EN User manual

SPZ2000

PC webcam

9 Service and support 14

Need help? 14

Information to the customer 14

Safety precautions 14

Disclaimer 14

FCC compliance 15

Compliance with Electro-Magnetic Field

(EMF) 15

Recycling 15

Limitations of damages 16

Contents

1 Your webcam 2

Welcome 2

What’s in the box 2

Functional overview 3

2 Get started 4

(Optional) Install the webcam software 4

Connect the webcam to your PC/notebook 4

3 Use the webcam for video chatting 5

4 Philips CamSuite 6

5 Philips CamSuite Capture 7

Take and view a photo 7

Record and play a video 7

Image resolution 7

Screen mode 8

Gallery 8

Open the photo/video folder 8

Photo/Video menu 8

Send photo(s)/video(s) via email 9

Delete photo(s)/video(s) from the

gallery 9

6 Properties 10

7 Technicalspecications  11

8 Frequently asked questions (FAQ) 12

How can I adjust image quality? 12

The microphone of my Philips SPZ2000

webcam does not work (properly).What

should I do? 12

Using my Philips SPZ2000 webcam makes

my PC/notebook run slow.What should I

do? 13

No image is available on the screen.What

should I do? 13

English

What’s in the box

Please check that the following items are

packed in the Philips SPZ2000 webcam box.

Philips SPZ2000 webcam•

Quick start guide•

www.philips.com/welcome

SPZXXXX

Quick Start Guide

1 Your webcam

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

At www.philips.com/welcome, select•

your language and choose Register my

product. Then follow the on-screen

instructions for registration.

Please read the following instructions carefully,

and retain them for future reference.

Welcome

The Philips SPZ2000 webcam you have just

purchased is manufactured to the highest

standards and will give you years of trouble-free

use. Brilliant images and amazing sound quality,

that’s what you get with the SPZ2000 webcam.

After installation, the new webcam can be

used for all sorts of applications, such as:

• Video: Use the Philips SPZ2000 webcam

for video chatting and video calling. The

webcam works with Skype, Windows®

Live Messenger, Yahoo! Messenger, AOL

Instant Messenger, QQ and other instant

messaging and VoIP (Voice over Internet

Protocol) services;

• Video sharing: Create your own video

clips and share them with friends and

family via email, etc.;

• Snapshot images: Use the snapshot

button to easily take photos and share

your photos via Facebook, Flickr,

MySpace, and etc.;

The following sections in this manual give a

step-by-step description on how to use the

Philips SPZ2000 webcam.

iUSB connector

Connect the webcam to the USB•

port of the notebook or desktop PC

Supply power to the webcam when•

it is connected to the notebook or

desktop PC

jCable holder

Hold the cable for cable•

management

Functional overview

aFocus ring

Adjust the focus of the image•

manually

bSnapshot button

With Philips applications installed,•

take photos directly

cPower LED

Lights up when the webcam is in use•

dLens

eSlide cover

Protect your privacy and the lens•

fBuilt-in microphone

Capture voice and sound during•

video calling and recording

gRotating joint

Changetheviewingeldofthe•

webcam manually

hClamp with rubber rims

Mountthewebcamonyour(at•

panel) PC monitor or notebook screen

English

Connect the webcam to your

PC/notebook

1Turn on the PC/notebook.

2Clamp the webcam on your PC monitor

or notebook display.

Extend the clamp to place the•

webcam on a desk or (large) desktop

monitor.

3Connect the cable to a USB port on the

PC/notebook.

After the webcam is properly»

connected, the following pop-up

window is displayed at the lower right

corner of the screen .

4Adjust the webcam in a proper angle.

2 Get started

(Optional) Install the webcam

software

Note

To use special features provided by Philips•

CamSuite and Webcam Driver SPZ2000,

visit www.philips.com/support and download

the applications from the website. Philips

CamSuite only works on PCs with the

operating systems Microsoft®Windows XP®

(SP2 and higher), Vista, or Windows 7. After

the software installation, you can adjust Philips

SPZ2000 webcam settings on respective

property pages.

1At www.philips.com/support, click the

Choose country / language box to select

your country/language.

2Click the Search box, enter SPZ2000 and

then click the search button.

3Click Support for SPZ2000 .

Under»Product support,youwillnd

information about Software and driver.

4Download the software installer that you

want.

5Run the installer and follow the

instructions on the screen to complete

the installation.

After the software installation is»

complete, the Philips CamSuite icon

is displayed at the lower right corner of

the screen.

Tip

You can use the same way to download the•

latest software available for Philips SPZ2000

webcam.

3 Use the webcam

for video

chatting

Philips SPZ2000 webcam works with Skype,

Windows®Live Messenger,Yahoo! Messenger,

AOL Instant Messenger, QQ and other instant

messaging and VoIP (Voice over Internet

Protocol) services.

After you install one of the above applications,

you can plug the webcam into the PC/

notebook and use it for video chatting.

You can also slide the cover to protect your

privacy and the lens.

English

4 Philips CamSuite

Philips CamSuite provides a quick access to a

number of the most used features and settings.

To enjoy the special features and settings

provided by Philips CamSuite, install it before

using it with Philips SPZ2000 webcam.

After you install Philips CamSuite, you can

double-click the Philips CamSuite icon on

the Windows toolbar to access the Philips

CamSuite control panel.

Record and play a video

Note

If you select any resolution higher than 640•

x 480 (VGA), the recording icon is disabled.

You can select a lower resolution to enable

recording.

1Adjust the camera in a proper angle.

2In the Philips CamSuite Capture window,

click to start recording.

To pause recording, click• .

3To stop recording, click .

A video is recorded and stored in the»

video gallery.

4To play a video in the video gallery,

double-click it.

Tip

Before you play a video, ensure that you•

have a multimedia player installed on the PC/

notebook.

Image resolution

You can set different image resolutions for

photos/videos taken via the webcam:

160 x 120 (SQVGA)•

176 x 144 (QCIF)•

320 x 240 (E-mail size)•

352 x 288 (CIF)•

640 x 480 (VGA)•

1280 x 960 (1.3MP, for photo only)•

Note

For video recording, the maximum resolution•

is up to 640 x 480 (VGA).

1In the Philips CamSuite Capture window,

click the drop-down arrow.

The provided resolution options are»

listed.

5 Philips CamSuite

Capture

Via Philips CamSuite Capture, you have access

to the following webcam features:

Take photos•

Record videos•

Send photos or videos by email•

Adjust settings for photo, video,•

mute, and multimedia folders

1To launch Philips CamSuite Capture, click

on the Philips CamSuite control panel

or double-click on the desktop.

2To close Philips CamSuite Capture, click

the close button at the top right corner

of the Philips CamSuite Capture window.

Tip

If you are already using the webcam in another•

application, you will not be able to see any

image in the viewer of Philips CamSuite

Capture.

Take and view a photo

1Adjust the camera in a proper angle.

2In the Philips CamSuite Capture window,

click .

A photo is taken and stored in the»

photo gallery.

3To view a photo in the photo gallery,

double-click it.

English

Open the photo/video folder

In the photo gallery:

Select a photo and then click• to open

the photo folder.

In the video gallery:

Select a video and then click• to open

the video folder.

Photo/Video menu

To display the photo/video menu via right-

click on the mouse:

1In the photo/video gallery, select a photo/

video.

2Right-click the mouse.

The photo/video menu is displayed.»

3Select an option to continue.

Options on the photo menu:

• [View]: To view the selected

photo(s)

• [Email]: To send the selected

photo(s) via email

• [Delete]: To delete the selected

photo(s)

Options on the video menu:

• [Play]: To play the selected video(s)

2Select a preferred resolution option.

To apply another resolution setting,•

repeat Step 1 and Step 2.

Screen mode

Via Philips CamSuite Capture, you can view a

photo or play a video in different modes:

Normal screen mode•

Full screen mode•

Fit on screen•

1In the Philips CamSuite Capture window,

click to switch between modes, from

[Normal screen mode] to [Full screen

mode] / [Fit on screen] or from [Full

screen mode] / [Fit on screen] to

[Normal screen mode].

You can select»[Fit on screen] or [Full

screen mode] in the drop down list.

Gallery

Photos and videos taken via the webcam are

stored in the photo or video gallery and in the

selected photo or video folder (multimedia

folders).

To access the gallery:

1In Philips CamSuite Capture, click

to show gallery.

2Click to show the photo gallery.

Click• to show the video gallery.

To hide the gallery, click• .

• [Email]: To send the selected

video(s) via email

• [Delete]: To delete the selected

video(s)

Send photo(s)/video(s) via email

1In the photo/video gallery, select

photo(s)/video(s) that you want to send

via email.

2Click .

An email message is displayed with the»

selected photo(s)/video(s) attached.

3Send the email.

Delete photo(s)/video(s) from the

gallery

1In the photo/video gallery, select

photo(s)/video(s) that you want to delete.

2Click beside .

3In the pop-up window, click [ Yes].

The selected photo(s)/video(s) are»

deleted from the gallery.

To cancel the deletion, click• [No] in the

pop-up window.

English

Otros manuales para SPZ2000

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara web de Philips

Philips

Philips SPC2050NC/00 Manual de usuario

Philips

Philips DMVC300K FunCam Manual de usuario

Philips

Philips PCVC740 Manual de usuario

Philips

Philips SPZ5000 Manual de usuario

Philips

Philips SPC325NC Manual de usuario

Philips

Philips SPC640NC/00 Manual de usuario

Philips

Philips PCVC720K/40 Manual de usuario

Philips

Philips VGA SPC621NC Manual de usuario

Philips

Philips SPC230NC/00 Manual de usuario

Philips

Philips PCVC720K99 Manual de usuario

Philips

Philips SPC505NC Manual de usuario

Philips

Philips SPC230NC/27 Manual de usuario

Philips

Philips SPC630NC Manual de usuario

Philips

Philips SPC610NC Manual de usuario

Philips

Philips Share SPC1030NC/27 Manual de usuario

Philips

Philips SPC535NC/00 Manual de usuario

Philips

Philips SPC530NC Manual de usuario

Philips

Philips SPC600NC/37 Manual de usuario

Philips

Philips Share SPC1030NC Manual de usuario

Philips

Philips SPC 900NC Manual de usuario

Philips

Philips SPC530NC/27 Manual de usuario

Philips

Philips SPC1330NC/00 Manual de usuario

Philips

Philips SPC210NC - SPC Web Camera Manual de usuario

Philips

Philips SPC110NC Manual de usuario

Manuales populares de Cámara web de otras marcas

Digitus

Digitus DA-70815 Manual de usuario

Logitech

Logitech C510 Manual de usuario

D-Link

D-Link DCS-5025L Manual de usuario

BTC

BTC PC160S Manual de usuario

Trust

Trust 12440 Manual de usuario

FS FC270S Manual de usuario

Adesso

Adesso CyberTrack V10 Manual de usuario

MAGINON

MAGINON M-Cam 1 Manual de usuario

RoboCam

RoboCam SPARK Manual de usuario

Logitech

Logitech C170 Manual de usuario

Real-El

Real-El FC-225 Manual de usuario

Logitech

Logitech TV Cam Manual de usuario

Gigaware

Gigaware 25-1176 Manual de usuario

birddog

birddog EYES P200 Manual de usuario

Dicota

Dicota Contact Manual de usuario

Afidus

Afidus ATL-200 Manual de usuario

Connectland

Connectland CAM-CNL-C119 Manual de usuario

Biamp

Biamp Neets 4K Webcam Manual de usuario
