Philips SPC315NC Manual de usuario

SPC315NC

User manual

Need help?

Online help: http://www.philips.com/support

For interactive help, downloads and frequently asked questions.

Please check that the following items are packed in the Philips

SPC315NC box.They are provided to help you set up and use

your Philips SPC315NC.

Philips SPC315NC Installation CD-ROM Quick Installation

WebCam including manual Guide

Headset with headphone

and microphone

SPC315NC

Installation CD v.1.00

9082 100 03367

What’s in the box?

1 Rotating lens

For manually changing the vertical angle of the WebCam.

2 Focus ring

For adjusting the focus of the image manually.

3 Clamp with rubber rims

For attaching the WebCam to your monitor or laptop screen.

4 USB connector

For connecting the WebCam to the USB port of the laptop or

desktop PC.

The WebCam will derive its power from the laptop or desktop

PC when a USB connection is made.

5 Snapshot button

Enables you to take photos without using your mouse.

6 Power LED

Lights up blue when the WebCam is in use.

7 Quicklaunch button

For quick and easy start-up of the V-Lounge software.

8 Headset with headphone and microphone

For talking and listening to your meeting partner during video

chatting.

9 Audio cable

Black headphone plug (n)- for connecting to the microphone

socket of the pc sound card.

Grey microphone plug (!) - for connecting to the headphone or

green socket of the pc sound card.

Legend of functions

2 Need help?

3 What’s in the box?

4 Legend of functions

5 Contents

6 Welcome

7 Things you should know

7 Safety precautions

7 Copyright

8 Installation

8 Installing the WebCam software

10 Connecting the WebCam to your PC / laptop

11 WebCam settings

11 General controls

12 Picture controls

14 Audio controls

15 Using the applications

15 VLounge

16 Skype

16 MSN Messenger

17 Yahoo! Messenger

17 AOL Instant Messenger

17 Making snapshots using Windows®XP

18 Technical specifications

19 Important information

19 Disclaimer

19 FCC compliance

20 Environmental information

20 System requirements

20 Disclaimer of warranty

20 Limitations of damages

Contents

The Philips SPC315NC WebCam you have just purchased is

manufactured to the highest standards and will give you years of

trouble-free use. Brilliant images and blazing colours, that's what

you get with the SPC315NC WebCam. Forget about installing

interface cards and separate power supplies, because you don't

need them any more. Power is supplied direct to the webcam

through the USB cable and the webcam returns audio and video

straight to your PC!

After installation, the new WebCam can be used for all sorts of

applications, such as:

•Video conferencing: use the Philips SPC315NC Webcam for

video chatting and conferencing (the Philips SPC315NC

WebCam works with Skype, MSN Messenger,Yahoo! Messenger

and AOL Messenger;

•Video e-mail / Video capture: create your own video

presentations, video mail, product demonstrations, training

videos, Internet clips etc.;

•Snapshot images: use images in presentations, create postcards,

or send them via e-mail or on diskette.The WebCam works

with all applications that use the TWAIN interface to acquire an

image.

•Editing and special effects: after recording the images you want

with the Philips SPC315NC WebCam, the images can be easily

edited using image or video editing programs.

The following sections in this manual give a step-by-step

description of the installation process and explain how to use the

Philips SPC315NC WebCam.

Welcome

Please read the following instructions carefully, and retain them for

future reference. It may be helpful to have the instructions for use

for the PC at hand for reference.

Safety precautions

Observe the following guidelines to ensure that the WebCam will

operate safely and to prevent defects.

• Do not use your camera in environments outside the following

range: temperature: 0°C to 40°C, relative humidity: 45% ~

85%.

• Do not use or store your camera in/under:

– direct sunlight exposure;

– very humid and dusty environment;

– near any kind of heat sources.

• If your WebCam gets wet, dry it with soft cloth as soon as

possible.

• If the lens is dirty, Do NOT touch the lens with your fingers.

• Clean the outside of the WebCam with a soft cloth.

• Do NOT use cleaning fluids based on alcohol, methylated spirit,

ammonia, etc.

• Do NOT attempt to disassemble or repair your WebCam by

yourself. Do not open the WebCam. In the event of technical

difficulties return it to your Philips retailer.

• Do NOT use your WebCam in the water.

• Protect the WebCam from oil, vapour, steam, moisture, and

dust.

• Never point the WebCam lens at the sun.

reserved. No part of this publication may be reproduced,

transmitted, transcribed, stored in a retrieval system or translated

into any language or computer language, in any form or by any

means, electronic, mechanical, magnetic, optical, chemical, manual

or otherwise, without prior written permission from Philips.

Brands and product names are trademarks or registered

trademarks of their respective companies.

Things you should know

Installation

Installing the WebCam software

The software supplied only works on PCs with the operating

systems Microsoft®Windows®98SE, ME, 2000 and XP.

Notes!

– Unplug all your USB devices (except USB keyboard and

USB mouse) before you start.

– Do not plug in your WebCam yet. Run the Installation CD-ROM

first.

– Have your Windows®CD-ROM at hand.

– The SPC315NC WebCam is 'XP Plug & Play'.This means if you are

running Windows XP and you have installed Service Pack 2 and

the latest Microsoft Windows XP updates you don't need to install

the SPC315NC WebCam driver. Simply plug in the camera and you

can start using your SPC315NC WebCam.

1Place the installation CD-ROM in your PC’s / laptop’s

CD-ROM / DVD drive.

> After a couple of seconds the the ‘Language selection’ screen

appears automatically.

Note!

If the 'Language selection' screen does not appear automatically,

open the Microsoft®Windows®Explorer and double click on the

'Set-up.exe' icon in the CD-ROM directory.

2Select your language and click on the 'OK' button.

> The following screen appears.

3Select at least the ‘SPC315NC PC WebCam Driver’ and

‘Philips VLounge’ and click on the 'Next' button.

> The following software license agreement appears.

4Click on 'Yes' to continue the installation.

> The following screen, including a progress bar, appears.

> The following screen appears when the installation was

successful.

5Click on 'Finish'.

6Restart your PC / laptop when you have finished installing the

software.

> The V(ideo)-Lounge desktop shortcut will be installed after

installation.

> Via VLounge you have access to all camera-related software. See

‘Using the applications’.

7You can now connect your WebCam.

Installation

Connecting the WebCam to your PC /

laptop

1Be sure to run the installation CD first, before connecting the

WebCam to the PC / laptop.

2Turn on the PC / laptop.

3Connect the USB connector of the USB cable to the USB port

of the PC / laptop.

The

WebCam

will now derive its power from the PC / laptop.

4Use the clamp and the two rubber rims to attach the WebCam

to your PC monitor or laptop screen or fold out the clamp and

place the camera on your desk.

5Connect the headset audio cable to the sound card of your

PC / laptop.

• Connect the black headphone plug (n) to the headphone

socket of the PC sound card.

• Connect the grey microphone plug (!) to the microphone or

green socket of the sound card.

Installation

MICROPHONE
