Philips SmartPro Compact Manual de usuario

FC8778

300001532021

1 sec.

1 x

3 sec.

10 sec.

20 sec.

9 10

2021

English 6

Bahasa Melayu 23

ภาษาไทย 40

繁體中文 56

한국어 71

English

Introduction

Congratulations on your purchase and welcome to Philips! To fully benefit

from the support that Philips offers, register your product at

www.philips.com/welcome.

General description (Fig. 1)

1 Top cover

2 Handle of dust container lid

3 Dust container lid

4 Filter

5 Dust container

6 Fan

7 Bumper

8 Docking station sensor

9 Start/stop button

10 Display

11 TriActive XL nozzle

12 Front wheel

13 Side brush shafts

14 Drop-off sensors

15 Battery compartment

16 Wheels

17 Suction opening

18 Side brushes

19 Small plug

20 Adapter

21 Docking station

Display

1 2

1Warning indicator

2WiFi connection indicator

How your robot works

What your robot cleans

This robot is equipped with features that make it a suitable cleaner to help

you clean the floors in your home.

The robot is especially suitable for cleaning hard floors, such as wooden,

tiled or linoleum floors. It may experience problems cleaning soft floors,

such as carpet or rugs. If you use the robot on a carpet or rug, please stay

6English

close by the first time to see if the robot can deal with this type of floor. The

robot also needs supervision when you use it on very dark or shiny hard

floors.

How your robot cleans

Cleaning system

The robot has a 2-stage cleaning system to clean your floors efficiently.

-The two side brushes help the robot clean in corners and along walls.

They also help to remove dirt from the floor and move it towards the

suction opening.

-The suction power of the robot picks up loose dirt and transports it

through the suction opening into the dust container.

Cleaning patterns

In its auto cleaning mode, the robot uses an automatic sequence of cleaning

patterns to clean each area of the room optimally. The cleaning patterns it

uses are:

1 Z-pattern or zigzag pattern

2 Random pattern

English

3 Wall-following pattern

4 Spot-cleaning pattern

In its auto cleaning mode, the robot uses these patterns in a fixed

sequence:z-pattern, random pattern, wall-following pattern, and spot-

cleaning pattern.

When the robot has completed this sequence of patterns, it starts moving in

Z-pattern again. The robot continues to use this sequence of patterns to

clean the room until the rechargeable battery runs low, or until it is switched

off manually.

Note: You can also select each mode individually in the app.

How your robot avoids height differences

The robot has three drop-off sensors in its bottom. It uses these drop-off

sensors to detect and avoid height differences such as staircases.

Note: It is normal for the robot to move slightly over the edge of a height

difference, as its front drop-off sensor is located behind the bumper.

Caution: In some cases, the drop-off sensors may not detect a staircase or

other height difference in time. Therefore monitor the robot carefully the

first few times you use it, and when you operate it near a staircase or

another height difference. It is important that you clean the drop-off

sensors regularly to ensure the robot continues to detect height

differences properly (see chapter ' Cleaning and maintenance' for

instructions).

Before first use

Mounting the side brushes

1Unpack the side brushes and place the robot upside down on a table or

on the floor.

8English

2Push the side brushes onto the shafts on the bottom of the robot.

Note: Make sure you attach the side brushes properly. Press them onto

the shaft until you hear them lock into position with a click.

Preparing for use

Installing the docking station

1Insert the small plug of the adapter into the socket on the docking station

(1) and insert the adapter into the wall socket (2).

2Place the docking station on a horizontal, level floor against a wall.

100cm 30cm

80cm

Note: Make sure that there are no obstacles or height differences 80 cm

in front, 30 cm to the right and 100 cm to the left of the docking station.

Important note: deep sleep mode

In deep sleep mode, the robot does not respond at all when you press a

button. To reactivate the robot when it is in deep sleep mode:

1 sec. 3 sec.

1Press the start/stop button on the robot for one second to switch the

robot from deep sleep mode to standby mode.

2Press the start/stop button on the robot briefly or press the start button

in the app to start cleaning.

3If the robot does not start cleaning, place it on the plugged-in docking

station to recharge its rechargeable battery.

The robot enters deep sleep mode when you press the start/stop button for

3 seconds. It may also enter the deep sleep mode when its battery is empty.

The battery may, for instance, run empty if the robot is unable to find its

docking station.

English

Note: You cannot get the robot out of its deep sleep mode with the

start/stop button in the app, press the start/button on the robot.

Charging

-When charging for the first time and when the rechargeable battery of

the robot is empty, the charging time is four hours.

-When the rechargeable battery is fully charged, your robot can clean for

up to 120 minutes.

-Your robot can only be charged on the docking station.

Charging automatically during use

1When the robot has finished cleaning or when only 15% of the battery

power remains, it automatically searches for the docking station to

recharge. When the robot searches for the docking station, the start/stop

button flashes quickly.

2When the rechargeable battery is fully charged, the start/stop button

lights up continuously.

Note: The robot only searches for the docking station automatically when it

started cleaning from the docking station.

Charging on the docking station

1Press the start/stop button on the robot.

2Place the robot on the plugged-in docking station.

3The start/stop button starts flashing slowly.

10 English

4When the rechargeable battery is fully charged, the start/stop button

lights up continuously.

Setting up the WiFi connection

1Search for 'Philips SmartPro' in the Apple App Store or in the Google Play

Store.

2Download and install the Philips SmartPro app.

SmartPro

Connect to

your robot

Connect

Don’t own a robot yet?

FC8830/FC8832/FC8932 Buy one!

3Open the app and press the 'Connect' button.

4Press the start/stop button on the robot for 10 seconds to switch on the

robot and activate the WiFi setup mode and the user interface of the

robot. The WiFi setup is active if the WiFi connection indicator flashes

orange.

SmartPro

Already connected? Choose your Robot below...

Connect your robot

Start demo mode

5Press 'Connect your robot'.

Follow these 4 easy steps to connect

your Philips robot vacuum cleaner to

your home wiFi and pair with your

phone.

For a successful WiFi connection, position the Philips

Robot vacuum cleaner within reach of your router.

Obstacles such as walls may aect the WiFi

performance. It is advised to to use a WPA2 secured

Wi-Fi network.

GET STARTED

Easy WiFi setup

6Press ‘Get started’ and follow the on-screen instructions on the display.

There are four steps.

7The WiFi connection indicator lights up solid blue when the WiFi

connection has been established.

English

“I’m waiting for a command”

DemoRVC

“I’ll clean for 90 minutes”

60 m2or more

Dry wipe: OFF

Combine modes

Clean Settings

Start cleaning

Return to charging base

Dashboard

8The robot is connected when you see the robot in the screen of your app.

This will look like the picture on the left.

What to do if WiFi setup fails

If no WiFi connection is established after 1 minute, the appliance enters

access point mode and waits for a new attempt to set up the connection.

For iPhones:

1Open settings, choose 'Wi-Fi' and select 'PHILIPS Setup'.

2Select the access point starting with 'PHILIPS Setup'.

3Go back to the Philips SmartPro app and click 'Next' to set up the WiFi

connection.

Android smartphones:

1Go to 'Settings' and tap WiFi.

2Select 'PHILIPS Setup'.

3Go back to the Philips SmartPro app and click 'Next' to set up the WiFi

connection.

WiFi specifications

-The robot is designed to be connected to standard consumer routers

that use WEP, WPA-PSK, WPA2-PSK encryption keys, or no encryption

(open WiFi network).

-Connecting the robot to public hotspots, office networks or hotel

networks is not possible in most cases.

-The robot will not work with 5 GHz routers. If you encounter problems

with connecting the robot to the router, please check if your router can

also be changed to the 2.4 GHz setting.

Using your robot

Preparing the room for a cleaning run

Before you start the robot on its cleaning run, make sure that you remove all

loose and fragile objects from the floor.

Also remove all cables, wires and cords from the floor.

Functions of the start/stop button

The start/stop button has 5 functions:

12 English
