Issue 2.4 June 2021

40-784A User Manual

PXI Microwave Multiplexer Modules

Page (II) MICROWAVE MULTIPLEXER MODULE 40-784A

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

MICROWAVE MULTIPLEXER MODULE 40-784A

pickering

WARNING

Only the correct connector series should be mated with these modules. The 40-784A range uses SMA

connectors for the 6GHz, 18GHz and 26.5GHz modules, and SMA-2.9 connectors for the 40GHz modules. The

user should only mate the correct type to the module, failure to do so may result in damage to the connector.

Also, it is important that the SMA connector’s nut is properly tightened to the correct torque with a 5/16 inch

wrench. This should be 3-5 in·lbs (0.3 to 0.6 N·m) for brass, and 7-10 in·lbs (0.8–1.1 N·m) for stainless steel

connectors.

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) MICROWAVE MULTIPLEXER MODULE 40-784A

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy reference should be made to the safety instructions for

provisions of lifting and moving.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

MICROWAVE MULTIPLEXER MODULE 40-784A

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Section 3

Installation....................................................................................3.1

Pre Operation Checks...........................................................3.1

Hardware Installation ............................................................3.2

Software Installation .............................................................3.2

Testing Operation ..................................................................3.3

Section 4

Programming Guide....................................................................4.1

Programming Options For Pickering PXI Modules ............4.1

Module Architecture..............................................................4.2

Programming The Module ....................................................4.3

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting.........................................................................6.1

Section 7

Maintenance Information............................................................7.1

CONTENTS

Page (VI) MICROWAVE MULTIPLEXER MODULE 40-784A

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

MICROWAVE MULTIPLEXER MODULE 40-784A

pickering

Page (VII)

REED RELAY MODULE 40-110/115/120/125

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the host chassis are populated with blanking plates to prevent access to user

I/O signals that may be present. Blanking panels are available to order from Pickering in a variety

of slot widths. If the product is not used in this manner for example by using an extender card then

additional care must be taken to avoid contact with exposed signals.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

anti-static bags.

CAUTION - PRODUCT DOCUMENTATION SYMBOL

and understood before attempting to install or operate the product.

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O

signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on

the front of the unit.

Page (VIII) MICROWAVE MULTIPLEXER MODULE 40-784A

pickering

THIS PAGE INTENTIONALLY BLANK

Page 1.1

MICROWAVE MULTIPLEXER MODULE 40-784A

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

PXI Microwave Multiplexer Modules 40-784A

ISSUE 3.1 MAY 2021

ySingle, Dual or Triple Subminiature SP6T & SP4T MUXs

y6 GHz, 18 GHz, 26.5 GHz & 40 GHz Bandwidths

yCustom Versions Available

yExcellent RF & Repeatability Characteristics

yExtended Life For 6 GHz/18 GHz/26.5 GHz Models –

10 M Operations Guaranteed & Typically >25 M!

yFaster Operate Time than Conventional

Microwave Relay Solutions (Typically <10.5 ms)

yLED Indication

yVISA, IVI & Kernel Drivers Supplied for Windows

ySupported by

PXI, PXIe Hybrid and Pickering LXI

Modular Chassis

y3 Year Warranty

The 40-784A PXI microwave multiplexer modules have a

characteristic impedance of 50 Ω and are capable of switching

signals up to 40 GHz. Available in single, dual or triple, SP6T

or SP4T formats, they are suitable for constructing complex

microwave switching. Connection is by high performance

front panel mounted SMA or SMA-2.9 connectors.

These modules provide a high performance solution for RF

and microwave switching, the performance at low frequencies

providing superior isolation, insertion loss and VSWR to EMR

or solid state designs.

40-784A Triple

SP4T MUX

4Com

MUX Bank 1

off

4Com

off

MUX Bank 2

4Com

off

MUX Bank 3

4Com

off

40-784A Single

SP6T MUX

3Com

off

3Com

off

MUX Bank 1

MUX Bank 2

3Com

off

MUX Bank 3

3Com

off

40-784A Triple

SP6T MUX

40-784A Single

SP4T MUX

40-784A Dual

SP4T MUX

4Com

MUX Bank 1

off

4Com

off

MUX Bank 2

3Com

off

3Com

off

MUX Bank 1

MUX Bank 2

40-784A Dual

SP6T MUX

For applications where space is critical, users should

consider the remote relay versions of the 40-785A which

support up to 3 remotely mounted multiplexers from a

single PXI slot.

Page 1.2 MICROWAVE MULTIPLEXER MODULE 40-784A

pickering

SECTION 1 - TECHNICAL SPECIFICATION

Microwave Multiplexer, 40-784A

pickeringtest.com

Speciﬁcations

Switching Speciﬁcation

Relay Manufacturer: Radiall

Conﬁguration: SP6T or SP4T Microwave

Multiplexer with 1, 2 or 3

independent banks.

LED Indicators: Multiplexers have blue

LEDs to indicate a closed

RF path.

Operate Time: Typically <10.5 ms

Maximum Cold Switch Voltage: 100 V

Maximum Carry Current: 1 A

Multiplexer Speciﬁcation - 6 GHz Versions

Characteristic Impedance: 50 Ω

Connectors: SMA

Bandwidth DC to 6 GHz

Maximum RF Carry Power: 220 W (0-3 GHz)

150 W (3-6 GHz)

Isolation: >80 dB (0-3 GHz)

>70 dB (3-6 GHz)

Insertion Loss: <0.2 dB (0-3 GHz)

<0.3 dB (3-6 GHz)

VSWR: <1:1.2 (0-3 GHz)

<1:1.3 (3-6 GHz)

Expected Life (low power): >10 million operations

per position guaranteed

(typically >25 million)

Insertion Loss Repeatability: Within 0.01 dB

Typical VSWR Plot for 6 GHz Versions

Typical Isolation (dB) Plot for 6 GHz Versions

Typical Insertion Loss (dB) Plot for 6 GHz Versions

Tabla de contenidos

Otros manuales de Multiplexor de Pickering

Pickering

Pickering SIMRC 1050 Manual de usuario

Pickering

Pickering 40-610A Manual de usuario

Pickering

Pickering 40-613 Manual de usuario

Pickering

Pickering 60-590 Manual de usuario

Pickering

Pickering PXI Power MUX BRIC 40-571 Manual de usuario

Pickering

Pickering 40-683A Manual de usuario

Pickering

Pickering LXI 60-820 Manual de usuario

Pickering

Pickering PXI 40-660 Manual de usuario

Pickering

Pickering 60-721A Manual de usuario

Pickering

Pickering PXI 40-655 Manual de usuario

Pickering

Pickering 40-617A Manual de usuario

Pickering

Pickering SYSTEM 10 Manual de usuario

Pickering

Pickering SYSTEM 10 Manual de usuario

Pickering

Pickering 40-756 Manual de usuario

Pickering

Pickering SYSTEM 10 Manual de usuario

Pickering

Pickering 20-610 Manual de usuario

Pickering

Pickering PXI 40-740 Manual de usuario

Pickering

Pickering PXI 40-882B Manual de usuario

Pickering

Pickering 40-667B Manual de usuario

Pickering

Pickering 40-761 Series Manual de usuario

Pickering

Pickering PXI 40-850A Manual de usuario

Pickering

Pickering 42-204 Manual de usuario

Pickering

Pickering 40-310 Manual de usuario

Pickering

Pickering 40-850 Manual de usuario

Manuales populares de Multiplexor de otras marcas

Campbell

Campbell AM416 Manual de usuario

Paradyne

Paradyne SIM2000 Manual de usuario

Panasonic

Panasonic WJFS616 - SWITCHER Manual de usuario

Lanex

Lanex TM-77 Manual de usuario

Bosch

Bosch VSS8394/01T Manual de usuario

Quark-Elec

Quark-Elec QK-A035 Manual de usuario

ADTRAN

ADTRAN Frameport 768 Manual de usuario

Elo TouchSystems

Elo TouchSystems E247 Manual de usuario

Paradyne

Paradyne Hotwire 8786 Manual de usuario

RFL Electronics

RFL Electronics 9508D UCC Manual de usuario

Miranda

Miranda AMX-101i Manual de instrucciones

ShipModul

ShipModul MiniPlex-AIX NMEA-0183 Manual de usuario

GE StoreSafe SDVR-10 Manual de usuario

American Fibertek

American Fibertek MTX-8410C Manual de usuario

ADC

ADC HiGain ELU-319 5E Manual de usuario

Paradyne

Paradyne Hotwire 8774 Manual de usuario

American Fibertek

American Fibertek MTX-8810C-SL Manual de usuario

Viessmann

Viessmann 5229 Manual de usuario
