 3
Section 1 Introduction 5
1.1 Validity of documentation 5
1.2 Using the documentation 5
1.3 Definition of symbols 5
Section 2 Overview 7
2.1 Module features 7
Section 3 Safety 8
3.1 Intended use 8
3.2 System requirements 8
3.3 Safety regulations 8
3.3.1 Use of qualified personnel 8
3.3.2 Warranty and liability 9
3.3.3 Disposal 9
Section 4 Function description 10
4.1 Process data 10
4.2 Block diagram 12
4.3 Supply 13
4.4 PROFINET 13
4.5 EtherNet/IP 13
4.6 Reaction time 14
4.7 Configuration options 14
Section 5 Exchanging an IO-Link device 16
Section 6 Exchanging a master 17
Section 7 Installation 18
7.1 General installation guidelines 18
7.1.1 Dimensions 18
7.2 Inserting and removing an electronic module 19
7.2.1 Inserting an electronic module 19
7.2.2 Removing an electronic module 21
7.2.3 Changing an electronic module during operation 21
Section 8 Wiring 22
8.1 General wiring guidelines 22
8.1.1 Connection mechanism for terminal blocks 22
8.2 Terminal configuration 22
8.2.1 Connection examples 23
Section 9 Operation 26
9.1 Display elements and messages 26
Contents
Operating Manual PSS u2 ES 4IOL
1004880-EN-01 4
Section 10 Technical details 29
Section 11 Order reference 31
11.1 Product 31
11.2 Accessories 31
Introduction
Operating Manual PSS u2 ES 4IOL
1004880-EN-01 5
1 Introduction
1.1 Validity of documentation
This operating manual explains the function and operation, describes the installation and
provides guidelines on how to connect the product.
This documentation is valid for the product PSS u2 ES 4IOL. It is valid until new document-
ation is published.
1.2 Using the documentation
This document is intended for instruction. Only install and commission the product if you
have read and understood this document. The document should be retained for future ref-
erence.
Please refer to the PSS u2 Installation Manual.
1.3 Definition of symbols
Information that is particularly important is identified as follows:
DANGER!
This warning must be heeded! It warns of a hazardous situation that poses
an immediate threat of serious injury and death and indicates preventive
measures that can be taken.
WARNING!
This warning must be heeded! It warns of a hazardous situation that could
lead to serious injury and death and indicates preventive measures that can
be taken.
CAUTION!
This refers to a hazard that can lead to a less serious or minor injury plus
material damage, and also provides information on preventive measures
that can be taken.
NOTICE
This describes a situation in which the product or devices could be dam-
aged and also provides information on preventive measures that can be
taken. It also highlights areas within the text that are of particular import-
ance.
Introduction
Operating Manual PSS u2 ES 4IOL
1004880-EN-01 6
INFORMATION
This gives advice on applications and provides information on special fea-
tures.
Overview
Operating Manual PSS u2 ES 4IOL
1004880-EN-01 7
2 Overview
Module structure:
A module consists of
}An electronic module
}A terminal block with cage clamp terminals and
}A backplane
The electronic modules are plugged into the backplane and determine the function. The
backplane is used for communication between the head module and the electronic modules
and forms the carrier unit for the electronic modules. The terminal block is plugged into the
electronic modules and is used to connect the field wiring.
Details of the terminal blocks that can be used are available under "Intended Use".
2.1 Module features
The product has the following features:
}IO-Link master in accordance with IO-Link specification v1.1
}4 IO-Link ports for connecting 4 IO-Link devices or 4 sensors / 4 actuators respectively
}Voltage outputs L+/L- for sensor and actuator supply
}Supported transmission rates:
– COM1 (4.8 kBd)
– COM2 (38.4 kBd)
– COM3 (230.4 kBd)
}Up to 32 bytes of process data per port
}Up to 128 bytes of process data, including header, per module
}Device configuration saved in the master
}Energy-saving functions
}LEDs for:
– IO-Link mode
– Module error
– Operating status
Safety
Operating Manual PSS u2 ES 4IOL
1004880-EN-01 8
3 Safety
3.1 Intended use
The module (IO-Link master) provides standard IO-Link ports and may be used to connect
IO-Link devices or sensors/actuators for standard applications.
Intended use includes making the electrical installation EMC-compliant. The module is de-
signed for use in an industrial environment. Interference may occur if used in other areas.
The following is deemed improper use in particular
}Any component, technical or electrical modification to the module,
}Use of the module outside the areas described in this manual,
}Any use of the module that is not in accordance with the technical details.
The module PSS u2 ES 4IOL may be used in conjunction with the following terminal block:
}16-pin terminal block
3.2 System requirements
INFORMATION
The module is supported by
}PASconfig from version 3.0.0
– We recommend that you always use the latest version (download
from www.pilz.com).
3.3 Safety regulations
3.3.1 Use of qualified personnel
The products may only be assembled, installed, programmed, commissioned, operated,
maintained and decommissioned by competent persons.
A competent person is a qualified and knowledgeable person who, because of their train-
ing, experience and current professional activity, has the specialist knowledge required. To
be able to inspect, assess and operate devices, systems and machines, the person has to
be informed of the state of the art and the applicable national, European and international
laws, directives and standards.
It is the company’s responsibility only to employ personnel who
}Are familiar with the basic regulations concerning health and safety / accident preven-
tion,
}Have read and understood the information provided in the section entitled Safety
}Have a good knowledge of the generic and specialist standards applicable to the spe-
cific application.
Safety
Operating Manual PSS u2 ES 4IOL
1004880-EN-01 9
3.3.2 Warranty and liability
All claims to warranty and liability will be rendered invalid if
}The product was used contrary to the purpose for which it is intended,
}Damage can be attributed to not having followed the guidelines in the manual,
}Operating personnel are not suitably qualified,
}Any type of modification has been made (e.g. exchanging components on the PCB
boards, soldering work etc.).
3.3.3 Disposal
}When decommissioning, please comply with local regulations regarding the disposal of
electronic devices (e.g. Electrical and Electronic Equipment Act).
Function description
Operating Manual PSS u2 ES 4IOL
1004880-EN-01 10
4 Function description
4.1 Process data
}The size of the IO-Link master's process image is variable. It depends on the size of the
process image of the devices that are used.
}The IO-Link master's process image of inputs (PII) consists of the PII of the devices and
a 3 Byte header.
}The IO-Link master's process image of outputs (PIO) consists of the PIO of the devices
and a 3 Byte header.
}The header always precedes the devices' process data.
}The maximum size of the process image of inputs (PII), including the header, is 128
Bytes per module and 32 Bytes per port.
}The maximum size of the process image of outputs (PIO), including the header, is 128
Bytes per module and 32 Bytes per port.
Example of the module's process image
The example below shows the structure of the process image for the IO-Link master mod-
ule. A process image size of 8 Bytes was used for the example. The example uses two IO-
Link sensors, each with a process image size of 2 Bytes and an IO-Link actuator with a pro-
cess image size of 1 Byte. Unused bytes are filled with zeros.
Port 2
Byte 6
Byte 4 Byte 5
EmptyHeader
Byte 3
EmptyEmptyEmpty
Byte 0...2
Port 0
Byte 6
Byte 4 Byte 5
EmptyHeader
Byte 3
Byte 0...2
PII
PIO
Port 0 Port 1 Port 1
Byte 7
Byte 7
Fig.: Example of the module's process image
Legend
PII Process image of inputs
Header For details of structure see sections entitled "Header in the process image
of inputs" and "Header in the process image of outputs".
Port 0 IO-Link device with 2 Bytes of input data
Port 1 IO-Link device with 2 Bytes of input data
PIO Process image of outputs
Port 2 IO-Link device with 1 Byte of output data
Empty Unused bytes, which are filled with zeros
