Philips MCM2000 Manual de usuario

Philips

Micro music system

MCM2000

Relax to great music

Obsessed with sound

Listen to all your favorites on your portable music player with USB Direct and MP3 Link.

This Philips Micro system also plays MP3-CD, WMA-CD and CD-R/RW, and features Bass

Reflex speakers for powerful and dramatic bass.

Enrich your sound experience

• Bass Reflex Speaker System delivers a powerful, deeper bass

• Digital Sound Control for optimized music style settings

• Dynamic Bass Boost for deep and dramatic sound

• 20W RMS total output power

Enjoy your music from multiple sources

• Play MP3/WMA-CD, CD and CD-RW

• USB Direct for MP3/WMA music playback

• MP3 Link for portable music playback

Easy to use

• Motorized CD loader for convenience access

• Digital tuning with preset stations for extra convenience

• Radio Data System for station information and data services

MCM2000/05

Highlights

Micro music system

Bass Reflex Speaker System

Bass Reflex Speaker System delivers a deep bass

experience from a compact loudspeaker box

system. It differs from a conventional

loudspeaker box system in the addition of a bass

pipe that is acoustically aligned to the woofer to

optimize the low frequency roll-off of the

system. The result is deeper controlled bass and

lower distortion. The system works by

resonating the air mass in the bass pipe to

vibrate like a conventional woofer. Combined

with the response of the woofer, the system

extends the overall low frequency sounds to

create a whole new dimension of deep bass.

Digital Sound Control

Digital Sound Control offers you a choice of

pre-set Jazz, Rock, Pop and Classic controls you

can use to optimise the frequency ranges for

different musical styles. Each mode uses graphic

equalizing technology to automatically adjust the

sound balance and enhance the most important

sound frequencies in your chosen music style.

Ultimately, Digital Sound Control makes it easy

for you get the most out of your music by

precisely adjusting the sound balance to match

the type of music you are playing.

Dynamic Bass Boost

Dynamic Bass Boost maximizes your music

enjoyment by emphasizing the bass content of

the music throughout the range of volume

settings - from low to high – at the touch of a

button! Bottom-end bass frequencies usually get

lost when the volume is set at a low level. To

counteract this, Dynamic Bass Boost can be

switched on to boost bass levels, so you can

enjoy consistent sound even when you turn

down the volume.

USB Direct

With the USB Direct mode, you can simply

select the music on a USB device and playback all

your content. All you have to do is plug in your

USB device to playback music or export content

from the device.

MP3 Link

The MP3 link connectivity allows direct playback

of MP3 content from portable media players.

Besides the benefit of enjoying your favorite

music in the superior sound quality delivered by

the audio system, the MP3 link is also extremely

convenient as all you have to do is to plug your

portable MP3 player to the audio system.

Radio Data System (RDS)

The Radio Data System (RDS) lets you tune into

radio stations without having to remember the

frequencies. In standard mode. RDS displays the

station name instead of the transmission

frequency, facilitating quick and easy tuning. RDS

also allows stations to send text messages such

as news and station information directly to the

radio display. Commonly used in Europe, RDS

text is sent out on the same frequency the radio

station broadcasts on. You can choose either

the basic RDS display (station name) or

subscribe to additional text-based services.

MCM2000/05

Specifications

Micro music system

Sound

• Output power: 2 x 10 W RMS

• Sound enhancement: digital sound control, Dynamic

Bass Boost

Loudspeakers

• Speaker drivers: 4" woofer

• Speaker types: bass reflex speaker system

Audio playback

• Disc playback modes: fast forward/backward, next/

previous track search, repeat/shuffle/program

• Playback media: CD, CD-R/RW, MP3-CD, USB flash

drive, WMA-CD

• USB Direct playback modes: fast backward/fast

forward, play/pause, previous/next, repeat, shuffle,

stop

• Others: ID3-tag support

Tuner/Reception/Transmission

• Tuner bands: FM mono, FM stereo

• Station presets: 20

• RDS: program type, radio text, RDS clock set,

station name

• Antenna: FM antenna (75 ohm)

• Tuner enhancement: auto digital tuning, auto scan,

Easy set (plug & play)

Connectivity

• Headphone: 3.5 mm

• MP3 Link: 3.5mm stereo line in

• USB: USB host

Convenience

• Alarms: CD Alarm, Radio Alarm, USB alarm

• Clock: On main display, sleep timer

• Display type: LCD display

•Loadertype:tray

Accessories

• Included accessories: AC Power Cord, FM antenna,

Quick Use Guide

• Remote control: 31-key remote

• User Manual: English

Dimensions

• Main unit width: 200 mm

• Main unit height: 118 mm

• Main unit depth: 210 mm

• Main speaker dimensions (W x D): 140 x 144 mm

• Main speaker height: 224 mm

• Packaging width: 576 mm

• Packaging height: 274 mm

• Packaging depth: 190 mm

• Gross weight: 3.8 kg

• Net weight: 3.24 kg

Power

• Power supply: 220-240V, 50Hz

•

Issue date 2011-08-31

Version: 1.0.6

12 NC: 8670 000 85072

EAN: 87 12581 62641 9

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com
