Philips MCD110/94 Manual de usuario

MCD110

www.philips.com/welcome

EN User manual

MCD110_94_UM_EN_V1.0.indd 1 10/28/2009 1:39:53 PM

English

6 Adjust settings 17

General setup 17

Audio setup 17

Video setup 17

Preferences 18

7 Product information 19

Specications 19

Supported disc formats 19

USB playability information 20

8 Troubleshooting 20

Contents

1 Important 4

Safety 4

Notice 5

2 Your DVD Micro Theater 6

Introduction 6

What’s in the box 7

Overview of the main unit 7

Overview of the remote control 7

3 Connect 9

Connect TV 9

Connect power 10

4 Get started 11

Activate demonstration mode 11

Prepare the remote control 11

Turn on 11

Find the correct viewing channel 11

Select the correct TV system 12

Change system menu language 12

Turn on Progressive Scan 12

5 Play 13

Play a disc 13

Play from USB 14

PlayMP3/WMA/pictureles 14

Play control 14

Play options 15

Picture view options 16

MCD110_94_UM_EN_V1.0.indd 3 10/28/2009 1:39:53 PM

gDo not block any ventilation openings.

Install in accordance with the

manufacturer’s instructions.

hDo not install near any heat sources

such as radiators, heat registers, stoves,

or other apparatus (including ampliers)

that produce heat.

iProtect the power cord from being

walked on or pinched, particularly at

plugs, convenience receptacles, and the

point where they exit from the apparatus.

jOnly use attachments/accessories

specied by the manufacturer.

kUse only with the cart,

stand, tripod, bracket,

or table specied by

the manufacturer or

sold with the apparatus.

When a cart is used, use

caution when moving the cart/apparatus

combination to avoid injury from tip-over.

lUnplug this apparatus during lightning

storms or when unused for long periods

of time.

m Refer all servicing to qualied service

personnel. Servicing is required when

the apparatus has been damaged in any

way, such as power-supply cord or plug

is damaged, liquid has been spilled or

objects have fallen into the apparatus,

the apparatus has been exposed to rain

or moisture, does not operate normally,

or has been dropped.

nBattery usage CAUTION – To prevent

battery leakage which may result in

bodily injury, property damage, or

damage to the unit:

Install all batteries correctly, + and -•

as marked on the unit.

Do not mix batteries (old and new•

or carbon and alkaline, etc.).

Remove batteries when the unit is•

not used for a long time.

1 Important

Safety

This ‘bolt of lightning’ indicates uninsulated

material within your unit may cause an

electrical shock. For the safety of everyone

in your household, please do not remove

product covering.

The ‘exclamation point’ calls attention to

features for which you should read the

enclosed literature closely to prevent

operating and maintenance problems.

WARNING:Toreducetheriskofreor

electric shock, this apparatus should not be

exposedtorainormoistureandobjectslled

with liquids, such as vases, should not be

placed on this apparatus.

CAUTION: To prevent electric shock, match

wide blade of plug to wide slot, fully insert.

Important Safety Instructions

aRead these instructions.

bKeep these instructions.

cHeed all warnings.

dFollow all instructions.

eDo not use this apparatus near water.

fClean only with dry cloth.

MCD110_94_UM_EN_V1.0.indd 4 10/28/2009 1:39:54 PM

Notice

Anychangesormodicationsmadetothis

device that are not expressly approved by

Philips Consumer Lifestyle may void the user’s

authority to operate the equipment.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separate into three materials: cardboard (box),

polystyrene foam (buffer) and polyethylene

(bags, protective foam sheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

a specialized company. Please observe the

local regulations regarding the disposal of

packaging materials, exhausted batteries and

old equipment.

The making of unauthorized copies of

copy-protected material, including computer

programs,les,broadcastsandsound

recordings, may be an infringement of

copyrights and constitute a criminal offence.

This equipment should not be used for such

purposes.

‘DVD Video’ is a trademark of DVD Format/

Logo Licensing Corporation.

Manufactured under license from Dolby

Laboratories. Dolby and the double-D symbol

are trademarks of Dolby Laboratories.

oApparatus shall not be exposed to

dripping or splashing.

pDo not place any sources of danger on

the apparatus (e.g. liquid lled objects,

lighted candles).

qThis product may contain lead and

mercury. Disposal of these materials

may be regulated due to environmental

considerations. For disposal or recycling

information, please contact your local

authorities or the Electronic Industries

Alliance: www.eiae.org.

Caution

Use of controls or adjustments or•

performance of procedures other than herein

may result in hazardous radiation exposure or

other unsafe operation.

Warning

Where the MAINS plug or an appliance•

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

Warning

Never remove the casing of this unit.•

Never lubricate any part of this unit.•

Placethisunitonaat,hardandstable•

surface.

Never place this unit on other electrical

•

equipment.

Only use this unit indoors. Keep this unit away

•

fromwater,moistureandliquid-lledobjects.

Keep this unit away from direct sunlight, naked

•

amesorheat.

Never look into the laser beam inside the unit.

•

English

MCD110_94_UM_EN_V1.0.indd 5 10/28/2009 1:39:55 PM

2 Your DVD

Micro Theater

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this unit, you can:

watch video from DVD/VCD/SVCD or•

USB devices

enjoy audio from discs or USB devices•

view pictures from discs or USB devices•

The unit supports these media/disc formats:

You can play DVD discs with the following

region codes:

DVD region code Countries

India

Recordable

ReWritable

The USB-IF Logos are trademarks of Universal

Serial Bus Implementers Forum, Inc.

This apparatus includes this label:

Note

The type plate is located on the bottom of the•

apparatus.

MCD110_94_UM_EN_V1.0.indd 6 10/28/2009 1:39:56 PM

Open or close the disc•

compartment.

iUSB DIRECT

USB socket.•

jDisc compartment

kSOURCE

Select a source.•

Turn on the apparatus; switch to•

standby mode.

Overview of the remote

control

What’s in the box

Check and identify the contents of your package:

Main unit•

Remote control•

Composite video cable (yellow)•

Audio cables (red/white)•

User manual•

Quick start guide•

Overview of the main unit

aVOLUME /

Adjust volume.•

bDisplay panel

Display current status.•

cRemote control sensor

Skip to the previous/next track.•

Skip to the previous/next title or•

chapter.

Search within a track.•

Start or pause play.•

Stop play.•

In demo mode, activate or deactivate•

demonstration.

a b

l k j h gi

dc ef

English

MCD110_94_UM_EN_V1.0.indd 7 10/28/2009 1:39:59 PM

mNumeric keypad

Select a title/chapter/track directly.•

nZOOM/PROG

Zoom in or out a picture/video•

image.

Program titles/chapters for DVD play.•

Program tracks.•

oGOTO

During disc play, specify a position to•

start play.

pMODE

Select repeat play modes.•

Selectshufeplaymodes.•

qDISC MENU

For video discs: access or exit the•

disc menu.

For video discs with playback•

control(PBC): turn on/off PBC.

rDISPLAY

Display play information on a•

connected TV.

Turn on the apparatus; switch to•

standby mode.

bSOURCE

Select a source.•

cMUTE

Mute or restore volume.•

dSLOW/ ANGLE

For menus, navigate up/down.•

Rotate or invert pictures.•

(• SLOW) For video: select a slow

play mode.

(• ANGLE) Select a DVD camera

angle.

e/ ( / )

For menus, navigate left/right.•

Move an enlarged image left/right.•

Rotate or invert pictures.•

Search within a track.•

f/ OK

Start or pause play.•

Conrmaselection.•

gSYSTEM MENU

Access or exit the system setup•

menu.

Stop play.•

Skip to the previous/next track.•

Skip to the previous/next title or•

chapter.

jVOL +/-

Adjust volume.•

kAUDIO

For VCD, select stereo, mono-left or•

mono-right channel.

For DVD video, select an audio•

language.

lSUBTITLE

Select a subtitle language.•

MCD110_94_UM_EN_V1.0.indd 8 10/28/2009 1:40:00 PM

Note

The progressive scan video quality is only•

available when a progressive scan TV is

connected.

If your TV does not support progressive scan,

•

you cannot view the picture.

For how to activate progressive scan on your

•

TV, refer to the TV user manual.

Connect a progressive scan TV through

component video for higher quality video.

1Connect component video cables (red/

blue/green - not supplied) to:

the• VIDEO OUT (Pr/Cr Pb/Cb Y)

sockets on this unit.

the component input sockets on the•

TV.

Option 3: Connect through

composite video

1Connect the supplied composite video

cable to:

the• VIDEO OUT socket on this unit.

the video input socket on the TV.•

3 Connect

Connect TV

Connect video cables

With this connection, you can watch video

from the unit on the TV screen.

You can select the best video connection that

your TV supports.

Option 1: connect through component•

video (for a standard TV or Progressive

Scan TV).

Option 2: connect through composite•

video (CVBS) (for a standard TV).

Option 1: Connect through

component video

Connect a progressive scan TV through

component video for higher quality video.

English

MCD110_94_UM_EN_V1.0.indd 9 10/28/2009 1:40:01 PM

Connect power

Caution

Risk of product damage! Ensure that the•

power supply voltage corresponds to the

voltage printed on the back or the underside

of the unit.

Before connecting the AC power cord, ensure

•

you have completed all other connections.

1Connect the AC power cord to the wall

socket.

Connect audio cables

1To play sound from this unit through the

TV, connect the supplied audio cables

(red/white) to:

the• AUDIO OUT L/R sockets on

this unit.

the audio input sockets on the TV.•

MCD110_94_UM_EN_V1.0.indd 10 10/28/2009 1:40:02 PM

3Insert one lithium CR2025 battery with

correct polarity (+/-) as indicated.

4Close the battery compartment.

Note

Before you press any function button on the•

remotecontrol,rstselectthecorrectsource

with the remote control.

Turn on

1Press .

The unit switches to the last selected»

source.

Switch to standby mode

1Press again.

Find the correct viewing

channel

1Press to turn on the unit.

2Press SOURCE repeatedly to select the

disc source.

3Turn on the TV and switch to the correct

video-in channel in one of the following

ways:

Go to the lowest channel on your•

TV, then press the Channel Down

button until you see the blue screen.

Press the source button repeatedly•

on the remote control of your TV.

Tip

The video-in channel is between the lowest•

and highest channels and may be called

FRONT, A/V IN, VIDEO etc. See the TV user

manual on how to select the correct input on

the TV.

4 Get started

Caution

Use of controls or adjustments or•

performance of procedures other than herein

may result in hazardous radiation exposure or

other unsafe operation.

Always follow the instructions in this chapter in

sequence.

If you contact Philips, you will be asked for the

model and serial number of this apparatus.The

model number and serial number are on the

bottom of the apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Activate demonstration mode

You can see an overview of all features.

1In standby mode, press on the main

unit to activate the demonstration mode.

A demonstration of major available»

features starts.

To deactivate the demonstration mode:

1Press on the main unit again.

Prepare the remote control

Caution

Risk of explosion! Keep batteries away from•

heat,sunshineorre.Neverdiscardbatteries

inre.

For rst-time use:

1Remove the protective tab to activate the

remote control battery.

2Open the battery compartment.

English

MCD110_94_UM_EN_V1.0.indd 11 10/28/2009 1:40:03 PM

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Micro sistema de música de Philips

Philips

Philips DCM186B/79 Manual de usuario

Philips

Philips MCD268/93 Manual de usuario

Philips

Philips MCD2010/12 Manual de usuario

Philips

Philips MCD113/93 Manual de usuario

Philips

Philips MCM239/55 Manual de usuario

Philips

Philips MCM1150/55 Manual de usuario

Philips

Philips MC136/29 Manual de usuario

Philips

Philips BTB2515 Manual de usuario

Philips

Philips MCM277/05B Manual de usuario

Philips

Philips BTM2180/37 Manual de usuario

Philips

Philips MCM119/12 Manual de usuario

Philips

Philips MCM761/12 Manual de usuario

Philips

Philips MCM2250 Manual de usuario

Philips

Philips DCM109/79 Manual de usuario

Philips

Philips MCM277 Manual de usuario

Philips

Philips MCD 289/55 Manual de usuario

Philips

Philips MCM1055/51 Manual de usuario

Philips

Philips AZB200 Manual de usuario

Philips

Philips MC146/12 Manual de usuario

Philips

Philips DCM2055 Manual de usuario

Philips

Philips MCD710/12 Manual de usuario

Philips

Philips MCD263/98 Manual de usuario

Philips

Philips MCM2300W Manual de usuario

Philips

Philips MCM765/77 Manual de usuario

Manuales populares de Micro sistema de música de otras marcas

Rautz

Rautz MC-5100DU Manual de usuario

Sanyo

Sanyo DC-D9 Manual de usuario

Curtis

Curtis RCD744 Manual de usuario

Samsung

Samsung MM-UC8 Manual de usuario

Akai

Akai AMP300UCI Manual de usuario

Hyundai

Hyundai MS 132 DU3BL Manual de usuario

JVC

JVC UX-GP5 Manual de usuario

Tiger Electronics

Tiger Electronics Hitclips Beat Bot 6000 Manual de usuario

Optimus

Optimus SYSTEM 731 Manual de usuario

Hitachi

Hitachi AXM209UK Manual de usuario

Sharp

Sharp XL-MP110DVD Manual de usuario

Tiger Electronics

Tiger Electronics Hitclips Micro Music Watch 59947 Manual de usuario

ProAudio

ProAudio MC 9010 iP Manual de usuario

Samsung

Samsung MM-ZJ9 Manual de usuario

Sharp

Sharp MD-X7 Manual de usuario

Sharp

Sharp DK-KP95P Manual de usuario

Akura

Akura APTCDC832PR Manual de usuario

iLive

iLive IHB248B Manual de usuario
