Philips MCM2005 Manual de usuario

www.philips.com/welcome

MCM2005

Always there to help you

User Manual

Question?

Contact

Philips

2EN

Contents

1 Important 3

Safety 3

Notice 4

2 Your Micro Music System 5

Introduction 5

What's in the box 5

Overview of the main unit 6

Overview of the remote control 7

3 Get started 8

Connect speakers 8

Connect FM aerial 9

Connect power 9

Prepare the remote control 9

Turn on 10

Set clock 10

Demonstrate the unit's features 10

Store radio stations automatically 10

4 Play 11

Play from disc 11

Play from USB 11

Basic play operations 11

5 Listen to FM radio 12

Tune to FM radio stations 12

Program radio stations automatically 12

Program radio stations manually 12

Tune to a preset radio station 12

Show RDS information 12

6 Other features 13

Set alarm timer 13

Set sleep timer 14

Listen to external audio device 14

Listen through headphone 14

7 Product information 14

Specications 14

USB playability information 15

Supported MP3 disc formats 15

8 Troubleshooting 16

3EN

1 Important

Safety

This ‘bolt of lightning’ indicates uninsulated

material within your unit may cause an electrical

shock. For the safety of everyone in your

household, please do not remove product

covering.

The ‘exclamation point’ calls attention to

features for which you should read the enclosed

literature closely to prevent operating and

maintenance problems.

WARNING:Toreducetheriskofreorelectric

shock, this apparatus should not be exposed to

rainormoistureandobjectslledwithliquids,

such as vases, should not be placed on this

apparatus.

CAUTION:To prevent electric shock, match

wide blade of plug to wide slot, fully insert.

Warning

•Never remove the casing of this apparatus.

•Never lubricate any part of this apparatus.

•Never place this apparatus on other electrical

equipment.

•Keep this apparatus away from direct sunlight, naked

amesorheat.

•Ensure that you always have easy access to the power

cord, plug or adaptor to disconnect the apparatus from

the power.

•Use only power supplies listed in the user manual.

• The device shall not exposed to dripping

or splashing.

• Do no place any source of danger on the

device(e.g.liquidlledobjects.litcandles).

• Where the MAINS plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

Caution

•Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation..

Hearing safety

Caution

•To prevent possible hearing damage, do not listen at

high volume levels for long periods.

Listen at a moderate volume.

• Using headphones at a high volume can

impair your hearing.This product can

produce sounds in decibel ranges that may

cause hearing loss for a normal person,

even for exposure less than a minute.The

higher decibel ranges are offered for those

that may have already experienced some

hearing loss.

• Sound can be deceiving. Over time your

hearing ‘comfort level’ adapts to higher

volumes of sound. So after prolonged

listening, what sounds ‘normal’ can actually

be loud and harmful to your hearing.To

guard against this, set your volume to a safe

level before your hearing adapts and leave

it there.

4EN

To establish a safe volume level:

• Set your volume control at a low setting.

• Slowly increase the sound until you can

hear it comfortably and clearly, without

distortion.

Listen for reasonable periods of time:

• Prolonged exposure to sound, even at

normally ‘safe’ levels, can also cause hearing

loss.

• Besuretouseyourequipmentreasonably

and take appropriate breaks.

Be sure to observe the following guidelines

when using your headphones.

• Listen at reasonable volumes for

reasonable periods of time.

• Be careful not to adjust the volume as your

hearing adapts.

• Do not turn up the volume so high that

you can’t hear what’s around you.

• You should use caution or temporarily

discontinue use in potentially hazardous

situations.

Notice

Anychangesormodicationsmadetothis

device that are not expressly approved by

WOOX Innovations may void the user’s

authoritytooperatetheequipment.

This product complies with the radio

interferencerequirementsoftheEuropean

Community.

Your product is designed and manufactured

withhighqualitymaterialsandcomponents,

which can be recycled and reused.

When this crossed-out wheeled bin symbol is

attached to a product it means that the product

is covered by the European Directive 2002/96/

EC.

Please inform yourself about the local separate

collection system for electrical and electronic

products.

Please act according to your local rules and

do not dispose of your old products with your

normal household waste. Correct disposal of

your old product helps to prevent potential

negativeconsequencesfortheenvironmentand

human health.

Your product contains batteries covered by

the European Directive 2006/66/EC, which

cannot be disposed with normal household

waste.Please inform yourself about the local

rules on separate collection of batteries

because correct disposal helps to prevent

negativeconsequencesfortheenvironmental

and human health.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separateintothreematerials:cardboard(box),

polystyrenefoam(buffer)andpolyethylene

(bags,protectivefoamsheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

a specialized company. Please observe the

local regulations regarding the disposal of

packaging materials, exhausted batteries and old

equipment.

The making of unauthorized copies of copy-

protected material, including computer

5EN

programs,les,broadcastsandsound

recordings, may be an infringement of

copyrights and constitute a criminal offence.

Thisequipmentshouldnotbeusedforsuch

purposes.

This apparatus includes this label:

Note

•The type plate is located on the bottom of the main

unit.

2 Your Micro

Music System

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this unit, you can:

• enjoy audio from discs, USB devices, and

other external devices

• listen to radio stations

You can enrich sound output with these sound

effects:

• DigitalSoundControl(DSC)

• DynamicBassBoost(DBB)

The unit supports these media formats:

What's in the box

Check and identify the contents of your

package:

• Main unit

• Remote control

• Speakerbox(×2)

• FM antenna

• Short user manual

6EN

Overview of the main unit

a Disc compartment

• Hold a disc.

• USB socket.

c AUDIO IN

• Connect an external audio device.

• Headphone socket.

• Turn on or off the unit.

• Switch to standby mode or Eco Power

standby mode.

f IR sensor

• Detect signals from the remote

control.

g SOURCE

• Select a source.

hij

h /

• In DISC and USB modes, skip to

previous/next track.

• In DISC and USB modes, search within

a track.

• Tune to a radio station.

• Start or pause play.

• Stop play.

• Erase a program.

k -PRESET/ALBUM+

• In DISC and USB modes, skip to

previous/next album.

• Select a preset radio station.

l Display panel

• Show current status.

• Open or close the disc compartment.

7EN

n VOLUME

• Adjust volume.

• Adjust time.

Overview of the remote

control

PRESET/ALBUM

PROG/

CLOCK SET

SLEEP/

TIMER

RDS

DSCDBB

VOL

REPEAT/

SHUFFLE

456

789

USB

DISPLAY

• Turn on or off the unit.

• Switch to standby or Eco Power

standby mode.

• Mute or restore volume.

c CD

• Select DISC source.

d /

• In DISC and USB modes, skip to

previous/next track.

• In DISC and USB modes, search within

a track.

• Tune to a radio station.

e USB

• Select USB source.

f RDS

• For selected FM radio stations: display

RDS information.

• Synchronize clock with an RDS station.

• Stop play.

• Erase a program.

h VOL +/-

• Adjust volume.

i Numeric keypad

• In DISC mode, select a track directly.

j PROG/CLOCK SET

• Program tracks.

• Program radio stations.

• Set clock.

k SLEEP/TIMER

• Set sleep timer.

• Set alarm timer.

l DSC

• Select a preset sound setting.

m DBB

• Turn on or off dynamic bass

enhancement.

8EN

n REPEAT/SHUFFLE

• Play tracks randomly.

• Select a repeat play mode.

o DISPLAY

• Display play information.

• Show time during USB and disc

playback.

p AUDIO IN

• Select AUDIO IN source.

• Start or pause play.

• Select FM stereo or FM mono.

r PRESET/ALBUM / /

• In DISC and USB modes, skip to

previous/next album.

• Select a preset radio station.

s FM

• SelectTUNER(FMradio)source.

3 Get started

Caution

•Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

Always follow the instructions in this chapter in

sequence.

If you contact Philips, you will be asked for the

model and serial number of this apparatus.The

model number and serial number are on the

bottom of the main unit.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Connect speakers

Note

•For optimal sound, use the supplied speakers only.

•Connect only speakers with impedance that is the

same or higher than the supplied speakers. Refer to the

Specicationssectionofthismanual.

1 Insert the speaker wires completely into

the speaker input sockets on the back of

the unit.

9EN

Connect FM aerial

Tip

•For optimal reception, fully extend and adjust the

position of the antenna.

•For better FM stereo reception, connect an outdoor

FM antenna to the FM AERIAL socket.

•The unit does not support MW radio reception.

Connect the supplied FM antenna to the FM

socket on the back of the main unit.

Connect power

Caution

•Risk of product damage! Ensure that the power supply

voltage corresponds to the voltage printed on the back

or the underside of the unit.

•Risk of electric shock! When you unplug the AC power

cord, always pull the plug from the socket. Never pull

the cord.

•Before you connect the AC power cord, ensure that

you have completed all other connections.

Connect the power cable to the wall socket.

Prepare the remote control

Caution

•Risk of explosion! Keep batteries away from heat,

sunshine,orre.Neverdiscardbatteriesinre.

To insert the remote control battery:

1 Open the battery compartment.

2 Insert 2 AAA batteries with correct

polarity(+/-)asindicated.

3 Close the battery compartment.

Note

•If you are not going to use the remote control for a

long time, remove the batteries.

•Do not use old and new or different types of batteries

in combination.

•Batteries contain chemical substances, so they should

be disposed of properly.

•During operation, always point the remote control at

the IR sensor.

10EN

Turn on

Press .

» The unit switches to the last selected

source.

Switch to standby mode

Press for over 3 seconds to switch the unit to

Eco Power Standby mode.

» The backlight on the display panel turns off.

To switch the unit to standby mode:

In Eco Power Standby mode, press for over 3

seconds to switch to Standby mode.

» Theclock(ifset)appearsonthedisplay

panel.s

Set clock

1 In standby mode, press PROG/CLOCK

SET for 3 seconds to activate clock setting

mode.

» [CLOCK SET] scrolls on the display,

then the time format [24H] or [12H]

appears.

2 Press / to select 24H or 12H.

3 Press PROG/CLOCK SETtoconrm.

» The hour digits begin to blink.

4 Repeat steps 2 to 3 to set hour and

minute.

Note

•To exit clock setting mode without storing, press .

•If no button is pressed in 90 seconds, the unit exits

clock setting mode automatically.

Demonstrate the unit's

features

In the standby mode, press until [DEMO

ON] is displayed.

» This unit's features are displayed one by

one.

• To turn off the demonstration, press

again.

Store radio stations

automatically

If no radio stations are stored, the unit can store

radio stations automatically.

1 Press to turn on the unit.

2 Press FM.

» [AUTO INSTALL -- PRESS PLAY --

STOP CANCEL] (press to start

automatic installation, or press to

cancel)isdisplayed.

3 Press .

» Theradiostationswithsufcientsignal

strength are stored automatically.

» After all available radio stations are

stored,therststoredradiostation

broadcasts automatically.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Micro sistema de música de Philips

Philips

Philips MC147/79 Manual de usuario

Philips

Philips MCD122/12 Manual de usuario

Philips

Philips MCM206/12 Manual de usuario

Philips

Philips MCD196/98 Manual de usuario

Philips

Philips DCM2020/05 Manual de usuario

Philips

Philips MCD 190 Manual de usuario

Philips

Philips DCM3020/79 Manual de usuario

Philips

Philips MBD3000/12 Manual de usuario

Philips

Philips MCD113/93 Manual de usuario

Philips

Philips MCD120/98 Manual de usuario

Philips

Philips DCM2020/96 Manual de usuario

Philips

Philips MCM2300/77 Manual de usuario

Philips

Philips MCDB710/05 Manual de usuario

Philips

Philips MC156/22 Manual de usuario

Philips

Philips MCM277/05B Manual de usuario

Philips

Philips MCM103/98 Manual de usuario

Philips

Philips MCM1006/93 Manual de usuario

Philips

Philips MCM204 Manual de usuario

Philips

Philips RTH718/98 Manual de usuario

Philips

Philips DCM3100 Manual de usuario

Philips

Philips DCB-188 Manual de usuario

Philips

Philips DCB152 Manual de usuario

Philips

Philips MCD288 Manual de usuario

Philips

Philips MCM761/12 Manual de usuario

Manuales populares de Micro sistema de música de otras marcas

Rautz

Rautz MC-5100DU Manual de usuario

Sanyo

Sanyo DC-D9 Manual de usuario

Curtis

Curtis RCD744 Manual de usuario

Samsung

Samsung MM-UC8 Manual de usuario

Akai

Akai AMP300UCI Manual de usuario

Hyundai

Hyundai MS 132 DU3BL Manual de usuario

JVC

JVC UX-GP5 Manual de usuario

Tiger Electronics

Tiger Electronics Hitclips Beat Bot 6000 Manual de usuario

Optimus

Optimus SYSTEM 731 Manual de usuario

Hitachi

Hitachi AXM209UK Manual de usuario

Sharp

Sharp XL-MP110DVD Manual de usuario

Tiger Electronics

Tiger Electronics Hitclips Micro Music Watch 59947 Manual de usuario

ProAudio

ProAudio MC 9010 iP Manual de usuario

Samsung

Samsung MM-ZJ9 Manual de usuario

Sharp

Sharp MD-X7 Manual de usuario

Sharp

Sharp DK-KP95P Manual de usuario

Akura

Akura APTCDC832PR Manual de usuario

iLive

iLive IHB248B Manual de usuario
