Philips SPC710NC Manual de usuario

SPC710NC/SPC715NC

User manual

Need help?

Online help: http://www.philips.com/support

For interactive help, downloads and frequently asked questions.

Please check that the following items are packed in the Philips

SPC710NC/SPC715NC box.They are provided to help you set

up and use your Philips SPC710NC/SPC715NC.

Philips SPC710NC/ Installation CD-ROM Quick Installation

SPC715NC including manual Guide

WebCam

Headset with headphone

and microphone

(SPC715NC only)

SPC 710 NC

Installation CD v.1.00

9082 100 03367

What’s in the box?

1 Viewing angle

For manually changing the vertical angle of the WebCam.

2 Quicklaunch button

For quick and easy start-up of the VLounge Premium

software.

3 Rotating lens

For adjusting the focus of the image manually.

4 Clamp with rubber rim

For attaching the WebCam to your monitor.

5 USB connector

For connecting the WebCam to the USB port of the PC.

The WebCam will derive its power from the PC when a USB

connection is made.

6 Snapshot button

For taking photo’s.

7 Built in digital microphone

For adding voice and sound when video chatting and video

recording.

8Screw thread

For mounting the WebCam to a tripod.

9 Activity LED

Lights up when the WebCam is in use.

10 Headset with headphone and microphone

(SPC715NC only)

For talking and listening to your meeting partner during video

chatting.

11 Audio cable (SPC715NC only)

Black headphone plug (n)- for connecting to the microphone

socket of the pc sound card.

Grey microphone plug (!) - for connecting to the headphone or

green socket of the pc sound card.

Legend of functions

2 Need help?

3 What’s in the box?

4 Legend of functions

5 Contents

6 Welcome

7 Things you should know

7 Safety precautions

7 Copyright

8 Installation

8 Installing the WebCam software

10 Connecting the WebCam to your PC/laptop

11 WebCam settings

11 General controls

12 Picture controls

15 Audio controls

16 Using the applications

16 VLounge Premium

17 Skype

17 MSN Messenger

18 Yahoo! Messenger

18 AOL Instant Messenger

19 Making snapshots using Windows®XP

19 Technical specifications

20 Important information

20 Disclaimer

20 FCC compliance

21 Environmental information

21 System requirements

21 Disclaimer of warranty

21 Limitations of damages

Contents

The Philips SPC710NC/SPC715NC WebCam you have just

purchased is manufactured to the highest standards and will give

you years of trouble-free use. Brilliant images and blazing colors,

that's what you get with the SPC710NC/SPC715NC WebCam.

Forget about installing interface cards and separate power

supplies, because you don't need them any more. Power is

supplied direct to the WebCam through the USB cable and the

WebCam returns audio and video straight to your PC!

After installation, the new WebCam can be used for all sorts of

applications, such as:

•Video conferencing: use the Philips SPC710NC/SPC715NC

WebCam for video chatting and conferencing (the Philips

SPC710NC/SPC715NC WebCam works with Skype,

MSN Messenger,Yahoo! Messenger and AOL Messenger);

•Video e-mail / Video capture: create your own video

presentations, video mail, product demonstrations, training

videos, Internet clips etc.;

•Snapshot images: use images in presentations, create postcards,

or send them via e-mail or on diskette.The WebCam works

with all applications that use the TWAIN interface to acquire an

image.

•Editing and special effects: after recording the images you want

with the Philips SPC710NC/SPC715NC WebCam, the images

can be easily edited using image or video editing programs.

The following sections in this manual give a step-by-step

description of the installation process and explain how to use the

Philips SPC710NC/SPC715NC WebCam.

Welcome

Please read the following instructions carefully, and retain them for

future reference. It may be helpful to have the instructions for use

for the PC at hand for reference.

Safety precautions

Observe the following guidelines to ensure that the WebCam will

operate safely and to prevent defects.

• Do not use your WebCam in environments outside the

following range: temperature: 0°C to 40°C, relative humidity:

45% ~ 85%.

• Do not use or store your WebCam in/under:

– direct sunlight exposure;

– very humid and dusty environment;

– near any kind of heat sources.

• If your WebCam gets wet, dry it with soft cloth as soon as

possible.

• If the lens is dirty, Do NOT touch the lens with your fingers.

• Clean the outside of the WebCam with a soft cloth.

• Do NOT use cleaning fluids based on alcohol, methylated spirit,

ammonia, etc.

• Do NOT attempt to disassemble or repair your WebCam by

yourself. Do not open the WebCam. In the event of technical

difficulties return it to your Philips retailer.

• Do NOT use your WebCam in the water.

•

Protect the WebCam from oil, vapour, steam, moisture, and dust.

• Never point the WebCam lens at the sun.

reserved. No part of this publication may be reproduced,

transmitted, transcribed, stored in a retrieval system or translated

into any language or computer language, in any form or by any

means, electronic, mechanical, magnetic, optical, chemical, manual

or otherwise, without prior written permission from Philips.

Brands and product names are trademarks or registered

trademarks of their respective companies.

Things you should know

Installation

Installing the WebCam software

The software supplied only works on PCs with the operating

systems Microsoft®Windows®98SE, ME, 2000 and XP.

Notes!

– Unplug all your USB devices (except USB keyboard and

USB mouse) before you start.

– Do not plug in your WebCam yet. Run the Installation CD-ROM

first.

– Have your Windows®CD-ROM at hand.

1Place the installation CD-ROM in your PC’s / laptop’s

CD-ROM / DVD drive.

> After a couple of seconds the ‘Language selection’ screen

appears automatically.

Note!

If the 'Language selection' screen does not appear automatically,

open the Microsoft®Windows®Explorer and double click on the

'Set-up.exe' icon in the CD-ROM directory.

2Select your language and click on the 'OK' button.

> The following screen appears.

3Select at least ‘SPC710NC WebCam Driver’ and ‘Philips

VLounge Premium’.

Click the 'Next' button.

> The following software license agreement appears.

4Click on 'Yes' to continue the installation.

> The following screen, including a progress bar, appears.

> The following screen appears when the installation was

successful.

5Click on 'Finish'.

6Restart your PC / laptop when you have finished installing the

software.

> The V(ideo)-Lounge Premium desktop shortcut will be

installed after installation.

> Via VLounge Premium you have access to all WebCam-related

software. See ‘Using the applications’.

7You can now connect your WebCam.

Installation

Connecting the WebCam to your PC /

laptop

1Be sure to run the installation CD first, before connecting the

WebCam to the PC / laptop.

2Turn on the PC / laptop.

3Connect the USB connector of the USB cable to the USB port

of the PC / laptop.

The

WebCam

will now derive its power from the PC / laptop.

4Use the clamp and the two rubber rims to attach the WebCam

to your PC monitor or laptop screen or fold out the clamp and

place the WebCam on your desk.

5Connect the headset audio cable

(SPC715NC only)

to the sound

card of your PC / laptop.

• Connect the black headphone plug (n) to the headphone

socket of the PC sound card.

• Connect the grey microphone plug (!) to the microphone or

green socket of the sound card.

Installation

MICROPHONE
