Philips DCB2070/10 Manual de usuario

EN User manual 3

DA Brugervejledning 23Brugervejledning 2323

DE Benutzerhandbuch 45Benutzerhandbuch 4545

FR Mode d’emploi 69

IT Manuale utente 91

NO Brukerhåndbok 115

DCB2070

www.philips.com/welcome

English

Contents

1 Important 4

Know these safety symbols 4

Hearing Safety 5

2 Your Micro System 5

Introduction 5

What's in the box 5

Overview of the main unit 6

Overview of the remote control 7

3 Get started 9

Placement 9

Prepare FM/DAB+ antenna 9

Prepare the remote control 9

Connect power 9

Set clock 10

Turn on 10

4 Play 11

Play disc 11

Play from USB 11

Play from iPod/iPhone/iPad 11

Play options 12

Adjust sound 13

Display different information 13

5 Listen to DAB+ radio 13

Tune to DAB+ radio stations 13

Store DAB+ radio stations

automatically 14

Store DAB+ radio stations manually 14

Select a preset DAB+ radio station 14

Show DAB+ information 14

Use DAB+ menu 14

6 Listen to FM radio 15

Tune to FM radio stations 15

Store FM radio stations automatically 15

Store FM radio stations manually 16

Select a preset radio station 16

Show RDS information 16

Select stereo/mono broadcast 16

Use FM menu 16

7 Other features 17

Adjust system settings 17

Set the alarm timer 18

Set the sleep timer 18

Play from external audio device 18

Listen through the headphone 18

8 Product information 19

 

USB playability information 19

Supported MP3 disc formats 20

9 Troubleshooting 20

10 Notice 21

4EN

1 Important

 Read these instructions.

 Follow all instructions.

 Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

 Do not install near any heat sources such

as radiators, heat registers, stoves, or



produce heat.

 Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the unit.

 

by the manufacturer.

 Unplug this unit during lightning storms or

when unused for long periods of time.

 

personnel. Servicing is required when the

unit has been damaged in any way, such

as power-supply cord or plug is damaged,

liquid has been spilled or objects have

fallen into the apparatus, the unit has been

exposed to rain or moisture, does not

operate normally, or has been dropped.

 Battery usage CAUTION –To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

remote control:

 Install all batteries correctly, + and - as

marked on the remote control.

 Do not mix batteries (old and new or



 Remove batteries when the remote control

is not used for a long time.

 The unit shall not be exposed to dripping

or splashing.

 Do not place any sources of danger on





 Where the plug of the Direct Plug-in

Adapter is used as the disconnect device,

the disconnect device shall remain readily

operable.

Know these safety symbols

This 'bolt of lightning' indicates uninsulated

material within your unit may cause an electrical

shock. For the safety of everyone in your

household, please do not remove product

covering.

The 'exclamation point' calls attention to

features for which you should read the enclosed

literature closely to prevent operating and

maintenance problems.



shock, this apparatus should not be exposed to



such as vases, should not be placed on this

apparatus.

CAUTION:To prevent electric shock, match

wide blade of plug to wide slot, fully insert.

Warning

 Never remove the casing of this apparatus.

 Never lubricate any part of this apparatus.

 Never place this apparatus on other electrical

equipment.

 Keep this apparatus away from direct sunlight, naked



 Never look into the laser beam inside this apparatus.

 Ensure that you always have easy access to the power

cord, plug or adaptor to disconnect this apparatus from

the power.

English

Hearing Safety

Danger

 To avoid hearing damage, limit the time you use the

headphones at high volume and set the volume to a

safe level.The louder the volume, the shorter is the safe

listening time.

Be sure to observe the following guidelines

when using your headphones.

 Listen at reasonable volumes for

reasonable periods of time.

 Be careful not to adjust the volume

continuously upwards as your hearing

adapts.

 Do not turn up the volume so high that

you can’t hear what’s around you.

 You should use caution or temporarily

discontinue use in potentially hazardous

situations.

 Excessive sound pressure from earphones

and headphones can cause hearing loss.

Caution

 Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

2 Your Micro

System

Congratulations on your purchase, and



support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this unit, you can:

 enjoy audio from discs, iPod/iPhone/iPad,

USB devices, and other external devices

 listen to FM/DAB+ radio

You can enrich sound output with these sound

effects:

 

 

What's in the box

Check and identify the contents of your

package:

 Main unit

 Remote control

 Power adapter

 1 x MP3 link cable

 

 User manual

 Quick start guide

 Wall mounting instructions

If you contact Philips, you will be asked for the

model and serial number of this apparatus.The

model number and serial number are on the

bottom of the apparatus.Write the numbers

here:

Model No. _____________________________

Serial No. _____________________________

6EN

Overview of the main unit

 Connect USB device.

 Headphone socket.

 Turn the unit on/off.

 Switch to standby mode.

d SOURCE

 Select a source: CD, USB, DAB+, FM,

MP3 Link, or Dock.

DOCK for

DC IN

ANT

MP3-LINK

OK/MENU /

SOURCE VOLUME VOLUME

e /

 Skip to the previous/next track.

 Search within a track/disc.

 Tune to radio stations.

 Adjust time.

f OK /

 Start/pause play.

 

 Switch between mono and stereo

broadcast.

g MP3-LINK

 Connect an external audio device.

English

 Open/close the disk tray.

i VOLUME + / -

 Adjust volume.

j MENU /

 Access iPod/iPhone/iPad menu.

 Access FM/DAB+ menu.

 Stop play or erase a program.

k Display panel

 Show play information.

l Disc tray

m DOCK for iPod/iPhone/iPad

n DC IN

 Connect power.

o FM ANT

 Improve FM/DAB+ radio reception.

p FOR SOFTWARE UPDATE ONLY

 Update software via USB connector



Overview of the remote

control

 Turn the unit on/off.

 Switch to standby mode.

 Mute/unmute sound.

PRESET/ALBUM

PROG/

CLOCK SET

SLEEP/

TIMER

DSC DBB

DAB

VOL

456

789

MODE/

SCAN

USB

LINK

DOCK

DISPLAY

RDS

8EN

c CD

 Select CD source.

d /

 Skip to the previous/next track.

 Search within a track/disc.

 Tune to radio stations.

 Adjust time.

e USB/MP3 LINK

 Select USB/MP3 link source.

f RDS/DISPLAY

 For selected FM radio stations: display

RDS information.

 Show time and play information.

 Show DAB+ information.

 Start/pause play.

h VOL +/-

 Adjust volume.

i Numeric Keypad 0 - 9

 Select a track from a disc/USB device

directly.

 Select a preset radio station.

j PROG/CLOCK SET

 Program tracks.

 Program radio stations.

 Set time.

k SLEEP/TIMER

 Set sleep/alarm timer.

l DSC

 Select a preset sound setting.

m DBB

 Turn dynamic bass enhancement on/

off.

n MODE/SCAN

 Select a play mode.

 Scan/store radio stations automatically.

o MENU/

 Access iPod/iPhone/iPad menu.

 Access FM/DAB+ menu.

 Stop play or erase a program.

p DOCK

 Select iPod/iPhone/iPad source.

q OK

 

 Switch between mono and stereo

broadcast.

r /

 Select a preset radio station.

 Skip to previous/next album.

s FM/DAB

 Select FM/DAB+ tuner source.

English

3 Get started

Caution

 Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

Always follow the instructions in this chapter in

sequence.

Placement



mount the unit on a wall.

Mount on a wall

See the wall mounting instructions included in

the package.

Prepare FM/DAB+ antenna

For better reception, fully extend and adjust the

position of the FM/DAB+ antenna.

Note

 To prevent interference, position the antenna as far as

possible fromTV,VCR, or other radiation source.

Prepare the remote control

Caution

 Risk of explosion! Keep batteries away from heat,



 Risk of decreased battery life! Never mix different

brands or types of batteries.

 Risk of product damage! When the remote control is

not used for long periods, remove the batteries.

To install the remote control battery:

1 Open the battery compartment.

2 Insert 2 AAA batteries with correct



3 Close the battery compartment.

Connect power

Caution

 Risk of product damage! Ensure that the power supply

voltage corresponds to the voltage printed on the back

or the underside of the unit.

 Risk of electric shock! When you unplug the power

adapter, always pull the plug from the socket. Never

pull the cord.

 Before connecting the power adapter, make sure that

you have completed all other connections.

Note

 The type plate is located at the back of the unit.

10 EN

Connect the power adapter to:

 the DC IN socket on the main unit.

 the wall socket.

Set clock

1 Press to switch the unit to standby

mode.

» --:-- is displayed.

2 Press and hold CLOCK SET on the

remote control for two seconds.

» [SET CLOCK] 

the display, and then 12 or 24 hour

format blinks.

3 Press / repeatedly to select hour

format.

4 Press CLOCK SET

5 Repeat steps 3-4 to set the hour and

minute respectively.

6 Repeat steps 3-4 to select whether to

synchronize time of this unit with DAB+

stations.

 [DAB TIME SYNC [N] ]: time

synchronization is deactivated.

 [DAB TIME SYNC [Y] ]: the unit

synchronizes time from the DAB+

stations automatically.

Note

 The accuracy of the transmitted time depends on the

DAB+ station that transmits the time signal.

 If no button is pressed in 90 seconds, the unit exits

clock setting mode automatically.

Turn on

Press .

» The unit switches to the last selected

source.

Note

 To select a source, press SOURCE repeatedly or the

source selection buttons on the remote control.

Switch to standby mode

Press again to switch the unit to standby

mode.

» 

panel.

English

4 Play

Play disc

1 Press to open the disc compartment.

2 Insert a disc with the printed side facing up.

3 Press to close the disc compartment.

4 Press CD on the remote control to select

the disc source.

» [Reading]

moment, then CD starts playing

automatically. If not, press .

Play from USB

Note

 Make sure that the USB device contains playable audio

content.

1 Insert the USB device into the socket.

2 Press USB on the remote control to select

the USB source.

» Play starts automatically. If not, press

Play from iPod/iPhone/iPad

You can enjoy audio from iPod/iPhone/iPad

through this unit.

Compatible iPod/iPhone/iPad

The unit supports the following iPod, iPhone

and iPad models:

Made for.

 iPod touch (1st, 2nd, 3rd, and 4th



 iPod nano (2nd, 3rd, 4th, 5th, and 6th



 iPhone 4

 iPhone 3GS

 iPhone 3G

 iPhone

 iPad 2

 iPad

Load the iPod/iPhone/iPad

1 Push the dock compartment to open it.

2 Place the iPod/iPhone/iPad in the dock.

Otros manuales para DCB2070/10

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Micro sistema de música de Philips

Philips

Philips MC147 Manual de usuario

Philips

Philips BTB8000 Manual de usuario

Philips

Philips DCM1075/98 Manual de usuario

Philips

Philips MCM148 Manual de usuario

Philips

Philips MCM7000/12 Manual de usuario

Philips

Philips MCD1060 Manual de usuario

Philips

Philips MCM149/96 Manual de usuario

Philips

Philips MCD122/98 Manual de usuario

Philips

Philips BTM2310/55 Manual de usuario

Philips

Philips MCM1050 Manual de usuario

Philips

Philips MCM772 Manual de usuario

Philips

Philips MCM239D/05 Manual de usuario

Philips

Philips MCM103/96 Manual de usuario

Philips

Philips MCM138D/79 Manual de usuario

Philips

Philips MCM3050/12 Manual de usuario

Philips

Philips DCM1170 Manual de usuario

Philips

Philips DCM713/12 Manual de usuario

Philips

Philips MCM239/55 Manual de usuario

Philips

Philips MCM233/12 Manual de usuario

Philips

Philips DCM3020/79 Manual de usuario

Philips

Philips MCDB710/05 Manual de usuario

Philips

Philips DCM109 Manual de usuario

Philips

Philips MCW770 Manual de usuario

Philips

Philips MCD139B/98 Manual de usuario

Manuales populares de Micro sistema de música de otras marcas

Rautz

Rautz MC-5100DU Manual de usuario

Sanyo

Sanyo DC-D9 Manual de usuario

Curtis

Curtis RCD744 Manual de usuario

Samsung

Samsung MM-UC8 Manual de usuario

Akai

Akai AMP300UCI Manual de usuario

Hyundai

Hyundai MS 132 DU3BL Manual de usuario

JVC

JVC UX-GP5 Manual de usuario

Tiger Electronics

Tiger Electronics Hitclips Beat Bot 6000 Manual de usuario

Optimus

Optimus SYSTEM 731 Manual de usuario

Hitachi

Hitachi AXM209UK Manual de usuario

Sharp

Sharp XL-MP110DVD Manual de usuario

Tiger Electronics

Tiger Electronics Hitclips Micro Music Watch 59947 Manual de usuario

ProAudio

ProAudio MC 9010 iP Manual de usuario

Samsung

Samsung MM-ZJ9 Manual de usuario

Sharp

Sharp MD-X7 Manual de usuario

Sharp

Sharp DK-KP95P Manual de usuario

Akura

Akura APTCDC832PR Manual de usuario

iLive

iLive IHB248B Manual de usuario
