Philips SLV3220 Manual de usuario

Wireless TV Link

User Manual

SLV3220

F202019

SLV3220 WIRELESS TVLINK TRANSMITTER

SLV3220 WIRELESS TVLINK RECEIVER

WIRELESS

SOURCE

DC 9V

VIDEOAUDIO L


1 2 3 4

CHANNEL

SOURCE 1 SOURCE 2

DC 9V

CHANNEL


1 2 3 4

SOURCE

B1312 14

21 4 53

678910

151617

Contents

Page

Overview 4

Control and display elements 4

Your Wireless TV Link 5

Safety 5

Installation 6

Operation 7

Enjoy your Wireless TV Link 7

Troubleshooting 9

Information 11

Maintenance and service 11

Recycling and disposal 11

Warranty 12

Glossary 12

EN Overview

Control and display elements

A Transmitter

1 Integrated remote control blaster light

2 On/off switch

3 Power light:

> red: standby

> green: on

4 TV2 source indicator

5 SOURCE button

6 Power input connector (DC 9V)

7 Wireless channel selection switch

8 SOURCE 2 connectors (red/white/yellow)

9 SCART cable

10 Remote control blaster cord port

B Receiver

12 Integrated remote control blaster light

13 On/off switch

14 Power light:

> red: standby

> green: on

15 Power input connector (DC 9V)

16 Wireless channel selection switch

17 SCART cable

F Remote control blaster cord

19 Connector

20 Blaster light

Your Wireless TV Link

You can say good-bye to wires. With your Wireless TV

Link you can now wirelessly connect a second TV and

choose between two devices to watch on your second

TV.

Safety

• Read the instructions in this manual carefully before

you connect, install and use the product.

• Keep this manual for future reference.

• The product is for indoor use only.

• Do not use the product close to water.

• Do not expose the product to extreme heat.

• In case of technical difficulties, do not open the

product. Bring it to your Philips dealer.

• Do not cover the product.

• Connect the power adapters only to a

220-240 V AC/50 Hz power supply.

• The product can cause interference to other

equipment. Check if any equipment near the product

can be affected before you start using it.

EN Installation

Install the remote control blaster cord

1 Switch off the transmitter (A).

2 Connect the remote control blaster cord (F) to the

IR socket.

3 Position the blaster light in front of the IR sensor of

the video source.

4 Switch on the transmitter (A).

5 Take the remote control of a video source with you.

6 Go to TV2.

7 Switch on TV2.

8 Switch on the receiver (B).

9 Select the correct SCART input on TV2.

10 Operate the video source with its remote control.

11 If necessary, repeat the steps 3 to 10 for the other

video source.

For basic installation, see

the quick start guide that

came with your Wireless

TV Link.

See the user manual of the video source

for the exact location of the IR sensor

on the front panel.

Installation

Remove interference on TV2

1 Find the PICTURE CHANNEL switch on the

transmitter (A).

2 Set the PICTURE CHANNEL switch to a

different number.

3 Find the PICTURE CHANNEL switch on the

receiver (B).

4 Set the PICTURE CHANNEL switch to the same

number as on the transmitter (A).

Operation

Enjoy your Wireless TV Link

Watch a cable TV program on TV2

1 Switch on the transmitter (A).

2 Switch on the VCR or DVD recorder.

For basic operation, see

the quick start guide that

came with your Wireless

TV Link.

Your VCR or DVD recorder needs to

be connected to the transmitter (A) of

the Wireless TV Link and connected to

the Cable-TV signal.

EN Operation

3 Press SOURCE on the transmitter to select the

VCR or DVD recorder.

4 Take the remote control of the VCR or DVD

recorder with you.

5 Go to TV2.

6 Switch on TV2.

7 Switch on the receiver

8 Select the channel on the VCR or DVD recorder

with its remote control.

Watch a video source on TV1

Operate TV1 and the video source as usual.

SOURCE21

Turn off the auto standby mode when

you use the VCR or DVD recorder to

watch a cable tv program. Refer to the

user manual of the VCR or DVD

recorder.

If the VCR or DVD recorder records a

television program, you watch the

recorded channel.

Troubleshooting

Problem Tip

No image or

wrong image on

TV1

• Make sure video sources are con-

nected to the transmitter (A).

• Make sure the transmitter (A) is

connected to TV1.

• Make sure SCART cables are

firmly inserted.

• Make sure the video source is

switched on.

• Make sure the correct SCART

input on TV1 is selected.

No image or

wrong image on

TV2

• Make sure SCART cables are

firmly inserted.

• Make sure the receiver (B) is con-

nected to TV2.

• Make sure both receiver (B) and

transmitter (A) are switched on.

• Make sure the video source is

switched on.

• Make sure the correct SCART

input on TV2 is selected.

• Select the correct video source

with SOURCE on the transmit-

ter (A). See page 7.

• If the video source gives proper

image on TV1:

Make sure the video source gives

video signal in CVBS mode. See

its user manual

• Change the wireless channel that

is used for communication. See

page 7.

• The receiver (B) is out of range of

the transmitter (A). The number

of walls and ceilings in between

the receiver (B) and transmitter

(A) restrict the distance.

EN Troubleshooting

Problem Tip

Interference on

the image of TV2. • Slightly change the position of the

receiver or the transmitter.

• Change the wireless channel that

is used for communication. See

page 7.

• The receiver (B) is out of range of

the transmitter (A). The number

of walls and ceilings in between

the receiver (B) and transmitter

(A) restrict the distance.

The video sources

do not respond to

the remote con-

trol commands

from TV2.

• Point the remote control directly

to the receiver.

• Replace the batteries of the

remote controls with new ones.

• Install the remote control blaster

cord (F). See page 6.

• The maximum operating distance

of the remote control is 5 m.

The television

program disap-

pears on TV2.

• Turn off the auto standby mode

of the video source. See its user

manual.

• Follow the instructions to recon-

nect the video sources. See the

quick start guide.

Buzzing sound

when you use the

remote control.

• Slightly change the position of the

receiver or the transmitter until

the buzzing sound stops.

• Sometimes it is not possible to

solve the problem.

Easylink feature

does not work. • Check if the TV and VCR support

Easylink.

• Check if you used full-wired

SCART cables.

Black and white

image with S-VHS

VCR.

• Check if the SCART connector of

the S-VHS VCR gives signal in

CVBS. See its user manual.
