Philips BTM1560/12 Manual de usuario

www.philips.com/support

User manual

BTM1560

Micro Music

System

1EN

Contents

1 Important 2

Safety 2

Notice 3

2 Your Micro Music System 4

Introduction 4

What's in the box 4

Overview of the main unit 5

Overview of the remote control 6

3 Get started 8

Connect speakers 8

Connect power 8

Prepare the remote control 9

Power on 9

Set the clock 9

4 Play 10

Play from disc 10

Play from USB 10

Control play 10

Skip tracks 10

Program tracks 11

Play from Bluetooth-enabled

devices 11

5 Listen to FM radio 12

Tune to a radio station 12

Store radio stations automatically 12

Store radio stations manually 13

Select a preset radio station 13

6 Adjust sound 13

Select a preset sound eect 13

Adjust volume level 13

Mute sound 13

7 Other features 14

Set the alarm timer 14

Set the sleep timer 14

Listen to an external device 14

Charge your devices 15

8 Product information 16

Specications 16

USB playability information 16

Supported MP3 disc formats 17

9 Troubleshooting 17

2EN

1 Important

Safety

Read and understand all instructions

before you use this micro music system.

If damage is caused by failure to follow

the instructions, the warranty does not

apply.

This 'bolt of lightning' indicates

uninsulated material within the device

may cause an electrical shock. For the

safety of everyone in your household,

please do not remove the covering.

The 'exclamation mark' calls attention to

features for which you should read the

enclosed literature closely to prevent

operating and maintenance problems.

WARNING: To reduce the risk of re or

electric shock, the device should not be

exposed to rain or moisture and objects

lled with liquids, such as vases, should

not be placed on the device.

CAUTION: To prevent electric shock,

fully insert the plug. (For regions with

polarized plugs: To prevent electric

shock, match wide blade to wide slot.)

Warning

•Never remove the casing of this apparatus.

•Never lubricate any part of this apparatus.

•Never look into the laser beam inside this

apparatus.

•Never place this apparatus on other

electrical equipment.

•Keep this apparatus away from direct

sunlight, naked ames or heat.

•Ensure that you always have easy access

to the power cord, plug or adaptor to

disconnect the apparatus from the power.

• Make sure that there is enough

free space around the product for

ventilation.

• Only use attachments/accessories

specied by the manufacturer.

• Battery usage CAUTION – To

prevent battery leakage which may

result in bodily injury, property

damage, or damage to the product:

• Install the battery correctly, +

and - as marked on the product.

• The battery (packed or installed)

shall not be exposed to

excessive heat such as sunshine,

re or the like.

• Remove the battery when the

product is not used for a long

time.

• The product shall not exposed to

dripping or splashing.

• Do no place any source of danger

on the product (e.g. liquid lled

objects. lit candles).

• Where the MAINS plug or an

appliance coupler is used as the

disconnect device, the disconnect

device shall remain readily

operable.

3EN

Notice

Any changes or modications made

to this device that are not expressly

approved by Gibson Innovations may

void the user’s authority to operate the

equipment.

Compliance

Hereby, Gibson Innovations declares

that this product is in compliance

with the essential requirements

and other relevant provisions of

Directive 2014/53/EU. You can nd the

Declaration of Conformity on www.

philips.com/support.

Care of the environment

Disposal of your old product and

battery

Your product is designed and

manufactured with high quality

materials and components, which can

be recycled and reused.

This symbol on a product means that

the product is covered by European

Directive 2012/19/EU.

This symbol means that the product

contains batteries covered by European

Directive 2013/56/EU which cannot be

disposed of with normal household

waste.

Inform yourself about the local separate

collection system for electrical and

electronic products and batteries.

Follow local rules and never dispose of

the product and batteries with normal

household waste. Correct disposal

of old products and batteries helps

prevent negative consequences for the

environment and human health.

Removing the disposable batteries

To remove the disposable batteries, see

battery installation section.

Environmental information

All unnecessary packaging has been

omitted. We have tried to make the

packaging easy to separate into three

materials: cardboard (box), polystyrene

foam (buer) and polyethylene (bags,

protective foam sheet.)

Your system consists of materials

which can be recycled and reused

if disassembled by a specialized

company. Please observe the local

regulations regarding the disposal

of packaging materials, exhausted

batteries and old equipment.

The Bluetooth® word mark and logos

are registered trademarks owned by

Bluetooth SIG, Inc. and any use of such

marks by Gibson Innovations is under

license.

The making of unauthorized copies

of copy-protected material, including

computer programs, les, broadcasts

and sound recordings, may be an

infringement of copyrights and

constitute a criminal oence. This

equipment should not be used for such

purposes.

4EN

Care for your product

• Do not insert any objects other than

discs into the disc compartment.

• Do not insert warped or cracked

discs into the disc compartment.

• Remove the discs from the disc

compartment if you are not using

the product for an extended period

of time.

• Only use microber cloth to clean

the product.

This apparatus includes this label:

Note

•The type plate is located on the back of the

product.

2 Your Micro

Music System

Congratulations on your purchase, and

welcome to Philips! To fully benet from

the support that Philips oers, register

your product at www.philips.com/

support.

Introduction

With this unit, you can:

• enjoy audio from discs, USB

devices, Bluetooth devices, and

other external devices;

• listen to FM radio stations.

The unit supports these media formats:

What's in the box

Check and identify the contents of your

package:

• Main unit

• Remote control (with one AAA

battery)

• Speaker boxes (×2)

• Printed materials

5EN

a IR sensor

b LED indicator

• Standby indicator: turns red

when this product is switched to

standby.

• Bluetooth indicator: turns

blue to indicate the Bluetooth

connection status.

• Switch this product on or to

standby.

• Connect USB storage devices.

• Open or close the disc

compartment.

f Disc compartment

g Volume knob

• Adjust volume.

h Display panel

• Show current status.

Overview of the main unit

AUDIO IN

6EN

• Press to select a source: DISC,

USB, TUNER, AUDIO IN, BT.

• In Bluetooth mode, press and

hold for more than 2 seconds

to disconnect the currently

connected device and enter

pairing mode.

• Start or pause play.

• Stop play.

• Erase a program.

• Skip to previous/next track.

• Search within a track/disc.

• Tune to a radio station.

• Adjust time.

k antenna

• Improve FM radio reception.

• Connect external audio devices.

m socket

• Connect with the speakers.

Overview of the remote

control

• Switch this product on or to

standby.

• Select CD source.

• Select FM source.

d /

• Skip to the previous/next track.

• Search within a track/disc/USB.

7EN

• Tune to a FM station.

• Adjust time.

• Select shue mode to play

tracks randomly.

• Select repeat mode to play a

track or all tracks repeatedly.

f /

• Select a preset radio station.

• Skip to previous/next album.

• Display playback information.

• Set sleep timer.

• Set alarm timer.

• Set the clock.

• View clock information.

• In standby, press and hold to

toggle clock display on or o.

• Program tracks.

• Program radio stations.

• Auto store radio stations.

• Mute or restore volume.

• Select a preset sound eect.

m +/- (volume)

• Adjust volume.

• Adjust display brightness.

• Stop play or erase a program.

• Press to start, pause, or resume

play.

• Select USB source.

• Select AUDIO IN source.

• Select Bluetooth source

• In Bluetooth mode, press and

hold for more than 2 seconds

to disconnect the currently

connected device and enter

pairing mode.

8EN

3 Get started

Caution

•Use of controls or adjustments or

performance of procedures other than

herein may result in hazardous radiation

exposure or other unsafe operation.

Always follow the instructions in this

chapter in sequence.

Connect speakers

Note

•Insert the stripped portion of each speaker

wire into the socket completely.

•For better sound quality, use the supplied

speakers only.

1 For the right speaker, nd the

sockets on the back of the main unit

marked "R".

2 Insert the red wire into the red (+)

socket, and the black wire into the

black (-) socket.

3 For the left speaker, nd the sockets

on the main unit marked "L".

4 Repeat step 2 to insert the left

speaker wire.

To insert each speaker wire:

1 Hold down the socket ap.

2 Insert the speaker wire fully.

3 Release the socket ap.

AUDIOIN

FMANT

Connect power

Caution

•Risk of product damage! Ensure that the

power supply voltage corresponds to

the voltage printed on the back or the

underside of the unit.

•Risk of electric shock! Before you plug the

AC power cord, make sure that the plug is

xed securely. When you unplug the AC

power cord, always pull the plug, never pull

the cord.

•Before you connect the AC power cord,

make sure that you have completed all the

other connections.

AUDIO IN

FMANT

Connect the power cable to the wall

socket.

9EN

Prepare the remote

control

Caution

•Risk of product damage! When the remote

control is not used for long periods, remove

the batteries.

•Batteries contain chemical substances, so

they should be disposed of properly.

To insert the remote control battery:

1 Open the battery compartment.

2 Insert the supplied AAA battery with

correct polarity (+/-) as indicated.

3 Close the battery compartment.

Power on

Press .

» The product switches to the last

selected source.

Switch to standby mode

Press again to switch the product to

standby with no clock display, or to

standby with clock display.

» The red standby indicator lights up.

• In standby, you may press and hold

to toggle clock display on

or o.

Note

•The product switches to standby mode

after 15 minutes inactive.

•To achieve the ecient energy saving

performance, unplug any external

electronic device from the USB port when

the device is not in use.

Set the clock

1 In power on mode, press and hold

CLOCK for more than 2 seconds to

enter the clock setting mode.

» or is displayed.

2 Press / to select 24H or 12H

hour format, and then press .

» The hour digits begin to blink.

3 Press / to set the hour, and

then press .

» The minute digits begin to blink.

4 Press / to set the minute, and

then press .

» The clock is set.

Note

•To view clock in power on mode, press

briey .

•In standby, you may press and hold

to toggle clock display on or o.

•If clock display is turned on in standby,

power consumption increases.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Micro sistema de música de Philips

Philips

Philips MCD122/98 Manual de usuario

Philips

Philips MC147 Manual de usuario

Philips

Philips MBD3000/12 Manual de usuario

Philips

Philips MS6500/18 Manual de usuario

Philips

Philips MCM3000/12 Manual de usuario

Philips

Philips MCDB710/05 Manual de usuario

Philips

Philips DCB2272 Hoja de información del producto

Philips

Philips DCB188/12 Manual de usuario

Philips

Philips DCB2070/10 Manual de usuario

Philips

Philips DCB293 Manual de usuario

Philips

Philips MCD710/12 Manual de usuario

Philips

Philips MCM206/12 Manual de usuario

Philips

Philips DCM2260 Manual de usuario

Philips

Philips TAM8905 Manual de usuario

Philips

Philips MCM103/93 Manual de usuario

Philips

Philips DualDock DCB2270 Manual de usuario

Philips

Philips MCM1150 Manual de usuario

Philips

Philips DCB2070/10 Manual de usuario

Philips

Philips MCM2050/05 Manual de usuario

Philips

Philips MCM2300 Manual de usuario

Philips

Philips MCM2150 Manual de usuario

Philips

Philips DCM2055/05 Manual de usuario

Philips

Philips MC175/01 Manual de usuario

Philips

Philips MCM277/98 Manual de usuario

Manuales populares de Micro sistema de música de otras marcas

Rautz

Rautz MC-5100DU Manual de usuario

Sanyo

Sanyo DC-D9 Manual de usuario

Curtis

Curtis RCD744 Manual de usuario

Samsung

Samsung MM-UC8 Manual de usuario

Akai

Akai AMP300UCI Manual de usuario

Hyundai

Hyundai MS 132 DU3BL Manual de usuario

JVC

JVC UX-GP5 Manual de usuario

Tiger Electronics

Tiger Electronics Hitclips Beat Bot 6000 Manual de usuario

Optimus

Optimus SYSTEM 731 Manual de usuario

Hitachi

Hitachi AXM209UK Manual de usuario

Sharp

Sharp XL-MP110DVD Manual de usuario

Tiger Electronics

Tiger Electronics Hitclips Micro Music Watch 59947 Manual de usuario

ProAudio

ProAudio MC 9010 iP Manual de usuario

Samsung

Samsung MM-ZJ9 Manual de usuario

Sharp

Sharp MD-X7 Manual de usuario

Sharp

Sharp DK-KP95P Manual de usuario

Akura

Akura APTCDC832PR Manual de usuario

iLive

iLive IHB248B Manual de usuario
